SERVICE MANUAL

DATA

•Replace this Service Manual with ”Revision Publishing” when it is issued.

BASIC TAPE MECHANISM : 2ZM-3MK2 PR7NM

BASIC CD MECHANISM : AZG-1 ZD3RNDM

COMPACT DISC STEREO

CASSETTE RECEIVER

NSX-SZ80

NSX-SZ83

NSX-AJ80

NSX-SZ80E

S/M Code No. 09-001-424-4T1

SIMPLE

ELECTRICAL MAIN PARTS LIST - 1/9

NOTE: The characters in the suffix column indicate the part usage.

NSZ80LHSM ..............XX..................................A...................

NSZ83LHSM ..............XX...................................B..................

NAJ80USM ...............XX....................................C.................

NSZ80HASM ..............XX.....................................D................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

87-A21-398-010 IC,STK490-110 ....................

C 1 87-010-387-080 CAP,E 470-25 SME ABCD................

C 3 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 4 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 4 87-A11-148-080 CAP,TC U 0.1-50 Z F ABCD................

C 5 87-A11-148-080 CAP,TC U 0.1-50 Z F ABCD................

C 6 87-010-917-000 CAP,E 3300-50 M SMG ABCD................

C 7 87-010-917-000 CAP,E 3300-50 M SMG ABCD................

C 8 87-A11-148-080 CAP,TC U 0.1-50 Z F ABCD................

C 9 87-A11-148-080 CAP,TC U 0.1-50 Z F ABCD................

C 10 87-A11-148-080 CAP,TC U 0.1-50 Z F ABCD................

C 11 87-A11-148-080 CAP,TC U 0.1-50 Z F ABCD................

C 12 87-016-520-000 CAP,E 3300-65 M SMG ..C.................

C 12 87-016-657-090 CAP,E 3300-71 AB.D................

C 13 87-016-520-000 CAP,E 3300-65 M SMG ..C.................

C 13 87-016-657-090 CAP,E 3300-71 AB.D................

C 16 87-010-403-080 CAP, ELECT 3.3-50V ABCD................

C 21 87-016-658-000 CAP,E 4700-35 M SMG ABCD................

C 22 87-016-658-000 CAP,E 4700-35 M SMG ABCD................

C 25 87-010-382-080 CAP, ELECT 22-25V ABCD................

C 26 87-010-383-080 CAP, ELECT 33-25V ..C.................

C 27 87-010-382-080 CAP, ELECT 22-25V ABCD................

C 28 87-010-383-080 CAP, ELECT 33-25V ..C.................

C 32 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 33 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 34 87-010-247-080 CAP, ELECT 100-50V ABCD................

C 36 87-010-381-080 CAP, ELECT 330-16V ABCD................

C 38 87-010-384-080 CAP, ELECT 100-25V ABCD................

C 39 87-010-384-080 CAP, ELECT 100-25V ABCD................

C 40 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 60 87-010-403-080 CAP, ELECT 3.3-50V ABCD................

C 80 87-010-401-080 CAP, ELECT 1-50V AB.D................

C 81 87-010-374-080 CAP, ELECT 47-10V AB.D................

C 82 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 101 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 101 87-010-178-080 CHIP CAP 1000P ABCD................

C 102 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 102 87-010-178-080 CHIP CAP 1000P ABCD................

C 103 87-010-312-080 C-CAP,S 15P-50 CH ABCD................

C 103 87-010-545-080 CAP, ELECT 0.22-50V ABCD................

C 104 87-012-157-080 C-CAP,S 330P-50 CH ABCD................

C 104 87-010-545-080 CAP, ELECT 0.22-50V ABCD................

C 104 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 105 87-010-415-040 CAP,E 10-50 5L ABCD................

C 105 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 106 87-010-493-040 CAP,E 0.47-50 GAS ABCD................

C 107 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 107 87-A10-189-040 CAP,E 220-10 ABCD................

C 108 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 108 87-A10-189-040 CAP,E 220-10 ABCD................

C 110 87-010-178-080 CHIP CAP 1000P ABCD................

C 111 87-010-545-080 CAP, ELECT 0.22-50V ABCD................

C 112 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 112 87-010-545-080 CAP, ELECT 0.22-50V ABCD................

C 113 87-A10-354-080 C-CAP,S 0.047-50 K B ABCD................

C 113 87-010-545-080 CAP, ELECT 0.22-50V ABCD................

C 113 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 114 87-010-545-080 CAP, ELECT 0.22-50V ABCD................

C 114 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 115 87-010-546-080 CAP, ELECT 0.33-50V ABCD................

C 115 87-010-866-080 CAP, ELECT 10-63 ..C.................

C 115 87-016-299-080 CAP,E 10-100 SME AB.D................

C 116 87-010-546-080 CAP, ELECT 0.33-50V ABCD................

C 116 87-010-866-080 CAP, ELECT 10-63 ..C.................

C 116 87-016-299-080 CAP,E 10-100 SME AB.D................

C 118 87-012-145-080 CAP, CHIP S 270P CH ABCD................

C 119 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 120 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 121 87-010-546-080 CAP, ELECT 0.33-50V ABCD................

C 122 87-010-546-080 CAP, ELECT 0.33-50V ABCD................

C 133 87-010-186-080 CAP,CHIP 4700P ABCD................

C 153 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 161 87-010-176-080 C-CAP,S 680P-50 SL ....................

C 162 87-010-176-080 C-CAP,S 680P-50 SL ....................

C 171 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 172 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 173 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 174 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 175 87-010-191-080 C-CAP,S 0.015-50 F ....................

C 176 87-010-191-080 C-CAP,S 0.015-50 F ....................

C 177 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 178 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 180 87-010-178-080 CHIP CAP 1000P ABCD................

C 181 87-010-178-080 CHIP CAP 1000P ABCD................

C 201 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 201 87-A10-300-080 CAP,M 0.027-50 J ABCD................

C 202 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

C 202 87-A10-300-080 CAP,M 0.027-50 J ABCD................

C 203 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 203 87-A10-300-080 CAP,M 0.027-50 J ABCD................

C 204 87-012-157-080 C-CAP,S 330P-50 CH ABCD................

C 204 87-A10-300-080 CAP,M 0.027-50 J ABCD................

C 205 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

C 205 87-010-180-080 C-CER 1500P ABCD................

C 206 87-010-180-080 C-CER 1500P ABCD................

C 207 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 208 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 209 87-010-187-080 CAP CHIP S5600P ABCD................

C 210 87-010-187-080 CAP CHIP S5600P ABCD................

C 211 87-012-393-080 C-CAP,S 0.22-16 R K ABCD................

C 211 87-010-402-080 CAP, ELECT 2.2-50V ABCD................

C 212 87-012-393-080 C-CAP,S 0.22-16 R K ABCD................

C 212 87-010-402-080 CAP, ELECT 2.2-50V ABCD................

C 213 87-012-393-080 C-CAP,S 0.22-16 R K ABCD................

C 214 87-012-393-080 C-CAP,S 0.22-16 R K ABCD................

C 214 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 215 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 215 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 216 87-010-177-080 C-CAP,S 820P-50 SL ABCD................

C 216 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 217 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 217 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABCD................

C 218 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 218 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABCD................

C 219 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 220 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 221 87-010-177-080 C-CAP,S 820P-50 SL ABCD................

C 221 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 221 87-010-421-040 CAP,E 4.7-50 5L ABCD................

C 222 87-010-177-080 C-CAP,S 820P-50 SL ABCD................

C 222 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 222 87-010-421-040 CAP,E 4.7-50 5L ABCD................

C 223 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 223 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 223 87-A10-797-040 CAP,E 47-35 M 5L SRM AB..................

C 223 87-010-408-040 CAP,E 47-50 SME ..CD................

C 224 87-012-369-080 C-CAP,S 0.047-50F ABCD................

C 224 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 224 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 225 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 226 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 227 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 228 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 229 87-010-177-080 C-CAP,S 820P-50 SL ABCD................

C 230 87-010-177-080 C-CAP,S 820P-50 SL ABCD................

C 231 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABCD................

C 232 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABCD................

C 233 87-010-374-080 CAP, ELECT 47-10V ABCD................

C 234 87-010-374-080 CAP, ELECT 47-10V ABCD................

C 235 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 236 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 237 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 238 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 239 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 240 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 253 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 254 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 255 87-010-190-080 S CHIP F 0.01 ....................

C 256 87-010-190-080 S CHIP F 0.01 ....................

C 257 87-010-190-080 S CHIP F 0.01 ....................

C 258 87-010-190-080 S CHIP F 0.01 ....................

C 259 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 260 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 301 87-010-178-080 CHIP CAP 1000P ABCD................

C 302 87-010-178-080 CHIP CAP 1000P ABCD................

C 303 87-012-157-080 C-CAP,S 330P-50 CH ABCD................

C 303 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 304 87-012-157-080 C-CAP,S 330P-50 CH ABCD................

C 304 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 305 87-012-157-080 C-CAP,S 330P-50 CH ABCD................

C 306 87-012-157-080 C-CAP,S 330P-50 CH ABCD................

C 309 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 309 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 310 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 310 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 311 87-010-198-080 CAP, CHIP 0.022 ABCD................

C 311 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 312 87-010-198-080 CAP, CHIP 0.022 ABCD................

C 312 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 312 87-010-498-040 CAP,E 10-16 GAS ABCD................

C 313 87-010-179-080 CAP,CHIP S B1200P ABCD................

C 315 87-A10-596-080 C-CAP,S 100P-100 J CH ABCD................

C 316 87-A10-596-080 C-CAP,S 100P-100 J CH ABCD................

C 317 87-A10-201-080 C-CAP,S0.33-16 KB ....................

C 317 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

ELECTRICAL MAIN PARTS LIST - 2/9

C 318 87-A10-201-080 C-CAP,S0.33-16 KB ....................

C 318 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 319 87-012-141-080 CHIP-CAPACITOR,0.22-16F ....................

C 320 87-012-141-080 CHIP-CAPACITOR,0.22-16F ....................

C 321 87-012-393-080 C-CAP,S 0.22-16 R K ABCD................

C 321 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 321 87-012-142-080 CAP, S 0.33-16 ABCD................

C 321 87-012-141-080 CHIP-CAPACITOR,0.22-16F ....................

C 322 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 322 87-012-142-080 CAP, S 0.33-16 ABCD................

C 322 87-012-141-080 CHIP-CAPACITOR,0.22-16F ....................

C 323 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 324 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 324 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 325 87-010-186-080 CAP,CHIP 4700P ABCD................

C 325 87-010-370-080 CAP,E 330-6.3 SME ABCD................

C 327 87-010-404-080 CAP, ELECT 4.7-50V ABCD................

C 328 87-010-404-080 CAP, ELECT 4.7-50V ABCD................

C 330 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 335 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 336 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 351 87-012-140-080 CAP 470P ABCD................

C 352 87-012-140-080 CAP 470P ABCD................

C 354 87-010-175-080 CAP 560P ABCD................

C 355 87-010-178-080 CHIP CAP 1000P ABCD................

C 356 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 357 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 358 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 359 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 360 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 371 87-010-177-080 C-CAP,S 820P-50 SL ....................

C 372 87-010-177-080 C-CAP,S 820P-50 SL ....................

C 373 87-016-083-080 C-CAP,S 0.15-16 RK ABCD................

C 374 87-016-083-080 C-CAP,S 0.15-16 RK ABCD................

C 375 87-010-545-080 CAP, ELECT 0.22-50V ....................

C 376 87-010-545-080 CAP, ELECT 0.22-50V ....................

C 379 87-010-382-080 CAP, ELECT 22-25V ABCD................

C 380 87-010-382-080 CAP, ELECT 22-25V ABCD................

C 381 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 382 87-010-312-080 C-CAP,S 15P-50 CH ABCD................

C 382 87-010-318-080 C-CAP,S 47P-50 CH ABCD................

C 382 87-010-320-080 CHIP CAP 68P ABCD................

C 383 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 384 87-010-402-080 CAP, ELECT 2.2-50V ABCD................

C 385 87-010-184-080 CHIP CAPACITOR 3300P(K) ....................

C 386 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 387 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 388 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

C 391 87-010-319-080 C-CAP,S 56P-50 CH ABCD................

C 391 87-012-145-080 CAP, CHIP S 270P CH ABCD................

C 392 87-010-319-080 C-CAP,S 56P-50 CH ABCD................

C 392 87-012-145-080 CAP, CHIP S 270P CH ABCD................

C 392 87-010-320-080 CHIP CAP 68P ABCD................

C 393 87-010-319-080 C-CAP,S 56P-50 CH ABCD................

C 393 87-012-145-080 CAP, CHIP S 270P CH ABCD................

C 394 87-010-319-080 C-CAP,S 56P-50 CH ABCD................

C 394 87-012-145-080 CAP, CHIP S 270P CH ABCD................

C 401 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 401 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 402 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 403 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 403 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 404 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 404 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 405 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 406 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 407 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 408 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 461 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 462 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 463 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 464 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 465 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 501 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 502 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 503 87-012-393-080 C-CAP,S 0.22-16 R K ABCD................

C 504 87-012-393-080 C-CAP,S 0.22-16 R K ABCD................

C 505 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABCD................

C 506 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 507 87-010-177-080 C-CAP,S 820P-50 SL ABCD................

C 508 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 509 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 510 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 511 87-010-177-080 C-CAP,S 820P-50 SL ABCD................

C 512 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABCD................

C 513 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 514 87-010-374-080 CAP, ELECT 47-10V ABCD................

C 515 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 516 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 517 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 518 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

ELECTRICAL MAIN PARTS LIST - 3/9

C 531 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 532 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 533 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 534 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

C 535 87-010-178-080 CHIP CAP 1000P ABCD................

C 536 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 538 87-010-318-080 C-CAP,S 47P-50 CH ABCD................

C 541 87-010-178-080 CHIP CAP 1000P ABCD................

C 601 87-010-186-080 CAP,CHIP 4700P ABCD................

C 602 87-010-405-040 CAP,E 10-50 ABCD................

C 603 87-010-320-080 CHIP CAP 68P ABCD................

C 604 87-010-546-040 CAP,E 0.33-50 ABCD................

C 606 87-010-112-040 CAP,E 100-16 ABCD................

C 607 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 608 87-010-178-080 CHIP CAP 1000P ABCD................

C 609 87-010-181-080 CAP,CHIP S 1800P ABCD................

C 610 87-010-181-080 CAP,CHIP S 1800P ABCD................

C 611 87-010-956-080 CHIP-CAP,S 0.068-25B ABCD................

C 612 87-016-369-080 C-CAP,S 0.033-25 B K ABCD................

C 613 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 614 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 616 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 617 87-012-369-080 C-CAP,S 0.047-50F ABCD................

C 618 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 619 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 620 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 621 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 621 87-010-178-080 CHIP CAP 1000P ABCD................

C 623 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 624 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 626 87-010-596-080 CAP, S 0.047-16 ABCD................

C 627 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

C 628 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

C 629 87-010-596-080 CAP, S 0.047-16 ABCD................

C 630 87-010-383-080 CAP, ELECT 33-25V ABCD................

C 631 87-010-185-080 C-CAP,S 3900P-50 B ABCD................

C 632 87-010-185-080 C-CAP,S 3900P-50 B ABCD................

C 634 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 635 87-A10-307-080 CAP,M 0.1-50 J ABCD................

C 636 87-A10-307-080 CAP,M 0.1-50 J ABCD................

C 637 87-A10-307-080 CAP,M 0.1-50 J ABCD................

C 638 87-A10-307-080 CAP,M 0.1-50 J ABCD................

C 639 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 641 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 642 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 643 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 644 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 652 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 653 87-010-213-080 C-CAP,S 0.015-50 B ABCD................

C 671 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 672 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 673 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 679 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 680 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 682 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 701 87-010-406-040 CAP,E 22-50 SME ABCD................

C 771 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 773 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 774 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 779 87-A10-679-080 C-CAP,S 3300P-50 JR ..C.................

C 780 87-A10-679-080 C-CAP,S 3300P-50 JR ..C.................

C 788 87-010-149-080 C-CAP,S 5P-50 CH ABCD................

C 789 87-A10-592-080 C-CAP,S 0.015-50 J B ..C.................

C 789 87-A11-530-080 C-CAP,S 0.018-50 J B AB.D................

C 789 87-A10-801-080 C-CAP,S 0.022-16 J B CM ....................

C 790 87-A10-592-080 C-CAP,S 0.015-50 J B ..C.................

C 790 87-A11-530-080 C-CAP,S 0.018-50 J B AB.D................

C 790 87-A10-801-080 C-CAP,S 0.022-16 J B CM ....................

C 791 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 793 87-010-404-080 CAP, ELECT 4.7-50V ABCD................

C 797 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 799 87-010-407-080 CAP, ELECT 33-50V ABCD................

C 800 87-012-369-080 C-CAP,S 0.047-50F ABCD................

C 801 87-010-403-080 CAP, ELECT 3.3-50V ABCD................

C 802 87-012-369-080 C-CAP,S 0.047-50F ABCD................

C 802 87-012-154-080 C-CAP,S 150P-50 CH AB.D................

C 803 87-010-198-080 CAP, CHIP 0.022 ABCD................

C 804 87-010-187-080 CAP CHIP S5600P AB.D................

C 804 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 806 87-010-401-040 CAP,E 1-50 SME AB.D................

C 807 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

C 808 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 809 87-012-155-080 C-CAP 180P-50CH AB.D................

C 809 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 810 87-010-263-040 CAP,E 100-10 AB.D................

C 810 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 811 87-010-403-080 CAP, ELECT 3.3-50V ABCD................

C 811 87-010-545-040 CAP,E 0.22-50 SME AB.D................

C 812 87-010-403-080 CAP, ELECT 3.3-50V ABCD................

C 812 87-010-405-040 CAP,E 10-50 AB.D................

C 815 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

C 816 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

ELECTRICAL MAIN PARTS LIST - 4/9

C 818 87-010-180-080 C-CER 1500P ....................

C 819 87-010-179-080 CAP,CHIP S B1200P ABCD................

C 820 87-010-179-080 CAP,CHIP S B1200P ABCD................

C 821 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 823 87-012-349-080 C-CAP,S 1000P-50 CH ....................

C 823 87-010-177-080 C-CAP,S 820P-50 SL ABCD................

C 824 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 825 87-010-596-080 CAP, S 0.047-16 ABCD................

C 831 87-010-406-080 CAP, ELECT 22-50 ....................

C 850 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 869 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 871 87-012-156-080 C-CAP,S 220P-50 CH ....................

C 872 87-012-156-080 C-CAP,S 220P-50 CH ....................

C 873 87-012-140-080 CAP 470P ....................

C 874 87-010-405-080 CAP, ELECT 10-50V ....................

C 875 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 876 87-010-405-080 CAP, ELECT 10-50V ....................

C 877 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 878 87-010-316-080 C-CAP,S 33P-50 CH ....................

C 879 87-010-314-080 C-CAP,S 22P-50V ....................

C 941 87-010-314-080 C-CAP,S 22P-50V ....................

C 942 87-010-146-080 CHIP CAP 2PF ....................

C 943 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 945 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 946 87-010-971-080 C-CAP,S 4700P-50 B J ....................

C 948 87-012-140-080 CAP 470P ....................

C 948 87-010-148-080 CAP, CHIP S 75P SL ....................

C 953 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 954 87-010-400-080 CAP, ELECT 0.47-50V ....................

C 956 87-010-263-080 CAP, ELECT 100-10V ....................

C 957 87-010-311-080 CAP 12P ....................

C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 961 87-010-152-080 C-CAP,S 8P-50 CH ABCD................

C 962 87-010-401-080 CAP, ELECT 1-50V ....................

C 963 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z ABCD................

C 964 87-010-854-080 C-CAP,S 560PCH ....................

C 971 87-010-381-080 CAP, ELECT 330-16V ABCD................

C 972 87-010-404-080 CAP, ELECT 4.7-50V ABCD................

C 981 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 982 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 985 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 989 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 991 87-010-312-080 C-CAP,S 15P-50 CH ABCD................

C 992 87-010-312-080 C-CAP,S 15P-50 CH ABCD................

C 993 87-010-178-080 CHIP CAP 1000P ABCD................

C 995 87-010-178-080 CHIP CAP 1000P ABCD................

C 997 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................

C 998 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 999 87-A11-155-080 CAP,TC U 0.01-16 Z F ABCD................

CF 831 87-008-423-010 CERAMIC FILTER, SFE10.7 ....................

CF 831 87-008-261-010 FILTER, SFE10.7MA5-A ABCD................

CF 832 82-785-747-010 CF MS2 GHY R ....................

CF 832 87-008-261-010 FILTER, SFE10.7MA5-A ABCD................

CN 1 87-A60-996-010 CONN,13P V BLK TAC-L13X-A3 ABCD................

CN 1 87-A61-110-010 CONN,9P V TID-A ABCD................

CN 2 87-A61-108-010 CONN,5P V TID-A ABCD................

CN 91 87-A60-109-010 CONN,2P V S2M-2W AB.D................

CN 101 87-A61-011-010 CONN,13P H BLK TAC-L13P-A3 ABCD................

CN 101 87-A60-996-010 CONN,13P V BLK TAC-L13X-A3 ABCD................

CN 101 87-099-720-010 CONN,30P TYK-B(P) ABCD................

CN 101 87-099-195-010 CONN,7P 6216 V ABCD................

CN 102 87-A61-011-010 CONN,13P H BLK TAC-L13P-A3 ABCD................

CN 102 87-049-919-010 CONN,3P EH V WHT ABCD................

CN 103 87-A60-619-010 CONN,2P V 2MM JMT ABCD................

CN 104 87-099-017-010 CONN, 15P 6216 V ABCD................

CN 106 87-099-195-010 CONN,7P 6216 V ABCD................

CN 301 87-A60-620-010 CONN,3P V 2MM JMT ABCD................

CN 301 87-099-195-010 CONN,7P 6216 V ABCD................

CN 302 87-099-195-010 CONN,7P 6216 V ABCD................

CN 351 87-A60-625-010 CONN,8P V 2MM JMT ABCD................

CN 601 87-099-719-010 CONN,30P TYK-B(X) ABCD................

CN 602 87-099-194-010 CONN,6P 6216V ABCD................

CN 603 87-099-212-010 CONN,5P 6216 V ABCD................

CN 604 87-099-210-010 CONN,5P 6216 H ABCD................

CN 901 87-A60-161-010 CONN,13P H FE ABCD................

CNA 1 8A-NF6-646-010 CONN ASSY,9P TID-A(460) ABCD................

CNA 2 8A-NF6-630-010 CONN ASSY,3P (VM) ANF-6 ..CD................

CNA 2 8A-NF6-640-010 CONN ASSY,3P (VM) ANF-6 AB..................

CNA 101 8A-NF6-670-010 CONN ASSY,2P (MUTE) ANF-6 ABCD................

CNA 101 8A-NF6-645-010 CONN ASSY,5P TID-A(530) ABCD................

CNA 102 8A-NF6-660-010 CONN ASSY,3P (SATE) ANF-6 ABCD................

D 1 87-A40-673-090 DIODE,D10XB20 AB.D................

D 1 87-A40-547-090 DIODE,D5SBA20 ABCD................

D 1 87-A40-547-090 DIODE,D5SBA20 ..C.................

D 2 87-A40-673-090 DIODE,D10XB20 ABCD................

D 14 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 15 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 16 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 17 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 18 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 19 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 20 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

ELECTRICAL MAIN PARTS LIST - 5/9

D 21 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 25 87-A40-553-080 DIODE,1N4003 LES ABCD................

D 26 87-A40-553-080 DIODE,1N4003 LES ABCD................

D 27 87-A40-553-080 DIODE,1N4003 LES ABCD................

D 28 87-A40-553-080 DIODE,1N4003 LES ABCD................

D 29 87-A40-784-080 ZENER,UZ39BSB ABCD................

D 31 87-A40-764-080 ZENER,UZ10BSC ABCD................

D 33 87-A40-553-080 DIODE,1N4003 LES ABCD................

D 61 87-A40-313-080 C-DIODE,MC 2840 ABCD................

D 62 87-A40-313-080 C-DIODE,MC 2840 ABCD................

D 63 87-A40-270-080 C-DIODE,MC2838 ABCD................

D 64 87-A40-269-080 C-DIODE,MC2836 ABCD................

D 65 87-A40-768-080 ZENER,UZ16BSA ..CD................

D 84 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 85 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 101 87-A40-269-080 C-DIODE,MC2836 ABCD................

D 101 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 103 87-A40-313-080 C-DIODE,MC 2840 ABCD................

D 108 87-A40-752-080 ZENER,UZ6.2BSC ABCD................

D 150 87-A40-270-080 C-DIODE,MC2838 ABCD................

D 201 87-A40-269-080 C-DIODE,MC2836 ABCD................

D 201 87-A40-748-080 ZENER,UZ5.6BSA ABCD................

D 203 87-A40-313-080 C-DIODE,MC 2840 ABCD................

D 204 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 317 87-A40-270-080 C-DIODE,MC2838 ABCD................

D 318 87-A40-270-080 C-DIODE,MC2838 ABCD................

D 319 87-A40-313-080 C-DIODE,MC 2840 ABCD................

D 320 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 321 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 322 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 323 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 324 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 326 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 328 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 352 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 353 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 385 87-A40-802-080 ZENER,UZ5.1BSC ABCD................

D 401 87-A40-270-080 C-DIODE,MC2838 ABCD................

D 402 87-A40-553-080 DIODE,1N4003 LES ABCD................

D 403 87-A40-553-080 DIODE,1N4003 LES ABCD................

D 501 87-A40-747-080 ZENER,UZ5.1BSB ABCD................

D 602 87-A40-745-080 ZENER,UZ4.7BSA ABCD................

D 603 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 701 87-A40-269-080 C-DIODE,MC2836 ABCD................

D 801 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 801 87-A40-749-080 ZENER,UZ5.6BSB AB.D................

D 901 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

D 942 87-A40-270-080 C-DIODE,MC2838 ....................

D 944 87-A40-736-080 DIODE,1N4148M(SEM) ....................

D 951 87-A40-618-080 VARI-CAP,SVC 348(S/T) ....................

D 991 87-017-149-080 ZENER,HZS6A2L ABCD................

D 992 87-A40-736-080 DIODE,1N4148M(SEM) ABCD................

FB 301 87-008-372-080 FILTER, EMI BL OIRNI ....................

FB 501 87-008-372-080 FILTER, EMI BL OIRNI ABCD................

FB 601 87-008-372-080 FILTER, EMI BL OIRNI ABCD................

FB 801 87-008-372-080 FILTER, EMI BL OIRNI AB.D................

FFE 831 A8-6ZA-191-130 6ZA-1 FEENM ....................

FFE 831 A8-6ZA-19C-170 6ZA-1 YFEENC ....................

FFE 831 A8-8ZA-190-030 8ZA-1 FEUNM ABCD................

FFE 831 A8-8ZA-193-070 8ZA-1 YFEUNC ....................

FL 201 8A-NF6-601-010 FL,BJ750GNK 13G-35S ANF-6 ABCD................

IC 101 8A-NF6-610-010 C-IC,LC876564V-XXX ABCD................

IC 101 8A-NF6-605-010 C-IC,LC876572V-XXX ....................

IC 101 87-A21-417-010 IC,STK490-310 ....................

IC 101 87-A21-418-010 IC,STK490-340 ABCD................

IC 201 87-A21-018-040 C-IC,M65849BFP631D ABCD................

IC 201 87-A21-396-010 IC,STK490-040 ..C.................

IC 201 87-A21-397-010 IC,STK490-070 AB.D................

IC 202 87-A21-018-040 C-IC,M65849BFP631D ABCD................

IC 251 87-A20-914-010 IC,SPS-442-1-F ABCD................

IC 302 87-A20-355-010 IC,CXA1553P ....................

IC 303 87-A20-783-040 C-IC,BA7762AFS ABCD................

IC 380 87-A21-577-040 C-IC,M61506FP ABCD................

IC 401 87-A21-021-040 C-IC,BU2099FV ABCD................

IC 402 87-070-289-040 IC,BU 2092F ABCD................

IC 501 87-A21-018-040 C-IC,M65849BFP631D ABCD................

IC 601 87-A21-452-040 C-IC,BD3876KS2 AB..................

IC 601 87-A21-452-030 C-IC,BD3876KS2 ..CD................

IC 801 87-A21-051-040 C-IC,BU9990-03FS AB.D................

IC 801 87-A21-415-010 IC,LA1843 ABCD................

IC 861 87-A20-440-040 C-IC,BU1920FS ....................

IC 991 87-070-127-110 IC,LC72131 D ABCD................

J 102 87-A60-238-010 TERMINAL,SP 4P (MSC) ABCD................

J 103 87-A60-929-010 JACK,DIA6.3 BLK ST W/S TAI ABCD................

J 201 87-A61-148-010 JACK,PIN 4P R/W BLUE ABCD................

J 301 87-A61-189-010 JACK,3.5 MONO ABCD................

J 302 87-A61-189-010 JACK,3.5 MONO ABCD................

J 601 87-A61-242-010 JACK,6.3 BLK MONO W/SW V KM ABCD................

J 601 87-A60-885-010 JACK,PIN 6P R/W MSC ABCD................

J 602 87-A61-242-010 JACK,6.3 BLK MONO W/SW V KM ABCD................

J 831 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 ABCD................

J 832 87-A60-403-010 TERMINAL,ANT PAL 2P HSP-312V05 ....................

ELECTRICAL MAIN PARTS LIST - 6/9

J 940 81-754-629-010 CONNECTOR, 2P ....................

L 101 87-A50-610-010 COIL,1UH K(MDEC) ..CD................

L 101 87-003-383-010 COIL,1UH-S AB..................

L 101 87-A50-333-010 COIL,OSC 9.43MHZ ABCD................

L 102 87-A50-610-010 COIL,1UH K(MDEC) ..CD................

L 102 87-003-383-010 COIL,1UH-S AB..................

L 251 87-003-383-010 COIL,1UH-S ABCD................

L 252 87-003-383-010 COIL,1UH-S ABCD................

L 301 87-003-383-010 COIL,1UH-S ABCD................

L 301 87-A50-049-010 COIL,TRAP 85K(COI) ABCD................

L 302 87-003-383-010 COIL,1UH-S ABCD................

L 302 87-A50-049-010 COIL,TRAP 85K(COI) ABCD................

L 351 87-007-342-010 COIL,OSC 85K BIAS ABCD................

L 801 87-A50-093-010 COIL,CLOCK 5.76MHZ AB.D................

L 801 87-A50-540-010 COIL,FM DET(TOK) ABCD................

L 802 87-A91-552-010 FLTR,CFMT-450AL (TOK) ....................

L 802 87-A91-551-010 FLTR,PCFJZH-450 L(TOK) ABCD................

L 811 87-005-847-080 COIL,2.2UH(CECS) ABCD................

L 821 87-A50-027-010 COIL,1 POLE MPX(TOK) ....................

L 821 87-A50-209-010 COIL,1POLE MPX(MIT) ABCD................

L 822 87-A50-027-010 COIL,1 POLE MPX(TOK) ....................

L 822 87-A50-209-010 COIL,1POLE MPX(MIT) ABCD................

L 832 87-005-847-080 COIL,2.2UH(CECS) ABCD................

L 861 87-005-847-080 COIL,2.2UH(CECS) ....................

L 941 87-A50-020-010 COIL,ANT LW(COI) ....................

L 941 87-A50-022-010 COIL,ANT SW(COI) ....................

L 942 87-A50-019-010 COIL,OSC LW(COI) ....................

L 942 87-A50-550-010 COIL,OSC SW-2N(COI) ....................

L 943 87-A50-522-080 COIL,1MH K CEC ....................

L 944 87-A50-159-010 COIL,10MH K C2B ....................

L 951 8A-NF8-668-010 COIL,AM PACK 2(TOK) ....................

L 951 8A-NF8-667-010 COIL,AM PACK 4(TOK) ABCD................

L 952 87-A50-430-010 COIL,ANT MW(3BSW) ....................

L 953 87-A50-431-010 COIL,OSC MW(3BSW) ....................

LED 401 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 402 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 403 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 404 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 405 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 406 87-A40-496-040 LED,SLR-342MCT31 GRN ABCD................

LED 407 87-A40-496-040 LED,SLR-342MCT31 GRN ABCD................

LED 408 87-A40-496-040 LED,SLR-342MCT31 GRN ABCD................

LED 409 87-A40-496-040 LED,SLR-342MCT31 GRN ABCD................

LED 410 87-A40-496-040 LED,SLR-342MCT31 GRN ABCD................

LED 416 87-A40-809-080 LED,LTL-307KK PGRN ..CD................

LED 416 87-A40-619-080 LED,SLR-56PT-TE7-W GRN AB..................

LED 417 87-A40-809-080 LED,LTL-307KK PGRN ..CD................

LED 417 87-A40-619-080 LED,SLR-56PT-TE7-W GRN AB..................

LED 418 87-A40-809-080 LED,LTL-307KK PGRN ..CD................

LED 418 87-A40-619-080 LED,SLR-56PT-TE7-W GRN AB..................

LED 419 87-A40-809-080 LED,LTL-307KK PGRN ..CD................

LED 419 87-A40-619-080 LED,SLR-56PT-TE7-W GRN AB..................

LED 420 87-A40-809-080 LED,LTL-307KK PGRN ..CD................

LED 420 87-A40-619-080 LED,SLR-56PT-TE7-W GRN AB..................

LED 421 87-A40-809-080 LED,LTL-307KK PGRN ..CD................

LED 421 87-A40-619-080 LED,SLR-56PT-TE7-W GRN AB..................

LED 425 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 426 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 431 87-A40-678-010 LED,SELU1E10CXM BLUE-DEF ABCD................

LED 432 87-A40-678-010 LED,SELU1E10CXM BLUE-DEF ABCD................

LED 433 87-A40-678-010 LED,SELU1E10CXM BLUE-DEF ABCD................

LED 440 87-A91-665-010 LED,SELU1E10 CXM-SLF55 BLUE ABCD................

LED 441 87-A91-665-010 LED,SELU1E10 CXM-SLF55 BLUE ABCD................

LED 451 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 452 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 453 87-017-756-040 LED,SLR-342DCT31 ORN ABCD................

LED 454 87-A40-496-040 LED,SLR-342MCT31 GRN ABCD................

LED 455 87-A40-496-040 LED,SLR-342MCT31 GRN ABCD................

LED 456 87-A40-496-040 LED,SLR-342MCT31 GRN ABCD................

LED 499 87-A40-317-080 LED,SLR-342VCT31 RED ABCD................

PT 2 8A-NF8-662-010 PT,SUB ANF-8 (E) ....................

PT 2 8A-NF8-673-010 PT,SUB ANF-8 (H)KAMI AB.D................

PT 2 8A-NF8-661-010 PT,SUB ANF-8 (U) ..C.................

Q 1 87-026-245-080 TR,DTC114ES ABCD................

Q 2 87-A30-198-080 TR,KTC3199GR ABCD................

Q 7 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 9 87-A30-318-080 TR,CSA952K ABCD................

Q 13 89-213-702-010 TR,2SB1370 (1.8W) ABCD................

Q 14 89-213-702-010 TR,2SB1370 (1.8W) ABCD................

Q 81 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 82 87-026-610-080 TR,KTC3198GR ABCD................

Q 84 87-026-609-080 TR,KTA1266GR ABCD................

Q 101 87-A30-087-080 C-FET,2SK2158 ABCD................

Q 101 87-A30-107-070 C-TR,CMBT5401 ABCD................

Q 102 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 102 87-A30-107-070 C-TR,CMBT5401 ABCD................

Q 103 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 103 87-A30-468-080 C-TR,KRC102S-RTK ABCD................

Q 104 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 104 87-A30-484-080 C-TR,KRA102S ABCD................

Q 105 87-A30-269-040 C-FET,2SJ461-T1 ABCD................

Q 105 87-A30-484-080 C-TR,KRA102S ABCD................

ELECTRICAL MAIN PARTS LIST - 7/9

Q 106 87-A30-269-040 C-FET,2SJ461-T1 ABCD................

Q 107 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 107 87-026-610-080 TR,KTC3198GR ABCD................

Q 108 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 108 87-A30-484-080 C-TR,KRA102S ABCD................

Q 109 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 110 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 113 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 150 87-A30-107-070 C-TR,CMBT5401 ABCD................

Q 151 87-A30-106-040 C-TR,CMBT5551 ABCD................

Q 201 87-A30-107-070 C-TR,CMBT5401 ABCD................

Q 202 87-A30-107-070 C-TR,CMBT5401 ABCD................

Q 203 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 204 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 301 87-A30-086-040 C-TR,CSD1306E ABCD................

Q 302 87-A30-086-040 C-TR,CSD1306E ABCD................

Q 303 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 304 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 305 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 306 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 307 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 308 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 311 87-A30-190-080 TR,CC5551 ABCD................

Q 312 87-A30-190-080 TR,CC5551 ABCD................

Q 313 89-420-613-010 TR,2SD2061F ABCD................

Q 314 89-420-613-010 TR,2SD2061F ABCD................

Q 315 89-213-703-010 TR,2SB1370F ABCD................

Q 316 89-213-703-010 TR,2SB1370F ABCD................

Q 317 87-A30-107-070 C-TR,CMBT5401 ABCD................

Q 318 87-A30-107-070 C-TR,CMBT5401 ABCD................

Q 319 87-A30-106-040 C-TR,CMBT5551 ABCD................

Q 320 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 321 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 351 87-A30-087-080 C-FET,2SK2158 ABCD................

Q 353 87-A30-087-080 C-FET,2SK2158 ABCD................

Q 354 87-A30-087-080 C-FET,2SK2158 ABCD................

Q 355 87-A30-063-080 C-TR,KRA104S ABCD................

Q 356 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 357 87-026-609-080 TR,KTA1266GR ABCD................

Q 358 87-026-610-080 TR,KTC3198GR ABCD................

Q 359 87-026-610-080 TR,KTC3198GR ABCD................

Q 383 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 401 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 402 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 531 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 532 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 601 87-A30-087-080 C-FET,2SK2158 ABCD................

Q 601 87-026-610-080 TR,KTC3198GR ABCD................

Q 602 87-A30-269-040 C-FET,2SJ461-T1 ....................

Q 602 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 603 87-A30-087-080 C-FET,2SK2158 ....................

Q 603 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 604 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 605 87-A30-086-070 C-TR,CSD1306E ABCD................

Q 606 87-A30-086-070 C-TR,CSD1306E ABCD................

Q 607 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 608 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 609 87-A30-075-080 C-TR,2SA1235F ABCD................

Q 701 87-A30-329-080 TR,CD1585BC ABCD................

Q 704 87-A30-318-080 TR,CSA952K ABCD................

Q 705 87-A30-318-080 TR,CSA952K ABCD................

Q 801 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 802 87-A30-076-080 C-TR,2SC3052F ABCD................

Q 835 89-327-143-080 TR,2SC2714 (0.1W) ABCD................

Q 837 87-A30-489-080 C-TR,KRA107S ABCD................

Q 861 87-A30-076-080 C-TR,2SC3052F ....................

Q 863 87-A30-076-080 C-TR,2SC3052F ....................

Q 942 87-A30-075-080 C-TR,2SA1235F ....................

Q 943 87-A30-075-080 C-TR,2SA1235F ....................

Q 944 87-A30-076-080 C-TR,2SC3052F ....................

Q 945 87-A30-076-080 C-TR,2SC3052F ....................

Q 948 87-A30-086-070 C-TR,CSD1306E ....................

Q 949 87-A30-076-080 C-TR,2SC3052F ....................

Q 951 87-A30-484-080 C-TR,KRA102S ....................

Q 952 87-A30-086-070 C-TR,CSD1306E ....................

Q 953 89-503-602-080 C-FET,2SK360E ....................

Q 981 87-A30-234-080 TR,CSC4115BC ABCD................

R 129 87-A00-262-080 RES,M/F 0.15-2W J ABCD................

R 130 87-A00-262-080 RES,M/F 0.15-2W J ABCD................

R 161 87-A00-441-050 RES,270-1/2W J RP ABCD................

R 162 87-A00-441-050 RES,270-1/2W J RP ABCD................

R 163 87-A00-441-050 RES,270-1/2W J RP ABCD................

R 164 87-A00-441-050 RES,270-1/2W J RP ABCD................

R 231 87-A00-258-080 RES,M/F 0.22-1W J ABCD................

R 232 87-A00-258-080 RES,M/F 0.22-1W J ABCD................

R 790 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

RY 1 87-A91-281-010 RELAY,AC DC12V OSA-SS-212DM5 AB.D................

RY 2 87-A90-976-010 RELAY,AC12V SDT-S-112LMR ..C.................

S 1 87-A90-165-010 SW,SL 1-2-3 SWS2301 AB.D................

S 101 87-A91-591-010 SW,RTRY RE0121PVB25FINA24 ABCD................

S 102 87-A91-664-010 SW,RTRY RE0121PVB30F ABCD................

ELECTRICAL MAIN PARTS LIST - 8/9

S 307 87-A91-024-180 SW,TACT KSH0611BT ABCD................

S 308 87-A91-024-180 SW,TACT KSH0611BT ABCD................

S 309 87-A91-024-180 SW,TACT KSH0611BT ABCD................

S 348 87-A91-024-180 SW,TACT KSH0611BT ABCD................

SFR 301 87-A90-557-080 SFR,33K H HOKU ....................

SFR 302 87-A90-557-080 SFR,33K H HOKU ....................

SFR 303 87-A90-557-080 SFR,33K H HOKU ....................

SFR 304 87-A90-557-080 SFR,33K H HOKU ....................

SFR 305 87-A90-433-080 SFR,50K H NVZ6TLTA ABCD................

SFR 306 87-A90-433-080 SFR,50K H NVZ6TLTA ABCD................

T 1 87-A60-317-010 TERMINAL, 1P MSC ABCD................

T 2 87-A60-317-010 TERMINAL, 1P MSC ABCD................

TC 941 87-011-254-080 TRIMER,20P LAR ....................

TC 942 87-011-253-080 TRIMER,30P LAR ....................

WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P ABCD................

WH 101 87-A90-459-010 HLDR,WIRE 2.5-5P ABCD................

X 861 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309 ....................

X 991 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 ABCD................

ELECTRICAL MAIN PARTS LIST - 9/9

This manual suits for next models

Table of contents

Popular Car Receiver manuals by other brands

Linear Series

Linear Series LS5050 Operation and installation manual

Kenwood

Kenwood KRC-160 instruction manual

Sony

Sony XR-CA430X Service manual

T+A Elektroakustik

T+A Elektroakustik K1 CD-RECEIVER operating instructions

SoundMax

SoundMax SM-CDM1052 instruction manual

Xtrons

Xtrons HD107HD user manual

Mopar

Mopar RB3 manual

Clarion

Clarion ADDZEST DMZ615 owner's manual

Sony

Sony XAV-601BT Specifications

PIE

PIE GM12-POD/S Operation manual

Hyundai

Hyundai H-910H instruction manual

Sony

Sony XR-C6100 Service manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Installation/connections

Motorola

Motorola VWA63 Service manual

Sound Storm

Sound Storm STM93R user manual

Nextar

Nextar D3201 instruction manual

Alpine

Alpine CDE-163BT owner's manual

Kenwood

Kenwood KDC-X303 quick start guide

Aiwa NSX-SZ80LH User manual

Popular Car Receiver manuals by other brands
