AKA EXCALIBUR User manual

EXCALIBUR®, VIKING™, TORNADO® VALVE (pat#5791328), LIGHTNING BOLT®, SODA
CANMOD/SCM™andSIDEWINDER®(patpend)areTrademarksorRegisteredTrademarks
ofAKALMP, Inc. Design rights and all rights reserved.All patterns, drawings, photographs, in-
structions or manuals remain the intellectual property of the manufacturer. Covered under US
Patent5791328andotherPatentsPending.Allrightswillbestrictlyenforced.
All rights reserved. No part of this work covered by the copyright hereon may be
reoproduced or used in any form or by any means without the written permission of
AKA.
2004
Excalibur and Viking Manual
Version 3.0
Nov 2003

I. Safety Guidelines & Instructions
II. Specifications
III. Operating instructions
A. Power Supply
B. Compressed Air/Nitrogen Supply
C. Turning “ON & FIRING” the Marker
D. VelocityAdjustment
IV. Electronics
A. Equalizer Board
B. Nelson Board
V. Maintenance
A. Cleaning
B. Sidewinder
C. Ball Detents
D. SCM™ / LPR
E. Tornado Valve
F. Lightning bolt
G. Excalibur Hammer
H. Viking Hammer
I. Excalibur Ram
J. Trigger Frame
K. Solenoid valves
L. O-rings and Screws
VI. Troubleshooting
VII. Schematics
A. 2004 Excalibur®
B. 2004 Viking™
VIII. Warranty, Liability and Contact Information
CONTENTS

Introduction:
Congratulations on purchasing an EXCALIBUR® or VIKING™ paintball marker. We hope you
enjoy using this marker. Please read the information in the manual and get familiar with you
markerbeforeuse.
Thismanualcovers boththeEXCALIBUR®and VIKING™seriesofpaintballmarkersaswellas
coveringtheSIDEWINDER® regulatorandtheSCM™low pressurepneumaticsregulator.This
manualincludesinformationfor boththe2000-2003and the2004modelsofEXCALIBUR® and
VIKING™.Thismanual isaworkinprogress andwillbecontinuously updatedasneeded.Ifyou
have suggestions to help improve this manual contact us through e-mail and let us know. We
decided to place the manual on disk for the simplicity of keeping it up to date and to eliminate
paperwaste.
The specifications and photographs in this material are for information and general guidance
purposeonly.Ourproducts arecontinuallyupdatedandchangesmay bemadetospecification,
design or appearance from time to time. These changes are subject to change without notice.
AKALMP reserves the right to revise and improve its products as it sees fit.
EXCALIBUR®, VIKING™, TORNADO® VALVE (pat#5791328), LIGHTNING BOLT®, SODA
CANMOD/SCM™andSIDEWINDER®(patpend) areTrademarksorRegisteredTrademarks
of AKALMP, Inc. Design rights and all rights reserved. All patterns, drawings, photographs,
instructionsormanualsremainthe intellectual propertyofthemanufacturer. Covered underUS
Patent5791328andotherPatentsPending.Allrightswillbestrictlyenforced.
I. SAFETY GUIDELINES &
INSTRUCTIONS.
SAFETY GUIDELINES & INSTRUCTIONS FOR SAFE HANDLING OF EXCALIBUR® &
VIKING™ MARKERS.
•TheEXCALIBUR®andVIKING™arenot toys.
•Carelessorimproper use,includingfailuretofollowinstructionsintheoperatorsmanual, could
causeseriousinjuryor death.
•Paintballindustrystandardhead/face/throat/eye/earprotectiondesignedspecificallyforpaintball
meetingASTMstandardF1776mustbewornbyuserandanypersonwithinrangeofanypaintball
marker.
•Do not shoot at a person at close range.
•Observealllocallaws,regulationsandguidelines.
•Useonlyonpaintballfieldswhere safety rules arestrictlyenforced.
•Youmustbeatleast18yearsofagetopurchasetheEXCALIBUR®orVIKING™.

•Individuals under 18 years of age must have adult supervision when using or handling the
EXCALIBUR®orVIKING™.
•Useonly nitrogen and compressed air fromapprovedstoragebottle.Donotuse CO2.
•Do not exceed 850 psi input pressure.
•Readoperator’smanualbeforeuseandcomplywithallsafetyinstructions.
•Use.68 caliber paintballsonly.
•AlwayskeepEXCALIBUR®orVIKING™turned off when notinuse.
•Alwaysswitchgassourceoff when EXCALIBUR®orVIKING™isnotinuse.
•Treat ever EXCALIBUR® or VIKING™ as if it is loaded.
•NeverpointtheEXCALIBUR®or VIKING™ atanyoneoranythingyoudo not intendtoshoot.
•UseapprovedbarrelblockingdevicesontheEXCALIBUR®orVIKING™whennotinuse.
•Never shoot at velocities in excess of 300 FPS.
•Neverputfingersoranyforeignobjectsintothepaintballfeed tube.
•AlwaysremoveallpaintballsfromtheEXCALIBUR®orVIKING™ whennotinuseonoroffthe
field.
•Regulators and LPR’s can store gas after the bottle has been removed. Always degas
EXCALIBUR®orVIKING™whennotin use or beforeworkingonthemarkers.
•Whenadjusting,servicingorusing the Excalibur,ALWAYS WEAREYEPROTECTION
•Beforedoing any work to the Excalibur® (patpend), make sure it is turned off,the air source
hasbeenremoved,andall paintballs have beenremoved.
•Seekprofessionalassistanceforadviceifyouareunsureofanything.

2004 EXCALIBUR SPECS:
•Model: Excalibur®(pat.pending)
•Version: B
•Caliber: .68
•Action: ClosedBoltElectro-pneumatic
Operation
•Gas Source: Compressed air or Nitrogen
•Power Supply: 9Voltbattery
•ROF (Cyclic Rate): 13+ BPS
(unlimitedROFwithEYE’s)
•Standard Barrel Length: 12.0" Javelin
(ACThreads)
•Length: 7.25inches
•Height: 8.3inches(Top of feed tube to
bottom of grip)
•Width: 1.75inches
•Weight: 3lbs(Withoutbattery&barrel)
•Operating Pressure: 140-180 PSI @ 280
FPS (depending on paint size)
•Input PSI to SIDEWINDER: 400-900 PSI
•Pneumatics Pressure: 65-85 PSI
Features:
•Tornado® Valve(Pat. #5791328)
•Lightning®Bolt(Delrin)withQuickRelease
Pin
•Javelin™ Barrel
•45 Grip
•DualballDetentforcenteringtheballinthe
breech
•Built-InVerticalMount
•SIDEWINDER®(patpend)Vertical
PressureReg.
•AKAThreaded Vertical Feedtube
•AdjustableTrigger(3adjustmentpoints)
•Adjustable WAS circuit board
•ReadytoinstallAnti-chopeyes.
•Adjustable SCM™ Low Pressure
Regulator(LPR).
•PullThroughCleaning
•Easy Disassembly & Low Maintenance
II. SPECIFICATIONS.
2000-2003 EXCALIBUR SPECS:
•Model: Excalibur®(pat.pending)
•Version: A
•Caliber: .68
•Action: ClosedBoltElectro-pneumatic
Operation
•Gas Source: Compressed air or Nitrogen
•Power Supply: 9 Volt battery
•ROF (Cyclic Rate): 13+BPS
•Standard Barrel Length: 12.0" Javelin
(ACThreads)
•Length: 8.0inches
•Height: 8.4inches(Top of feed tube to
bottom of grip)
•Width: 1.75inches
•Weight: 3.lbs (Without battery & barrel)
•Operating Pressure: 140-180 PSI @ 280
FPS (depending on paint size)
•Input PSI to SIDEWINDER: 400-850 PSI
•Pneumatics Pressure: 65-85 PSI
Features:
•Tornado® Valve(Pat. #5791328)
•Lightning®Bolt(Delrin)withQuickRelease
Pin
•Javelin™ Barrel
•45 Grip
•Wire Ball Detent
•Built-InVerticalMount
•SIDEWINDER®(patpend)Vertical
PressureReg.
•Threaded Vertical Feedtube
•AdjustableTrigger(3adjustmentpoints)
•Adjustable WAS circuit board
•AdjustablePneumaticsLowPressure
Regulator(LPR).
•PullThroughCleaning
•Easy Disassembly & Low Maintenance
•Rugged Design
•Barrel Plug
•Carrying Case

2004 VIKING™ SPECIFICATIONS:
•Model: Viking™(pat pend)
•Version:B
•Caliber: .68
•Action: OpenBoltElectro-pneumatic
Operation
•Gas Source: Compressed air or Nitrogen
•Power Supply: 9 Volt battery
•ROF (Cyclic Rate): 13+BPS (unlimited
ROFwithEYE’s)
•Standard Barrel Length: 12.0" Javelin
(ACThreads)
•Length: 7.5 inches
•Height: 8.3 inches (Top of feed tube to
bottom of grip)
•Width: 1.75 inches
•Weight: 3.lbs (Without battery & barrel)
•Operating Pressure: 140-180 PSI @ 280
FPS (depending on paint size)
•Input PSI to SIDEWINDER: 400-850 PSI
•Pneumatics Pressure: 65-85 PSI
Features:
•Tornado® Valve(Pat. #5791328)
•Lightning®Bolt(Delrin)withQuickRelease
Pin
•Javelin™ Barrel
•45 Grip
•DualballDetentforcenteringtheballinthe
breech
•Built-InVerticalMount
•SIDEWINDER®(patpend)Vertical
PressureReg.
•AKAThreaded Vertical Feedtube
•AdjustableTrigger(3adjustmentpoints)
•Adjustable Equalizer circuit board
•ReadytoinstallAnti-chopeyes.
•AdjustableSCM™LowPressureRegulator
(LPR).
•PullThroughCleaning
•Easy Disassembly & Low Maintenance
2001-2003 VIKING™ SPECIFICATIONS:
•Model: Viking™(patpend)
•Version: A
•Caliber: .68
•Action: OpenBoltElectro-pneumatic
Operation
•Gas Source: Compressed air or Nitrogen
•Power Supply: 9 Volt battery
•ROF (Cyclic Rate): 13+BPS (unlimited
ROFwithEYE’s)
•Standard Barrel Length: 12.0" Javelin
(ACThreads)
•Length: 8.0inches
•Height: 8.4inches(Top of feed tube to
bottom of grip)
•Width: 1.75inches
•Weight: 3.lbs(Withoutbattery& barrel)
•Operating Pressure: 140-180 PSI @ 280
FPS (depending on paint size)
•Input PSI to SIDEWINDER: 400-850 PSI
•Pneumatics Pressure: 65-85 PSI
Features:
•Tornado®Valve (Pat. #5791328)
•Lightning®Bolt(Delrin)withQuickRelease
Pin
•Javelin™ Barrel
•45 Grip
•Wire Ball Detent
•Built-InVerticalMount
•SIDEWINDER®(patpend)Vertical
PressureReg.
•Threaded Vertical Feedtube
•AdjustableTrigger(3adjustmentpoints)
•Adjustable Equalizer circuit board
•AdjustablePneumaticsLowPressure
Regulator(LPR).
•PullThroughCleaning
•Easy Disassembly & Low Maintenance
•Rugged Design
•Barrel Blocking Device
•Carrying Case

A. POWER SUPPLY:
TheECALIBUR®andVIKING™ usesa9-volt
batterystoredinthegripasitspowersupply.
Formaximumnumberof shotsandvelocity
stabilityyoushould onlyusehighquality
alkalinebatteries.
Installing a Battery:
Step 1: Make sure the marker is unloaded,
de-gassedandturnedoff.Removeoneof the
twoscrewsholdingthegrippanel on the left
sideofthemarker. Rotatethepaneloutofthe
way.Removethe9-volt batteryfromthe
batterycable.Makesurenot to pullthe
batterycableapart.
Step2:Installthenew9-volt batteryonthe
battery cable and place it back into the grip
frame.Makesurenowiresonthe battery
cablearepinched.Gentlyloopthe wiring and
layitonthesideofthebattery.
Step 3: Rotate the grip panel back into place.
Thenreplacethegrippanelscrew.Your
EXCALIBUR®andVIKING™isnow
poweredandreadytouse.
III. OPERATING INSTRUCTIONS.
B. COMPRESSED AIR/NITROGEN
SUPPLY.
TheEXCALIBUR®andVIKING™ are
designed to operate on nitrogen or
compressedair.Itrequiresahighflowof
CLEANgas.Mostadjustablenitrogen
systemsorpresetbottlesystems,will work
fine.TheEXCALIBUR®and VIKING™ are
suppliedwithaSIDEWINDER®regulator
whichhasbeendesignedtoworkatthelow
pressurerangeinwhichtheEXCALIBUR®
andVIKING™operate.The inputpressureto
theSIDEWINDER®regulatorshouldbe 400
to500psiifyouhaveanadjustablenitrogen
system.Ifyou haveapresetbottlethenthe
850 psi input is okay but the Low Pressure
450nitrogenbottlesarebetter.
CAUTIONS:
Airsuppliedatfieldsandtournamentsis
often dirty if a compressor is used. Scuba air
isnotalwayscleaneither. This dirty air is one
reasonforpaintballguns and regulator
failures.Nexttimeyour gunorregulatorfails
atatournament,stop-beforeblaming the
manufacturerofthe paintballgun orregulator,
andcheckyourairsupply.Someofthisdirt
eventuallyendsupin themarker. Electronic
markerswithsolenoidvalves are particularly
vulnerabletodirt.Forthisreason, we
recommendaportablefiltersuchasthe
GUARDIAN™forfilling yournitrogensystem
oranitrogensystem with abuilt-infilterwhen
usingtheEXCALIBUR®or VIKING™.
Mostmetalfittingsandsteelbraided hoses
arenickel-platedbrasswhichcanleavemetal
shavinginyour markerwhenyouinstalla
hose.Alwaysrunairthroughthe hosesand
fittingsbeforeattachingthemtoamarkerto
make sure the air line is clear of debris. Metal
shavescandamagetheinternals of the
marker.

Useonlysteelbraidedhoseandstainless
steelquickdisconnectsorMacro-line.Micro-
linerestrictsairflowandunsafeforuse in
paintball.
DONOTUSETEFLONTAPE.Improperuse
ofTeflontapecanresultinpieces of tape
goingthroughtheregulator andintothe
marker.Thiscancauseblockagesand
damagetosolenoidvalves.
Donotuseofpro-connectsandfittingslike
those,theyrestrictairflowwhich can causea
dropin efficiency or can cause drop off
problemswhilefiringtheEXCALIBUR®or
VIKING™.Theydonothavea highenough
airflowforlowpressuremarkers.
C.Turning “ON” the marker.
1.Aftermakingsurethemarkerisunloaded
andde-gassedandyouhaveinstalled the
battery.
2.Turnon theairsource.Onthe
EXCALIBUR®,iftheboltis not in its forward
positionitwillnowmoveforwardclosingthe
breech.Thebolton theVIKING™willmove to
therearofthemarker.
3. Pointing the marker in a safe direction
awayfromyou andothers.Turnthemarker
“ON”usingtherecessedpowerswitch on the
side of the marker or in the back of the
marker.WhentheLEDstartsblinkingthenthe
marker is ready to fire.
4.Thepaintballmarkerisnowreadytofire.
5.Simplypointinasafedirectionandpullthe
trigger.Alwayskeepyourfingeroutofthe
triggerguardwhenyouarenotfiring the
paintballmarker.
D.Velocity adjustment.
ThevelocityoftheEXCALIBUR® and
VIKING™iscontrolleddirectlythroughthe
SIDEWINDER®(patpend)regulatormounted
verticallyinfrontof thetriggerframe.The
SIDEWINDER®(patpend)regulatoris
standardontheEXCALIBUR® and VIKING™
andisadjustedinthisfashionwhilelookingat
thebottomoftheSIDEWINDER®(pat pend)
regulator.Whenmakingvelocityadjustments
youshoulduse extremelyfineadjustmentsso
asnottogopastthedesired velocity. If you
areunsurewhereyouroperating pressure is,
simplyturnthe pressuredownuntilthevelocity
dropstoabout200fps thenslowlyturnthe
pressurebackup.
Do not exceed a
velocity of 300 FPS.
1.Turningthe adjusterscrewclockwisewill
lowerthepressure, thusloweringthevelocity.
2.Turningtheadjuster screwcounter-
clockwisewillincreasethepressureraising
thevelocity.

IV. ELECTRONICS:
EqualizerTM
Installation and Usage Manual for
AKA Viking and Excalibur
EqualizerTM is a trademark of Wicked Air Sportz
Allmaterialincluding, butnotlimitedtophotographs,text,and conceptscontainedinthis manual
is copyright ©2002-2003 By WickedAir Sportz and Jim Drew. Distribution of this data without
permissionisstrictlyprohibited! All rightsreserved,worldwide. Reprintedwith permission. This
sectionprovidedbyWickedAirSportz http://www.wickedairsportz.com/home.htm.

Introduction
ThankyouforpurchasingtheEqualizerTM board.
Thisboardis adirectreplacementforthestock
circuitboardfoundinyourAKAmarker.
Pleasereadthrough thisentiremanualbefore
youattempttheinstallation of yourEqualizerTM
board!
Installation Requirements
To installyourEqualizerTM board,youwill need
theappropriatesizedallenwrenches andaflat,
clean,worksurface.
TheinstallationoftheEqualizerTM boardisnot
difficult. Ifafterreadingthroughthismanual,you
believe you cannot perform the installation,
pleaseseeksomeonewhocanassistyou.
Thismanualshouldprovide ampleinformation
andclaritytoinstall this product.
Warranty Information
TheEqualizerTM boardcarriesa limitedlifetime
warranty. Unitssubjecttoimproperinstallation,
misuse, abuse, or modifications will not be
coveredunderthis warranty.
Wicked Air Sportz may at its discretion either
repairorreplacetheunit. Thecustomerwillpay
all freight charges to and from Wicked Air
Sportz.
All defective units will be returned to the
customerviaUSPS PriorityMail. Atthetimeof
printing this manual, this rate is $4.40. This
amount must be included with any unit to be
repaired,orthe unitwillbereturnedUPSCOD/
Freightcollect.
Liability
By using this product, you agree to hold
Wicked Air Sportz free from any type of
liability either directly or indirectly due to
the use of this product.
SECTION 1 – INSTALLATION
Step 1 – Removing the Grip Frame
Before disassembling the marker, make
sure the marker power switch is in the off
position.
Removethetwoscrewsthatholdthegripframe
tothebody.
Step 2 – Removing the Circuit Board From
the Grip Frame Tray
Twoplasticscrewsare used to hold the circuit
boardinplace. Usingthepropersizeflattipped
screwdriver, carefully remove the screws that
holdsthecircuitboardinplace.
Oncethescrewsareremoved,gentlypullupon
the circuit board assembly to give yourself
enoughroomtograbaholdof it.
Step 3 – Disconnecting/Connecting the
Plugs
Carefullyremoveeachconnectorfromthestock
board (one by one) and place each connector
in the same socket location on the Equalizer
board. Refer to Figure 1 for proper plug
placement.
Step 4 – Mounting the Board Into the Grip
Frame Tray
Carefully press the EqualizerTM into the area
designed for the circuit board to fit in. Make
sure that you do not pinch any wires in the
harness. Line up the holes (opposite corners
of the EqualizerTM). Now, insert the plastic
screws into the holes and tighten the screws
until they are just snug. DO NOT
OVERTIGHTEN!

Step 5 – Testing the Board
Beforereassemblingthemarker,youshoulddo
aquicktesttomakesurethatconnectionsare
correct and that the board is working. Making
sure that nothing is grounding the grip frame,
move the power switch to the on position. If
everythingisworking,youshould see theLED
light up orange. If this occurs, turn the power
switchtotheoffpositionandcontinuetostep6.
If you don’t see the LED light up, make sure
your battery is connected. If that is not the
problem,thenchecktheconnectorplugs. Ifyou
require further assistance, please email the
technical support department
([email protected]).
Step 6 – Reassemble the Marker
Reassembleyourmarkerbyattaching the grip
frametothebody,and using the twoscrewsto
holdthemtogether.
Congratulations! You have now successfully
completed the installation of your EqualizerTM
board!
NOTE: The Equalizer board can be used with
either the Viking or Excalibur markers. The
Equalizer detects which marker it is installed
in, and adjusts parameters to handle the
differentfiringsequencesandeyesmodes.
SECTION 2 – USAGE
The EqualizerTM has numerous features,
which can be a bit overwhelming to those
that are not use to having so much
flexibility.
The Boot Sequence
WhentheEqualizerTM bootsup,theLEDwilllight
up orange and then either green (NORMAL
mode)orred(COMPETITION mode).
Feature Descriptions
Dwell
Dwell is the amount of time that the
solenoid will be activated. This time is
measured in milliseconds (1/1000th of a
second). The user can alter the Dwell only
when in NORMAL mode. In COMPETITION
mode, it is not possible to change settings
via the trigger programming. The factory
default is 8.0ms. Changes can be made in
.1ms units via the Equalink.
Increasing your Dwell will increase the
velocity of your marker. If you are
experiencing a great variance in your
chrono results, try increasing your Dwell.
If your dwell is too low, consistency will
suffer greatly.
Debounce
Debounce is the amount of time the trigger
switch must be stable in the up position
before checking for another trigger pull.
This time is measured in milliseconds. The
user can alter the Debounce only when in
NORMAL mode. Possible values are from
1ms to 255ms. The factory default is 10ms.
Changes are made in 1ms units.
If you find that your marker is double firing,
increase the Debounce time. To make your
marker fire faster due to being more

responsive to the trigger, decrease the
Debounce time.
Remember, if you pull the trigger once and
the recoil causes your marker to fire again
byitself, itis NOLEGALfortournamentplay
and is a SEVERE SAFETY HAZARD!
Eye Mode
The Eye Mode is can be set to one of four
different modes for the VikingTM:
Bypass - The anti-chop system is disabled.
When this occurs, the maximum rate of fire
is limited to 13 balls per second to help
prevent chopping of balls in the breech.
Delayed – This is like the normal method
of firing used in the original Intimidator
selectfireand semi-only boards. Ifyoupull
the trigger and noball is found in the
breech within ¾ of a second, the marker is
fired anyways. If a ball is found before the
time expires, the marker will immediately
fire(beforethe ¾ofsecond timeisup). This
isthedefaulteyemode.
Forced – In this mode, the marker will not
fire unless there is a ball in the breech. In
this mode, your marker will not “dry fire”
ever. Thisis the recommended eye mode.
Simulate – In this mode, a ball is simulated
to be in the breech. This allows you to fire
themarkerwithjustair,atthefullspeed that
the marker is capable of firing! This mode
can be used for practicing trigger pull
methods, without wasting paint. DO NOT
SHOOTPAINTINTHISMODE!
It is highly recommended that tournament
players use the Forced mode. Ifyou have
a hopper jam or something hangs up in the
feed tube, and you are using Delayed
mode, it is possible to chop a ball if one
breaks free at the instant the firing
sequence starts. Although this is not
common, this does happen enough to
justify the creation of this mode. The
factory default is Delayed.
The Eye Mode can be set to one of four
different modes for the Excaliburâ:
Bypass - The anti-chop system is disabled.
When this occurs, the maximum rate of fire
is limited to 10 balls per second to help
prevent chopping of balls in the breech.
Normal – In this mode, the chambered ball
willfire (ifthereisone)andtheboltwillopen
forupto ¾of asecondbefore automatically
closing. If a ball is found before this time
expires, the bolt will immediately close.
Thisisthedefaulteyemode.
Classic – In this mode, the chambered ball
willfire(if thereis one),andtheboltwill stay
open as long as you keep holding the
trigger (just like a stockAutococker).
Sniper – In this mode, the chambered ball
will fire (if there is one), and the bolt will not
cycle until you release the trigger. When
the trigger is released, bolt will open for up
to ¾ of a second before automatically
closing. If a ball is found before this time
expires, the bolt will immediately close.
NOTE: IN ALL CASES, IF YOU DO NOT
HAVE AN EYE SYSTEM, THE COMPUTER
WILL AUTOMATICALLY SWITCH TO
BYPASS MODE!
HopperTrigger
The EqualizerTM hardware has the ability to
generate a positive or negative going
pulse, for a duration that is user
programmable. Although the EqualizerTM

cannot supply power to your hopper to run
it (in place of its own batteries), it can
provideatrigger that could forceactivation
for a programmable period of time. More
information about the interface to the
EqualizerTM will be provided in separate
documentation. Possible values are .1 to
2.0 seconds, with either a positive or
negative going pulse. The factory default is
positive pulse, lasting 1.0 second. This
configuration was designed to work
directly with the Warpfeed from Air Gun
Designs. Changes to these parameters
require the Equalink cable.
LED Colors and Meanings
The LED is a type that can light up in one
of 3 different colors. The EqualizerTM uses
this to indicate to the user when certain
events are occurring. This is a breakdown
of what the LED states represent:
•Solid Green - In or entering
programming mode.
•Blinking Green - Normal operation,
anti-chop system is enabled.
•Blinkin g Orange - Normaloperation,
anti-chop system is disabled.
•Blinking Red - Battery is low.
•Red/Green toggle - There is an error
with the anti-chop system.
GeneralUsageTips
The LED boot sequence is as follows: solid
orange (booting), solid green (normal
mode) or solid red (competition mode
You can manually bypass the anti-chop
system by moving the bolt forward
(blockingtheinfrared beam)and pullingthe
trigger3times. When the anti-chopsystem
is bypassed the LED will blink orange
(instead of green).
The first two times you pull the trigger, the
LED will toggle red/green to let you know
that an error occurred with the anti-chop
system. If a shell fragment entered the
breech,itcould beclearedon thenextshot.
Thus, disabling the anti-chop system
immediately on the first problem is
somethingthatthe EqualizerTM does notdo.
Withaneye system,the rateoffire islimited
only by how fast the pneumatics will cycle,
how fast you can pull the trigger, and how
fast your loader can feed your marker.
Because the EqualizerTM can easily exceed
the feed rate of standard agitated hoppers,
it is recommended that you use an
advanced hopper (TurboRev equipped
Revolution) or a force-feed type of hopper
for the best possible performance.
While in programming mode, the marker’s
ability to shoot is completely disabled.
TournamentLock
It is possible to put the EqualizerTM into a
tournament lock (COMPETITION) mode.
You can do this by making sure the power
switch is in the off position, grounding
(connecting) the two center pins on the
Equalink interface connector, and then
moving the power switch to on position.
Each time you ‘reboot’ with the pins
grounded, the NORMAL and
COMPETITION modes will toggle. The
markerwillnot firewiththe jumper inplace!
Removing the jumper will allow the normal
operation of the marker.
Programming the Dwell, Debounce, and Eye
ModeUsingtheTrigger
The Dwell, Debounce, and Eye Mode
functions are programmable by following
these instructions:
Make sure the power switch is on the off
position. During programming, make sure
that your marker has a barrel condom in
place or the air supply shut off. Although it
is not possible to fire the marker while in

programming mode, it is always good to
practice safe marker handling.
Pull the trigger, and hold it in the back
position. Now, turn the power switch to the
on position. The LED will light green. Now,
immediately release the trigger. The LED
will light red.
Pulling and releasing the trigger will toggle
the LED color between red, green, and
orange.
Red indicates you are in the Dwell
programming mode, green indicates you
are in the Debounce programming mode,
and orange indicates you are in the Eye
Mode programming mode. Once you have
reached orange, an additional trigger pull
willstartthe sequence ofcolors over again.
This is also known as the “programming
starting point”.
When you decide which programming
mode you want, pull the trigger and hold it
until the LED goes out and then release the
trigger. There willbe a 2secondpause,and
then the LED will flash the same color of
the programming mode you are in
(red=Dwell, green=Debounce, orange=eye
mode).
For the Dwell and Debounce programming
modes, each flash represents 1ms
(millisecond) of time. For example, if you
were programming the Dwell and the
settings were the default, you would see
theLED flashred 8timesinarow,indicating
the dwell is set to 8ms. The flashing of the
LED shows you the current setting before
you program it.
For the Eye Mode programming mode, the
total number of flashes represents the
mode of the anti-chop system.
Dwell and Debounce
Once the LED stops flashing, you can now
pull and release the trigger once for every
1ms of time you want the setting to be. For
example, if you were programming the
Debounce for 5ms, you would pull and
release the trigger 5 times. On each pull of
the trigger, the LED will light up (indicating
thatthepull hasbeen detected). Ifyouhave
decided not to program this mode, simply
do not touch the trigger for 5 seconds. The
LED will toggle green/red alternately to
indicate there was a programming error,
and then go back to the programming
starting point.
Eye Mode
Once the LED stops flashing, you can now
pull and release the trigger the number of
times necessary to set the Eye Mode.
The following is a list of the possible Eye
Modes and the flashes (also trigger pulls
required):
•1 flash – Bypassed mode (for
Viking and Excalibur)
•2 flashes - Delayed mode (Viking)
or Normal mode (Excalibur)
•3 flashes – Forced mode (Viking)
or Class mode (Excalibur)
•4 flashes - Simulate mode (Viking)
or Sniper mode (Excalibur)
Ifyoupull and releasethetrigger morethan
4 times, then the LED will toggle green/red
alternately to indicate there was a
programmingerror, andthengo back tothe
programming starting point.
Programming Complete
Once you pulled and released the trigger
the number of times necessary to set the
function, wait a few seconds. The LED will
flash red/green/orange in rapid succession
(numerous times) to let you know that the
new setting has been saved. After this, the

LED will return to the color representing
what the current programming mode is. At
this point, you can once again press and
releasethetrigger to toggle betweenDwell,
Debounce, and Eye Mode programming
modes.
You can perform a complete reset of the
Dwell, Debounce, and Eye Mode to the
factory defaults when you are in the
program starting point (where you can
toggle the programming mode).
To do this, just hold down the trigger for 5
full seconds. It does not matter what
programming mode you are currently in
(Dwell, Debounce, or Eye Mode). The
LED will start flashing red, letting you
know that a reset operation is being
performed. After this occurs, you will be
back to the programming starting point.

B. NELSON BOARDS.
Note:As ofApril 2003 these boards are no
longerbeingusedorproducedforthe
EXCALIBUR®orVIKING™thissectionis
onlybeingincludeasareferenceforpeople
stillusingtheoldNelsonboards.
(TheExcalibur®(patpend)iscontrolledby a
stateoftheartsoftwaredriven computer
board.Theboardisequippedwithmany
featuresthatarenot foundonotherelectronic
paintball markers. First the board is equipped
withaspecialvoltageregulationand control
systemnotfound onanyotherelectronic
marker.Thissystemwillincreasethelifespan
ofthebattery.Theboardismadewith
connectorsforevery attachmentnecessary.
Nosolderingofwiresisneeded.If the trigger
microswitchgoesbadjustunplugitand
replacewithanewone.Thesamegoesfor
thebatteryplug,the LED,theon-offswitch,
andthesolenoidvalves.Thereisalsoa
programmingportandarechargingport.
Whenusingrechargeablebatteriesyou don’t
havetoremovethe battery justuseanadaptor
andrechargethebattery.Thereisalsoa port
thatwillsupportaWarpFeedandanIntella-
feedsystem.Thecircuitboardisprotected
againstmoisture,butdonotimmersethe
Viking™(pat pend) inwater.TheViking™(pat
pend)istournamentlegal,astheboard
operatesinsemi-automaticmodeonly.)
Circuit board schematics:
2nd GENERATION NELSON CIRCUIT
BOARD.
1st GENERATION NELSON CIRCUIT
BOARD.
Rate of Fire adjustment:
Theonlywayfor the EXCALIBUR®and
VIKING™parameterstobechangedis
throughadjustingthesoftwareviaacomputer.
Theonlywaytoadjusttherate of fire is to
adjustthedwellsettings.This does three
things:
First,itallowsfor very fineadjustmenttothe
dwellsettings.Youcanadjusteachparameter
a millisecond at a time if you like.
Second,wheneverthereisanupdate, instead
ofhavingtochange the boardyoucanjust
downloadthenewsoftware.
Third,itmakesthemarker completely
tournamentlegalsincethereis no physical
wayontheboardtoadjustthe firing
parameters.
EXCALIBUR® factory dwell parameters:
•Hammer drive: 10ms
TheHAMMERDRIVEisthe total amountof
timethatthehammer solenoid staysturnedon
pushingthehammerforward againstthe
Tornado®(Pat # 5791328)valvethusalso
openingthevalveandreleasingairtoshoot
thepaintball.
****NEW, READ CAREFULLY, NEW****
•Hammer Draw Enable: 10ms
This is a new type of dwell setting not

seen before in an electronic paintball
marker. Thissettingisusedwithanew
featurethathasbeenaddedtothecircuit
boardthatincreasesbatterylife.This dwell
settingisusedin conjunction withthehammer
drivedwellsettingto control theamountof
timethatthecircuitboarddrawspowerfrom
thebatterytochargethe coils on thehammer
solenoidandtochargeupthecapacitorsthat
willcontinuetopowerthe hammer solenoid
afterthecircuitboardstopsdrawingpower
fromthebattery.
Example.Thehammerfiresfor10
millisecondsandtheHammerDrawEnable
dwellissetfor7milliseconds.Thismeansthat
duringthe10millisecondsthatthehammer is
activatedthebatteryisonly supplying powerto
thesolenoidforthefirst7millisecondsofthe
hammercycletherestisfromthecapacitors.
•Hammer release: 5ms
TheHAMMERRELEASEistheamountof
timeafterthehammerisfiredbeforethebolt
isactivated.Itdelaystheactivation of thebolt,
thusallowingtheballto clear thebarreland
eliminatesblowbackthroughthe feed tube.
•Bolt drive: 55ms
TheBOLTDRIVEistheamount of time that
theboltsolenoidstays turnedon,thus
controllingthetimethat the boltstaysopen
allowingaballtodropintothebreech.
****NEW, READ CAREFULLY, NEW****
•BOLT Draw Enable: 20ms
This is a new type of dwell setting not
seen before in an electronic paintball
marker. Thissettingisusedwithanew
featurethathasbeenaddedtothecircuit
boardthatincreasesbatterylife.This dwell
settingisusedinconjunction with thebolt
drivedwellsettingto control theamountof
timethatthecircuitboarddrawspowerfrom
thebatterytochargethecoils on the bolt
solenoidandtochargeupthecapacitorsthat
willcontinuetopowerthebolt solenoid after
thecircuitboardstopsdrawingpowerfrom
thebattery.
Example.Theboltfiresfor55milliseconds
and the Bolt Draw Enable dwell is set for 20
milliseconds.Thismeansthatduring the 55
millisecondsthattheboltisactivatedthe
batteryisonlysupplyingpower to the solenoid
forthefirst20millisecondsoftheboltcycle
therestisfromthecapacitors.
•Bolt release: 25ms
TheBOLTRELEASEis the amount of time
aftertheboltsolenoidhas turned off forthe
bolttoreturntotheclosedpositionloadinga
paintballintheprocess.Thissetting allows
thebolttocompletelycloseandseal the ball
intothebarrelofthemarker. If this time is set
tooshortthemarkermayskipduringhighrate
offire(ROF)andtheeffectiveness of the ball
shotwilldropoff.Youshouldneverhave to
changethissetting.
Thesoftwarewillcalculatethe max rateoffire
withthedwell settingsyouhavechosen.
Thesenumberscontroltherate of fireofthe
Excalibur®(patpend).Youcanchange these
numbersdirectlytochangetherate of fire.
VIKING™ factory dwell parameters:
•Hammer drive: 17ms
TheHAMMERDRIVEisthe total amountof
timethatthehammer solenoid staysturnedon
pushingthehammerforward againstthe
Tornado®(Pat # 5791328)valvethusalso
openingthevalveandreleasingairtoshoot
thepaintball.
****NEW, READ CAREFULLY, NEW****
•Hammer Draw Enable: 17ms
This is a new type of dwell setting not
seen before in an electronic paintball
marker. Thissettingisusedwithanew
featurethathasbeenaddedtothecircuit
boardthatincreasesbatterylife.This dwell
settingisusedin conjunction withthehammer
drivedwellsettingto control theamountof

timethatthecircuitboarddrawspowerfrom
thebatterytochargethecoilsonthe solenoid
andtochargeupthecapacitorsthatwill
continuetopowerthesolenoidafter the circuit
boardstopsdrawingpowerfromthebattery.
Example.Thehammerfiresfor17
millisecondsandtheHammerDrawEnable
dwellissetfor10milliseconds.Thismeans
thatduringthe17milliseconds that the
hammerisactivatedthebatteryis only
supplyingpowertothesolenoidforthefirst10
millisecondsofthehammercycletherestis
fromthecapacitors.
•Hammer release: 60ms
TheHAMMERRELEASEistheamountof
timethatthebolttakestoretractandallowa
balltodropintothechamber.
Thesoftwarewillcalculatethe max rateoffire
withthedwell settingsyouhavechosen.
Thesenumberscontroltherate of fireofthe
Viking™(patpend).You can change these
numbersdirectlytochangetherate of fire.
Dwell adjustments:
To change thefiringparametersof the marker,
firstmakesurethemarkerisunloaded,de-
gassedandturnedoff.Refertothe
programmerinstructions.
Warp Feed and Intella feed:
TheWarp Feed andIntella-Feedportsallows
youtoattachthe Warp Feed systemfromAir
GunsDesignsand/or anIntella-Feedstyle
systemtoyourhopper.Ifasecondboardis
designed to go into a VL loader that will use
thesamesignalastheWarp Feed system but
runtheVLloaderoffof its own powersupply
thiswillgive youanIntella-feedsystem.
Removing the circuit board:
To remove thecircuitboard,simplyremove
thetwoscrewsholdingthegripframeand
gripplateontothe marker body.Thencarefully
pullthegripassemblystraight away fromthe
markerbody.Therearetwolocatingpinsin
the grip plate so the grip plate and grip cannot
movesideways.Thisiswhythe grip assembly
mustbepulledstraightaway fromthemarker.
Thencarefullyunplugthetwosolenoidvalves
fromtheconnectorsocketsonthe circuit
board. Place the marker body to the side.
Removethetwoplasticscrews that holdthe
circuitboardtothegripplate.Carefullylift the
circuitboardoutofthegripplate.Unplug the
plugsfromtheconnectorsocketsthat are for
thetriggerswitch,batteryconnector, LEDand
on-offswitch.
Whenpluggingtheconnectors back in,the
orderfromthebackendoftheboardmoving
forwardisasfollows. Theon-offswitch,then
thebattery,andfinallythe triggerswitch.
Whenconnectingthesolenoids thethree-pin
connectoristheboltandthetwopin
connectoristhehammer.
Becarefulnottopinchorbindthewires.On
the battery cable it is best to make a loop and
thenlaytheloopon the sideofthebattery.
Thiswillreducethe movementofthebattery
andkeep the wires from getting damaged.

V. MAINTENANCE.
A.CLEANING.
Aclean marker is a happy marker.Thebarrel
ontheEXCALIBUR®andVIKING™can be
cleanedduringagamebyeitherunscrewing
thebarrelfromthemarker or by removingthe
boltandswabbingthroughthe marker andthe
barrel.
Theboltcanbefield-strippedfromthe
EXCALIBUR®andVIKING™while the
markerispressurizedwithgas.Thisallows
youtocleanthemarker and oiltheboltwhen
needed.
TheExcalibur®and VIKING™shouldbe
cleanedexternallyusing acottoncloth.
Allexternaland internalmovingpartsshould
belubricatedusinglightsynthetic oilonly. Oil
can be added by placing a few drops in the
inputquickdisconnectonthe
SIDEWINDER®(patpend)regulatorand then
dryfiringthegun.Afew drops should alsobe
placedontheo-ringsonthe Lightning bolt.
This should be done every time you play,
and the bolt should be oiled throughout
the day of play.
Recommendedlubricants:Extreme-lube from
AKALMPorPalmerPursuitspaintballgunoil.
Under no circumstances should you use
Vaseline, WD-40, Grease of any kind (ie.
NO DOW 33), Engine Oil, 3-in-1, gun oils,
and any similar oils. If you have a
question about the type of paintball gun
oil you are using e-mail us.
Theelectronicsareprotectedagainst
moisture,buttheEXCALIBUR®and
VIKING™electroniccomponents should
neverbe immersed in water or damage may
occur.
AllthethreadsontheEXCALIBUR®and
VIKING™areAmericanthreads.All
setscrewsareAmericansizes.
If the EXCALIBUR® is to be stored for more
thenafew months,removethevalve spring.
Thiswillincreasethespring’slifespan.Itisa
good idea to do this with both hammer and
valvespringsonanypaintball gun that istobe
storedforalongtime.
B. SIDEWINDER®(Pat Pending)
REGULATOR.
TheSIDEWINDER®(PatPend)regulator was
originallydesignedspecificallyforuseonthe
EXCALIBUR®becauseofitsextremelylow
operatingpressureofapproximately140-180
psi.Thisregulatorwill work wellonotherguns
also.Thedesignoftheregulator permits the
airhosetobeconnectedtotheguninany
locationtheuserwisheswithina360degree
circlearoundthebaseofthe regulator,while
stillallowingtheregulator tobeexternally
adjustedfromthebottom.Thetopendcapof
theregulatorcanbereplacedwith different
lengthonestoallow the usertoadjusttotal
lengthofthe reg.
SIDEWINDER®(pat pend) Specifications:
•Model: SIDEWINDER®(patpend)
•Version: B
•Gas Source: Compressed air, Nitrogen or
CO2
•Length: 4.875inches
•Width: 1.00 dia main body/1.125 dia
swivelsleeve
•Weight: .275lbs(Withquickdisconnect)
•Externally Adjustable Output Pressure:
0-700PSI
•Input pressure: 0-900 PSI
Adjusting the SIDEWINDER®(pat pend)
Regulator:
Decrease output:

Lookingattheregulator from thebottom,turn
theallenwrenchclockwisetodecrease the
pressure.
Increase output:
Lookingattheregulator from thebottom,turn
theallenwrench counterclockwiseto
increasethepressure.
Dead Zone:
SincetheSIDEWINDER®(patpend)
regulatorwasdesignedtogodowntozero
psioutput,thereisspaceafteritreacheszero
thattheadjuster screwcanbeturnedfarther. If
youturntheadjusterscrewgently untilit
bottomsout,thenitwillbe 3 to 4turnscounter
clockwiseuntilthepressurestartstorise
again.Thisisthedeadzone.
Side Notes and Troubleshooting:
Remembertoshootthegunseveral times
afteranyadjustment tothe
SIDEWINDER®(patpend)regulatorso you
canmakesurethevelocity stabilizes.
Iftheregulatorcreepsin pressure range,
check to make sure there is not a piece of
debrisinbetweentheregulatorseatandthe
regulatorpiston.Ifitcontinues to creep
replacetheregulatorcore.
Iftheregulatorspressure dropsandthen
slowlycreepsbackupthereg.seatmayneed
to be replaced.
WhenusingtheSIDEWINDER®(pat pend)
withCO2youwillhaveto oil the regulator ona
moreregular basis. The CO2 carries the oil
awayfromthemoving partsquickly.
Makesuretheventholeontheside of
regulatorbodymiddleisopenandclean.Ifit
ispluggedtheregulator willnotfunction
properly.
TheSIDEWINDER®(patpend)regulator is
onlydesignedforamaximum input pressure
of 900 psi.
Useonlysteelbraidedhoseandstainless
steelquickdisconnectsorMacro-line.Micro-
linerestrictsairflowandisunsafeforusein
paintball.
Disassembly of SIDEWINDER®(pat pend)
Regulator:
Toproperlydisassemblethe
SIDEWINDER®(patpend)regulatorand not
scratchtheoutside,youwillneed a few items:
Two piecesof 2x4s about 4 inches long, a
clothstrapwrenchwhich can purchasedata
hardwareorautomotivestore,abenchvise,a
goodadjustablewrenchandasetofallen
wrenches.Thestrapwrench can beusedon
manydifferentthingsoutsideofpaintballso its
handytohavearound.Justfollow the
instructionsanditwillbeeasy.
1.Removeallairsources.
2.Clampingthereg.upsidedown.Clampthe
reg.bodyupperandreg.middlebetweenthe
two pieces of wood. The wood will keep the
regulatorsoutsidesurfacefromgetting
scratchedup.
3.Usingtheadjustable wrenchontheswivel
nutun-screwthe swivelassemblyfromthe
bottomoftheregulator.Onceloose,unscrew
thetwopieces.Becarefulnottolosethereg.
washerthatisinsidethisportionofthe
regulator.
4.Reclamptheregulator between thetwo
piecesofwood,clamp on the reg. body upper.
Usingthestrapwrenchloosen the reg.body
middlefromthereg.body upper. Inspectthe
o-rings for damage or wear. Replace if
needed.
5.Oncethetwohalvesare separated you can
removethepistonandspringsfromthe
regulatorbodymiddle.Becarefulnotto
damagethepistonortheo-rings.Remember
inwhatorderthepartscameoutofthe
regulator.Replaceo-ringsorspringsif
needed.
