SERVICE MANUAL
DATA
VX-F20DV1 U
DVD COLOR TELEVISION BASIC DVD MECHANISM: AZG-D ZDADM
SIMPLE
S/M Code No. 09-008-437-0T1
• Replace this Service manual with “Revision Publishing” when it is issued.

PARTS LIST
-2-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
01 -- U1M VX-F20DV1
X ACC 87-047-160-010 1A BAT,R03(PL) JPN U1M VX-F20DV1
O ACC 87-B30-311-010 1 ADAPTOR,300 75 TSN-02 U1M VX-F20DV1
O ACC 8A-JD1-670-010 2A RC UN T,RC-AVC01 U1M VX-F20DV1
O APPEAR 8A-JD1-001-010 -- CAB ,FR U1M VX-F20DV1
O APPEAR 8A-JD1-002-010 -- PANEL,MA N U1M VX-F20DV1
O APPEAR 8A-JD1-003-010 -- PANEL,TRAY U1M VX-F20DV1
O APPEAR 8A-JD1-004-010 -- PANEL,REAR 1 U1M VX-F20DV1
O APPEAR 8A-JD1-005-010 -- PANEL,REAR 2 U1M VX-F20DV1
O APPEAR 8A-JD1-006-010 -- W NDOW,D SPLAY DVD U1M VX-F20DV1
O APPEAR 8A-JD1-007-010 -- KEY,SCREEN U1M VX-F20DV1
O APPEAR 8A-JD1-008-010 -- KEY,MA N U1M VX-F20DV1
O APPEAR 8A-JD1-009-010 -- KEY,VOL U1M VX-F20DV1
O APPEAR 8A-JD1-010-010 -- KEY,STOP U1M VX-F20DV1
O APPEAR 8A-JD1-011-010 -- COVER, PLAY KEY U1M VX-F20DV1
O APPEAR 8A-JD1-012-010 -- BTN,PLAY U1M VX-F20DV1
O APPEAR 8A-JD1-013-010 -- BTN,POWER U1M VX-F20DV1
O APPEAR 8A-JD1-014-010 -- LENS,SCREEN U1M VX-F20DV1
O APPEAR 8A-JD1-015-010 -- LENS,LED U1M VX-F20DV1
O APPEAR 8A-JD1-017-010 -- CAB ,REAR U U1M VX-F20DV1
X APPEAR 8A-JD1-040-010 -- PLATE,REAR 2 U1M VX-F20DV1
X APPEAR 8A-JD1-041-010 -- PLATE,REAR 1 U1M VX-F20DV1
O APPEAR 8Z-HU1-033-010 1D BADGE,DVD U1M VX-F20DV1
O APPEAR 8Z-JE7-008-010 0E BADGE,A WA ST 52.5 U1M VX-F20DV1
O AUD O 87-067-688-010 0E BVTT+3-6 U1M VX-F20DV1
O AUD O C 0401 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0402 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0403 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0404 87-A10-307-080 0E CAP,M 0.1-50 J U1M VX-F20DV1
O AUD O C 0405 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0406 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O AUD O C 0407 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0408 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0409 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0410 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0411 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
X AUD O C 0412 88-700-559-810 0E CAP,M 470P-50 J U1M VX-F20DV1
O AUD O C 0413 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0414 87-A10-305-080 0E CAP,M 0.068-50 J U1M VX-F20DV1
O AUD O C 0415 87-A10-293-080 0E CAP,M 6800P-50 J U1M VX-F20DV1
O AUD O C 0416 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O AUD O C 0417 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0418 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0419 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0420 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0421 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0422 87-A10-293-080 0E CAP,M 6800P-50 J U1M VX-F20DV1
X AUD O C 0423 88-700-559-810 0E CAP,M 470P-50 J U1M VX-F20DV1
O AUD O C 0424 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O AUD O C 0425 87-A10-305-080 0E CAP,M 0.068-50 J U1M VX-F20DV1
O AUD O C 0426 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0427 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
O AUD O C 0428 87-010-189-080 0E C-CAP,S 8200P-50 K B U1M VX-F20DV1
O AUD O C 0429 87-012-365-080 0E C-CAP,S 0.027-25 K B U1M VX-F20DV1
O AUD O C 0430 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O AUD O C 0431 87-010-189-080 0E C-CAP,S 8200P-50 K B U1M VX-F20DV1
O AUD O C 0432 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0433 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O AUD O C 0434 87-012-365-080 0E C-CAP,S 0.027-25 K B U1M VX-F20DV1
O AUD O C 0435 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O AUD O C 0436 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O AUD O C 0437 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O AUD O C 0438 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 U1M VX-F20DV1
O AUD O C 0439 87-A10-307-080 0E CAP,M 0.1-50 J U1M VX-F20DV1
O AUD O C 0440 87-A10-307-080 0E CAP,M 0.1-50 J U1M VX-F20DV1
O AUD O C 0441 87-A10-307-080 0E CAP,M 0.1-50 J U1M VX-F20DV1
O AUD O C 0442 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O AUD O C 0443 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0444 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1

PARTS LIST
-3-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
O AUD O C 0445 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0446 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0447 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0448 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0449 87-010-402-080 0E CAP,E 2.2-50 M 11L SME U1M VX-F20DV1
O AUD O C 0450 87-010-247-080 0E CAP,E 100-50 M SME U1M VX-F20DV1
O AUD O C 0451 87-010-388-080 1A CAP,E 1000-25 M SME U1M VX-F20DV1
O AUD O C 0452 87-010-388-080 1A CAP,E 1000-25 M SME U1M VX-F20DV1
O AUD O C 0453 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0454 87-010-917-090 1D CAP,E 3300-50 M SMG U1M VX-F20DV1
O AUD O C 0455 87-010-247-080 0E CAP,E 100-50 M SME U1M VX-F20DV1
O AUD O C 0460 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0464 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O AUD O C 0465 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 U1M VX-F20DV1
O AUD O C 0466 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0467 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O AUD O C 0468 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0469 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0470 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM U1M VX-F20DV1
O AUD O C 0471 87-012-155-080 0E C-CAP,S 180P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0472 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0473 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0474 87-A10-295-080 0E CAP,M 0.01-50 J U1M VX-F20DV1
O AUD O C 0475 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 U1M VX-F20DV1
O AUD O C 0476 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O AUD O C 0477 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0478 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0479 87-010-318-080 0E C-CAP,S 47P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0480 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0481 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0482 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 U1M VX-F20DV1
O AUD O C 0483 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O AUD O C 0484 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0486 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0487 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 U1M VX-F20DV1
O AUD O C 0488 87-010-384-080 0E CAP,E 100-25 M 11L SME U1M VX-F20DV1
O AUD O C 0489 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0493 87-A10-307-080 0E CAP,M 0.1-50 J U1M VX-F20DV1
O AUD O C 0494 87-A10-307-080 0E CAP,M 0.1-50 J U1M VX-F20DV1
X AUD O C 0495 88-710-949-810 1A CAP,M 0.47-50 J TFL U1M VX-F20DV1
X AUD O C 0496 88-710-949-810 1A CAP,M 0.47-50 J TFL U1M VX-F20DV1
O AUD O C 0497 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0498 87-010-402-080 0E CAP,E 2.2-50 M 11L SME U1M VX-F20DV1
O AUD O C 0751 87-010-545-080 0E CAP,E 0.22-50 M 11L SME U1M VX-F20DV1
O AUD O C 0752 87-010-402-080 0E CAP,E 2.2-50 M 11L SME U1M VX-F20DV1
O AUD O C 0753 87-010-545-080 0E CAP,E 0.22-50 M 11L SME U1M VX-F20DV1
O AUD O C 0754 87-010-402-080 0E CAP,E 2.2-50 M 11L SME U1M VX-F20DV1
O AUD O C 0755 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0756 87-010-545-080 0E CAP,E 0.22-50 M 11L SME U1M VX-F20DV1
O AUD O C 0757 87-010-402-080 0E CAP,E 2.2-50 M 11L SME U1M VX-F20DV1
O AUD O C 0758 87-010-545-080 0E CAP,E 0.22-50 M 11L SME U1M VX-F20DV1
O AUD O C 0759 87-010-402-080 0E CAP,E 2.2-50 M 11L SME U1M VX-F20DV1
O AUD O C 0760 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
O AUD O C 0761 87-010-314-080 0E C-CAP,S 22P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0762 87-010-314-080 0E C-CAP,S 22P-50 J CH GRM U1M VX-F20DV1
O AUD O C 0763 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0764 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O AUD O C 0765 87-010-382-080 0E CAP,E 22-25 M 11L SME U1M VX-F20DV1
O AUD O C 0766 87-010-402-080 0E CAP,E 2.2-50 M 11L SME U1M VX-F20DV1
O AUD O C 0767 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O AUD O C 0768 87-010-402-080 0E CAP,E 2.2-50 M 11L SME U1M VX-F20DV1
O AUD O C 0769 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0770 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0780 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O AUD O C 0781 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
! O AUD O CN 0401 87-009-314-010 0E CONN,8P V 51048 U1M VX-F20DV1
! O AUD O CN 0404 87-049-469-010 0E CONN,4P V WHT EH U1M VX-F20DV1
O AUD O CN 0405 87-009-317-010 0E CONN,11P V 51048 U1M VX-F20DV1
O AUD O CN 0406 87-099-407-010 0E CONN,7P V WHT EH U1M VX-F20DV1
O AUD O CN 0407 8A-JD1-675-010 -- CONN ASSY,8P V AUD O TO JO NT U1M VX-F20DV1

PARTS LIST
-4-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
! O AUD O CN 0409 87-009-033-010 0E CONN,5P V WHT PH U1M VX-F20DV1
O AUD O CNA0401 8A-JD1-659-010 0E CONN ASSY,1P AUD O TO FR-JACK U1M VX-F20DV1
O AUD O CNA0402 8A-JE7-610-010 1A CONN ASSY,6P V WHT AU-MA N U1M VX-F20DV1
O AUD O CNA0403 8A-JE7-611-010 1B CONN ASSY,11P V WHT AU-VD U1M VX-F20DV1
O AUD O CNA0408 8Z-JE7-663-010 0E CONN ASSY,2P COMB-NK U1M VX-F20DV1
O AUD O CNA0414 8A-JE7-626-010 0E CONN ASSY,1P AU-MA N U1M VX-F20DV1
O AUD O CNA0416 8A-JD1-659-010 0E CONN ASSY,1P AUD O TO FR-JACK U1M VX-F20DV1
S AUD O D 0401 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S AUD O D 0402 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S AUD O D 0403 87-A40-234-080 0E ZENER,MTZJ5.6A U1M VX-F20DV1
S AUD O D 0405 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S AUD O D 0409 87-020-125-080 0E C-D ODE,1SS181 U1M VX-F20DV1
O AUD O DL 0401 87-A91-598-010 1H DELAY L NE,350NS EQFK5-MT U1M VX-F20DV1
O AUD O FR 0401 87-A00-478-090 1A RES,FUSE 2.2-1W J U1M VX-F20DV1
O AUD O FR 0402 87-A00-478-090 1A RES,FUSE 2.2-1W J U1M VX-F20DV1
X AUD O HT 0404 8Z-JB4-640-110 1B HT-S NK, BW75L70 (F10) U1M VX-F20DV1
S AUD O C 0401 87-A21-103-040 1E C- C,MM1454XFBE U1M VX-F20DV1
S AUD O C 0402 87-A21-022-040 1D C- C,BA3880FS U1M VX-F20DV1
S AUD O C 0403 87-A21-554-010 1H C,TA1216AN U1M VX-F20DV1
S AUD O C 0404 87-A21-283-010 1C C,AN5277 U1M VX-F20DV1
S AUD O C 0405 87-001-536-010 1A C,NJM78M05FA U1M VX-F20DV1
S AUD O C 0406 87-A21-220-010 1F C,MM1311AD U1M VX-F20DV1
S AUD O C 0407 87-A21-219-010 1F C,TC90A45P U1M VX-F20DV1
O AUD O L 0401 87-005-614-080 0E CO L,100UH J LAV35 U1M VX-F20DV1
O AUD O L 0403 87-005-614-080 0E CO L,100UH J LAV35 U1M VX-F20DV1
O AUD O L 0404 87-005-614-080 0E CO L,100UH J LAV35 U1M VX-F20DV1
O AUD O L 0405 87-003-284-080 0E CO L,27UH J LAL02 U1M VX-F20DV1
O AUD O L 0406 87-003-284-080 0E CO L,27UH J LAL02 U1M VX-F20DV1
O AUD O L 0407 87-A50-555-010 1B CO L,100UH K 7212M-101K U1M VX-F20DV1
S AUD O Q 0402 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0403 89-110-372-080 0E C-TR,2SA1037K(R) U1M VX-F20DV1
S AUD O Q 0404 89-110-372-080 0E C-TR,2SA1037K(R) U1M VX-F20DV1
S AUD O Q 0405 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0406 87-026-617-080 0E C-TR,DTC323TK T147 U1M VX-F20DV1
S AUD O Q 0407 87-026-617-080 0E C-TR,DTC323TK T147 U1M VX-F20DV1
S AUD O Q 0408 87-A30-062-080 0E C-TR,KRC104S U1M VX-F20DV1
S AUD O Q 0409 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0410 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0411 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0412 89-110-372-080 0E C-TR,2SA1037K(R) U1M VX-F20DV1
S AUD O Q 0413 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0414 89-110-372-080 0E C-TR,2SA1037K(R) U1M VX-F20DV1
S AUD O Q 0415 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0416 89-110-372-080 0E C-TR,2SA1037K(R) U1M VX-F20DV1
S AUD O Q 0417 89-110-372-080 0E C-TR,2SA1037K(R) U1M VX-F20DV1
S AUD O Q 0418 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0751 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0752 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
S AUD O Q 0756 89-324-122-080 0E C-TR,2SC2412KR U1M VX-F20DV1
X AUD O R 0401 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0402 88-118-183-080 0E C-RES,S 18K-1/10W J U1M VX-F20DV1
X AUD O R 0403 88-118-153-080 0E C-RES,S 15K-1/10W J U1M VX-F20DV1
X AUD O R 0404 88-118-152-080 0E C-RES,S 1.5K-1/10W J U1M VX-F20DV1
X AUD O R 0405 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0406 88-118-183-080 0E C-RES,S 18K-1/10W J U1M VX-F20DV1
X AUD O R 0407 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0408 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0409 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0410 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0411 88-118-122-080 0E C-RES,S 1.2K-1/10W J U1M VX-F20DV1
X AUD O R 0412 88-118-392-080 0E C-RES,S 3.9K-1/10W J U1M VX-F20DV1
X AUD O R 0413 88-118-122-080 0E C-RES,S 1.2K-1/10W J U1M VX-F20DV1
X AUD O R 0414 88-118-392-080 0E C-RES,S 3.9K-1/10W J U1M VX-F20DV1
X AUD O R 0415 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0416 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0417 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0418 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X AUD O R 0419 88-118-223-080 0E C-RES,S 22K-1/10W J U1M VX-F20DV1
X AUD O R 0420 88-118-222-080 0E C-RES,S 2.2K-1/10W J U1M VX-F20DV1
X AUD O R 0421 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1

PARTS LIST
-5-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
X AUD O R 0422 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0423 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0424 88-118-101-080 0E C-RES,S 100-1/10W J U1M VX-F20DV1
X AUD O R 0425 88-118-101-080 0E C-RES,S 100-1/10W J U1M VX-F20DV1
X AUD O R 0426 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0427 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0428 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0429 88-118-473-080 0E C-RES,S 47K-1/10W J U1M VX-F20DV1
X AUD O R 0430 88-118-122-080 0E C-RES,S 1.2K-1/10W J U1M VX-F20DV1
X AUD O R 0431 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
O AUD O R 0432 87-A00-753-090 -- RES,M/F 1.6-7W K RSV7 U1M VX-F20DV1
X AUD O R 0434 88-118-223-080 0E C-RES,S 22K-1/10W J U1M VX-F20DV1
X AUD O R 0435 88-118-393-080 0E C-RES,S 39K-1/10W J U1M VX-F20DV1
X AUD O R 0436 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0437 88-118-822-080 0E C-RES,S 8.2K-1/10W J U1M VX-F20DV1
X AUD O R 0438 88-118-822-080 0E C-RES,S 8.2K-1/10W J U1M VX-F20DV1
X AUD O R 0439 88-118-183-080 0E C-RES,S 18K-1/10W J U1M VX-F20DV1
X AUD O R 0440 88-118-183-080 0E C-RES,S 18K-1/10W J U1M VX-F20DV1
X AUD O R 0441 88-118-152-080 0E C-RES,S 1.5K-1/10W J U1M VX-F20DV1
X AUD O R 0442 88-118-152-080 0E C-RES,S 1.5K-1/10W J U1M VX-F20DV1
X AUD O R 0443 88-118-222-080 0E C-RES,S 2.2K-1/10W J U1M VX-F20DV1
X AUD O R 0444 88-118-222-080 0E C-RES,S 2.2K-1/10W J U1M VX-F20DV1
X AUD O R 0445 88-118-223-080 0E C-RES,S 22K-1/10W J U1M VX-F20DV1
X AUD O R 0446 88-118-223-080 0E C-RES,S 22K-1/10W J U1M VX-F20DV1
X AUD O R 0449 88-118-223-080 0E C-RES,S 22K-1/10W J U1M VX-F20DV1
X AUD O R 0456 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0458 88-118-000-080 0E C-JUMPER,S U1M VX-F20DV1
X AUD O R 0459 88-118-000-080 0E C-JUMPER,S U1M VX-F20DV1
X AUD O R 0460 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0461 88-118-472-080 0E C-RES,S 4.7K-1/10W J U1M VX-F20DV1
X AUD O R 0462 88-118-391-080 0E C-RES,S 390-1/10W J U1M VX-F20DV1
X AUD O R 0463 88-118-561-080 0E C-RES,S 560-1/10W J U1M VX-F20DV1
X AUD O R 0464 88-118-222-080 0E C-RES,S 2.2K-1/10W J U1M VX-F20DV1
X AUD O R 0465 88-118-101-080 0E C-RES,S 100-1/10W J U1M VX-F20DV1
X AUD O R 0466 88-118-101-080 0E C-RES,S 100-1/10W J U1M VX-F20DV1
X AUD O R 0467 88-118-821-080 0E C-RES,S 820-1/10W J U1M VX-F20DV1
X AUD O R 0468 88-118-561-080 0E C-RES,S 560-1/10W J U1M VX-F20DV1
X AUD O R 0469 88-118-561-080 0E C-RES,S 560-1/10W J U1M VX-F20DV1
X AUD O R 0470 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0471 88-118-221-080 0E C-RES,S 220-1/10W J U1M VX-F20DV1
X AUD O R 0472 88-118-271-080 0E C-RES,S 270-1/10W J U1M VX-F20DV1
X AUD O R 0473 88-118-562-080 0E C-RES,S 5.6K-1/10W J U1M VX-F20DV1
X AUD O R 0474 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0475 88-118-681-080 0E C-RES,S 680-1/10W J U1M VX-F20DV1
X AUD O R 0476 88-118-561-080 0E C-RES,S 560-1/10W J U1M VX-F20DV1
X AUD O R 0477 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0478 88-118-221-080 0E C-RES,S 220-1/10W J U1M VX-F20DV1
X AUD O R 0479 88-118-271-080 0E C-RES,S 270-1/10W J U1M VX-F20DV1
X AUD O R 0480 88-118-562-080 0E C-RES,S 5.6K-1/10W J U1M VX-F20DV1
X AUD O R 0482 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0483 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0484 88-118-221-080 0E C-RES,S 220-1/10W J U1M VX-F20DV1
X AUD O R 0485 88-118-221-080 0E C-RES,S 220-1/10W J U1M VX-F20DV1
X AUD O R 0486 88-118-221-080 0E C-RES,S 220-1/10W J U1M VX-F20DV1
X AUD O R 0487 88-118-471-080 0E C-RES,S 470-1/10W J U1M VX-F20DV1
X AUD O R 0488 88-118-152-080 0E C-RES,S 1.5K-1/10W J U1M VX-F20DV1
X AUD O R 0489 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0490 88-118-562-080 0E C-RES,S 5.6K-1/10W J U1M VX-F20DV1
X AUD O R 0491 88-118-122-080 0E C-RES,S 1.2K-1/10W J U1M VX-F20DV1
X AUD O R 0492 88-118-222-080 0E C-RES,S 2.2K-1/10W J U1M VX-F20DV1
X AUD O R 0495 88-121-472-080 0E RES,4.7K-1/8W J U1M VX-F20DV1
X AUD O R 0497 88-121-822-080 0E RES,8.2K-1/8W J U1M VX-F20DV1
X AUD O R 0499 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0751 88-118-331-080 0E C-RES,S 330-1/10W J U1M VX-F20DV1
X AUD O R 0752 88-118-331-080 0E C-RES,S 330-1/10W J U1M VX-F20DV1
X AUD O R 0753 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0754 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0755 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0756 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0759 88-118-123-080 0E C-RES,S 12K-1/10W J U1M VX-F20DV1

PARTS LIST
-6-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
X AUD O R 0760 88-118-103-080 0E C-RES,S 10K-1/10W J U1M VX-F20DV1
X AUD O R 0761 88-118-102-080 0E C-RES,S 1K-1/10W J U1M VX-F20DV1
X AUD O R 0762 88-118-472-080 0E C-RES,S 4.7K-1/10W J U1M VX-F20DV1
X AUD O R 0763 88-121-472-080 0E RES,4.7K-1/8W J U1M VX-F20DV1
X AUD O R 0764 88-121-472-080 0E RES,4.7K-1/8W J U1M VX-F20DV1
X AUD O R 0774 88-118-224-080 0E C-RES,S 220K-1/10W J U1M VX-F20DV1
X AUD O R 0775 88-118-224-080 0E C-RES,S 220K-1/10W J U1M VX-F20DV1
X AUD O SH 0406 8A-JD1-222-010 -- SHLD-PLATE, C 1 U1M VX-F20DV1
X AUD O SH 0407 8A-JD1-223-010 -- SHLD-PLATE, C 2 U1M VX-F20DV1
O AUD O W 0401 8A-JE7-612-010 0E F-CABLE,8P 2.0 70MM U1M VX-F20DV1
O AUD O W 0405 8A-JE7-613-010 0E F-CABLE,11P 2.0 70MM U1M VX-F20DV1
! O CRT 8A-JE7-607-010 9Z CRT,A51LTH196X01 (O) U1M VX-F20DV1
X DEFLECT ON 83-JT1-215-110 0E HT-S NK U1M VX-F20DV1
O DEFLECT ON 87-067-579-010 0E BVT2+3-8 W/0 SL0T U1M VX-F20DV1
O DEFLECT ON 87-067-641-010 0E UTT2+3-8 W/O SLOT BLK U1M VX-F20DV1
O DEFLECT ON 87-067-758-010 0E BVT2+3-12 W/0 SL0T U1M VX-F20DV1
X DEFLECT ON * 8Z-JE7-212-010 -- PLATE,FOOT U1M VX-F20DV1
X DEFLECT ON * 8Z-JE7-212-010 -- PLATE,FOOT U1M VX-F20DV1
O DEFLECT ON C 0501 87-010-404-080 0E CAP,E 4.7-50 M 11L SME U1M VX-F20DV1
X DEFLECT ON C 0502 88-218-542-080 0E CAP,CER 390P-50 K YB U1M VX-F20DV1
X DEFLECT ON C 0503 88-700-810-810 0E CAP,M 0.01-50 J AMZV U1M VX-F20DV1
O DEFLECT ON C 0504 87-010-393-080 0E CAP,E 100-35 M SME U1M VX-F20DV1
O DEFLECT ON C 0505 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 U1M VX-F20DV1
X DEFLECT ON C 0506 88-710-399-810 0E CAP,M 0.68-50 J TFL ECQV U1M VX-F20DV1
O DEFLECT ON C 0508 87-010-398-090 1B CAP,E 2200-35 M SME U1M VX-F20DV1
O DEFLECT ON C 0509 87-A11-245-080 0E CAP,M/P 0.1-100 J TF-ECQV U1M VX-F20DV1
O DEFLECT ON C 0510 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
X DEFLECT ON C 0601 88-218-612-080 0E CAP,CER 1000P-50 K YB U1M VX-F20DV1
X DEFLECT ON C 0603 88-707-939-810 0E CAP,M 0.22-50 J TF U1M VX-F20DV1
O DEFLECT ON C 0605 87-A11-336-090 1A CAP,M/P 0.01-1.6K H ECWH(VB) U1M VX-F20DV1
O DEFLECT ON C 0607 87-A12-050-090 1B CAP,M/P 0.013-800 H ECWH(VB) U1M VX-F20DV1
O DEFLECT ON C 0608 87-A10-859-010 0E CAP,CER 390P-2K K R LONG U1M VX-F20DV1
O DEFLECT ON C 0609 87-A11-278-090 1A CAP,M/P 0.47-250 J ECWF(SR) U1M VX-F20DV1
O DEFLECT ON C 0610 87-A10-867-090 1A CAP,CER 2200P-2K K R U1M VX-F20DV1
O DEFLECT ON C 0611 87-010-963-080 0E CAP,E 2.2-160 M 11L SME U1M VX-F20DV1
! O DEFLECT ON C 0612 87-010-976-080 0E CAP,CER 1000P-500 K B DD10 U1M VX-F20DV1
O DEFLECT ON C 0613 87-016-373-080 1A CAP,E 10-250 M SME U1M VX-F20DV1
! O DEFLECT ON C 0614 87-010-976-080 0E CAP,CER 1000P-500 K B DD10 U1M VX-F20DV1
O DEFLECT ON C 0615 87-A10-843-080 0E CAP,CER 680P-1K K R U1M VX-F20DV1
O DEFLECT ON C 0616 87-A10-843-080 0E CAP,CER 680P-1K K R U1M VX-F20DV1
O DEFLECT ON C 0617 87-A12-082-090 1A CAP,E 1000-35 SMG U1M VX-F20DV1
O DEFLECT ON C 0618 87-A10-301-080 0E CAP,M 0.033-50 J U1M VX-F20DV1
O DEFLECT ON C 0619 87-A11-987-080 0E CAP,CER 6800P-250 K R HR U1M VX-F20DV1
O DEFLECT ON C 0620 87-010-395-080 1A CAP,E 330-35 M SME U1M VX-F20DV1
O DEFLECT ON C 0621 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 U1M VX-F20DV1
O DEFLECT ON C 0622 87-A11-124-080 0E CAP,TC U 2200P-50 K B U1M VX-F20DV1
O DEFLECT ON C 0623 87-A12-171-080 0E CAP,E 4.7-50 K SH U1M VX-F20DV1
! O DEFLECT ON C 0624 87-010-976-080 0E CAP,CER 1000P-500 K B DD10 U1M VX-F20DV1
O DEFLECT ON C 0626 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O DEFLECT ON C 0627 87-A11-984-080 0E CAP,CER 270P-500 K B DD10 U1M VX-F20DV1
O DEFLECT ON C 0629 87-A10-469-080 0E CAP,CER 2200P-500 K B DD10 U1M VX-F20DV1
O DEFLECT ON C 0630 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O DEFLECT ON C 0631 87-010-263-080 0E CAP,E 100-10 M 11L SME U1M VX-F20DV1
O DEFLECT ON C 0655 87-A11-354-090 1B CAP,E 100-160 M SMG U1M VX-F20DV1
O DEFLECT ON CN 0601 87-099-762-010 1A CONN,5P V TBL-P BOSS U1M VX-F20DV1
O DEFLECT ON CNA0602 8Z-JE7-661-110 1A CONN ASSY,5P V WHT TV-NK U1M VX-F20DV1
O DEFLECT ON CNA0603 8A-JD1-658-010 0E CONN ASSY,1P TV-FBT TO PS-SW U1M VX-F20DV1
S DEFLECT ON D 0501 87-A40-318-080 1A ZENER,RM26 V1 U1M VX-F20DV1
S DEFLECT ON D 0502 87-070-092-080 0E D ODE,S5566B U1M VX-F20DV1
S DEFLECT ON D 0601 87-A40-735-090 1A D ODE,ERC06-15 U1M VX-F20DV1
S DEFLECT ON D 0602 87-A40-286-080 0E D ODE,RGP10JE-5025 U1M VX-F20DV1
S DEFLECT ON D 0603 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S DEFLECT ON D 0604 87-A40-286-080 0E D ODE,RGP10JE-5025 U1M VX-F20DV1
S DEFLECT ON D 0605 87-A40-001-080 0E ZENER,MTZJ12C U1M VX-F20DV1
S DEFLECT ON D 0609 87-017-593-090 1A D ODE,RGP15J U1M VX-F20DV1
S DEFLECT ON D 0611 87-A40-286-080 0E D ODE,RGP10JE-5025 U1M VX-F20DV1
S DEFLECT ON D 0613 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S DEFLECT ON D 0614 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S DEFLECT ON D 0615 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
O DEFLECT ON FB 0601 87-003-223-080 0E F-BEAD, BL02RN2 U1M VX-F20DV1

PARTS LIST
-7-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
O DEFLECT ON FR 0607 87-A00-652-090 0E RES,FUSE 0.33-1W J RF 1SL12.5 U1M VX-F20DV1
O DEFLECT ON FR 0608 87-A00-628-090 1A RES,FUSE 0.68-1W J RF 1SL12.5 U1M VX-F20DV1
O DEFLECT ON FR 0610 87-A00-628-090 1A RES,FUSE 0.68-1W J RF 1SL12.5 U1M VX-F20DV1
X DEFLECT ON HT 0501 8Z-JE7-211-010 0E HT-S NK,V-OUT U1M VX-F20DV1
X DEFLECT ON HT 0602 8Z-JE7-213-010 1A HT-S NK,ASSY H U1M VX-F20DV1
X DEFLECT ON HT 0603 8Z-JE7-215-010 0E HT-S NK,P N U1M VX-F20DV1
S DEFLECT ON C 0501 87-070-237-010 1C C,LA7832 U1M VX-F20DV1
S DEFLECT ON C 0601 87-070-417-010 1A C,NJM4558DD U1M VX-F20DV1
O DEFLECT ON L 0603 87-005-757-010 1C CO L,3.3MH K U1M VX-F20DV1
O DEFLECT ON L 0604 87-A50-616-080 1B CO L,2.2MH J LHL10 U1M VX-F20DV1
O DEFLECT ON L 0605 8Z-JE7-608-010 1B CO L,HLC ZJE-7 U1M VX-F20DV1
! S DEFLECT ON PR 0601 87-A90-429-080 1A FUSE,1.25A 125V A 251 U1M VX-F20DV1
S DEFLECT ON Q 0601 89-324-820-080 0E TR,2SC2482 U1M VX-F20DV1
S DEFLECT ON Q 0602 87-A30-364-010 1D TR,2SD2578-CA U1M VX-F20DV1
S DEFLECT ON Q 0603 87-A30-363-010 1B TR,2SD2531 U1M VX-F20DV1
S DEFLECT ON Q 0604 87-A30-065-080 0E TR,2SC2785FE U1M VX-F20DV1
S DEFLECT ON Q 0605 89-110-154-080 0E TR,2SA1015Y U1M VX-F20DV1
X DEFLECT ON R 0501 88-121-183-080 0E RES,18K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0502 88-140-222-080 0E RES,2.2K-1/2W J U1M VX-F20DV1
X DEFLECT ON R 0503 88-121-393-080 0E RES,39K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0505 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
O DEFLECT ON R 0506 87-A00-197-090 0E RES,M/F 1.2-1W J RSF(S) U1M VX-F20DV1
O DEFLECT ON R 0508 87-A00-541-090 0E RES,M/F 390-1W J RSF(S) U1M VX-F20DV1
X DEFLECT ON R 0509 88-121-473-080 0E RES,47K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0510 88-121-472-080 0E RES,4.7K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0512 88-121-332-080 0E RES,3.3K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0602 88-121-472-080 0E RES,4.7K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0603 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
O DEFLECT ON R 0604 87-A00-565-090 1D RES,M/F 1.2K-7W J RSU7 U1M VX-F20DV1
X DEFLECT ON R 0605 88-121-473-080 0E RES,47K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0606 88-121-183-080 0E RES,18K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0607 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0608 88-121-273-080 0E RES,27K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0609 88-121-394-080 0E RES,390K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0610 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0611 88-130-103-080 0E RES,10K-1/4W J U1M VX-F20DV1
O DEFLECT ON R 0612 87-A00-629-090 0E RES,M/F 5.6-1W J RSF(S) U1M VX-F20DV1
X DEFLECT ON R 0613 88-140-821-080 0E RES,820-1/2W J U1M VX-F20DV1
X DEFLECT ON R 0614 88-121-393-080 0E RES,39K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0615 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0616 88-130-182-080 0E RES,1.8K-1/4W J U1M VX-F20DV1
X DEFLECT ON R 0617 88-130-332-080 0E RES,3.3K-1/4W J U1M VX-F20DV1
X DEFLECT ON R 0618 88-130-123-080 0E RES,12K-1/4W J U1M VX-F20DV1
X DEFLECT ON R 0619 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0620 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0621 88-121-273-080 0E RES,27K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0622 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0623 88-130-683-080 0E RES,68K-1/4W J U1M VX-F20DV1
X DEFLECT ON R 0624 88-140-332-080 0E RES,3.3K-1/2W J U1M VX-F20DV1
X DEFLECT ON R 0625 88-140-562-080 0E RES,5.6K-1/2W J U1M VX-F20DV1
O DEFLECT ON R 0626 87-A00-676-090 1A RES,M/F 100-7W J RSV7 U1M VX-F20DV1
X DEFLECT ON R 0627 88-140-104-080 0E RES,100K-1/2W J U1M VX-F20DV1
X DEFLECT ON R 0629 88-140-332-080 0E RES,3.3K-1/2W J U1M VX-F20DV1
X DEFLECT ON R 0632 88-121-153-080 0E RES,15K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0633 88-121-153-080 0E RES,15K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0634 88-121-153-080 0E RES,15K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0636 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0637 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X DEFLECT ON R 0638 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
! O DEFLECT ON SFR0501 87-024-430-080 0E SFR,2.2K H RH063MC U1M VX-F20DV1
O DEFLECT ON SFR0601 87-024-434-080 0E SFR,22K H RH063MC U1M VX-F20DV1
O DEFLECT ON SFR0602 87-024-429-080 0E SFR,1K H RH063MC U1M VX-F20DV1
O DEFLECT ON SFR0603 87-A91-856-080 -- SFR,K 22K H EVM EAS U1M VX-F20DV1
! O DEFLECT ON T 0601 8Z-JE7-606-010 2B FBT,D NX-4013 ZJE-7 U1M VX-F20DV1
! O DEFLECT ON T 0602 85-JT2-653-010 1C PT,HDT-TV141-2 U1M VX-F20DV1
X DVD UN T M8-AZG-D9R-030 -- AZG-D ZDADM U1M VX-F20DV1
O FR-FL C 0712 87-010-560-040 0E CAP,E 10-50 M 5L MA U1M VX-F20DV1
O FR-FL C 0713 87-010-560-040 0E CAP,E 10-50 M 5L MA U1M VX-F20DV1
O FR-FL C 0715 87-010-550-040 0E CAP,E 100-6.3 M 5L SRE U1M VX-F20DV1
O FR-FL C 0716 87-010-831-080 0E C-CAP,U 0.1-16 Z F U1M VX-F20DV1

PARTS LIST
-8-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
O FR-FL CN 0701 87-099-556-010 0E CONN,10P H TUC-P10X-B1 U1M VX-F20DV1
! O FR-FL CN 0702 87-099-557-010 0E CONN,11P H TUC-P11X-B1 U1M VX-F20DV1
O FR-FL CN 0703 87-099-563-010 1A CONN,20P TUC-P20X-B1 U1M VX-F20DV1
O FR-FL D 0701 87-002-738-080 0E LED,SEL2210R-TP6 RED U1M VX-F20DV1
O FR-FL FL 0701 88-NF9-630-010 2A FL,10-BT-207GK U1M VX-F20DV1
O FR-FL HL 0701 8A-JD1-205-010 -- HLDR,FL U1M VX-F20DV1
S FR-FL C 0701 87-070-083-010 1C C,GP1U281X U1M VX-F20DV1
O FR-FL L 0701 87-003-147-080 0E CO L,22UH J LAL02 U1M VX-F20DV1
X FR-FL R 0703 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X FR-FL R 0704 88-121-152-080 0E RES,1.5K-1/8W J U1M VX-F20DV1
X FR-FL R 0705 88-121-182-080 0E RES,1.8K-1/8W J U1M VX-F20DV1
X FR-FL R 0706 88-121-272-080 0E RES,2.7K-1/8W J U1M VX-F20DV1
X FR-FL R 0713 88-108-102-080 0E C-RES,U 1K-1/16W J U1M VX-F20DV1
X FR-FL R 0714 88-108-152-080 0E C-RES,U 1.5K-1/16W J U1M VX-F20DV1
X FR-FL R 0715 88-108-182-080 0E C-RES,U 1.8K-1/16W J U1M VX-F20DV1
X FR-FL R 0716 88-108-272-080 0E C-RES,U 2.7K-1/16W J U1M VX-F20DV1
X FR-FL R 0717 88-108-332-080 0E C-RES,U 3.3K-1/16W J U1M VX-F20DV1
X FR-FL R 0718 88-108-472-080 0E C-RES,U 4.7K-1/16W J U1M VX-F20DV1
X FR-FL R 0722 88-118-333-080 0E C-RES,S 33K-1/10W J U1M VX-F20DV1
X FR-FL R 0723 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0724 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0725 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0726 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0727 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0728 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0729 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0730 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0731 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0732 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0733 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0734 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0735 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0736 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0737 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0738 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0739 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0740 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0741 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0742 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0743 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0745 88-121-101-080 0E RES,100-1/8W J U1M VX-F20DV1
X FR-FL R 0746 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0747 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0748 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0749 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0750 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0751 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0752 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0753 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X FR-FL R 0754 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
O FR-FL S 0701 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0702 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0703 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0704 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0705 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0711 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0712 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0713 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0714 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0715 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0716 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-FL S 0717 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-JACK C 0068 87-010-184-080 0E C-CAP,S 3300P-50 K B C2012 U1M VX-F20DV1
O FR-JACK C 0070 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
X FR-JACK CLP0001 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X FR-JACK CLP0002 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X FR-JACK CLP0003 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
O FR-JACK CN 0008 87-009-257-010 0E CONN,3P V 52147 U1M VX-F20DV1
O FR-JACK CN 0009 87-A61-126-080 0E MALE, 1P TP42097 U1M VX-F20DV1
O FR-JACK CN 0013 87-A61-126-080 0E MALE, 1P TP42097 U1M VX-F20DV1

PARTS LIST
-9-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
O FR-JACK CNA0001 8A-JD1-662-010 1A CONN ASSY,7P V FR-JACK TO TV U1M VX-F20DV1
O FR-JACK CNA0002 8A-JD1-676-010 -- CONN ASSY,8P V FR-J TO JO NT U1M VX-F20DV1
O FR-JACK J 0001 87-A61-296-010 1C JACK,P N 3P +S ALL GOLD YKC22- U1M VX-F20DV1
O FR-JACK J 0003 87-A60-420-010 1A JACK,3.5 ST (MSC) U1M VX-F20DV1
O FR-JACK R 0070 87-A00-667-090 0E RES,M/F 680-2W J RSF(S) U1M VX-F20DV1
O FR-JACK R 0071 87-A00-667-090 0E RES,M/F 680-2W J RSF(S) U1M VX-F20DV1
X FR-JACK R 0072 88-108-102-080 0E C-RES,U 1K-1/16W J U1M VX-F20DV1
X FR-JACK R 0073 88-108-823-080 0E C-RES,U 82K-1/16W J U1M VX-F20DV1
X FR-JACK R 0074 88-108-102-080 0E C-RES,U 1K-1/16W J U1M VX-F20DV1
X FR-JACK R 0075 88-108-823-080 0E C-RES,U 82K-1/16W J U1M VX-F20DV1
X FR-JACK R 0076 88-108-750-080 0E C-RES,U 75-1/16W J U1M VX-F20DV1
X FR-JACK R 0077 88-108-104-080 0E C-RES,U 100K-1/16W J U1M VX-F20DV1
X FR-JACK R 0078 88-108-750-080 0E C-RES,U 75-1/16W J U1M VX-F20DV1
X FR-JACK R 0079 88-108-750-080 0E C-RES,U 75-1/16W J U1M VX-F20DV1
X FR-JACK SH 0001 8A-JD1-221-010 -- PLATE,FR PWB U1M VX-F20DV1
! O FR-KEY CN 0801 87-009-310-010 0E CONN,4P V 51048 U1M VX-F20DV1
S FR-KEY D 0801 87-001-161-080 0E LED,SEL2410E GRN U1M VX-F20DV1
X FR-KEY R 0801 88-121-331-080 0E RES,330-1/8W J U1M VX-F20DV1
X FR-KEY R 0803 88-108-102-080 0E C-RES,U 1K-1/16W J U1M VX-F20DV1
X FR-KEY R 0804 88-108-152-080 0E C-RES,U 1.5K-1/16W J U1M VX-F20DV1
X FR-KEY R 0805 88-108-182-080 0E C-RES,U 1.8K-1/16W J U1M VX-F20DV1
X FR-KEY R 0806 88-108-272-080 0E C-RES,U 2.7K-1/16W J U1M VX-F20DV1
X FR-KEY R 0807 88-108-332-080 0E C-RES,U 3.3K-1/16W J U1M VX-F20DV1
X FR-KEY R 0808 88-121-472-080 0E RES,4.7K-1/8W J U1M VX-F20DV1
X FR-KEY R 0809 88-108-822-080 0E C-RES,U 8.2K-1/16W J U1M VX-F20DV1
O FR-KEY S 0801 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-KEY S 0802 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-KEY S 0803 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-KEY S 0804 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-KEY S 0805 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-KEY S 0806 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-KEY S 0807 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-KEY S 0808 87-A90-164-080 0E SW,TACT SKQNAB(N) U1M VX-F20DV1
O FR-KEY W 0801 8A-JD1-640-010 0E F-CABLE,4P 2.0 190MM FR-KEY U1M VX-F20DV1
O JO NT C 0102 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O JO NT C 0103 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O JO NT C 0104 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O JO NT C 0105 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0106 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O JO NT C 0107 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O JO NT C 0108 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O JO NT C 0109 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O JO NT C 0110 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0111 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0112 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0113 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O JO NT C 0114 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O JO NT C 0115 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0119 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0120 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0126 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0127 87-010-382-080 0E CAP,E 22-25 M 11L SME U1M VX-F20DV1
O JO NT C 0128 87-010-382-080 0E CAP,E 22-25 M 11L SME U1M VX-F20DV1
O JO NT C 0129 87-010-382-080 0E CAP,E 22-25 M 11L SME U1M VX-F20DV1
O JO NT C 0131 87-010-382-080 0E CAP,E 22-25 M 11L SME U1M VX-F20DV1
O JO NT C 0132 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 U1M VX-F20DV1
O JO NT C 0133 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 U1M VX-F20DV1
O JO NT C 0135 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0136 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0137 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O JO NT C 0138 87-012-155-010 0E C-CAP,S 180P-50 J CH U1M VX-F20DV1
O JO NT C 0139 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O JO NT C 0140 87-012-155-010 0E C-CAP,S 180P-50 J CH U1M VX-F20DV1
O JO NT C 0141 87-012-158-080 0E C-CAP,S 390P-50 J CH GRM U1M VX-F20DV1
O JO NT C 0142 87-012-158-080 0E C-CAP,S 390P-50 J CH GRM U1M VX-F20DV1
O JO NT C 0143 87-010-831-080 0E C-CAP,U 0.1-16 Z F U1M VX-F20DV1
O JO NT C 0144 87-010-831-080 0E C-CAP,U 0.1-16 Z F U1M VX-F20DV1
O JO NT C 0145 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O JO NT C 0146 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O JO NT C 0147 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1

PARTS LIST
-10-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
O JO NT C 0148 87-010-235-080 0E CAP,E 470-16 M SME U1M VX-F20DV1
O JO NT CN 0101 87-A61-272-010 0E CONN,11P V BLK FMN-BTRK U1M VX-F20DV1
O JO NT CN 0102 87-A61-273-010 0E CONN,5P V BLK FMN-BTRK U1M VX-F20DV1
O JO NT CN 0103 87-A61-274-010 0E CONN,13P V BLK FMN-BTRK U1M VX-F20DV1
O JO NT CN 0105 87-A60-629-010 0E CONN,12P V 2MM JMT U1M VX-F20DV1
O JO NT CN 0106 87-A60-632-010 0E CONN,15P V 2MM JMT U1M VX-F20DV1
O JO NT CN 0107 87-A60-631-010 0E CONN,14P V 2MM JMT U1M VX-F20DV1
O JO NT CN 0108 87-A60-625-010 0E CONN,8P V 2MM JMT U1M VX-F20DV1
O JO NT CN 0110 87-A60-625-010 0E CONN,8P V 2MM JMT U1M VX-F20DV1
O JO NT CN 0117 87-A61-126-080 0E MALE, 1P TP42097 U1M VX-F20DV1
O JO NT FB 0101 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0102 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0104 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0105 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0106 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0107 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0108 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0109 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0110 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0111 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0112 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
O JO NT FB 0113 87-003-223-080 0E F-BEAD, BL02RN2 U1M VX-F20DV1
X JO NT FB 0114 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
O JO NT FB 0115 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
X JO NT FB 0116 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
O JO NT FB 0117 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
X JO NT FB 0118 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X JO NT FB 0119 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
O JO NT FB 0120 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
X JO NT FB 0121 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
O JO NT FB 0122 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
X JO NT FB 0123 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
O JO NT FB 0124 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0125 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0126 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0127 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0128 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
O JO NT FB 0129 87-003-223-080 0E F-BEAD, BL02RN2 U1M VX-F20DV1
O JO NT FB 0130 87-003-223-080 0E F-BEAD, BL02RN2 U1M VX-F20DV1
O JO NT FB 0131 87-003-223-080 0E F-BEAD, BL02RN2 U1M VX-F20DV1
O JO NT FB 0132 87-003-223-080 0E F-BEAD, BL02RN2 U1M VX-F20DV1
X JO NT FB 0133 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
O JO NT FB 0134 87-A50-208-080 0E C-CO L,BLM11A601SPT U1M VX-F20DV1
X JO NT FB 0135 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT FB 0136 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT FB 0137 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT FB 0138 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT FB 0139 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT FB 0140 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT FB 0141 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT FB 0142 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
S JO NT C 0101 87-A21-585-010 -- C,MM1232XD U1M VX-F20DV1
S JO NT C 0102 87-A21-585-010 -- C,MM1232XD U1M VX-F20DV1
S JO NT C 0103 87-017-889-010 1A C,NJM4558LD U1M VX-F20DV1
O JO NT L 0101 87-005-440-080 0E CO L,47UH K FLR50 U1M VX-F20DV1
O JO NT L 0102 87-005-440-080 0E CO L,47UH K FLR50 U1M VX-F20DV1
O JO NT L 0103 87-005-444-080 0E CO L,100UH K FLR50 U1M VX-F20DV1
X JO NT R 0101 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0102 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0103 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0104 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0105 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0106 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0114 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0117 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0118 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0120 88-108-105-080 0E C-RES,U 1M-1/16W J U1M VX-F20DV1
X JO NT R 0121 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0125 88-108-105-080 0E C-RES,U 1M-1/16W J U1M VX-F20DV1
X JO NT R 0129 88-108-105-080 0E C-RES,U 1M-1/16W J U1M VX-F20DV1

PARTS LIST
-11-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
X JO NT R 0131 88-108-105-080 0E C-RES,U 1M-1/16W J U1M VX-F20DV1
X JO NT R 0132 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0134 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0135 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0136 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0137 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0138 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0139 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0140 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0141 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0142 88-108-101-080 0E C-RES,U 100-1/16W J U1M VX-F20DV1
X JO NT R 0143 88-108-101-080 0E C-RES,U 100-1/16W J U1M VX-F20DV1
X JO NT R 0144 88-108-472-080 0E C-RES,U 4.7K-1/16W J U1M VX-F20DV1
X JO NT R 0145 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0146 88-108-103-080 0E C-RES,U 10K-1/16W J U1M VX-F20DV1
X JO NT R 0147 88-108-472-080 0E C-RES,U 4.7K-1/16W J U1M VX-F20DV1
X JO NT R 0148 88-108-103-080 0E C-RES,U 10K-1/16W J U1M VX-F20DV1
X JO NT R 0149 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X JO NT R 0150 88-108-222-080 0E C-RES,U 2.2K-1/16W J U1M VX-F20DV1
X JO NT R 0151 88-108-222-080 0E C-RES,U 2.2K-1/16W J U1M VX-F20DV1
X JO NT R 0152 88-108-472-080 0E C-RES,U 4.7K-1/16W J U1M VX-F20DV1
O JO NT W 0101 8A-JD1-666-010 1A FF-CABLE,11P 1.0 380MM 30V U1M VX-F20DV1
O JO NT W 0102 8A-JD1-664-010 0E FF-CABLE,5P 1.0 430MM 30V U1M VX-F20DV1
O JO NT W 0103 8A-JD1-667-010 1A FF-CABLE,13P 1.0 370MM 30V U1M VX-F20DV1
O JO NT W 0105 8A-JD1-661-110 1B CONN ASSY,12P V JO NT TO UN T U1M VX-F20DV1
X LBL,POP 87-B40-034-010 1 LBL,USA 1-800 U1M VX-F20DV1
X LBL,POP 8A-JD1-970-010 -- LBL,POP U U1M VX-F20DV1
O NK 87-067-641-010 0E UTT2+3-8 W/O SLOT BLK U1M VX-F20DV1
O NK C 0901 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O NK C 0902 87-010-968-080 1A CAP,CER 680P-2K K B U1M VX-F20DV1
O NK C 0903 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O NK C 0906 87-010-400-080 0E CAP,E 0.47-50 M 11L SME U1M VX-F20DV1
O NK C 0907 87-010-235-080 0E CAP,E 470-16 M SME U1M VX-F20DV1
O NK C 0908 87-018-129-080 0E CAP,TC U 680P-50 K B UP050 U1M VX-F20DV1
O NK C 0909 87-018-129-080 0E CAP,TC U 680P-50 K B UP050 U1M VX-F20DV1
O NK C 0910 87-018-129-080 0E CAP,TC U 680P-50 K B UP050 U1M VX-F20DV1
O NK C 0911 87-018-127-080 0E CAP,TC U 470P-50 K B UP050 U1M VX-F20DV1
O NK C 0912 87-018-127-080 0E CAP,TC U 470P-50 K B UP050 U1M VX-F20DV1
O NK C 0913 87-018-127-080 0E CAP,TC U 470P-50 K B UP050 U1M VX-F20DV1
O NK C 0914 87-A10-052-080 0E CAP,E 2.2-250 U1M VX-F20DV1
O NK C 0915 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O NK C 0916 87-018-134-080 0E CAP,TC U 0.01-16 N Y UP050 U1M VX-F20DV1
O NK C 0917 87-010-970-090 1A CAP,CER 4700P-2K K B DE U1M VX-F20DV1
O NK C 0951 87-010-381-080 0E CAP,E 330-16 M SME U1M VX-F20DV1
O NK C 0954 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O NK C 0955 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O NK C 0956 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O NK C 0959 87-A10-050-010 0E CAP,CER 4700P-500 K U1M VX-F20DV1
O NK C 0960 87-010-221-080 0E CAP,E 470-10 M SME U1M VX-F20DV1
O NK C 0961 87-A12-168-080 1A CAP,E 33-160 M SMG U1M VX-F20DV1
O NK C 0962 87-A12-010-080 0E CAP,M/P 0.047-250 J ECQE2 U1M VX-F20DV1
O NK C 0963 87-A10-283-080 0E CAP,M 1000P-50 J U1M VX-F20DV1
O NK C 0964 87-A10-283-080 0E CAP,M 1000P-50 J U1M VX-F20DV1
O NK C 0965 87-010-963-080 0E CAP,E 2.2-160 M 11L SME U1M VX-F20DV1
O NK C 0966 87-A12-014-080 0E CAP,M/P 0.1-250 J ECQE2 U1M VX-F20DV1
O NK C 0967 87-A10-303-080 0E CAP,M 0.047-50 J U1M VX-F20DV1
O NK C 0968 87-010-221-080 0E CAP,E 470-10 M SME U1M VX-F20DV1
! O NK CN 0901 87-009-034-010 0E CONN,6P V WHT PH U1M VX-F20DV1
! O NK CN 0902 87-009-195-010 0E CONN,5P V WHT EH U1M VX-F20DV1
O NK CN 0903 87-A61-126-080 0E MALE, 1P TP42097 U1M VX-F20DV1
! O NK CN 0904 87-A61-060-080 0E CONN,1P V RED TP00706 U1M VX-F20DV1
! O NK CN 0951 87-009-030-010 0E CONN,2P V WHT PH U1M VX-F20DV1
! O NK CN 0952 87-099-043-010 0E CONN,2P V WHT EH U1M VX-F20DV1
S NK D 0901 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S NK D 0902 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S NK D 0903 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S NK D 0904 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S NK D 0905 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S NK D 0906 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S NK D 0907 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1

PARTS LIST
-12-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
S NK D 0908 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S NK D 0909 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S NK D 0951 87-017-650-080 0E D ODE,1SS119 U1M VX-F20DV1
S NK D 0952 87-017-650-080 0E D ODE,1SS119 U1M VX-F20DV1
S NK D 0953 87-017-650-080 0E D ODE,1SS119 U1M VX-F20DV1
S NK D 0954 87-017-650-080 0E D ODE,1SS119 U1M VX-F20DV1
S NK D 0955 87-017-650-080 0E D ODE,1SS119 U1M VX-F20DV1
S NK D 0956 87-A40-503-080 0E ZENER,MTZJ39B U1M VX-F20DV1
S NK D 0957 87-A40-503-080 0E ZENER,MTZJ39B U1M VX-F20DV1
X NK HT 0951 8Z-JE5-211-010 0E HT-S NK,NECK 2 U1M VX-F20DV1
X NK HT 0952 8Z-JE5-211-010 0E HT-S NK,NECK 2 U1M VX-F20DV1
O NK L 0901 87-005-614-080 0E CO L,100UH J LAV35 U1M VX-F20DV1
O NK L 0902 87-005-614-080 0E CO L,100UH J LAV35 U1M VX-F20DV1
O NK L 0903 87-005-614-080 0E CO L,100UH J LAV35 U1M VX-F20DV1
O NK L 0951 87-005-482-080 0E CO L,56UH J FLR50 U1M VX-F20DV1
O NK L 0952 87-005-481-080 0E CO L,47UH J FLR50 U1M VX-F20DV1
S NK Q 0901 87-A30-344-010 1B TR,2SC5147D U1M VX-F20DV1
S NK Q 0902 87-A30-344-010 1B TR,2SC5147D U1M VX-F20DV1
S NK Q 0903 87-A30-344-010 1B TR,2SC5147D U1M VX-F20DV1
S NK Q 0904 87-A30-065-080 0E TR,2SC2785FE U1M VX-F20DV1
S NK Q 0905 87-A30-065-080 0E TR,2SC2785FE U1M VX-F20DV1
S NK Q 0906 87-A30-065-080 0E TR,2SC2785FE U1M VX-F20DV1
S NK Q 0907 87-A30-065-080 0E TR,2SC2785FE U1M VX-F20DV1
S NK Q 0908 87-A30-066-080 0E TR,2SA1175FE U1M VX-F20DV1
S NK Q 0951 87-026-462-080 0E TR,2SC1740SRS U1M VX-F20DV1
S NK Q 0952 87-026-463-080 0E TR,2SA933SRS U1M VX-F20DV1
S NK Q 0953 87-026-462-080 0E TR,2SC1740SRS U1M VX-F20DV1
S NK Q 0954 87-026-462-080 0E TR,2SC1740SRS U1M VX-F20DV1
S NK Q 0955 89-407-742-080 1A TR,2SD774 U1M VX-F20DV1
S NK Q 0956 89-118-370-010 1B TR,2SA1837 U1M VX-F20DV1
S NK Q 0957 89-347-930-010 1B TR,2SC4793 U1M VX-F20DV1
O NK R 0901 87-A00-242-090 0E RES,M/F 8.2K-3W J RSF(S) U1M VX-F20DV1
O NK R 0902 87-A00-242-090 0E RES,M/F 8.2K-3W J RSF(S) U1M VX-F20DV1
O NK R 0903 87-A00-242-090 0E RES,M/F 8.2K-3W J RSF(S) U1M VX-F20DV1
X NK R 0904 88-144-332-080 0E RES,SD 3.3K-1/2W K U1M VX-F20DV1
X NK R 0905 88-144-332-080 0E RES,SD 3.3K-1/2W K U1M VX-F20DV1
X NK R 0906 88-144-332-080 0E RES,SD 3.3K-1/2W K U1M VX-F20DV1
X NK R 0907 88-121-221-080 0E RES,220-1/8W J U1M VX-F20DV1
X NK R 0908 88-121-221-080 0E RES,220-1/8W J U1M VX-F20DV1
X NK R 0909 88-121-221-080 0E RES,220-1/8W J U1M VX-F20DV1
X NK R 0910 88-121-471-080 0E RES,470-1/8W J U1M VX-F20DV1
X NK R 0911 88-121-471-080 0E RES,470-1/8W J U1M VX-F20DV1
X NK R 0912 88-121-471-080 0E RES,470-1/8W J U1M VX-F20DV1
X NK R 0913 88-121-561-080 0E RES,560-1/8W J U1M VX-F20DV1
X NK R 0914 88-121-561-080 0E RES,560-1/8W J U1M VX-F20DV1
X NK R 0915 88-121-561-080 0E RES,560-1/8W J U1M VX-F20DV1
X NK R 0916 88-121-680-080 0E RES,68-1/8W J U1M VX-F20DV1
X NK R 0917 88-121-680-080 0E RES,68-1/8W J U1M VX-F20DV1
X NK R 0918 88-121-680-080 0E RES,68-1/8W J U1M VX-F20DV1
X NK R 0919 88-121-820-080 0E RES,82-1/8W J U1M VX-F20DV1
X NK R 0920 88-121-820-080 0E RES,82-1/8W J U1M VX-F20DV1
X NK R 0921 88-121-820-080 0E RES,82-1/8W J U1M VX-F20DV1
X NK R 0922 88-121-101-080 0E RES,100-1/8W J U1M VX-F20DV1
X NK R 0924 88-121-270-080 0E RES,27-1/8W J U1M VX-F20DV1
X NK R 0925 88-121-560-080 0E RES,56-1/8W J U1M VX-F20DV1
X NK R 0926 88-121-560-080 0E RES,56-1/8W J U1M VX-F20DV1
X NK R 0927 88-121-560-080 0E RES,56-1/8W J U1M VX-F20DV1
X NK R 0928 88-121-151-080 0E RES,150-1/8W J U1M VX-F20DV1
X NK R 0929 88-121-151-080 0E RES,150-1/8W J U1M VX-F20DV1
X NK R 0930 88-121-151-080 0E RES,150-1/8W J U1M VX-F20DV1
X NK R 0931 88-121-821-080 0E RES,820-1/8W J U1M VX-F20DV1
X NK R 0932 88-121-821-080 0E RES,820-1/8W J U1M VX-F20DV1
X NK R 0934 88-121-821-080 0E RES,820-1/8W J U1M VX-F20DV1
X NK R 0935 88-140-224-080 0E RES,220K-1/2W J U1M VX-F20DV1
X NK R 0936 88-121-821-080 0E RES,820-1/8W J U1M VX-F20DV1
X NK R 0937 88-121-271-080 0E RES,270-1/8W J U1M VX-F20DV1
X NK R 0938 88-121-152-080 0E RES,1.5K-1/8W J U1M VX-F20DV1
X NK R 0939 88-121-152-080 0E RES,1.5K-1/8W J U1M VX-F20DV1
X NK R 0951 88-130-561-080 0E RES,560-1/4W J U1M VX-F20DV1
X NK R 0952 88-121-101-080 0E RES,100-1/8W J U1M VX-F20DV1

PARTS LIST
-13-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
X NK R 0953 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X NK R 0954 88-121-101-080 0E RES,100-1/8W J U1M VX-F20DV1
X NK R 0955 88-121-122-080 0E RES,1.2K-1/8W J U1M VX-F20DV1
X NK R 0956 88-121-182-080 0E RES,1.8K-1/8W J U1M VX-F20DV1
X NK R 0957 88-121-391-080 0E RES,390-1/8W J U1M VX-F20DV1
X NK R 0958 88-121-333-080 0E RES,33K-1/8W J U1M VX-F20DV1
X NK R 0959 88-121-393-080 0E RES,39K-1/8W J U1M VX-F20DV1
X NK R 0960 88-121-682-080 0E RES,6.8K-1/8W J U1M VX-F20DV1
X NK R 0961 88-121-271-080 0E RES,270-1/8W J U1M VX-F20DV1
X NK R 0962 88-121-152-080 0E RES,1.5K-1/8W J U1M VX-F20DV1
X NK R 0963 88-121-104-080 0E RES,100K-1/8W J U1M VX-F20DV1
X NK R 0964 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X NK R 0965 88-121-821-080 0E RES,820-1/8W J U1M VX-F20DV1
X NK R 0966 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X NK R 0967 88-121-561-080 0E RES,560-1/8W J U1M VX-F20DV1
O NK R 0968 87-022-382-090 0E RES,M/F 120-2W J U1M VX-F20DV1
O NK R 0969 87-A00-638-080 1A RES,M/F 47-1/2W J SPR U1M VX-F20DV1
O NK R 0970 87-A00-634-080 1A RES,M/F 2.7-1/4W J SPR U1M VX-F20DV1
O NK R 0971 87-A00-636-080 1A RES,M/F 560-1/4W J SPR U1M VX-F20DV1
X NK R 0972 88-121-183-080 0E RES,18K-1/8W J U1M VX-F20DV1
O NK R 0973 87-A00-637-080 1A RES,M/F 1K-1/4W J SPR U1M VX-F20DV1
O NK R 0974 87-022-556-090 1B RES,M/F 180-3W J U1M VX-F20DV1
X NK R 0975 88-121-183-080 0E RES,18K-1/8W J U1M VX-F20DV1
O NK R 0976 87-A00-636-080 1A RES,M/F 560-1/4W J SPR U1M VX-F20DV1
O NK R 0977 87-A00-634-080 1A RES,M/F 2.7-1/4W J SPR U1M VX-F20DV1
O NK R 0978 87-A00-635-080 1A RES,M/F 47-1/4W J SPR U1M VX-F20DV1
O NK SO 0901 8A-JE7-670-010 1B SOCKET,CRT 11P HPS1521-013411 U1M VX-F20DV1
O OPT C 0654 87-012-286-080 0E C-CAP,U 0.01-25 K B U1M VX-F20DV1
O OPT C 0655 87-010-382-080 0E CAP,E 22-25 M 11L SME U1M VX-F20DV1
O OPT CN 0650 87-099-416-010 0E CONN,3P H WHT EH U1M VX-F20DV1
X OPT FB 0650 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
! S OPT C 0651 87-017-825-010 1E C,GP1F32T U1M VX-F20DV1
X OPT R 0650 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
X OPT R 0651 88-118-330-080 0E C-RES,S 33-1/10W J U1M VX-F20DV1
X OPT R 0652 88-108-000-080 0E C-JUMPER,U U1M VX-F20DV1
O OPT W 0650 8A-JD1-665-110 0E CONN ASSY,3P V UN T TO OPT U1M VX-F20DV1
! X OTHER 82-JT1-206-010 0E CLOTH,15-50-0.5 U1M VX-F20DV1
X OTHER 82-JT2-213-010 0E CLOTH 15-30-0.5 U1M VX-F20DV1
O OTHER 83-JT1-217-010 0E SPR-E,EARTH U1M VX-F20DV1
X OTHER 86-LB2-203-010 0E CLOTH,15-300-0.5 U1M VX-F20DV1
X OTHER 86-LB7-203-010 -- CLOTH,7-20-0.5 U1M VX-F20DV1
X OTHER 87-038-039-010 0E B NDER,W RE U1M VX-F20DV1
! X OTHER 87-069-033-010 0E CABLE,T E U1M VX-F20DV1
X OTHER 87-069-036-010 0E CABLE,T E 146(N) U1M VX-F20DV1
O OTHER 8A-JD1-201-010 -- KEY,PLAY U1M VX-F20DV1
O OTHER 8A-JD1-202-010 -- FRAME,TV U1M VX-F20DV1
O OTHER 8A-JD1-203-010 -- FRAME,POWER U1M VX-F20DV1
O OTHER 8A-JD1-204-010 -- HLDR,PWB U1M VX-F20DV1
O OTHER 8A-JD1-206-010 -- HLDR,MECH L U1M VX-F20DV1
O OTHER 8A-JD1-207-010 -- HLDR,MECH R U1M VX-F20DV1
O OTHER 8A-JD1-208-010 -- FRAME,MECH FR U1M VX-F20DV1
O OTHER 8A-JD1-209-010 -- FRAME,MECH BK U1M VX-F20DV1
O OTHER 8A-JD1-210-010 -- FRAME,MECH L U1M VX-F20DV1
O OTHER 8A-JD1-211-010 -- FRAME,MECH R U1M VX-F20DV1
O OTHER 8A-JD1-215-010 -- SPR-C,POWER U1M VX-F20DV1
X OTHER 8A-JD1-216-010 -- SHLD-PLATE,TOP U1M VX-F20DV1
X OTHER 8A-JD1-217-010 -- SHLD-PLATE,TOP 2 U1M VX-F20DV1
X OTHER 8A-JD1-218-010 -- SHLD-PLATE,LOW U1M VX-F20DV1
X OTHER 8A-JD1-220-010 -- PLATE,E-FJ U1M VX-F20DV1
X OTHER 8A-JD1-224-010 -- PLATE,W NDOW U1M VX-F20DV1
X OTHER 8A-JD1-225-010 -- PLATE,BT UL U1M VX-F20DV1
X OTHER 8Z-JBE-208-110 0E TAPE,UL NO10 W25 U1M VX-F20DV1
O OTHER 8Z-JBS-205-010 0E W-G,10-20-2 U1M VX-F20DV1
O OTHERS,E 8A-JD1-648-010 1 CONN ASSY,4P SPEAKER U1M VX-F20DV1
! O OTHERS,E 8A-JE5-616-010 1C AC CORD ASSY,USA LK U1M VX-F20DV1
O OTHERS,E 8A-JE7-620-010 0E CONN ASSY,2P VM-NK U1M VX-F20DV1
! O OTHERS,E 8Z-JE7-609-010 1D ANODE-CAP,ZJE-7 U1M VX-F20DV1
! O OTHERS,E 8Z-JE7-610-010 1 HV-CABLE, 2P ZJE-7FOC-SCR U1M VX-F20DV1
O OTHERS,E * 86-LBN-625-010 1H CO L,DGC21 6LB-22 U1M VX-F20DV1
! O OTHERS,E * 87-A90-332-010 0E HLDR,SF-2001 HV CABLE U1M VX-F20DV1

PARTS LIST
-14-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
! O OTHERS,E * 87-A90-332-010 0E HLDR,SF-2001 HV CABLE U1M VX-F20DV1
O OTHERS,E * 8Z-JE7-607-110 1A CONN ASSY,1P CRT-GND U1M VX-F20DV1
X OTHERS,E SH 0601 8Z-JE7-222-010 1A SHLD-PLATE,FBT U1M VX-F20DV1
O OTHERS,E SP 0401 8A-JD1-681-010 -- SPKR,F 4*16 8OHM U1M VX-F20DV1
O OTHERS,E SP 0402 8A-JD1-681-010 -- SPKR,F 4*16 8OHM U1M VX-F20DV1
X PACK NG 87-066-133-010 0E BAG,PV 0.04-75-280 U1M VX-F20DV1
X PACK NG 87-B40-404-010 1 BAG,FOAMED 0.31-1250-950 U1M VX-F20DV1
X PACK NG 8A-JD1-851-010 2M CTN,PR NTED U1M U1M VX-F20DV1
X PACK NG 8A-JD1-852-010 -- CUSH ON,BOTTOM M U1M VX-F20DV1
X PACK NG 8A-JD1-853-010 -- CUSH ON,TOP M U1M VX-F20DV1
X PACK NG 8A-JD1-854-010 -- PAD,TRAY A U1M VX-F20DV1
X PLATE 84-711-909-010 1A LBL DATE CODE U1M VX-F20DV1
X PLATE 87-059-030-110 1 LBL,CAUT ON TV UL U1M VX-F20DV1
X PLATE 87-059-031-010 0E LBL,CAUT ON TV UL U1M VX-F20DV1
X PLATE 87-B40-282-010 0E LBL,BAR-CODE AU 35X8 U1M VX-F20DV1
X PLATE 87-B40-419-010 0E LBL,CAUT ON DVD U1M VX-F20DV1
X PLATE 8A-JD1-016-010 -- LBL,SPEC U1M VX-F20DV1
X PLATE 8A-JE7-009-010 1A LBL,CAUT ON TUBE 21F U1M VX-F20DV1
X PLATE 8A-JE7-011-010 1A LBL,TUBE 21F U1M VX-F20DV1
O POWER 87-067-579-010 0E BVT2+3-8 W/0 SL0T U1M VX-F20DV1
O POWER 87-067-619-010 0E BVTT+3-12 U1M VX-F20DV1
O POWER C 0801 87-010-384-080 0E CAP,E 100-25 M 11L SME U1M VX-F20DV1
O POWER C 0802 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 U1M VX-F20DV1
O POWER C 0804 87-A10-474-090 1A CAP,PP 0.01-1.25K J PHS U1M VX-F20DV1
O POWER C 0805 87-016-515-080 0E CAP,CER 1000P-1K K B DE U1M VX-F20DV1
O POWER C 0806 87-A12-169-090 1H CAP,E 470-200 M 25B SMH U1M VX-F20DV1
O POWER C 0807 87-A10-568-010 1A CAP,PP 1000P-630 J APH U1M VX-F20DV1
O POWER C 0808 87-010-384-080 0E CAP,E 100-25 M 11L SME U1M VX-F20DV1
O POWER C 0809 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 U1M VX-F20DV1
O POWER C 0810 87-018-129-080 0E CAP,TC U 680P-50 K B UP050 U1M VX-F20DV1
O POWER C 0811 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 U1M VX-F20DV1
O POWER C 0813 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 U1M VX-F20DV1
O POWER C 0814 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O POWER C 0816 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O POWER C 0817 87-A10-627-090 1B CAP,E 2200-50 M SMG U1M VX-F20DV1
O POWER C 0818 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 U1M VX-F20DV1
O POWER C 0820 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O POWER C 0821 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O POWER C 0822 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 U1M VX-F20DV1
O POWER C 0824 87-010-237-080 1A CAP,E 1000-16 M SME U1M VX-F20DV1
O POWER C 0829 87-010-384-080 0E CAP,E 100-25 M 11L SME U1M VX-F20DV1
O POWER C 0831 87-010-405-080 0E CAP,E 10-50 M 11L SME U1M VX-F20DV1
O POWER C 0834 87-A10-733-090 1B CAP,E 220-160 M SK U1M VX-F20DV1
O POWER C 0835 87-016-037-060 0E CAP,CER 1000P-2K K B DE U1M VX-F20DV1
O POWER C 0836 87-010-260-080 0E CAP,E 47-25 M 11L SME U1M VX-F20DV1
O POWER C 0838 87-A12-302-090 1A CAP,E 1000-50 M SMG U1M VX-F20DV1
O POWER C 0842 87-012-370-010 1A CAP,CER 3300P-250 M E ECKD U1M VX-F20DV1
O POWER C 0843 87-012-370-010 1A CAP,CER 3300P-250 M E ECKD U1M VX-F20DV1
O POWER C 0844 87-012-370-010 1A CAP,CER 3300P-250 M E ECKD U1M VX-F20DV1
O POWER C 0845 87-012-370-010 1A CAP,CER 3300P-250 M E ECKD U1M VX-F20DV1
O POWER C 0846 87-A10-207-080 0E CAP,TC U 0.01-50 K B UP050 U1M VX-F20DV1
! O POWER CN 0807 82-481-649-010 0E CONN,2P V VT-50P U1M VX-F20DV1
O POWER CNA0801 8A-JD1-668-010 1A CONN ASSY,2P TV TO PS-SW U1M VX-F20DV1
O POWER CNA0803 8A-JD1-669-010 1A CONN ASSY,2P TV TO PS U1M VX-F20DV1
S POWER D 0801 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S POWER D 0802 87-017-654-060 1C D ODE,GBU6JL6131 U1M VX-F20DV1
S POWER D 0803 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S POWER D 0804 87-A40-450-090 0E D ODE,RU 1P U1M VX-F20DV1
S POWER D 0805 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S POWER D 0807 87-A40-286-080 0E D ODE,RGP10JE-5025 U1M VX-F20DV1
S POWER D 0808 87-A40-286-080 0E D ODE,RGP10JE-5025 U1M VX-F20DV1
S POWER D 0809 87-A40-828-080 0E D ODE,AK 04 U1M VX-F20DV1
S POWER D 0815 87-A40-001-080 0E ZENER,MTZJ12C U1M VX-F20DV1
S POWER D 0816 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S POWER D 0817 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S POWER D 0821 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S POWER D 0822 87-A40-911-090 -- D ODE,RN2Z U1M VX-F20DV1
S POWER D 0823 87-A40-734-010 1B D ODE,FML-G12S U1M VX-F20DV1
S POWER D 0825 87-A40-234-080 0E ZENER,MTZJ5.6A U1M VX-F20DV1
S POWER D 0826 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1

PARTS LIST
-15-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
S POWER D 0827 87-A40-354-090 1B D ODE,UF3GL-6251 U1M VX-F20DV1
S POWER D 0830 87-A40-337-080 0E ZENER,MTZJ6.8B U1M VX-F20DV1
S POWER D 0831 87-A40-286-080 0E D ODE,RGP10JE-5025 U1M VX-F20DV1
O POWER FB 0801 87-003-320-080 1A F-BEAD,-9.0 FBR07HA121NB-00 U1M VX-F20DV1
O POWER FB 0802 87-003-320-080 1A F-BEAD,-9.0 FBR07HA121NB-00 U1M VX-F20DV1
O POWER FB 0803 87-003-320-080 1A F-BEAD,-9.0 FBR07HA121NB-00 U1M VX-F20DV1
O POWER FB 0804 87-003-320-080 1A F-BEAD,-9.0 FBR07HA121NB-00 U1M VX-F20DV1
O POWER FB 0805 87-003-320-080 1A F-BEAD,-9.0 FBR07HA121NB-00 U1M VX-F20DV1
O POWER FB 0806 87-003-320-080 1A F-BEAD,-9.0 FBR07HA121NB-00 U1M VX-F20DV1
O POWER FB 0807 87-003-320-080 1A F-BEAD,-9.0 FBR07HA121NB-00 U1M VX-F20DV1
X POWER HT 0801 8Z-JE7-641-010 1C HT-S NK,POWER U1M VX-F20DV1
X POWER HT 0802 8Z-JE7-210-010 0E HT-S NK,BRG U1M VX-F20DV1
S POWER C 0801 87-A21-468-010 1H C,STR-F6626 U1M VX-F20DV1
S POWER C 0802 87-A21-457-010 1C C,SE120N U1M VX-F20DV1
S POWER C 0803 87-001-536-010 1A C,NJM78M05FA U1M VX-F20DV1
S POWER C 0804 87-020-969-010 1B C,NJM78M09FA U1M VX-F20DV1
S POWER C 0805 87-A20-389-010 1A C,NJM7809FA U1M VX-F20DV1
O POWER L 0801 87-A50-170-010 1B CO L,390UH RCH106 U1M VX-F20DV1
O POWER L 0803 87-A50-176-080 1A CO L,33UH-PJ87 U1M VX-F20DV1
! S POWER PR 0801 87-A90-409-080 1A FUSE,1.5A 125V A 251 U1M VX-F20DV1
! S POWER PR 0802 87-A90-210-080 1A FUSE,7A 125V 251 U1M VX-F20DV1
! S POWER PR 0803 87-A90-070-080 1A FUSE,3.5A 125V 251 U1M VX-F20DV1
! O POWER PS 0801 87-A90-717-010 1A P-COUPLER,PC123FY2 U1M VX-F20DV1
! O POWER PT 0801 8A-JD1-654-010 -- PT,U SW AJD-1-TV U1M VX-F20DV1
S POWER Q 0801 89-318-155-080 0E TR,2SC1815GR U1M VX-F20DV1
S POWER Q 0806 87-A30-216-080 0E TR,2SA933AS(R) U1M VX-F20DV1
S POWER Q 0811 89-110-913-080 1A TR,2SA10910 U1M VX-F20DV1
O POWER R 0801 87-A00-665-010 1B RES,CEM 56-2W J BGR2U U1M VX-F20DV1
O POWER R 0802 87-A00-160-090 0E RES,M/F 33-2W J RSF(S) U1M VX-F20DV1
O POWER R 0803 87-A00-356-090 0E RES,M/F 22-2W J RSS2X U1M VX-F20DV1
O POWER R 0804 87-A00-633-090 1A RES,CEM 0.47-10W J RGC U1M VX-F20DV1
O POWER R 0805 87-A00-170-090 0E RES,M/F 82K-3W J RSF(S) U1M VX-F20DV1
O POWER R 0806 87-A00-380-090 1B RES,M/F 39K-3W J RSS H2 U1M VX-F20DV1
X POWER R 0807 88-130-220-080 0E RES,22-1/4W J U1M VX-F20DV1
X POWER R 0808 88-121-152-080 0E RES,1.5K-1/8W J U1M VX-F20DV1
X POWER R 0809 88-121-272-080 0E RES,2.7K-1/8W J U1M VX-F20DV1
X POWER R 0810 88-121-681-080 0E RES,680-1/8W J U1M VX-F20DV1
O POWER R 0811 87-A00-646-090 0E RES,CEM 0.1-5W K RGC5 U1M VX-F20DV1
X POWER R 0812 88-121-562-080 0E RES,5.6K-1/8W J U1M VX-F20DV1
X POWER R 0813 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X POWER R 0814 88-121-684-080 0E RES,680K-1/8W J U1M VX-F20DV1
X POWER R 0815 88-121-393-080 0E RES,39K-1/8W J U1M VX-F20DV1
X POWER R 0816 88-121-152-080 0E RES,1.5K-1/8W J U1M VX-F20DV1
O POWER R 0824 87-A00-315-090 0E RES,M/F 1K-1W J RSF(S) U1M VX-F20DV1
X POWER R 0827 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X POWER R 0828 88-121-563-080 0E RES,56K-1/8W J U1M VX-F20DV1
X POWER R 0829 88-121-123-080 0E RES,12K-1/8W J U1M VX-F20DV1
X POWER R 0830 88-121-123-080 0E RES,12K-1/8W J U1M VX-F20DV1
O POWER R 0833 87-A00-199-090 0E RES,M/F 12K-3W J RSF(S) U1M VX-F20DV1
O POWER R 0834 87-A00-223-090 0E RES,M/F 47K-2W J RSF(S) U1M VX-F20DV1
X POWER R 0835 88-121-392-080 0E RES,3.9K-1/8W J U1M VX-F20DV1
X POWER R 0836 88-121-392-080 0E RES,3.9K-1/8W J U1M VX-F20DV1
X POWER R 0840 88-121-153-080 0E RES,15K-1/8W J U1M VX-F20DV1
X POWER R 0841 88-121-224-080 0E RES,220K-1/8W J U1M VX-F20DV1
X POWER R 0843 88-140-332-080 0E RES,3.3K-1/2W J U1M VX-F20DV1
O POWER R 0844 87-A00-777-090 -- RES,M/F 0.91-2W J L-FORM NG RS U1M VX-F20DV1
X POWER R 0845 88-140-102-080 0E RES,1K-1/2W J U1M VX-F20DV1
! O POWER RY 0801 87-A91-390-010 1B RELAY,AC12V G5PA-1-8 U1M VX-F20DV1
! O POWER TH 0801 87-A90-254-010 1C POS-THMS,PTH451BG5R0M140 U1M VX-F20DV1
X PR NTS 87-B40-088-010 0E BAG,PV 0.04-300-400 PL U1M VX-F20DV1
X PR NTS 87-B50-053-010 0E WARR-CARD,USA CUST/AV,V SUAL U1M VX-F20DV1
O PR NTS 8A-JD1-904-010 -- B,U QU CK(E/S/F) U1M VX-F20DV1
O PS-2 87-067-703-010 0E BVT2+3-10 W/0 SL0T U1M VX-F20DV1
O PS-2 C 0212 87-012-370-010 1A CAP,CER 3300P-250 M E ECKD U1M VX-F20DV1
O PS-2 C 0213 87-012-370-010 1A CAP,CER 3300P-250 M E ECKD U1M VX-F20DV1
O PS-2 C 0215 87-010-386-080 0E CAP,E 330-25 M SME U1M VX-F20DV1
O PS-2 C 0217 87-A11-196-080 0E CAP,M/P 0.022-400 K MMC U1M VX-F20DV1
O PS-2 C 0218 87-A12-408-080 0E CAP,E 100-35 KMF U1M VX-F20DV1
O PS-2 C 0219 87-010-190-080 0E C-CAP,S 0.01-50 Z F C2012 U1M VX-F20DV1
O PS-2 C 0220 87-A11-794-080 0E CAP,CER 100P-2K K B U1M VX-F20DV1

PARTS LIST
-16-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
X PS-2 C 0221 88-700-550-810 0E CAP,M 470P-50 J U1M VX-F20DV1
O PS-2 C 0222 87-010-190-080 0E C-CAP,S 0.01-50 Z F C2012 U1M VX-F20DV1
X PS-2 C 0223 88-700-830-810 0E CAP,M 0.022-50 J AMZV U1M VX-F20DV1
O PS-2 C 0224 87-A10-493-080 1A CAP,E 1000-25 KMF U1M VX-F20DV1
O PS-2 C 0225 87-A10-011-090 2A CAP,E 2200-25 SMG U1M VX-F20DV1
O PS-2 C 0226 87-010-247-080 0E CAP,E 100-50 M SME U1M VX-F20DV1
O PS-2 C 0227 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O PS-2 C 0228 87-A10-646-090 1H CAP,E 220-400 SMH25.4*40) U1M VX-F20DV1
O PS-2 C 0229 87-010-247-080 0E CAP,E 100-50 M SME U1M VX-F20DV1
O PS-2 C 0230 87-010-247-080 0E CAP,E 100-50 M SME U1M VX-F20DV1
O PS-2 C 0231 87-A10-492-090 1B CAP,E 3300-10 KMF U1M VX-F20DV1
O PS-2 C 0232 87-010-381-080 0E CAP,E 330-16 M SME U1M VX-F20DV1
O PS-2 C 0233 87-010-247-080 0E CAP,E 100-50 M SME U1M VX-F20DV1
O PS-2 C 0234 87-010-221-080 0E CAP,E 470-10 M SME U1M VX-F20DV1
X PS-2 C 0235 88-700-810-810 0E CAP,M 0.01-50 J AMZV U1M VX-F20DV1
O PS-2 C 0237 87-A12-074-080 0E CAP,E 470-25 SMG U1M VX-F20DV1
O PS-2 C 0241 87-012-370-010 1A CAP,CER 3300P-250 M E ECKD U1M VX-F20DV1
O PS-2 C 0242 87-012-370-010 1A CAP,CER 3300P-250 M E ECKD U1M VX-F20DV1
O PS-2 C 0244 87-A10-831-080 1A CAP,E 1000-25 M SMG U1M VX-F20DV1
! O PS-2 C 0245 87-A10-374-010 1A CAP,M/P 0.1-275 M MKT 1.40 6-2 U1M VX-F20DV1
X PS-2 CLP0214 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
O PS-2 CN 0211 87-A60-937-010 0E CONN,2P V VH U1M VX-F20DV1
O PS-2 CN 0216 87-A60-632-010 0E CONN,15P V 2MM JMT U1M VX-F20DV1
O PS-2 CNA0214 8A-JD1-660-010 -- CONN ASSY,15P V PS TO JO NT U1M VX-F20DV1
S PS-2 D 0211 87-070-173-010 1A D ODE,S1WBA60 U1M VX-F20DV1
S PS-2 D 0212 87-A40-368-080 0E D ODE,EG01C U1M VX-F20DV1
S PS-2 D 0213 87-A40-853-080 0E D ODE,10ELS2 U1M VX-F20DV1
S PS-2 D 0215 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S PS-2 D 0216 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S PS-2 D 0217 87-A40-852-090 0E D ODE,30DF2(F) U1M VX-F20DV1
S PS-2 D 0218 87-070-274-080 0E D ODE,1N4003 SEM U1M VX-F20DV1
S PS-2 D 0219 87-A40-367-080 0E D ODE,EU01 U1M VX-F20DV1
S PS-2 D 0220 87-A40-851-090 0E D ODE,31DQ04(F) U1M VX-F20DV1
S PS-2 D 0221 87-A40-367-080 0E D ODE,EU01 U1M VX-F20DV1
S PS-2 D 0222 87-A40-353-080 0E ZENER,HZS33-3 U1M VX-F20DV1
S PS-2 D 0223 87-A40-367-080 0E D ODE,EU01 U1M VX-F20DV1
S PS-2 D 0224 87-017-079-080 0E ZENER,HZS4A3 U1M VX-F20DV1
S PS-2 D 0226 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S PS-2 D 0227 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S PS-2 D 0229 87-070-274-080 0E D ODE,1N4003 SEM U1M VX-F20DV1
S PS-2 D 0230 87-070-274-080 0E D ODE,1N4003 SEM U1M VX-F20DV1
S PS-2 D 0231 87-070-274-080 0E D ODE,1N4003 SEM U1M VX-F20DV1
O PS-2 FB 0211 87-003-223-080 0E F-BEAD, BL02RN2 U1M VX-F20DV1
X PS-2 FB 0212 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PS-2 FB 0213 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PS-2 FB 0214 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PS-2 FB 0215 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PS-2 HT 0211 8Z-JU1-219-010 0E HT-S NK,PS1 U1M VX-F20DV1
X PS-2 HT 0212 87-JUT-215-010 0E HT-S NK, C3 U1M VX-F20DV1
S PS-2 C 0211 87-A21-186-010 1H C,STR-F6552 U1M VX-F20DV1
S PS-2 C 0212 87-A20-649-080 1A C,HA17431VP U1M VX-F20DV1
S PS-2 C 0213 87-A20-389-010 1A C,NJM7809FA U1M VX-F20DV1
S PS-2 C 0214 87-001-576-010 1B C,NJM7812FA U1M VX-F20DV1
S PS-2 CF0211 87-A91-337-080 0E PROTECTOR, C CP-N75 U1M VX-F20DV1
S PS-2 CF0212 87-001-132-080 0E PROTECTOR, C CP-N38 U1M VX-F20DV1
S PS-2 CF0213 87-A91-337-080 0E PROTECTOR, C CP-N75 U1M VX-F20DV1
S PS-2 CF0214 87-001-132-080 0E PROTECTOR, C CP-N38 U1M VX-F20DV1
S PS-2 CF0215 87-001-132-080 0E PROTECTOR, C CP-N38 U1M VX-F20DV1
! S PS-2 CF0216 87-001-486-080 0E PROTECTOR, C CP-N15 U1M VX-F20DV1
O PS-2 L 0211 87-A50-193-080 0E CO L,10UH K LHL10 U1M VX-F20DV1
O PS-2 L 0212 87-A50-193-080 0E CO L,10UH K LHL10 U1M VX-F20DV1
O PS-2 L 0213 87-A50-444-080 0E CO L,22UH K LHL08 U1M VX-F20DV1
! O PS-2 LF 0211 87-A90-492-010 1A FLTR,18MH SS10V-05180 U1M VX-F20DV1
! O PS-2 PS 0211 87-A90-717-010 1A P-COUPLER,PC123FY2 U1M VX-F20DV1
! O PS-2 PT 0211 8A-JD1-651-010 1F PT, AJD-1 SWT U1M VX-F20DV1
S PS-2 Q 0211 87-A30-217-010 1A TR,2SB1436(R) U1M VX-F20DV1
S PS-2 Q 0212 87-026-235-080 0E C-TR,DTC114EK U1M VX-F20DV1
S PS-2 Q 0213 87-A30-218-080 0E TR,2SB1237Q U1M VX-F20DV1
S PS-2 Q 0214 87-026-235-080 0E C-TR,DTC114EK U1M VX-F20DV1
S PS-2 Q 0217 87-026-227-080 0E C-TR,DTA114EK U1M VX-F20DV1

PARTS LIST
-17-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
S PS-2 Q 0218 87-026-227-080 0E C-TR,DTA114EK U1M VX-F20DV1
S PS-2 Q 0219 87-026-227-080 0E C-TR,DTA114EK U1M VX-F20DV1
S PS-2 Q 0220 87-A30-220-080 0E TR,2SC1741AS(R) U1M VX-F20DV1
S PS-2 Q 0221 87-A30-220-080 0E TR,2SC1741AS(R) U1M VX-F20DV1
S PS-2 Q 0222 87-A30-217-010 1A TR,2SB1436(R) U1M VX-F20DV1
S PS-2 Q 0223 87-026-235-080 0E C-TR,DTC114EK U1M VX-F20DV1
S PS-2 Q 0224 87-026-227-080 0E C-TR,DTA114EK U1M VX-F20DV1
S PS-2 Q 0225 87-A30-063-080 0E C-TR,KRA104S U1M VX-F20DV1
S PS-2 Q 0226 87-026-235-080 0E C-TR,DTC114EK U1M VX-F20DV1
X PS-2 R 0212 88-130-829-080 0E RES,8.2-1/4W J U1M VX-F20DV1
O PS-2 R 0213 87-A00-558-090 0E RES,M/F 56K-2W J U1M VX-F20DV1
X PS-2 R 0214 88-121-399-080 0E RES,3.9-1/8W J U1M VX-F20DV1
X PS-2 R 0215 88-121-399-080 0E RES,3.9-1/8W J U1M VX-F20DV1
O PS-2 R 0216 87-022-565-090 0E RES,M/F 47K-1W J U1M VX-F20DV1
O PS-2 R 0217 87-022-565-090 0E RES,M/F 47K-1W J U1M VX-F20DV1
X PS-2 R 0222 88-130-332-080 0E RES,3.3K-1/4W J U1M VX-F20DV1
X PS-2 R 0223 88-130-681-080 0E RES,680-1/4W J U1M VX-F20DV1
O PS-2 R 0224 87-A00-765-090 -- RES,M/F 0.30-2W J U1M VX-F20DV1
X PS-2 R 0225 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X PS-2 R 0226 88-121-221-080 0E RES,220-1/8W J U1M VX-F20DV1
X PS-2 R 0227 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
O PS-2 R 0228 87-A00-279-080 0E RES,M/F 75-1/6W F U1M VX-F20DV1
O PS-2 R 0229 87-025-365-080 0E RES,M/F 680-1/6W F U1M VX-F20DV1
O PS-2 R 0230 87-025-365-080 0E RES,M/F 680-1/6W F U1M VX-F20DV1
X PS-2 R 0231 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X PS-2 R 0232 88-140-122-080 0E RES,1.2K-1/2W J U1M VX-F20DV1
X PS-2 R 0233 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X PS-2 R 0234 88-121-222-080 0E RES,2.2K-1/8W J U1M VX-F20DV1
X PS-2 R 0237 88-130-103-080 0E RES,10K-1/4W J U1M VX-F20DV1
X PS-2 R 0238 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X PS-2 R 0239 88-140-272-080 0E RES,2.7K-1/2W J U1M VX-F20DV1
X PS-2 R 0240 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X PS-2 R 0241 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X PS-2 R 0242 88-108-223-080 0E C-RES,U 22K-1/16W J U1M VX-F20DV1
X PS-2 R 0243 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X PS-2 R 0244 88-130-391-080 0E RES,390-1/4W J U1M VX-F20DV1
O PS-2 R 0245 87-029-124-060 0E RES,FUSE 2.2-1/4W J U1M VX-F20DV1
X PS-2 R 0246 88-121-229-080 0E RES,2.2-1/8W J U1M VX-F20DV1
X PS-2 R 0247 88-108-223-080 0E C-RES,U 22K-1/16W J U1M VX-F20DV1
X PS-2 R 0248 88-108-103-080 0E C-RES,U 10K-1/16W J U1M VX-F20DV1
X PS-2 R 0249 88-108-333-080 0E C-RES,U 33K-1/16W J U1M VX-F20DV1
! O PS-2 R 0250 87-029-374-010 0E RES,FUSE 47-1/4W J U1M VX-F20DV1
X PS-2 R 0251 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PS-2 R 0253 88-121-183-080 0E RES,18K-1/8W J U1M VX-F20DV1
X PS-2 R 0254 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X PS-2 R 0255 88-121-153-080 0E RES,15K-1/8W J U1M VX-F20DV1
X PS-2 R 0256 88-121-153-080 0E RES,15K-1/8W J U1M VX-F20DV1
X PS-2 R 0257 88-108-154-080 0E C-RES,U 150K-1/16W J U1M VX-F20DV1
O PS-2 R 0258 87-A00-149-090 0E RES,M/F 100-1W J RSF(S) U1M VX-F20DV1
! O PS-SW C 0201 87-A10-688-090 1A CAP,M/P 0.22-275 K (B81133) U1M VX-F20DV1
! O PS-SW C 0202 87-A10-688-090 1A CAP,M/P 0.22-275 K (B81133) U1M VX-F20DV1
! O PS-SW C 0203 87-A10-479-080 0E CAP,CER 2200P-250 M E KH U1M VX-F20DV1
! O PS-SW C 0204 87-A10-479-080 0E CAP,CER 2200P-250 M E KH U1M VX-F20DV1
! O PS-SW C 0205 87-A10-479-080 0E CAP,CER 2200P-250 M E KH U1M VX-F20DV1
! O PS-SW C 0206 87-A10-479-080 0E CAP,CER 2200P-250 M E KH U1M VX-F20DV1
X PS-SW CLP0201 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PS-SW CLP0202 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
! O PS-SW CN 0201 87-099-674-010 0E CONN,2P V VA U1M VX-F20DV1
O PS-SW CN 0202 87-A61-126-080 0E MALE, 1P TP42097 U1M VX-F20DV1
O PS-SW CN 0203 87-A60-003-010 0E CONN,2P V TBL-P BOSS U1M VX-F20DV1
O PS-SW CN 0204 87-A61-126-080 0E MALE, 1P TP42097 U1M VX-F20DV1
O PS-SW D 0201 8Z-JBH-606-010 0E VR S,TNR15G271K U1M VX-F20DV1
X PS-SW EY 0201 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PS-SW EY 0202 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PS-SW EY 0203 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PS-SW EY 0204 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PS-SW EY 0205 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PS-SW EY 0206 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PS-SW EY 0207 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PS-SW EY 0208 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1

PARTS LIST
-18-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
X PS-SW EY 0263 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PS-SW EY 0264 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
! S PS-SW F 0201 87-A91-106-010 0E FUSE,5A 125V T SER233 U1M VX-F20DV1
O PS-SW FC 0201 87-033-213-080 0E FUSE CLAMP,PFC5000 U1M VX-F20DV1
O PS-SW FC 0202 87-033-213-080 0E FUSE CLAMP,PFC5000 U1M VX-F20DV1
! O PS-SW LF 0201 87-A91-453-010 1D FLTR,L NE PLH10A7003R6P02B1 U1M VX-F20DV1
! O PS-SW LF 0202 87-A91-449-010 1D FLTR,L NE ELF18D450D U1M VX-F20DV1
O PS-SW R 0202 87-023-102-080 0E RES,SD 4.7M-1/2W K U1M VX-F20DV1
! O PS-SW S 0201 87-A91-410-010 1B SW,AC PUSH 1-1-1 ESB92SH1B U1M VX-F20DV1
X PS-SW W 0203 8A-JD1-645-010 0E W RE,PW AJD-1 BRN U1M VX-F20DV1
X PS-SW W 0204 8A-JD1-646-010 0E W RE,PW AJD-1 BLU U1M VX-F20DV1
X PS-SW W 0205 8A-JD1-647-010 0E W RE,PW AJD-1 BLK U1M VX-F20DV1
X PWB * 8A-JE7-601-010 1H PWB,MA N USA FT U1M VX-F20DV1
X PWB,B * 8A-JE7-602-010 1F PWB,COMB B U1M VX-F20DV1
X PWB,B * 8A-JE7-603-010 -- PWB,AUD O U1M VX-F20DV1
X PWB,B * 8A-JE7-604-010 -- PWB,PS U1M VX-F20DV1
X PWB,B * 8A-JE7-605-010 -- PWB,NK-VM U1M VX-F20DV1
X PWB,B * 8A-JE7-606-010 -- PWB,S-JK U1M VX-F20DV1
X PWB,B OTHER D 0910 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PWB,B OTHER EY 0401 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,B OTHER EY 0402 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,B OTHER EY 0403 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,B OTHER EY 0404 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,B OTHER L 0402 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PWB,C * 8A-JD1-621-010 -- PWB,COMB C U1M VX-F20DV1
X PWB,C * 8A-JD1-622-010 -- PWB,SYSTEM U1M VX-F20DV1
X PWB,C * 8A-JD1-623-010 -- PWB,FR-KEY U1M VX-F20DV1
X PWB,C * 8A-JD1-624-010 -- PWB,FR-JACK U1M VX-F20DV1
X PWB,C * 8A-JD1-625-010 -- PWB,JO NT U1M VX-F20DV1
X PWB,C * 8A-JD1-626-010 -- PWB,OPT U1M VX-F20DV1
X PWB,D * 8A-JD1-631-010 -- PWB,COMB D U1M VX-F20DV1
X PWB,D * 8A-JD1-632-010 -- PWB,PS-SW U1M VX-F20DV1
X PWB,D * 8A-JD1-633-010 -- PWB,PS-2 U1M VX-F20DV1
X PWB,D * 8A-JD1-634-010 -- PWB,FR-FL U1M VX-F20DV1
X PWB,OTHER 89-961-093-410 0E W RE,U22H1-9-5 U1M VX-F20DV1
X PWB,OTHER 89-964-223-410 0E W RE,U22H4-22-5 U1M VX-F20DV1
X PWB,OTHER 89-990-220-110 0E W RE,U24X0-22-3 U1M VX-F20DV1
X PWB,OTHER C 0111 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PWB,OTHER CLP0001 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER CLP0002 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER CLP0003 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER CLP0004 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER CLP0005 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER CLP0006 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER CLP0007 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER CLP0008 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER CLP0009 87-A60-884-010 0E P N,D A1 COAT NG-SHS U1M VX-F20DV1
X PWB,OTHER D 0806 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PWB,OTHER EY 0005 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0006 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0007 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0008 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0009 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0010 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0011 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0012 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0013 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0014 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0015 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0016 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0017 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0018 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0019 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0022 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0023 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0024 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0025 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0026 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0027 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0029 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1

PARTS LIST
-19-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
X PWB,OTHER EY 0030 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0031 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0032 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0033 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0034 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0035 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0036 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0037 81-JT1-216-010 0E EYELET,1.6-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0101 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0102 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0103 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0104 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0105 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0106 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0107 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0108 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0109 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0110 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0111 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0112 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0113 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0114 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0115 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0116 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0117 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0118 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0119 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0120 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0121 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0122 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0123 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0124 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER EY 0125 81-JT1-215-010 0E EYELET2.0-3.0 U1M VX-F20DV1
X PWB,OTHER R 0101 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PWB,OTHER R 0102 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PWB,OTHER R 0847 88-100-000-010 0E PLAT NG-JW, 0.58 SN95 U1M VX-F20DV1
X PWB,OTHER W 0001 89-961-223-410 0E W RE,U22H1-22-5 U1M VX-F20DV1
O S-JK C 0771 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM U1M VX-F20DV1
O S-JK C 0772 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 U1M VX-F20DV1
! O S-JK CN 0771 87-009-345-010 0E CONN,2P H WHT PH U1M VX-F20DV1
O S-JK CNA0771 8Z-JE5-631-010 1B CONN ASSY,5P S-JK U1M VX-F20DV1
O S-JK J 0771 87-A61-174-010 1B JACK,Y/CYKF51-5558 U1M VX-F20DV1
X S-JK R 0771 88-118-750-080 0E C-RES,S 75-1/10W J U1M VX-F20DV1
X S-JK R 0772 88-118-750-080 0E C-RES,S 75-1/10W J U1M VX-F20DV1
X S-JK R 0773 88-118-104-080 0E C-RES,S 100K-1/10W J U1M VX-F20DV1
O SCREW 86-LBB-206-010 0E S-SCREW,ASSY TV5-40 W20 U1M VX-F20DV1
O SCREW 87-067-680-010 0E BV T3B+3-10 U1M VX-F20DV1
O SCREW 87-067-689-010 0E BVTT+3-8 U1M VX-F20DV1
O SCREW 87-067-690-010 0E BV T3B+3-12 BLK U1M VX-F20DV1
O SCREW 87-067-844-010 0E BVT2+4-16 BLK U1M VX-F20DV1
O SCREW 87-078-070-010 0E BV T3B+4-12 U1M VX-F20DV1
O SCREW 87-761-096-410 0E VFT2+3-10 W/O SLOT U1M VX-F20DV1
O SCREW 8Z-JS1-210-010 0E BVT2+4-20 U1M VX-F20DV1
O SYSCON C 0002 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 U1M VX-F20DV1
O SYSCON C 0003 87-018-134-080 0E CAP,TC U 0.01-16 N Y UP050 U1M VX-F20DV1
O SYSCON C 0004 87-018-127-080 0E CAP,TC U 470P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0005 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O SYSCON C 0006 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 U1M VX-F20DV1
O SYSCON C 0007 87-010-248-080 0E CAP,E 220-10 M 11L SME U1M VX-F20DV1
O SYSCON C 0008 87-018-123-080 0E CAP,TC U 220P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0009 87-010-401-080 0E CAP,E 1-50 M 11L SME U1M VX-F20DV1
O SYSCON C 0010 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0011 87-018-134-080 0E CAP,TC U 0.01-16 N Y UP050 U1M VX-F20DV1
O SYSCON C 0012 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0013 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0014 87-010-263-080 0E CAP,E 100-10 M 11L SME U1M VX-F20DV1
O SYSCON C 0015 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0016 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0017 87-018-128-080 0E CAP,TC U 560P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0018 87-018-109-080 0E CAP,TC U 22P-50 J SL UP050 U1M VX-F20DV1

PARTS LIST
-20-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
O SYSCON C 0019 87-018-109-080 0E CAP,TC U 22P-50 J SL UP050 U1M VX-F20DV1
O SYSCON C 0020 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0021 87-018-109-080 0E CAP,TC U 22P-50 J SL UP050 U1M VX-F20DV1
O SYSCON C 0022 87-018-109-080 0E CAP,TC U 22P-50 J SL UP050 U1M VX-F20DV1
O SYSCON C 0023 87-018-123-080 0E CAP,TC U 220P-50 K B UP050 U1M VX-F20DV1
O SYSCON C 0024 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 U1M VX-F20DV1
O SYSCON C 0025 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 U1M VX-F20DV1
! O SYSCON CN 0001 87-009-195-010 0E CONN,5P V WHT EH U1M VX-F20DV1
! O SYSCON CN 0002 87-009-261-010 0E CONN,7P V 52147 U1M VX-F20DV1
S SYSCON D 0004 87-017-932-080 0E ZENER,MTZJ6.2B U1M VX-F20DV1
S SYSCON D 0005 87-017-932-080 0E ZENER,MTZJ6.2B U1M VX-F20DV1
S SYSCON D 0008 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
S SYSCON D 0009 87-020-465-080 0E D ODE,1SS133 U1M VX-F20DV1
O SYSCON FB 0001 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
O SYSCON FB 0002 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
O SYSCON FB 0003 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
O SYSCON FB 0004 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
O SYSCON FB 0005 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
O SYSCON FB 0006 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
O SYSCON FB 0007 87-008-372-080 0E FLTR,EM BL01 RN1 U1M VX-F20DV1
S SYSCON C 0001 8A-JD1-691-010 -- C,M37272MA-302SP U1M VX-F20DV1
S SYSCON C 0003 87-A21-378-010 1A C,S-24C04BDP-1A U1M VX-F20DV1
S SYSCON C 0004 87-A20-611-080 0E C,M51943BSL-700A U1M VX-F20DV1
O SYSCON L 0002 87-005-614-080 0E CO L,100UH J LAV35 U1M VX-F20DV1
S SYSCON Q 0001 87-A30-065-080 0E TR,2SC2785FE U1M VX-F20DV1
S SYSCON Q 0002 87-026-269-080 0E TR,DTA114ES U1M VX-F20DV1
S SYSCON Q 0003 87-A30-065-080 0E TR,2SC2785FE U1M VX-F20DV1
S SYSCON Q 0004 87-A30-065-080 0E TR,2SC2785FE U1M VX-F20DV1
S SYSCON Q 0005 87-A30-066-080 0E TR,2SA1175FE U1M VX-F20DV1
X SYSCON R 0001 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X SYSCON R 0002 88-121-221-080 0E RES,220-1/8W J U1M VX-F20DV1
X SYSCON R 0003 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X SYSCON R 0004 88-121-472-080 0E RES,4.7K-1/8W J U1M VX-F20DV1
X SYSCON R 0005 88-121-822-080 0E RES,8.2K-1/8W J U1M VX-F20DV1
X SYSCON R 0006 88-121-473-080 0E RES,47K-1/8W J U1M VX-F20DV1
X SYSCON R 0007 88-121-101-080 0E RES,100-1/8W J U1M VX-F20DV1
X SYSCON R 0008 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X SYSCON R 0009 88-121-272-080 0E RES,2.7K-1/8W J U1M VX-F20DV1
X SYSCON R 0010 88-121-271-080 0E RES,270-1/8W J U1M VX-F20DV1
X SYSCON R 0017 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X SYSCON R 0018 88-121-392-080 0E RES,3.9K-1/8W J U1M VX-F20DV1
X SYSCON R 0019 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X SYSCON R 0020 88-121-471-080 0E RES,470-1/8W J U1M VX-F20DV1
X SYSCON R 0021 88-121-272-080 0E RES,2.7K-1/8W J U1M VX-F20DV1
X SYSCON R 0022 88-121-105-080 0E RES,1M-1/8W J U1M VX-F20DV1
X SYSCON R 0023 88-121-682-080 0E RES,6.8K-1/8W J U1M VX-F20DV1
X SYSCON R 0024 88-121-473-080 0E RES,47K-1/8W J U1M VX-F20DV1
X SYSCON R 0025 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X SYSCON R 0026 88-121-222-080 0E RES,2.2K-1/8W J U1M VX-F20DV1
X SYSCON R 0027 88-121-271-080 0E RES,270-1/8W J U1M VX-F20DV1
X SYSCON R 0028 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X SYSCON R 0029 88-121-473-080 0E RES,47K-1/8W J U1M VX-F20DV1
X SYSCON R 0030 88-121-473-080 0E RES,47K-1/8W J U1M VX-F20DV1
X SYSCON R 0031 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X SYSCON R 0032 88-121-101-080 0E RES,100-1/8W J U1M VX-F20DV1
X SYSCON R 0033 88-121-101-080 0E RES,100-1/8W J U1M VX-F20DV1
X SYSCON R 0034 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X SYSCON R 0035 88-121-271-080 0E RES,270-1/8W J U1M VX-F20DV1
X SYSCON R 0036 88-121-473-080 0E RES,47K-1/8W J U1M VX-F20DV1
X SYSCON R 0037 88-121-681-080 0E RES,680-1/8W J U1M VX-F20DV1
X SYSCON R 0040 88-121-101-080 0E RES,100-1/8W J U1M VX-F20DV1
X SYSCON R 0042 88-121-221-080 0E RES,220-1/8W J U1M VX-F20DV1
X SYSCON R 0043 88-121-102-080 0E RES,1K-1/8W J U1M VX-F20DV1
X SYSCON R 0044 88-121-473-080 0E RES,47K-1/8W J U1M VX-F20DV1
X SYSCON R 0047 88-121-332-080 0E RES,3.3K-1/8W J U1M VX-F20DV1
X SYSCON R 0050 88-121-223-080 0E RES,22K-1/8W J U1M VX-F20DV1
X SYSCON R 0051 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X SYSCON R 0052 88-121-471-080 0E RES,470-1/8W J U1M VX-F20DV1
X SYSCON R 0053 88-121-103-080 0E RES,10K-1/8W J U1M VX-F20DV1
X SYSCON SH 0001 8Z-JBR-210-010 0E SHLD-CASE,M CRO U1M VX-F20DV1
