Aiwa CDC-R927M User manual

SERVICE MANUAL
DATA
BASIC CD MECHANISM : BZG-3 CNF
STEREO CAR CD RECEIVER
CDC-R927M
S/M Code No. 09-026-458-9N1
YZ(ST)

-2-
SPECIFICATION -1/1
RADIO SECTION
(FM)
Frequency Range: 87.5 MHz - 108 MHz (50-KHz steps)
Usable Sensitivity: 12.7 dBf
50 dB Quieting Sensitivity: 17.2 dBf
IF Rejection: 100 dB
Frequency Response: 30 Hz - 15,000 Hz
S/N Ratio: 67 dB
Stereo Separation: 35 dB at 1 kHz
Alternate Channel Selectivity: 98 dB
Capture Ratio: 3 dB
(MW)
Frequency Range: 531 kHz - 1,602 kHz (9-KHz steps)
Usable Sensitivity: 30 µV (30 dB)
(LW)
Frequency Range: 144 kHz - 288 kHz (1-kHz/9-kHz steps)
Usable Sensitivity: 30 µV (30 dB)
CD SECTION
Frequency Response: 17 Hz - 20 kHz +0/-3 dB
Dynamic Range: More than 92 dB
Channel Separation: More than 60 dB
S/N Ratio: More than 90 dB
Wow/Flutter: Unmeasurable
AUDIO SECTION
Max. Power Output: 45 W x 4 channels
AUX IN input
Input sensitivity (load impedance) AUX IN: 300 mV (10 kΩ)
GENERAL
Power-Supply Voltage: 14.4 V (11 to 16 V allowable), DC, negative ground
Load Impedance: 4 Ω
Tone Control: Bass ± 10 dB at 100 Hz, Treble ± 10 dB at 10 kHz
Preamp Output Voltage (load impedance): 2.2 V (10 kΩ)
Installed size: 182 (W) x 53 (H) x 155 (D) mm
CARD REMOTE CONTROL
Dimensions:Approx. 33 (W) x 85 (H) x 7.5 (D) mm
Weight:Approx. 20 g (including battery)
Specifications and external appearance are subject to
change without notice due to product improvement.

-3-
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING -1/1
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla
saattaa altistaa käyt-täjän turvallisuusluokan 1 ylittävälle näkymättömälle
lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i denna
bruksanvising, kan användaren utsättas för osynling laserstrålning, som
överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when open
and interlocks defeated avoid exposure to
beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardousradiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que ceux
spécifiés peut entraîner une dangereuse exposition aux radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude af funktion.
Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER product.
The CLASS 1 LASER PRODUCT label is located on the rear exterior.
Thisset employs laser. Therefore, besure to follow carefully the instructions
below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT WITH THE
EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO CONFIRM LASER
BEAM EMISSION. BE SURE TO OBSERVE FROM A DISTANCE OF
MORE THAN 30cm FROM THE SURFACE OF THE OBJECTIVE LENS
ON THE OPTICAL
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
Precaution to replace Optical block
(PICK720)
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
PICK-UPASSY. P.C.B
Solder

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-4-
ACCESSORIES PARTS LIST -1/1
CDC-R927M
YZSTF
O AS1001 8C-KC2-901-010 IB,YZ(9L)F R927M a
O AS1002 8C-KCG-913-010 IB,INST YZ,YV (9L,R)F a
O AS1003 87-B10-141-010 NUT,5 TYPE-2 a
O AS1004 87-B10-143-010 UT1+5-15 W/O SLOT a
O AS1005 87-B10-144-010 W,5.2-10-0.5 a
O AS1006 87-B10-145-010 W-SPR,5.3-8.5-1.5 a
O AS1007 8C-KCG-651-010 RC UNIT,CD1B a
O AS1008 8Z-KC1-231-110 HLDR,HALF -C a
O AS1009 8Z-KC1-232-010 KEY,REMOVE -C a
O AS1010 8Z-KC1-235-010 HLDR,REAR MTG a
O AS1011 8Z-KC1-244-010 S-SCREW,5*6 TH+ TAPPING ST a
O AS1012 8Z-KC1-250-010 S-SCREW,HEXAGON a

-5-
DISASSEMBLY INSTRUCTION - 1/2
DISASSMBLY PROCEDURE
1) Remove top and bottom cover.
2) Remove CD mechanism.
3) Remove FFC.
4) Remove wire solder.
5) Remove the screw of MAIN BOARD.
6) Remove the connector of the motor.
7) Remove CABI BASE AROUND and remove the screw of FRAME SUB assy right and left.
8) Move FRONT PANEL assy.
Notes
Each FFC shoud be passed the bottom of SHAFT Assy.

-6-
9) Remove MOTOR assy.
10) Remove FRONT assy.
11) Remove Panel SW assy.
(Extend FRAME SUB assy lightly and remove it at front side)
12) Remove SHAFT assy.
(Remove the washer. See figure)
Reassemble MOTOR assy at the position that is arranged with hole of GEAR CAM and hole of FRAME SUB assy like the figure)
Put the tip of a lever Assy gear at between the marks of GEAR CAM and reassemble FRONT assy.
(Extend FRAME SUB assy lightly.)
Put GEAR CAM at the position that hole of FRAME SUB assy can be seen from the left and right side hole of GEAR CAM, and reassemble SHAFT assy.
DISASSEMBLY INSTRUCTION - 1/2

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-7-
ELECTRICAL PARTS LIST - 1/10
CDC-R927M
YZSTF
CD O C 0201 87-010-552-040 CAP,E 22-16 M 5L SRE a
CD O C 0202 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0203 87-A10-189-040 CAP,E 220-10 M 5L a
CD O C 0221 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0222 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0223 87-012-337-080 C-CAP,U 56P-50 J CH GRM a
CD O C 0224 87-012-162-080 C-CAP,U 1P-50 C CH GRM a
CD O C 0225 87-A10-260-080 C-CAP,U 0.1-16 K B a
CD O C 0226 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0227 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0228 87-A10-260-080 C-CAP,U 0.1-16 K B a
CD O C 0229 87-A10-353-080 C-CAP,U 0.22-10 K B a
CD O C 0230 87-A10-353-080 C-CAP,U 0.22-10 K B a
CD O C 0232 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0233 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0234 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0235 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0237 87-012-285-080 C-CAP,U 8200P-50 K B GRM a
CD O C 0241 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0242 87-010-555-040 CAP,E 100-10 M 5L SRE a
CDC-R927M
YZSTF
CD O C 0245 87-012-270-080 C-CAP,U 470P-50 K B GRM a
CD O C 0246 87-012-270-080 C-CAP,U 470P-50 K B GRM a
CD O C 0247 87-A10-504-080 C-CAP,U 0.047-16 K B a
CD O C 0248 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0250 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0251 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0252 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
CD O C 0253 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
CD O C 0254 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
CD O C 0258 87-A10-504-080 C-CAP,U 0.047-16 K B a
CD O C 0259 87-A10-504-080 C-CAP,U 0.047-16 K B a
CD O C 0260 87-A10-504-080 C-CAP,U 0.047-16 K B a
CD O C 0261 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
CD O C 0262 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
CD O C 0263 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0264 87-010-785-080 C-CAP,U 0.015-25 K B GRM a
CD O C 0265 87-010-553-040 CAP,E 47-16 M 5L SRE a
CD O C 0268 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
CD O C 0269 87-010-553-040 CAP,E 47-16 M 5L SRE a
CD O C 0270 87-010-553-040 CAP,E 47-16 M 5L SRE a
CDC-R927M
YZSTF
CD O C 0271 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0272 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
CD O C 0273 87-012-199-080 C-CAP,U 220P-50 J CH GRM a
CD O C 0274 87-012-199-080 C-CAP,U 220P-50 J CH GRM a
CD O C 0276 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0278 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0279 87-A10-260-080 C-CAP,U 0.1-16 K B a
CD O C 0281 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
CD O C 0282 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
CD O C 0283 87-010-498-040 CAP,E 10-16 M 5L SRE a
CD O C 0284 87-010-498-040 CAP,E 10-16 M 5L SRE a
CD O C 0298 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0299 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
CD O CON0201 87-A61-220-080 C-CONN,20P H 52271-2090 a
CD O FFC0201 8C-KCG-661-010 FF-CABLE,20P 1.0 90MM a
CD S IC 0201 87-A22-080-040 C-IC,LA6557H a
CD S IC 0221 87-A22-081-040 C-IC,TA2153FN a
CD S IC 0241 8C-ZA5-611-030 C-IC,TC94A09F-301 a
CD X JR 0102 88-108-000-080 C-JUMPER,U a
CD X JR 0201 88-108-000-080 C-JUMPER,U a
CDC-R927M
YZSTF
CD X JR 0203 88-108-000-080 C-JUMPER,U a
CD O L 0221 87-003-102-080 COIL,10UH J LAL02 a
CD O L 0241 87-003-143-080 COIL,4.7UH K LAL02 a
CD O L 0242 87-003-143-080 COIL,4.7UH K LAL02 a
CD S Q 0201 87-A30-299-080 TR,2SB1326 a
CD S Q 0202 87-A30-287-040 C-TR,DTC114TKA a
CD S Q 0221 87-A30-289-040 C-TR,2SA1037AK(Q) a
CD X R 0201 88-108-000-080 C-JUMPER,U a
CD X R 0202 88-108-683-080 C-RES,U 68K-1/16W J a
CD O R 0203 88-108-822-080 C-RES,U 8.2K-1/16W J a
CD O R 0204 88-108-822-080 C-RES,U 8.2K-1/16W J a
CD X R 0205 88-108-000-080 C-JUMPER,U a
CD X R 0206 88-108-561-080 C-RES,U 560-1/16W J a
CD X R 0207 88-108-000-080 C-JUMPER,U a
CD O R 0208 88-108-101-080 C-RES,U 100-1/16W J a
CD O R 0209 88-108-562-080 C-RES,U 5.6K-1/16W J a
CD X R 0210 88-108-000-080 C-JUMPER,U a
CD X R 0211 88-108-820-080 C-RES,U 82-1/16W J a
CD X R 0212 88-108-393-080 C-RES,U 39K-1/16W J a
CD X R 0213 88-108-000-080 C-JUMPER,U a

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-8-
CDC-R927M
YZSTF
CD X R 0214 88-108-000-080 C-JUMPER,U a
CD X R 0215 88-108-154-080 C-RES,U 150K-1/16W J a
CD O R 0221 88-108-102-080 C-RES,U 1K-1/16W J a
CD X R 0222 88-108-683-080 C-RES,U 68K-1/16W J a
CD O R 0223 88-108-473-080 C-RES,U 47K-1/16W J a
CD X R 0224 88-108-222-080 C-RES,U 2.2K-1/16W J a
CD X R 0225 88-108-221-080 C-RES,U 220-1/16W J a
CD X R 0226 88-108-000-080 C-JUMPER,U a
CD X R 0227 88-108-104-080 C-RES,U 100K-1/16W J a
CD O R 0228 88-108-103-080 C-RES,U 10K-1/16W J a
CD O R 0229 88-108-103-080 C-RES,U 10K-1/16W J a
CD O R 0230 88-108-103-080 C-RES,U 10K-1/16W J a
CD O R 0231 88-108-563-080 C-RES,U 56K-1/16W J a
CD O R 0232 88-108-563-080 C-RES,U 56K-1/16W J a
CD O R 0233 88-108-563-080 C-RES,U 56K-1/16W J a
CD O R 0234 88-108-563-080 C-RES,U 56K-1/16W J a
CD X R 0235 88-108-273-080 C-RES,U 27K-1/16W J a
CD X R 0236 88-108-273-080 C-RES,U 27K-1/16W J a
CD X R 0237 88-108-683-080 C-RES,U 68K-1/16W J a
CD O R 0238 88-108-102-080 C-RES,U 1K-1/16W J a
CDC-R927M
YZSTF
CD X R 0239 88-108-000-080 C-JUMPER,U a
CD X R 0240 88-118-100-080 C-RES,S 10-1/10W J a
CD O R 0241 88-108-101-080 C-RES,U 100-1/16W J a
CD X R 0243 88-108-000-080 C-JUMPER,U a
CD X R 0244 88-108-333-080 C-RES,U 33K-1/16W J a
CD X R 0245 88-108-474-080 C-RES,U 470K-1/16W J a
CD O R 0246 88-108-473-080 C-RES,U 47K-1/16W J a
CD O R 0247 88-108-103-080 C-RES,U 10K-1/16W J a
CD O R 0249 88-108-102-080 C-RES,U 1K-1/16W J a
CD O R 0250 88-108-102-080 C-RES,U 1K-1/16W J a
CD X R 0251 88-108-000-080 C-JUMPER,U a
CD O R 0253 88-108-103-080 C-RES,U 10K-1/16W J a
CD X R 0254 88-108-474-080 C-RES,U 470K-1/16W J a
CD X R 0255 88-108-474-080 C-RES,U 470K-1/16W J a
CD X R 0256 88-108-104-080 C-RES,U 100K-1/16W J a
CD X R 0281 88-108-222-080 C-RES,U 2.2K-1/16W J a
CD X R 0282 88-108-222-080 C-RES,U 2.2K-1/16W J a
CD X R 0298 88-108-472-080 C-RES,U 4.7K-1/16W J a
CD X R 0299 88-108-472-080 C-RES,U 4.7K-1/16W J a
CD O X 0241 87-A70-376-080 VIB,CER 16.934MHZ CSTLS16M9X55 a
CDC-R927M
YZSTF
FRONT O C 0602 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
FRONT O C 0603 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
FRONT O C 0604 87-A10-504-080 C-CAP,U 0.047-16 K B a
FRONT O C 0605 87-012-199-080 C-CAP,U 220P-50 J CH GRM a
FRONT O C 0606 87-A10-504-080 C-CAP,U 0.047-16 K B a
FRONT O C 0607 87-A10-504-080 C-CAP,U 0.047-16 K B a
FRONT O C 0608 87-A10-504-080 C-CAP,U 0.047-16 K B a
FRONT O C 0609 87-A10-504-080 C-CAP,U 0.047-16 K B a
FRONT O C 0610 87-A10-047-080 C-CAP,U 1-10 Z F a
FRONT O C 0611 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
FRONT O C 0612 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
FRONT O C 0613 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
FRONT O C 0614 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
FRONT O C 0615 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
FRONT O C 0617 87-012-270-080 C-CAP,U 470P-50 K B GRM a
FRONT O C 0619 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
FRONT O C 0620 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
FRONT O CON0601 87-A61-585-080 C-CONN,24P H 54548-2490 a
FRONT S D 0601 87-A40-250-040 C-DIODE,DAN217 a
FRONT S D 0602 87-A40-817-040 C-ZENER,STZ6.8N a
CDC-R927M
YZSTF
FRONT S D 0603 87-A40-817-040 C-ZENER,STZ6.8N a
FRONT S IC 0601 87-A21-532-030 C-IC,LC75817W-8720 a
FRONT O IC 0602 87-A90-951-010 RCR UNIT,SBX1971-52 a
FRONT O LCD0601 8C-KC4-620-010 LCD,CKC-4 a
FRONT O LED0601 87-A91-355-040 C-LED,BR1112H-TR-RED a
FRONT O LED0602 87-A91-355-040 C-LED,BR1112H-TR-RED a
FRONT O LED0603 87-A91-355-040 C-LED,BR1112H-TR-RED a
FRONT O LED0604 87-A91-355-040 C-LED,BR1112H-TR-RED a
FRONT O LED0605 87-A41-085-010 LED,NSPW315BS WHT a
FRONT O LED0606 87-A91-355-040 C-LED,BR1112H-TR-RED a
FRONT O LED0607 87-A91-355-040 C-LED,BR1112H-TR-RED a
FRONT O LED0608 87-A41-118-040 C-LED,SEC1E01C-1 BLU a
FRONT O LED0609 87-A41-118-040 C-LED,SEC1E01C-1 BLU a
FRONT S Q 0610 89-324-122-040 C-TR,2SC2412KR a
FRONT S Q 0611 87-A30-287-040 C-TR,DTC114TKA a
FRONT S Q 0612 89-324-122-040 C-TR,2SC2412KR a
FRONT O R 0601 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0602 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0603 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0604 88-108-102-080 C-RES,U 1K-1/16W J a
ELECTRICAL PARTS LIST - 2/10

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-9-
CDC-R927M
YZSTF
FRONT X R 0605 88-108-333-080 C-RES,U 33K-1/16W J a
FRONT O R 0606 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0607 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0608 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0609 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0610 88-108-332-080 C-RES,U 3.3K-1/16W J a
FRONT X R 0611 88-118-331-080 C-RES,S 330-1/10W J a
FRONT O R 0612 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0613 88-108-180-080 C-RES,U 18-1/16W J a
FRONT O R 0614 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0615 88-118-681-080 C-RES,S 680-1/10W J a
FRONT X R 0616 88-118-681-080 C-RES,S 680-1/10W J a
FRONT X R 0617 88-118-221-080 C-RES,S 220-1/10W J a
FRONT O R 0618 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0619 88-108-223-080 C-RES,U 22K-1/16W J a
FRONT X R 0620 88-118-681-080 C-RES,S 680-1/10W J a
FRONT O R 0621 88-108-223-080 C-RES,U 22K-1/16W J a
FRONT X R 0622 88-118-331-080 C-RES,S 330-1/10W J a
FRONT X R 0623 88-118-331-080 C-RES,S 330-1/10W J a
FRONT O R 0624 88-108-473-080 C-RES,U 47K-1/16W J a
CDC-R927M
YZSTF
FRONT O R 0625 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0626 88-108-152-080 C-RES,U 1.5K-1/16W J a
FRONT O SW 0601 87-A90-001-080 C-SW,TACT SKQMAL a
FRONT O SW 0602 87-A90-001-080 C-SW,TACT SKQMAL a
FRONT O SW 0603 87-A90-001-080 C-SW,TACT SKQMAL a
FRONT O SW 0604 87-A90-001-080 C-SW,TACT SKQMAL a
FRONT O SW 0620 87-A90-001-080 C-SW,TACT SKQMAL a
FRONT O SW 0621 87-A92-330-010 SW,RTRY SRP-1211VE a
JACK O J 0601 87-A61-753-010 JACK,3.6 BLK HSJ1494-01 -020 a
KEY O C 0616 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
KEY O C 0618 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
KEY O CON0603 87-A61-586-080 C-CONN,16P V FLZT-SM1 a
KEY O L 0601 87-005-906-080 C-COIL,S 10UH K LK2125 a
KEY O L 0602 87-005-906-080 C-COIL,S 10UH K LK2125 a
KEY O LED0611 87-A91-355-040 C-LED,BR1112H-TR-RED a
KEY O LED0612 87-A91-355-040 C-LED,BR1112H-TR-RED a
KEY O LED0613 87-A91-355-040 C-LED,BR1112H-TR-RED a
KEY O LED0614 87-A91-355-040 C-LED,BR1112H-TR-RED a
KEY O LED0615 87-A91-355-040 C-LED,BR1112H-TR-RED a
KEY O LED0616 87-A91-355-040 C-LED,BR1112H-TR-RED a
CDC-R927M
YZSTF
KEY O LED0617 87-A91-355-040 C-LED,BR1112H-TR-RED a
KEY O LED0618 87-A91-355-040 C-LED,BR1112H-TR-RED a
KEY O LED0619 87-A41-118-040 C-LED,SEC1E01C-1 BLU a
KEY O LED0620 87-A41-118-040 C-LED,SEC1E01C-1 BLU a
KEY O LED0621 87-A41-118-040 C-LED,SEC1E01C-1 BLU a
KEY S Q 0614 87-A30-287-040 C-TR,DTC114TKA a
KEY S Q 0615 89-324-122-040 C-TR,2SC2412KR a
KEY S Q 0616 87-A30-287-040 C-TR,DTC114TKA a
KEY X R 0651 88-118-471-080 C-RES,S 470-1/10W J a
KEY X R 0652 88-118-681-080 C-RES,S 680-1/10W J a
KEY X R 0653 88-118-331-080 C-RES,S 330-1/10W J a
KEY X R 0654 88-118-331-080 C-RES,S 330-1/10W J a
KEY X R 0655 88-118-331-080 C-RES,S 330-1/10W J a
KEY X R 0656 88-118-331-080 C-RES,S 330-1/10W J a
KEY O R 0657 88-108-103-080 C-RES,U 10K-1/16W J a
KEY O SW 0606 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0607 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0608 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0609 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0610 87-A91-780-180 C-SW,TACT LS15B3T a
CDC-R927M
YZSTF
KEY O SW 0611 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0612 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0613 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0614 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0615 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0616 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0617 87-A91-780-180 C-SW,TACT LS15B3T a
KEY O SW 0618 87-A91-780-180 C-SW,TACT LS15B3T a
LED O FFC0731 8B-KC1-603-010 F-CABLE,2P (PWB LED) a
LED O LED0731 87-A40-228-010 LED,SLR-342MG T31 GREEN a
MAIN O ANT0101 8Z-KT1-614-010 ANT,AW-002 a
MAIN O C 0101 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
MAIN O C 0102 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0103 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
MAIN O C 0104 87-010-498-040 CAP,E 10-16 M 5L SRE a
MAIN O C 0105 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
MAIN O C 0106 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
MAIN O C 0107 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
MAIN O C 0108 87-010-498-040 CAP,E 10-16 M 5L SRE a
MAIN O C 0109 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
ELECTRICAL PARTS LIST - 3/10

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-10-
CDC-R927M
YZSTF
MAIN O C 0110 87-012-281-080 C-CAP,U 3900P-50 K B GRM a
MAIN O C 0111 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0112 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0113 87-010-555-040 CAP,E 100-10 M 5L SRE a
MAIN O C 0114 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0115 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0116 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
MAIN O C 0117 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0118 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0119 87-A10-248-080 C-CAP,U 0.1-16 K BR a
MAIN O C 0120 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
MAIN O C 0121 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0123 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0125 87-010-786-080 C-CAP,U 0.018-25 K B GRM a
MAIN O C 0126 87-010-786-080 C-CAP,U 0.018-25 K B GRM a
MAIN O C 0127 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0128 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0131 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0132 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0151 87-012-336-080 C-CAP,U 330P-50 J SL GRM a
CDC-R927M
YZSTF
MAIN O C 0152 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
MAIN O C 0153 87-012-271-080 C-CAP,U 560P-50 K B GRM a
MAIN O C 0154 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0155 87-012-182-080 C-CAP,U 27P-50 J CH GRM a
MAIN O C 0156 87-012-183-080 C-CAP,U 30P-50 J CH GRM a
MAIN O C 0157 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0158 87-010-553-040 CAP,E 47-16 M 5L SRE a
MAIN O C 0401 87-A11-062-080 C-CAP,S 2.2-16 Z F a
MAIN O C 0402 87-A11-062-080 C-CAP,S 2.2-16 Z F a
MAIN O C 0403 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0404 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0405 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
MAIN O C 0406 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
MAIN O C 0407 87-012-276-080 C-CAP,U 1500P-50 K B GRM a
MAIN O C 0408 87-012-276-080 C-CAP,U 1500P-50 K B GRM a
MAIN O C 0409 87-A11-062-080 C-CAP,S 2.2-16 Z F a
MAIN O C 0410 87-A11-062-080 C-CAP,S 2.2-16 Z F a
MAIN O C 0411 87-010-786-080 C-CAP,U 0.018-25 K B GRM a
MAIN O C 0412 87-010-786-080 C-CAP,U 0.018-25 K B GRM a
MAIN O C 0413 87-A10-781-080 C-CAP,U 0.15-10 K B a
CDC-R927M
YZSTF
MAIN O C 0414 87-A10-781-080 C-CAP,U 0.15-10 K B a
MAIN O C 0415 87-A10-781-080 C-CAP,U 0.15-10 K B a
MAIN O C 0416 87-A10-781-080 C-CAP,U 0.15-10 K B a
MAIN O C 0417 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0418 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0419 87-012-280-080 C-CAP,U 3300P-50 K B GRM a
MAIN O C 0420 87-012-280-080 C-CAP,U 3300P-50 K B GRM a
MAIN O C 0421 87-A11-070-080 C-CAP,U 0.033-16 K B a
MAIN O C 0422 87-A11-070-080 C-CAP,U 0.033-16 K B a
MAIN O C 0423 87-010-555-040 CAP,E 100-10 M 5L SRE a
MAIN O C 0424 87-010-497-040 CAP,E 4.7-35 M 5L SRE a
MAIN O C 0426 87-010-552-040 CAP,E 22-16 M 5L SRE a
MAIN O C 0427 87-010-555-040 CAP,E 100-10 M 5L SRE a
MAIN O C 0428 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0429 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0435 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0436 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0437 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0438 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0439 87-010-494-040 CAP,E 1-50 M 5L SRE a
CDC-R927M
YZSTF
MAIN O C 0441 87-010-498-040 CAP,E 10-16 M 5L SRE a
MAIN O C 0442 87-010-498-040 CAP,E 10-16 M 5L SRE a
MAIN O C 0443 87-010-498-040 CAP,E 10-16 M 5L SRE a
MAIN O C 0444 87-010-498-040 CAP,E 10-16 M 5L SRE a
MAIN O C 0445 87-010-491-040 CAP,E 0.22-50 M 5L SRE a
MAIN O C 0446 87-010-491-040 CAP,E 0.22-50 M 5L SRE a
MAIN O C 0453 87-010-498-040 CAP,E 10-16 M 5L SRE a
MAIN O C 0454 87-010-498-040 CAP,E 10-16 M 5L SRE a
MAIN O C 0457 87-012-270-080 C-CAP,U 470P-50 K B GRM a
MAIN O C 0458 87-012-270-080 C-CAP,U 470P-50 K B GRM a
MAIN O C 0461 87-012-281-080 C-CAP,U 3900P-50 K B GRM a
MAIN O C 0501 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
MAIN O C 0502 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
MAIN O C 0503 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
MAIN O C 0504 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
MAIN O C 0505 87-012-271-080 C-CAP,U 560P-50 K B GRM a
MAIN O C 0506 87-012-271-080 C-CAP,U 560P-50 K B GRM a
MAIN O C 0507 87-012-271-080 C-CAP,U 560P-50 K B GRM a
MAIN O C 0508 87-012-271-080 C-CAP,U 560P-50 K B GRM a
MAIN O C 0509 87-A12-390-080 C-CAP,S 1-25 Z F GRM40 a
ELECTRICAL PARTS LIST - 4/10

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-11-
CDC-R927M
YZSTF
MAIN O C 0510 87-010-553-040 CAP,E 47-16 M 5L SRE a
MAIN O C 0511 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a
MAIN O C 0512 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a
MAIN O C 0513 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a
MAIN O C 0514 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a
MAIN O C 0518 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0519 87-010-497-040 CAP,E 4.7-35 M 5L SRE a
MAIN O C 0520 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a
MAIN O C 0521 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a
MAIN O C 0522 87-010-552-040 CAP,E 22-16 M 5L SRE a
MAIN O C 0525 8A-KC7-623-000 CAP,E 2200-16 125 BT a
MAIN O C 0531 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a
MAIN O C 0701 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
MAIN O C 0702 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
MAIN O C 0705 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0707 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0721 87-010-196-080 C-CAP,S 0.1-25 Z F C2012 a
MAIN O C 0722 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0723 87-010-553-040 CAP,E 47-16 M 5L SRE a
MAIN O C 0724 87-010-196-080 C-CAP,S 0.1-25 Z F C2012 a
CDC-R927M
YZSTF
MAIN O C 0725 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0726 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0751 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0752 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0753 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
MAIN O C 0754 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0755 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
MAIN O C 0771 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0772 87-010-805-080 C-CAP,S 1-16 Z F GRM a
MAIN O C 0801 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0802 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0811 87-010-553-040 CAP,E 47-16 M 5L SRE a
MAIN O C 0812 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
MAIN O C 0813 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0814 87-010-553-040 CAP,E 47-16 M 5L SRE a
MAIN O C 0821 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0822 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
MAIN O C 0831 87-010-553-040 CAP,E 47-16 M 5L SRE a
MAIN O C 0832 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0834 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
CDC-R927M
YZSTF
MAIN O C 0838 87-A12-390-080 C-CAP,S 1-25 Z F GRM40 a
MAIN O C 0901 87-012-172-080 C-CAP,U 10P-50 D CH GRM a
MAIN O C 0902 87-012-172-080 C-CAP,U 10P-50 D CH GRM a
MAIN O C 0903 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MAIN O C 0904 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MAIN O C 0906 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0907 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0908 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0910 87-010-831-080 C-CAP,U 0.1-16 Z F GRM a
MAIN O C 0915 87-016-039-090 CAP,DL 0.022F-5.5 Z 70 FM a
MAIN O C 0971 87-A12-307-080 C-CAP,S 0.1-50 K B a
MAIN O C 0972 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
MAIN O C 0981 87-A10-260-080 C-CAP,U 0.1-16 K B a
MAIN O CNA0801 8A-KT1-645-010 CONN ASSY,8P ISO-BLACK-B X a
MAIN O CNA0802 8A-KT1-646-010 CONN ASSY,8P ISO-WHITE-B X a
MAIN O CON0701 87-A61-584-010 CONN,24P H 52089-2420 a
MAIN O CON0702 87-A61-583-010 CONN,16P H 52089-1620 a
MAIN O CON0721 87-A60-670-010 CONN,6P H 2MM JMT a
MAIN O CON0771 87-A61-219-010 CONN,20P H 52089-2020 a
MAIN S D 0101 87-A40-250-040 C-DIODE,DAN217 a
CDC-R927M
YZSTF
MAIN S D 0151 87-070-136-080 ZENER,MTZJ5.1B a
MAIN S D 0421 87-017-365-040 C-DIODE,DA204U a
MAIN S D 0422 87-017-366-040 C-DIODE,DAN202U a
MAIN S D 0501 87-001-783-080 DIODE,1N4002 a
MAIN S D 0502 87-001-783-080 DIODE,1N4002 a
MAIN S D 0503 87-001-783-080 DIODE,1N4002 a
MAIN S D 0504 87-001-783-080 DIODE,1N4002 a
MAIN S D 0505 87-001-783-080 DIODE,1N4002 a
MAIN S D 0506 87-001-783-080 DIODE,1N4002 a
MAIN S D 0507 87-001-783-080 DIODE,1N4002 a
MAIN S D 0508 87-001-783-080 DIODE,1N4002 a
MAIN S D 0509 87-020-465-080 DIODE,1SS133 a
MAIN S D 0510 87-A40-650-080 ZENER,MTZJ6.8A a
MAIN S D 0531 87-070-334-080 ZENER,MTZJ10B a
MAIN S D 0751 87-A40-817-040 C-ZENER,STZ6.8N a
MAIN S D 0752 87-A40-817-040 C-ZENER,STZ6.8N a
MAIN S D 0753 87-A40-817-040 C-ZENER,STZ6.8N a
MAIN S D 0801 87-A40-798-010 DIODE,1N5402 (3A/200V) a
MAIN S D 0811 87-A40-624-080 ZENER,MTZJ10A a
MAIN S D 0821 87-A40-344-080 ZENER,MTZJ6.2C a
ELECTRICAL PARTS LIST - 5/10

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-12-
CDC-R927M
YZSTF
MAIN S D 0822 87-017-367-040 C-DIODE,DAP202U a
MAIN S D 0831 87-A40-624-080 ZENER,MTZJ10A a
MAIN S D 0832 87-017-366-040 C-DIODE,DAN202U a
MAIN S D 0841 87-070-136-080 ZENER,MTZJ5.1B a
MAIN S D 0901 87-017-366-040 C-DIODE,DAN202U a
MAIN S D 0905 87-017-366-040 C-DIODE,DAN202U a
MAIN S D 0971 87-070-136-080 ZENER,MTZJ5.1B a
MAIN S D 0981 87-A40-620-080 ZENER,MTZJ6.2A a
MAIN S D 0982 87-070-136-080 ZENER,MTZJ5.1B a
MAIN ! S F 0801 8B-KC1-621-010 FUSE,15A 32V a
MAIN S IC 0151 88-KT1-607-080 C-IC,SAA6579T a
MAIN S IC 0401 87-A22-225-030 C-IC,LA2657M a
MAIN S IC 0402 87-017-917-040 C-IC,BU4066BCF a
MAIN S IC 0501 87-A22-157-010 IC,LA4743J a
MAIN S IC 0721 87-A20-712-040 C-IC,BA6417F a
MAIN S IC 0901 8C-KC2-611-030 C-IC,UPD178078GF-567-3BA a
MAIN S IC 0971 88-KT1-606-080 IC,PST994D a
MAIN O J 0401 87-A61-225-110 JACK,PIN 2P XR-401 a
MAIN O J 0751 8A-KC7-620-010 JACK,DIN 13P SKDS1302 a
MAIN O L 0101 87-003-143-080 COIL,4.7UH K LAL02 a
CDC-R927M
YZSTF
MAIN O L 0102 8Z-KT1-619-010 COIL,68MH K7-D a
MAIN X L 0151 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN O L 0451 87-003-102-080 COIL,10UH J LAL02 a
MAIN O L 0701 87-003-102-080 COIL,10UH J LAL02 a
MAIN O L 0702 87-005-906-080 C-COIL,S 10UH K LK2125 a
MAIN O L 0721 87-005-121-080 COIL,2.2UH M LAL04 a
MAIN O L 0801 8B-KCF-615-010 FLTR,AMORPHOUS -CHOKE a
MAIN O L 0901 87-005-906-080 C-COIL,S 10UH K LK2125 a
MAIN S Q 0101 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0102 87-A30-143-040 C-TR,2SA1576A a
MAIN S Q 0103 87-A30-144-040 C-TR,2SC4081 a
MAIN S Q 0105 87-A30-144-040 C-TR,2SC4081 a
MAIN S Q 0106 87-A30-144-040 C-TR,2SC4081 a
MAIN S Q 0107 87-A30-144-040 C-TR,2SC4081 a
MAIN S Q 0108 87-A30-144-040 C-TR,2SC4081 a
MAIN S Q 0405 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0406 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0407 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0408 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0409 87-A30-405-040 C-TR,DTC114TUA a
CDC-R927M
YZSTF
MAIN S Q 0410 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0411 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0421 87-A30-144-040 C-TR,2SC4081 a
MAIN S Q 0422 87-A30-385-040 C-TR,DTA114YUA a
MAIN S Q 0423 87-A30-144-040 C-TR,2SC4081 a
MAIN S Q 0521 87-A30-294-040 C-TR,DTB123YK a
MAIN S Q 0731 87-A30-385-040 C-TR,DTA114YUA a
MAIN S Q 0751 87-A30-385-040 C-TR,DTA114YUA a
MAIN S Q 0752 87-A30-404-040 C-TR,DTC114YUA a
MAIN S Q 0811 89-213-750-010 TR,2SB1375 a
MAIN S Q 0812 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0813 89-420-120-010 TR,2SD2012 a
MAIN O Q 0821 89-418-580-080 TR,2SD1858TV2 a
MAIN S Q 0831 89-420-120-010 TR,2SD2012 a
MAIN S Q 0832 87-A30-144-040 C-TR,2SC4081 a
MAIN S Q 0833 87-A30-143-040 C-TR,2SA1576A a
MAIN S Q 0834 87-A30-405-040 C-TR,DTC114TUA a
MAIN S Q 0901 87-A30-405-040 C-TR,DTC114TUA a
MAIN X R 0101 88-108-105-080 C-RES,U 1M-1/16W J a
MAIN O R 0102 88-108-102-080 C-RES,U 1K-1/16W J a
CDC-R927M
YZSTF
MAIN O R 0103 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0104 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0105 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0106 88-108-181-080 C-RES,U 180-1/16W J a
MAIN O R 0107 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN X R 0108 88-108-821-080 C-RES,U 820-1/16W J a
MAIN O R 0109 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0110 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0111 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN O R 0112 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0113 88-108-184-080 C-RES,U 180K-1/16W J a
MAIN X R 0114 88-118-100-080 C-RES,S 10-1/10W J a
MAIN X R 0115 88-108-330-080 C-RES,U 33-1/16W J a
MAIN X R 0116 88-108-100-080 C-RES,U 10-1/16W J a
MAIN X R 0117 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN O R 0118 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0119 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0120 88-121-102-080 RES,1K-1/8W J a
MAIN O R 0121 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0122 88-108-473-080 C-RES,U 47K-1/16W J a
ELECTRICAL PARTS LIST - 6/10

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-13-
CDC-R927M
YZSTF
MAIN O R 0123 88-108-123-080 C-RES,U 12K-1/16W J a
MAIN X R 0124 88-121-123-080 RES,12K-1/8W J a
MAIN X R 0125 88-121-473-080 RES,47K-1/8W J a
MAIN X R 0131 88-118-000-080 C-JUMPER,S a
MAIN X R 0151 88-108-331-080 C-RES,U 330-1/16W J a
MAIN X R 0152 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0401 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0402 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN O R 0403 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN O R 0404 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0405 88-108-392-080 C-RES,U 3.9K-1/16W J a
MAIN X R 0406 88-108-392-080 C-RES,U 3.9K-1/16W J a
MAIN O R 0407 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN O R 0408 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0409 88-108-683-080 C-RES,U 68K-1/16W J a
MAIN X R 0410 88-108-683-080 C-RES,U 68K-1/16W J a
MAIN X R 0411 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN X R 0412 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN X R 0413 88-108-683-080 C-RES,U 68K-1/16W J a
MAIN X R 0414 88-108-683-080 C-RES,U 68K-1/16W J a
CDC-R927M
YZSTF
MAIN X R 0415 88-118-470-080 C-RES,S 47-1/10W J a
MAIN X R 0418 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0419 88-118-270-080 C-RES,S 27-1/10W J a
MAIN X R 0421 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0422 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0423 88-121-472-080 RES,4.7K-1/8W J a
MAIN X R 0424 88-108-105-080 C-RES,U 1M-1/16W J a
MAIN O R 0425 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0426 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0427 88-108-105-080 C-RES,U 1M-1/16W J a
MAIN O R 0428 88-108-562-080 C-RES,U 5.6K-1/16W J a
MAIN X R 0429 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN O R 0431 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0432 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0433 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0434 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0435 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN O R 0436 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN O R 0437 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN O R 0438 88-108-223-080 C-RES,U 22K-1/16W J a
CDC-R927M
YZSTF
MAIN X R 0439 88-108-335-080 C-RES,U 3.3M-1/16W J a
MAIN X R 0440 88-108-335-080 C-RES,U 3.3M-1/16W J a
MAIN O R 0441 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0442 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0443 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0444 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0446 88-108-000-080 C-JUMPER,U a
MAIN O R 0447 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0448 88-108-000-080 C-JUMPER,U a
MAIN X R 0455 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0456 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0457 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0458 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0461 88-121-222-080 RES,2.2K-1/8W J a
MAIN X R 0462 88-108-122-080 C-RES,U 1.2K-1/16W J a
MAIN X R 0471 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0472 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN O R 0473 88-108-563-080 C-RES,U 56K-1/16W J a
MAIN O R 0474 88-108-563-080 C-RES,U 56K-1/16W J a
MAIN O R 0501 88-108-123-080 C-RES,U 12K-1/16W J a
CDC-R927M
YZSTF
MAIN O R 0502 88-108-123-080 C-RES,U 12K-1/16W J a
MAIN X R 0503 88-121-123-080 RES,12K-1/8W J a
MAIN X R 0504 88-121-123-080 RES,12K-1/8W J a
MAIN X R 0505 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0506 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0507 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0508 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0509 88-108-684-080 C-RES,U 680K-1/16W J a
MAIN X R 0510 88-108-684-080 C-RES,U 680K-1/16W J a
MAIN X R 0511 88-108-684-080 C-RES,U 680K-1/16W J a
MAIN X R 0512 88-108-684-080 C-RES,U 680K-1/16W J a
MAIN X R 0513 88-121-822-080 RES,8.2K-1/8W J a
MAIN X R 0514 88-108-105-080 C-RES,U 1M-1/16W J a
MAIN O R 0522 87-A10-260-080 C-CAP,U 0.1-16 K B a
MAIN X R 0523 88-108-000-080 C-JUMPER,U a
MAIN X R 0531 88-118-100-080 C-RES,S 10-1/10W J a
MAIN X R 0541 88-118-000-080 C-JUMPER,S a
MAIN X R 0542 88-118-000-080 C-JUMPER,S a
MAIN O R 0701 88-108-562-080 C-RES,U 5.6K-1/16W J a
MAIN O R 0702 88-108-562-080 C-RES,U 5.6K-1/16W J a
ELECTRICAL PARTS LIST - 7/10

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-14-
CDC-R927M
YZSTF
MAIN X R 0703 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0704 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN O R 0706 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0707 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0711 88-118-330-080 C-RES,S 33-1/10W J a
MAIN X R 0721 88-118-000-080 C-JUMPER,S a
MAIN O R 0722 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0723 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0724 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN O R 0725 88-108-123-080 C-RES,U 12K-1/16W J a
MAIN O R 0726 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0727 88-108-683-080 C-RES,U 68K-1/16W J a
MAIN X R 0728 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0732 88-118-181-080 C-RES,S 180-1/10W J a
MAIN X R 0751 88-121-562-080 RES,5.6K-1/8W J a
MAIN X R 0752 88-121-562-080 RES,5.6K-1/8W J a
MAIN X R 0753 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0754 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN O R 0755 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0756 88-108-102-080 C-RES,U 1K-1/16W J a
CDC-R927M
YZSTF
MAIN O R 0757 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0758 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0759 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0760 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0761 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0762 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN O R 0763 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0771 88-121-562-080 RES,5.6K-1/8W J a
MAIN X R 0772 88-121-562-080 RES,5.6K-1/8W J a
MAIN X R 0773 88-108-392-080 C-RES,U 3.9K-1/16W J a
MAIN X R 0774 88-108-392-080 C-RES,U 3.9K-1/16W J a
MAIN O R 0811 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0812 88-148-681-080 C-RES, 680-1/2W J a
MAIN X R 0814 88-118-391-080 C-RES,S 390-1/10W J a
MAIN X R 0815 88-118-391-080 C-RES,S 390-1/10W J a
MAIN X R 0816 88-140-229-080 RES,2.2-1/2W J a
MAIN X R 0817 88-118-102-080 C-RES,S 1K-1/10W J a
MAIN X R 0821 88-108-680-080 C-RES,U 68-1/16W J a
MAIN X R 0822 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0831 88-118-102-080 C-RES,S 1K-1/10W J a
CDC-R927M
YZSTF
MAIN X R 0832 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN O R 0833 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0834 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0841 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0901 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0902 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0903 88-121-102-080 RES,1K-1/8W J a
MAIN O R 0904 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0905 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0906 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0907 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0908 88-121-102-080 RES,1K-1/8W J a
MAIN O R 0909 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0910 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0911 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0912 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0913 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0914 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0915 88-121-563-080 RES,56K-1/8W J a
MAIN O R 0916 88-108-102-080 C-RES,U 1K-1/16W J a
CDC-R927M
YZSTF
MAIN O R 0917 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0918 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0921 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN O R 0922 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0923 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0924 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN O R 0925 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0926 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0927 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0928 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0929 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN O R 0932 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0933 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN O R 0934 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0935 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN O R 0936 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0937 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN O R 0943 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0944 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0945 88-108-104-080 C-RES,U 100K-1/16W J a
ELECTRICAL PARTS LIST - 8/10

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-15-
CDC-R927M
YZSTF
MAIN X R 0946 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0947 88-121-104-080 RES,100K-1/8W J a
MAIN X R 0948 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0949 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0950 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0951 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0952 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0956 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0957 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0958 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0959 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN O R 0961 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0962 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0963 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0964 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0965 88-121-102-080 RES,1K-1/8W J a
MAIN O R 0967 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0968 88-121-473-080 RES,47K-1/8W J a
MAIN O R 0969 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN O R 0971 88-108-153-080 C-RES,U 15K-1/16W J a
CDC-R927M
YZSTF
MAIN O R 0973 88-108-563-080 C-RES,U 56K-1/16W J a
MAIN O R 0981 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN O R 0982 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN O R 0992 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0994 88-108-000-080 C-JUMPER,U a
MAIN O SFR0101 87-024-437-080 SFR,100K H RH063MC a
MAIN O TU 0101 8C-KTA-621-010 TU UNIT, FAE347-E30 a
MAIN X W 0101 8Z-KC1-614-010 WIRE,ANT a
MAIN X W 0801 8A-KCG-615-010 WIRE,400 P-MUTE a
MAIN O X 0151 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309 a
MAIN O X 0901 87-A70-372-080 VIB,XTAL 6.3MHZ HC-49/U-S a
SENSOR O CNA0671 8B-KC7-617-010 CONN ASSY,6P EMP a
SENSOR O FFC0671 8B-KC7-618-010 F-CABLE,2P MOT a
SENSOR O PS 0671 87-A92-061-080 C-SNSR,GP1S092 HCPI a
SENSOR X R 0671 88-118-331-080 C-RES,S 330-1/10W J a
SENSOR O SW 0671 87-A92-039-080 C-SW,PUSH ESE22MH24XQ a
SW O SW 0001 87-A92-279-080 C-SW,PUSH 2-1 ESE22MH22XQ a
SW O SW 0002 87-A92-279-080 C-SW,PUSH 2-1 ESE22MH22XQ a
ELECTRICAL PARTS LIST - 9/10

ELECTRICAL PARTS LIST - 10/10
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ 1.0 0.5 0.35 104
Lt
W
• Regarding connectors, they are not stocked as they are not the initial order items.
The connectors are available after they are supplied from connector manufacturers upon the order is received.
-16-

-17-
TRANSISTOR ILLUSTRATION -1/1
BE
C
2SA1037
2SA1576
2SC2412
2SC4081
DTA114YUA
DTB123YK
DTC114TKA
DTC114TUA
DTC114YUA
E C B
2SB1326
2SD1858
B C E
2SB1375
2SD2012

-18-
BLOCK DIAGRAM - 1/1 (OVERALL)
TU101
IC901
IC401 J401
CNA802
IC501
J751
CNA801
REAR
L,R
IC402
BU4066BCF
Q405,406
Q407-410 Q422,423
IC151
SAA6579T Q101
CD C.B
MAIN C.B
SENSOR C.B
KEY C.B JACK C.B
FRONT C.B
IC721
CON721
CNA671
BA6417F
LCD601 IC601
-8720 SW621
AUDIO
CONTROL
LC75817W
CON601
CON701
FFC601
J601
AUX IN
CON603
CON702
LCD,CKC-4
SW601-604,620 SW606-618

-19-
SCHEMATIC DIAGRAM - 1/3 (MAIN/SENSOR/LED SECTION)
FFC671
SLR-342MG T31
GREEN
(ILLUMINATION)
LED731
47/16
R671
TO KEY C.B CON603TO FRONT C.B CON601
330
FFC731
SENSOR C.B
LED C.B
TO CD C.B CON201
LEVEL-M
CDS IN
LM SW
AUX IN
2SD1858TV2
MTZJ5.1B
15A 32V
0.5A
F802
!
D841
1/25(S)
!CNA802
CNA801
W801
BU4066BCF
MAIN C.B
SAA6579T
QUAL
4.332MHz
AM/FM OSC
(ANTENNA)
IF REQ/OUT
Q108
TO POWER SUPPLY TO SPEAKER
: AUDIO (PB) SIGNAL
TO CD CHANGER
100K RDS
VOLTAGE
ADJ.
180K
MOTOR DRIVER
LO/DX SW
U-COM

WIRING - 1/3 (MAIN C.B/SENSOR C.B/LED C.B )
-20-
BLK
(MOTOR)
M601
+
-
BLK
BRN
BLK BRN
BRN
BLK
BRN
RED
ORG
YEL
GRN
MAIN C.B
SENSOR C.B
LED C.B
C
BE
C
BE
C
BE
C
BE
C
EB C
EB
C
EB
B
ECB ECB ECB EC
B
ECB
EC
CE
B
C
BE C BE
C
EB
CE
B
C
EB
B
EC
B
EC
CE
B
C
BE
C
BE C
BE
C
BE
B
C
E
B
C
E
B
C
E
ECB
C457
C508 C521
C505
C458
C519
C522
R522
Q521
C507
C506
R506
C503
R405
R401
C403
C443
C453
R457 R458 R456
R101
D101
L101
C101 Q409
Q410 Q408
C102
R118
R437
R443
R438
R444
R436
R461
Q108
C131
R117
R109
Q901
Q106
C117
C132
C110
R107
R114
Q107
C119
R102
C106
R404 R406
R914
R958
R912
C118
R108
R944 R945
R962
R963
R964
C981
R925
R959
R926
R915
C707
R965
R928
R901
R902
R903
R425 C437
R774
R426
R967
C725
R726
C420
C414
C404
R411
R413
D503
D507
D506
D841
R841
PH.MUTE
W801
F801
F802
BRN
R816
D509
D502
D752
R763
R760
D531
C518
C418
R403
C413
C724
R723
R943
R994
R905
C834
R728
R727
R924 R956
R929
R927
R110
R105
R104
R431
R439 R440
Q407
W101
C105
Q405
Q102
R115 C104
R116
C108
C120
R103
C510 R502
C454
R509
R505
C501
R512
C504
R501
R455
R441
R435 R462
R442
R508
Q422
L451
J401
J401
R
L102
ANT101
ANT101
(ANTENNA)
IC501
IC401
IC901
SFR101
IC721
CON721
IC402
IC151
TU101
CON702 CON701
CON771
C502
R510
R523
R507
C441
R503
C445
Q101
C103
C446 R446
R448
Q406
R119
C121
C109
R131
Q103
R151
C107
R120
C127
C128
R121
R106
R122
C123
R946
D151
C116
C157
C152
C153
C439
D422
C113
R703 R704
R701
R429
R702
C702 R447
L701
C701
R113 R125
L151
C158
C156
C155
R152
X151
C154
R428
R961
Q423
R513
R124
R910 R909
R916
R937
C832 R831
R671
R673
SW671
LED731
(ILLUMINATION)
PS671
CNA671
TO CD C.B
CON201
FFC201
FFC671
FFC731
R672
R832
C838
R833
Q833
Q832
Q834
C722
R725 C726
R722
C831
R834
L721
D831
D821
C822
R982
D981 R981
Q812
C509
IC971
J751
R541
D504
D508
D501 C802
D822
Q813
R992
R934
D901
C910
R969
R721
C723
C721
R724
Q831
D982
R935
D832
R913 R907
R772
R817
C812
C814
C813 Q811
R815
R814
D811
Q821 R822
R911
R752
R751
R753
R514
D510
R971
R973
C971
D971
R415
R419
R418
C428
Q411
R414
C429
R409
R407
R474
C406
R408
R412
C427
C422
R472
C424
C511
R531
C531
C512
D753
D801
R758
R761
C755
C754
C753
R759
C520 C525
R542
C801
D505
R762
D751
R756
Q752
R811
C513
C514
C972
R821
R755
L801
Q751
R757
C821 R812
C811
R918
R908
R906
C438
R427
R754
R410
Q421
C752
R424R773 C751
D421
R423
R932
R771
C901
C907
R957
C908
C915
C126
C125
Q105 C112
C111
C151
R112
R111
C115
C114
L901
C906 R933
C402
C416
C772 R402
R936
X901
C903
C904
C461 R707
R921
R923
R904 R917
R948
R949
R968
C705
L702
R711
R952
R732 Q731
R947
R951
R922
R706
R950
D905
C902
R422
C436
C771
R123
C426
R434
R504
R433 R421
C411
C409
C407
C435
C412
C410
C408
C444
C417
C415 C401 C442 R471
C419
C421
C423
R473
C405
R432
R511
16
9
1
8
1
1
1
3
7
14
8
8
5
1
4
16
64
49 48
33
32
17
25 1
24 2
1
26
30
1
100
81
50
31
51
80
115
216
3
8642
7531 876
13 912 85
41
123
224
19
12
20
1
1
6
6
AUTO ANT+B
CNA802
(WHITE) CNA801
(BLACK)
TO SPEAKER
TO CD CHANGER
TO POWER SUPPLY
L
REAR
TO FRONT C.B CON601TO KEY C.B CON603
101112131415161718192021222324
A
B
C
D
E
F
G
I
J
K
L
M
N
O
P
Q
R
S
T
U
1234567892526272829303132
