Shelti Blue Line Hockey Breakout User manual

Assembly Instructions
Tools Required:
13 mm Wrench or Socket (Included)
5 mm Hex Wrench (Included)
Phillips Head Screw Driver
Level
Step #1
• Lift dome hockey cabinet out of the box and lay it on its side on a smooth surface.
•
Remove the legs from box and locate the accessory package
Contents Part Number Quantity
Dome Hockey Cabinet EM-DPA-0 1
Universal Leg Assembly EM-ULA-0 4
Accessory Package EM-ASA-0 1
Assembly Instructions 210-0154-0 1
Accessory Package Contents Part Number Quantity
5½" Carriage Leg Bolt 301-0074-0 4
4
¾
" Carriage Leg Bolt 301-0073-0 4
Leg Washer 303-0035-0 8
Leg Nut 203-0023-0 8
Hex Wrench - 5 mm 205-0068-0 1
Hex Wrench - 4 mm 205-0057-0 1
13 mm Wrench 1
8 mm Wrench 1
Electronic Scoring Unit 210-0180-0 1
Power Supply Adaptor 6v 210-0183-0 1
Flat Head Screw - Phillips Head M3x14 mm 301-0044-0 2
9/16 Washer - M6 303-0026-0 2
Nut - M5 302-0016-0 2
Rounded Head Screw - Phillips Head M3x14mm 301-0045-0 1
Washer - M5 303-0027-0 1
Dome Hockey Puck (1" dia.) 201-0018-0 3
Thank you for purchasing a Shelti product. All of us at Shelti want you to be completely satised with your
Breakout Dome Hockey game, so feel free to contact us for help with the assembly of your product, Shelti parts,
or other information you may require

Step #5 - Attach the Electronic Scoring Unit
Bolt the scoring unit to the
black brackets on the side of
the dome using the (2) nuts, (2)
washers and (2) bolts provided.
Slip the bolt through the hole
on the scoring unit and then
through the black bracket as
shown. Tighten with a phillips
head screwdriver and cresent
wrench. The scoring unit can
also be attached with a screw
and washer through the front of
the unit. Slip the screw through
the small hole in the dome from
the inside and tighten.
Locate the two
wires coming out
of the hole located
on the hinge
side of the dome.
Plug them into
the scoring unit
as shown. If you
scoring during a game
and the wrong team gets
credit, simply switch positions of the two identical cords.
The scoring unit can be powered either by using the AC
adapter provided and plugging it into a standard 110 outlet
or use (4) AA batteries (not included).
Step #6 - Operating the Scoring Unit
Turn the power switch to “on”. Select desired game option.
By default, it begins with the 15 minute game option. To
change the game option, push the “select” button. There
are seven total options including “Free play” which has no
time limit or scoring limit. After choosing a game option,
push the “Start” button to begin. To start over, press the”
Reset / Start” button again. The volume switch has three
settings: High, Low and O.
Step #2 - Attach the Legs
The narrower side of the leg should face the rod side
of the cabinet. Align the holes of the bottom two legs
and attach the enclosed carriage bolts, washers and
nuts. The longer (5½”) bolt attaches throught the
rod side of the apon and requires a 5mm hex wrench
for the bolt and a 13mm wrench or socket for the
nut. Tighten until bolt heads are snug with the table
surface. Over tightening could damage the side walls.
Align the top two legs and attach using the enclosed
carriage bolts, washers and nuts as shown.
Carefully rotate table 180˚ on
to it’s opposite side. Attach
remaining carriage bolts,
washers and nuts as shown.
Step #3 - Flip Over Table
Carefully lift up and rotate table on to its legs. Do not
allow weight of table to rock on any one or two legs
alone. Attach remaining carriage bolts, washers and
nuts as shown.
Step #4 - Thread the Power Cord (Optional)
Use the black rubber tube sticking out of the table to
help you “snake” the AC power cord through the table.
Push in the smaller end of the
AC power cord into the rubber
tube on the bottom of the table.
Now you can carefully pull on
the rubber tube through the top
of the cabinet. The power cord
should make it’s way through the
hole. This will allow you to plug
in the scoring unit later without
the cord hanging down the side
of the cabinet.
333 Morton Street
Bay City, Michigan 48706
Phone: [phone]
Fax: [phone]
www.shelti.com
[email protected]
