April 17, 2020
PRODUCT NAME: Navigator Pro Valve Controller
AKRON BRASS STYLE NUMBER: 9321, 9333 and 9335
MOTOR DRIVER FIRMWARE UPDATE TO VERSION 1-10
A condition has been reported to Akron Brass where the position of the valve (% Open/Closed) may be displayed
inaccurately after a power cycle. This inaccuracy may be up to 6%. While there is no impact to valve function, the
Akron Brass Company is recommending updating the Motor Driver System Firmware to version 1-10 to eliminate
this possibility.
NOTE: Updating firmware will not overwrite valve assignments, calibrations, or configurations.
To obtain the latest firmware:
Go to the URLs below based on what style number is being updated.
9333
https://www.akronbrass.com/navigator
-
valve
-
controller
-
with
-
tank
-
fill#product_tabs_download
9335
https://www.akronbrass.com/navigator
-
valve
-
controller
-
with
-
pressure
-
meter
-
and
-
flow
-
meter-9335#product_tabs_download
1. Select the “Style 9333 & 9335 Navigation Pro System File Rev. 1.5” link and save file “9335001_R1-5.abs to the
root directory of a USB flash drive.
2. Select the “9321 / 6064 Motor Driver System Software 1-10” link and save file “93210001_R1-10.abs” to the
root directory of a USB flash drive.
Update via USB port
1. Turn off power to the 9333/9335 and gain access to the back.
2. Remove the two screws holding the cover over the USB port and remove the cover. Retain for re-assembly after
update.
3. Insert the USB flash drive and turn on power to the 9333/9335 and 9321 Motor Driver
4. The 9333/9335 update will start automatically and may take up to 30 seconds, so do not remove power until
update completes.
5. To update the motor driver, navigate to the setup menu, select OEM CONFIGURATION and the VALVE
DOWNLOAD. Press ENTER. Select YES to download the new file. The display will show download progress and
will prompt you to remove the USB flash drive when completed.
9321
9333
9335

Contact Customer Care PH. 800.228.1161 (330.264.5678) or your Akron Representative for further details
20
-
0
3
6. To verify update completed successfully, navigate to the “About’ screen from the user menu as follows.
a. Press and hold the right gray button under the “MENU” item on the bottom right of the screen. The
“MENU” item on the screen will begin to blink several times then stop. Release the button.
b. The “Root Menu” is now displayed. Press the green “Open” button three times to advance the cursor
down so that the “About” item is highlighted.
c. Press and release the right gray button under the “ENTER” item on the bottom right of the screen. This
will display the “About” Screen that has the firmware information on it. Verify 9321 Motor Driver
firmware is at version 1-10 and 9333/9335 is at 1.5.
7. Replace the USB port cover and fasten two screws securely. Do not overtighten.
Update via AkroView
Refer to the AkroView Diagnostics Firmware Installation and Operations Manual for instructions on how to update
the firmware via AkroView.
If you have any questions, please contact the Akron Brass technical support team at
[email protected].
