Aiwa ALP40P User manual

1
CAUTION:
Usage of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
This unit should not be adjusted or repaired by anyone except qualified
service personnel.
PRECAUTIONS BEFORE USE
KEEP THESE INSTRUCTIONS IN MIND:
1. Do not use this device near water.
2. Clean only with a slightly damp cloth.
3. Do not cover or block any ventilation openings. When placing the
device on a shelf, leave 5 cm (2”) free space around the whole device.
4. Install in accordance with the supplied user manual.
5.
near the plugs and the cable’ s exit point . Do not place heavy items on the
power adapt or, wh ich may damage it. Keep the ent ire device out of children’ s
reach! When playing with the power cable, they can seriously injure
themselves.
6. Unplug this device during lightning storms or when unused for a long
period.
7. Keep the device away from heat sources such as radiators, heaters,
stoves, candles and other heat-generating products or naked flame.
8. Avoid using the device near strong magnetic fields.
9. Electrostatic discharge can disturb normal usage of this device. If so,
simply reset and restart the device following the instruction manual. During
file transmission, please handle with care and operate in a static-free
environment.
10. Warning! Never insert an object into the product through the vents or
openings. High voltage flows through the product and inserting an object can
cause electric shock and/or short circuit internal parts. For the same reason,
do not spill water or liquid on the product.
11. Do not use in wet or moist areas such as bathrooms, steamy kitchens
or near swimming pools.
12. Do not use this device when condensation may occur.
13. Although this device is manufactured with the utmost care and
checked several times before leaving the factory, it is still possible that
problems may occur, as with all electrical appliances. If you notice smoke, an
excessive build-up of heat or any other unexpected phenomena, you should
disconnect the plug from the main power socket immediately.
14. This device must operate on a power source as specified on the
specification label. If you are not sure of the type of power supply used in

2
your home, consult your dealer or local power company.
15. The socket outlet must be installed near the equipment and must be
easily accessible.
16. Do not overload ac outlets or extension cords. Overloading can
cause fire or electric shock.
17. Devices with class 1 construction should be connect ed to a main
socket outlet with a protective earthed connection.
18. Devices with class 2 construction do not require a earthed
connection.
19.
20.
Keep away from rodents. Rodents enjoy biting on power cords.
Always hold the plug when pulling it out of the main supply socket.
Do not pull the power cord. This can cause a short circuit.
21. Avoid placing the device on any surfaces that may be subject to
vibrations or shocks.
22. To clean the device, use a soft dry cloth. Do not use solvents or petrol
based fluids. To remove severe stains, you may use a damp cloth with dilute
detergent.
23. Damage or lost data caused by malfunction, misuse, modification of
the device or battery replacement will not be covered under warranty.
24. Do not interrupt the connection when the device is formatting or
transferring files. Otherwise, data may be corrupted or lost.
25. If the unit has USB playback function, the USB memory stick should be
plugged into the unit directly. Don’t use a USB extension cable because it
can cause interference resulting in failing of data.
26. The apparatus shall not be exposed to dripping or splashing and make
sure that no objects filled with liquids, such as vases, are placed on or near
the apparatus.
27. To completely disconnect the power input, the mains plug of the
apparatus shall be disconnected from the mains, as the disconnect device is
the mains plug of apparatus.
28. Battery shall not be exposed to excessive heat such as sunshine, fire
or the like.
29. Attention should be drawn to the environmental aspects of battery
disposal.
30.The unit should only be used in moderate climates. Avoid using in
extremely cold or extremely warm environments.
31. The rating label has been marked on the bottom or back panel of the
apparatus.
32. This device is not intended for use by people (including children) with
physical, sensory or mental disabilities, or a lack of experience and
knowledge, unless they’re under supervision or have received instructions
about the correct use of the device by the person who is responsible for their

3
safety.
33. This product is intended for indoor, household only and not for
commercial or industrial use.
34. Make sure the unit is adjusted to a stable position. Damage caused by
using this product in an unstable position or by failure to follow any other
warning or precaution contained within this user manual will not be covered
by warranty.
35. Never remove the casing of this apparatus.
36. Never place this apparatus on other electrical equipment.
37. Do not use or store this product in a place where it is subject to direct
sunlight, heat, excessive dust or vibration.
38. Do not allow children access to plastic bags.
39. Only use attachments/accessories specified by the manufacturer.
40. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as the power
supply cord or the plug, when liquid has been spilled or objects have fallen
into the apparatus, when the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
41. Do not use a damaged power cord or plug or a loose outlet. Doing so
may result in fire or electric shock.
42. Prolonged exposure to loud sounds from personal music players may
lead to temporary or permanent hearing loss.
INSTALLATION
•Unpack all parts and remove protective material.
•Do not connect the unit to the mains before checking the mains
voltage and before all other connections have been made.

4
Packing Included :
Main unit
Remote
(2 X AAA batteries
included)
AC Power Adapter Lens Cover User Manual
FLIP VOL
–
VOL
+
SOURCE
OK
MENU
EX IT
1 2 3
4 5 6
7 8 9
GOTO 0 ZOOM
OK
1 2 3
4 5 6
7 8 9
0
SOURCE
GOTO ZOOM
MENU
FLIP VOL – VOL+
EXIT
3.5 mm to RCA AV cable

5
Remove & Close The Lens Cover
Remove the lens cover before using Close the lens cover when unit not in use
LENS COVER
REMOV
ELENS COVER
CLOSE
Placing Your Projector
Your projector can be installed in four different configurations ( see picture
below):
Front Table:
Select this location with the projector placed
near the floor in front of the screen. This is the
most common way to position the projector
for quick setup and portability.
Front Ceiling:
Select this location with the projector
suspended upside-down from the ceiling in
front of the screen.
NOTE: A projector mount is required to install
the projector in a ceiling.
Rear Table:
Select this location with the projector placed
near the floor behind the screen.
NOTE: A special rear projection screen
is required.
Rear Ceiling:
Select this location with the projector
suspended upside-down from the ceiling
behind the screen.
NOTE:
A projector mount is required to install the
projector in a ceiling.
A special rear projection screen is required.
FRONT TABLE
FRONT CEILING
REAR TABLE
REAR
CEILING

6
Square /Rectangle
It is recommended to move the projector as close to
center of screen.
Distance Between The Projector And Screen
Measure the distance between the projector and where you want to
position the screen. This is the projection distance.
Placing Your Projector On Ceiling
When installing the projector in the ceiling, please purchase a projector mount
recommended by an installation professional and follow the instructions that
come with the mount.
Before installing the projector in the ceiling, please check to make sure the
ceiling structure can support the weight of the projector and the mount. If in
doubt, please ask the advice from an installation professorial.
NOTE: Projector mount and screw(s) not included
CEILING HANGER
FIXED HANGER HOLE
THE CENTER OF LENS
SCREEN
72
"
60
"
50
"
45
"
37
"

Note: This does not apply for ceiling mounted projectors.To adjust the vertical angle
of the image, adjust the Height Adjustment Peg on the bottom of the projector as
shown. Turn this Peg clockwise or anticlockwise to adjust the vertical angle.
Adjust The Focus And Keystone
Follow below picture to adjust the focus and trapezoidal screen.
Adjust the focus by turning the knob while
observing the image pixels near the center of the
screen. Optimal focus is obtained when the
pixels are clearly visible. Depending on the
projected screen size, the focus near the screen
edges may be less sharp than the screen center.
Keystone image is created when the projector
beam is projected to the screen in an angle.
Keystone correction will restore the distorted
image to a rectangular or square shape.
7
SCREEN
PROJECTOR
Height Adjustment Peg
FOCUS ADJ. KNOB
Then sharpen the image
by rotating focus knob.
TRAPEZOIDAL ADJ. KNOB
Vertical Angle

8
Controls Of Remote
OK
1 2 3
4 5 6
7 8 9
0
SOURCE
GOTO ZOOM
MENU
FLIP VOL – VOL +
EXIT
Power
Press to power ON.
Press and hold to power OFF.
Previous / Next
Press to skip between chapters or tracks.
Stop
Press to stop playback.
Flip
Press t display image 180°.
Play/Pause
Press to play or pause an individual
chapter or track.
Arrows/OK
Press to navigate and c rm selections in
Settings and other menus.
Menu
Press to access projector Settings.
Go To/Number Keypad
Press to enter spec ter or track
numbers. Use Play button to begin
playing.
Mute
Press to mute volume.
Back / Fwd
Press to search through an individual
chapter or track.
VOL+ / VOL−
Press to adjust audio level.
Source
Press to select media source
(AV, PC, HDMI, MEDIA).
Exit
Press to exit menus.
Zoom
Press to zoom display image in or out.
Remove the battery compartment cover on the back of your remote by
carefully sliding to open. The battery cover can then be lifted away. Fit the
correct batteries (2 X AAA batteries included), referring to the polarity
markings. Finally, replace the cover.
NOTES:
•Batteries shall not be exposed to excessive heat such as sunshine, fire
•Be sure that the batteries are installed with correct polarity.
•Do not mix old and new batteries.
•Only same or equivalent type batteries as recommended are to be used.
•Do not dispose of batteries in fire, battery may explode or leak. Do not try
to recharge a battery
AAA / UM4
AAA / UM4
BATTERY DOOR
•Do not mix alkaline, standard (carbon-zinc), or rechargeable (Nickel-cadmium,
Nickel-metal hydride etc) batteries.

9
VGA
IR
Controls OfProjector
1
2
3
4
5
6 7
8
9 10
11
12 MICROSD 13
14
CAU TION

10
1. Projector Lens
2.
Focus Adjustment
3.
Keystone Adjustment
4. Controls/Power Indicator
5. VGA/PC Input
6. Remote Sensor (duplicated on the
front of the projector)
7. Speakers
8. Height Adjustment Peg
9. Micro SD Card Port
10. HDMI Input 1 &2
11. USB Port
12. 3.5mm Audio Output
13. DC Power Port
14. 3.5mm AV Input
Controls
Source
Press to
change media
source mode.
Menu
Press to access
on-screen
menus and
options.
Arrows/OK
Press to
navigate on-
screen menus
and make
selections.
Back
Press to return
to a previous
page or setting
in the on-
screen menus.
Power/Pair
Press to
power on the
projector.
Press and hold
to power OFF.
Install Power Adapter
Follow below picture to connect power adapter
Connect small end of adapter FIRST. Plug the adapter body to power outlet.
Mains Socket
CAU TIO N

11
Connect HDMI Show The Image On Projector Screen
Follow below picture to connect HDMI cable and device.
1. Turn off the unit before connectingHDMI cable.
2. After connecting, press the button to turn on unit and power indicator will
light GREEN
3. Press the /SOURCE button to switch to HDMI mode, the video from
the HDMI device is displayed on the screen. There are 2 HDMI inputs
(HDMI 1 and HDMI 2), select the correct source accordingly.
4. Press the button to turn off unit power.
Note: For HD signal input through HDMI
HDMI CABLE
CABLE NOT INCLUDED
In rare cases, if the projector’s speaker has
no sound when playing a DVD movie in a
player through the HDMI input, please
check the player’s digital audio settings and
make sure it is set to “Auto” mode or “PCM”
mode.
Connect AV Show The Image On Projector Screen
Follow below picture to connect AV cable and device.
1. Turn off the unit before connecting AVcable.
2. Use AV cable to connect as per the below figure
3. After connecting, press the button to turn on unit and power indicator will
light GREEN
4. Press the / SOURCE button to switch toAV mode, the video from the connected
device will be displayed on the screen.
5. Press the button to turn off unit power.
CABLE INCLUDED
VIDEO CABLE
VIDEO PLAYER
LEFT CHANNEL
RIGHT CHANNEL
VIDEO CABLE : YELLOW
AUDIO LEFT CHANNEL :
WHITE AUDIO RIGHT
CHANNEL : RED

12
Connect VGA Show The Image On Projector Screen
Follow below picture to connect VGA cable and device.
1. Turn off the unit before connecting VGA cable.
2. Press the button to turn off power of your projector before connection.
3. After connecting, press the button to turn on unit and power indicator will
light GREEN
4. Press the /SOURCE button switch toVGA mode, the video from the
connected device will be displayed on the screen.
5. Press the button to turn off unit power.
To VGA PORT
OR
C OMPUTER CABLE C OMPUTER CABLE
CABLE NOT INCLUDED
NOTE BOOK DESKTOP
Please refer to the following table to adjust the output signal from computer
PC
VGA 640x480
31.5 60
34.7 70
37.9 72
37.5 75
SVGA 800x600
31.4 50
35.1 56
37.9 60
46.6 70
48.1 72
46.9 75
XGA 1024x768
40.3 50
48.4 60
56.5 70
VGA IR

13
Connect Audio Output ( Aux Out / Line Out / Earphones)
Follow below picture to connect audio cable and device.
1. Press the button to turn off projector power before connecting.
2. Use an audio cable as shown below to connect the external device tothe projector.
3. Turn on the projector and the external device. Now the projector sound will be
played on the external device speakers.
4. Turn off both the projector and the external device after use.
Station Amplifier
CABLE NOT INCLUDED
Audio cable
Install USB Device And Micro SD Card
Connect your USB device or microSD card to the respective slots.
Turn off the projector when inserting.
MICRO SD

14
MicroSD Card And USB Playback (Media Player)
Install USB
/ microSD device:
1. Turn off the unit before inserting USB/ microSD card.
2. Install the USB device into USB port.
3. After connecting, press the button to turn on unit and the power indicator lights up
GREEN.
4. Press the / SOURCE button to enter and use buttons to
search for MEDIA mode.
5. After selection , use buttons to search the MUSIC / PHOTO / MOVIE
icon and press the button to enter. If necessary , use the button to
select microSD card or USB and press the button to enter.
6. Use buttons to search the correct file and press the button to
preview playback file and press the button of unit or button of
remote to start playback.
7. Press button to fast search forward and rewind.
8. Press button to search next or previous file.
9. During playback, press the button to pause and press again to resume.
NOTE: Remove USB / microSD device, press the button to turn off power FIRST.
OK
OK
OK
Sub-Menu on Photo screen
1. During photo playback, press the
screens show up(figure 1).
2. Use the button to select
icon and press
Figure 1.
Sub-Menu on Music screen
3. During music playback, press the
(figure 2 ).
4. Use the button to select
icon and press
Figure 2
Sub-Menu on Movie screen
5. press the
(figure 3).
6. Use the button to select
icon and press
Figure 3
Rotate
Zo... Zo...
+-
M...
Rotate
Pause FB FF Next
Prev. Stop Re... Set A
PL... Info Go...
AB
i
MUTE
Pause FB FF Next
Prev. Stop Re...
Set A PL... Info St...
Sl... Go...
AB
i
AS...
Pause Next
Prev. Stop Re...
PL...
Info
i
background
music
screens show up
During photo playback,
screens show up

15
Using Bluetooth Playback
Pairing to Bluetooth Wireless Speakers or Sound Bar
NOTE: Bluetooth is OFF by default when the projector powers ON. Bluetooth can be turned ON or OFF from
the OPTIONS Menu.
1. Enable Bluetooth on the receiver (external speakers, sound bar, etc.) to which you wish to
connect. Devices such
as smartphones, tablets, or computers are not Bluetooth receivers and will
not connect to the projector. To eliminate
confusion, you should disable Bluetooth on all
receivers to which you do not wish to connect.
2. Power on the projector and make sure the projector's Bluetooth is ON (see note above). The
projector will begin searching for nearby Bluetooth devices to connect to, and will
automatically initiate pairing.
3. When successfully paired, the Bluetooth receiver should indicate it is connected, usually with a
chime or other audible noise. Check the user manual on your Bluetooth receiver for more
information.
4. When successfully connected, the projector will display the Bluetooth receiver's name on the
top right portion of the Main Menu screen, and sound played from the projector will be heard
through the Bluetooth receiver.
After initial pairing, the projector and the Bluetooth speakers will stay paired unless unpaired manually by
the user, or erased due to a reset of either device. If this occurs, or you find either unit is unable to
connect, repeat the above steps.

16
OK
Using Projector Menu 1.0
Press button to enter projector menu. Press again for previous status.
Use buttons to select manual page.
This manual shows on right upper of view
screen.
1. Picture Mode
Select Vivid, User (custom), Soft ,or Standard
2. Contrast ,Brightness, etc
Set Picture Mode to “User “ to adjust these settings
3. Color Temperature
Select Warm ,Cool, or Medium.
4. Aspect Ratio
Select 16:9, 4:3 , or Auto
5. Noise Reduction
Select Off, Low , Middle , High or Default
6. Screen
Color temper… (temperature)
Customer define Parameter
red 0-100
blue 0-100
green 0-100
Aspect Ratio
4:3 The signal in a 4:3 aspect ratio projection image
16:9 The signal in a 16:9 aspect ratio projection image
Color Temperature Medium
Aspect Ratio Auto
Noise Reduction Middle
Screen
Standard
5 0
50
50
50
50
Picture Mode
Contrast
Brightness
Color
Sharpness
Tint

17
OK
Using Projector Menu 2.0
Press button to enter projector menu. Press again for previous status.
Use buttons to select manual page.
This manual shows on right upper of view
screen.
1. Sound Mode
Select Music, Movie, User (custom), Sports ,or Standard
2. Treble, Bass
Set Sound Mode to “User “ to adjust these settings
3. Balance
Adjust the audio balance.
4. Surround Sound
Turn Surround Sound ON or OFF.
Sound Mode - User Parameter
Treble 0-100
Bass 0-100
Sound Mode Standard
Treble 50
Bass 50
Balance 0
Auto Volume Off
Surround Sound Off

18
OK
Using Projector Menu 3.0
Press
button to enter projector menu. Press again for previous status.
Use buttons to select manual page.
This manual shows on right upper of viewing
screen.
1. OSD Language
Select different language, Follow below figure.
3. Restore Factory Default
Select Y or N.
4. Panel Rotate
Select rotate 0, rotate 1, rotate 2, rotate 3..
5. INFO
Display the unit information as below.
English Hrvatski Nederlands Chinese
Franais Deutech Slovenina Slovak
Espanol Italiano Norsk
Portugues Magyar Srpski
Esky Polski Svenska
Dansk Romnete Suomi
0
English
OSD Language
Restore Factory Default
Panel Rotate
Info
Model: ALP40P
SN:EV0386/1
AIWA
SW Ver: V7.0
LOGO: AIWA
BT V4.1/V4.2
Bluetooth
Turn Bluetooth ON or OFF
Bluetooth
2.

19
OK
OK
Using Projector Menu 4.0
Press button to enter projector menu. Press again for previous status.
Use buttons to select manual page.
This manual shows on right upper of view
screen.
1. Clock-- --
Select clock to Day, Month, Year, Hour ,and Minutes.
2. Off Timer
Select turn off timer to Day, Hour ,and Minutes.
3. On Timer
Select turn on timer to Day, Hour ,and Minutes.
4. Sleep Timer
Select sleep timer to Off, 10min, 20min, 30 min, 60min, 90min, 120min,
180min, 240min
5. Auto Sleep
Select auto sleep function to Never, 4 hour, 6 hour, 8 hour.
Clock -- --
Off Timer Off
On Timer Off
Sleep Timer Off
Auto Sleep Never
