SERVICE MANUAL
DATA
BASIC TAPE MECHANISM : ZZM-1 R2NC2
BASIC CD MECHANISM : KSM-213CDM
COMPACT DISC STEREO RADIO
CASSETTE RECORDER
CSD-TD34
CSD-TD36
CSD-TD46
S/M Code No. 09-012-354-0S1
K(H),EZ(H)
LH(H),HRJ(H)
LH(H),HA(H)
In the above models, the laser pickup of the CD mechanism is changed from DA-11T3C
to KSM-213CDM.
If requiring the other information, see Service Manual of the
CSD-TD34 (TYPE:K, EZ)/CSD-TD36 (TYPE:LH)/CSD-TD46 (TYPE:LH)(S/M Code No.09-012-
354-0N1).
SUPPLEMENT
