Akoustyx R-100 User manual
Installation
In-Ear Monitors
MMCX Detachable cable
In the Box
In-ear Silicone Gels
Freebit ® ear interface
SM L
2-Flap
Ballistic Nylon
Storage Case
SML
Select the right size ear interface
®
Concha bowl
Small = Concha bowl height (h) less than 1”/25 mm
Medium = Concha bowl height (h) 1”/25 mm
Large = Concha bowl height (h) more than 1”/25 mm
h
Outer-ear gel
10.5cmx 22.2cm
Basic
Customized Fit
After the initial installation, select the most suitable
in-ear silicone gel or Memory Foam tip to get the best
customized fit
K
Or
R-100 User Manual
Premium Memory
Foam Tips S,M,L
SM L
Wearing
Secure the cable over ear
12
Memory Foam TIP INSTRUCTIONS
HOW TO INSTALL/USE
HOW TO CLEAN
Using only water, gently wipe with a clean, damp cloth.
Let the tips dry completely before use.
To install, firmly hold the Memory Foam tip between your thumb and forefinger. Place
the sound port into the core of the tip at a slight angle. Once the tip engages onto the
sound port, straighten out the tip and push the tip as far back as it will go.
Before inserting into the ear canal, roll the tip between your fingers to compress the
foam. Insert the tip as deep as possible without irritating the ear. Hold in place for 15-30
seconds, allowing the tip to expand and conform to your ear canal. This will create a
custom fit and perfect seal - providing an optimal audio experience.
Freebit ear-interface is licensed under patents EP2434777, US8630436 and corresponding international patents.
© Artists images courtesy of Mopho, Portugal.
"Akoustyx" & the "Akoustyx logo" are registered trademarks of Akoustyx LLC, registered in the U.S. and other countries.
This is a patented product design & is protected by patents in the U.S. & other countries.
© 2022 Akoustyx LLC. All rights reserved.
Move the slider to the
base of the back of the
neck for a secure fit
3
WARNING:
HEARING LOSS IS IRREVERSIBLE. LISTENING AT HIGH VOLUME LEVELS FOR EXTENDED
PERIODS CAN CAUSE PERMANENT HEARING DAMAGE. ALWAYS LISTEN AT A REASONABLE
AUDIO LEVEL TO AVOID HEARING DAMAGE.
DO NOT USE THESE IN-EAR MONITORS IN ANY ENVIRONMENTS WHICH REQUIRE YOUR
ATTENTION SUCH AS TRAFFIC OR OPERATING MACHINERY.
THIS PRODUCT DOES NOT CONTAIN ANY USER SERVICEABLE PARTS. ANY MODIFICATIONS
AND/OR TAMPERING WITH THE PRODUCT AND/OR PROVIDED ACCESSORIES WILL VOID THE
WARRANTY.
Driver
Sensitivity
Studio Reference Balanced Armature
115dB
Impedance 22Ω @ 1kHz
Frequency Response
Cable Length
15-22,000Hz
1.2M (4.0 ft)
SPECIFICATIONS
Insert the monitors slightly
backwards & turn forward as
shown. If using Freebit
interface, lock the extended
part in to the cymba-concha
flap for a secure fit
Designed in the Bay Area, California. Assembled & tuned in Nashville, Tenessee.
Made in USA of U.S. and imported parts.
* Specifications subject to changes without prior notice
www.akoustyx.com
