Aktobis WDH-AP1212 User manual

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Car Air Purifier WDH-AP1212
Dear Customer,
You have chosen a high-quality product. To ensure that you get a lot of enjoyment from
this product, here are a few more tips:
In case of any problems:
We hope that the unit meets your expectations! If, despite the greatest possible care, there
should ever be cause for complaint, please contact us briefly, as we are very concerned
about your satisfaction and would like to clear up any misunderstanding.

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Important safety instructions:
Do not place any objects on the appliance and make sure that the air intake and the
exhaust air are always free!
Supervise the air purifier when children or animals are near the unit !
Protect the unit from all moisture and wetness !
Only use the recommended voltage for operating the unit !
Do not expose the filters to insect spray, they could later release the insect spray
unintentionally !
Switch off and unplug the appliance if you want to clean it !
Only clean the appliance with mild cleaning agents !
Do not make any independent modifications to the unit or the cables !
Please do not operate the unit while driving !
Please switch off the unit immediately and disconnect it from the mains/power
supply if anything seems to be wrong !!! In this case, please contact a specialist
and do not attempt to repair the unit yourself !!!
Equipment and quality features:
HEPA activated carbon filter combination: The HEPA flow traps and filters particles as
small as 0.0003 mm. This includes pollen, germs, mould spores and dust with a purity rate
of 99 % !
The activated carbon granulate helps to break down many types of smoke and odours (e.g.
cigarette smoke) and also toxic vapours, gases and solvents.
Anion exchanger: Produces approx. 2 million anions per second, which proactively
combat smoke and other dirt particles in the room.
Air sensor: Automatically measures the tendency of the air quality and signals it in
different luminous colours.
2 air circulation levels: Strong & Weak

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Description of the unit parts:
Exhaust
air
Air sensor display
Control knob
Air intake
Filter cover
& stand
base
Filter
12 V (DC connection)
Rubber sole
Reset

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Instructions for use:
1. Preparation and installation of the filters
The car air purifier is equipped with two filters (HEPA-activated carbon combination) from
the factory. First open the lower filter cover by gently pressing in the side panels of the filter
cover with your fingers and then pulling it downwards (open). Now remove the two small
filters. Remove the protective cover of the new filters and then insert them back into the
unit. When inserting the filters, make sure that the white HEPA filter side always faces
outwards ! Finally, put the filter cover back on the unit. Now the car air purifier is ready for
use!
See the charts below:

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
2. Connection / Power supply
Connect the 12 V power cable included in the scope of delivery to the air purifier. Then
plug the other end into the power source (e.g. the cigarette lighter). Make sure that the
cable does not interfere with your driving at any time !
It is best to place the car air purifier in the centre arm console or in the cup holder. The unit
can easily be operated in different positions (standing, lying, inclined). The car air purifier
can then be switched on.
See the charts below:
3. Operation / Settings
The air purifier is completely controlled by the control knob. Press the control knob once
and the air purifier switches on and starts purifying the air with high air circulation.
Press the control knob a second time and the air purifier switches to low air circulation.
Pressing the control button again changes the mode back to high air circulation, etc.
To switch off the air purifier, press the control button continuously for about three (3)
seconds. The air purifier then switches off.
See the charts below:

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
4. The air sensor display
After switching on the air purifier, the unit starts measuring the air quality (tendency)
independently. Please note that the proper air quality tendency is only available after
approx. 2 - 6 minutes. During this phase, the air sensor displays "Purple" by default.
The following air sensor displays are possible on the unit:
5. Filter change
The filters last approximately 1440 hours, after which the air sensor indicator lights up red
and the car air purifier stops air purification operation. This process signals to you that a
filter change is necessary.
Disconnect the air purifier from the power supply.
Change the filter (see detailed description under point 1. "Preparing and installing the
filters").
Then connect the unit properly to the power supply.
Now press the reset button with a paper clip or biros for approx. 3 seconds (see diagram
below). Now the car air purifier is ready for operation again.
Air sensor display
Blue = Very good
Green = Good
Purple = Loaded
Red = Filter change request
Reset

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Technical data:
Model name: WDH-AP1212
Power supply: 12 V / 6 W
Max. Power consumption: 6 W
Max. Air circulation: 2.1 cbm/h
Dimension (H/W/D): 190 x 66 x 72 mm
Weight: 0,3 kg
We reserve the right to make deviations in the technical data!
Troubleshooting:
The unit itself emits an unpleasant odour:
The new air purifier still has a slight odour of its own (fresh plastic, new motor, new paint,
etc.). This new smell will dissipate within a very short time (1-2 weeks)!
The air sensor is causing problems:
1. Remember that the air purifier is not used when it is in a draught (e.g. between two
open windows).
2. In very rare cases, the air sensor may react negatively to certain substances (e.g.
polish, perfume, etc.) in your vehicle compartment. In these cases, you should ignore
the air sensor display.
It takes too long to neutralise smoke and/or odours:
In general, our air purifier is well suited for odour and smoke neutralisation. But please note
that the result/end result of our air purifier always depends on how much odour particles
are flowing in and how the air circulation is at your place !
This is because the inserted filters always absorb only a part of all odour particles per
pass. Therefore, one specifies at least three filter passes until all odour particles are
absorbed.
(Note: When filtering dust and particles, one filter pass is sufficient to clean the air, as all
particles are retained in the fine filter = 99% effectiveness. In the case of odours, the
activated carbon part of the filter is
mainly used and here the filter medium needs approx. three filter cycles per sqm³ of air
until one can speak of clean air = 33% effectiveness !!)
Furthermore, it is also important to consider that odour patterns can already be present in
the inventory (upholstery) - and depending on the nature of the individual materials, it can
take a considerable amount of time until these have released the odours again.
(The WDH-AP1212 car air purifier only eliminates odours that are circulated or filtered
through it).

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
The unit does not respond / The unit cannot be switched on:
1. Check whether the unit is properly connected to a power source and whether it is
currently supplying power. Especially in vehicles, it often happens that the power is
only available when the ignition is activated.
2. Check whether the filter change indicator lights up. If so, change the filters and then
press the rest button (see point 5. of the instruction manual).
Other:
Declaration of guarantee
Notwithstanding the statutory warranty claims, the manufacturer grants a warranty in
accordance with the laws of your country, but at least 1 year (in Germany 2 years for
private individuals). The warranty begins on the date of sale of the appliance to the end
user.
The guarantee only covers defects that are due to material or manufacturing faults.
Warranty repairs may only be carried out by an authorised customer service. To make a
warranty claim, please enclose the original sales receipt (with date of sale).
Excluded from the guarantee are:
- Normal wear and tear
- Improper applications, such as overloading the appliance or non-approved
accessories.
- Damage due to external influences, use of force or foreign objects
- Damage caused by non-observance of the operating instructions, e.g. connection to
an incorrect mains voltage or non-observance of the assembly instructions.
- Completely or partially dismantled units

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Conformity:
The air purifier has been tested and itself and/or parts thereof have been manufactured
under the following (safety) standards:
CE (EMC) conformity, of course.
Conformity tested according to: EN 50498:2010
EMC Directive 2014/30/EU
Correct disposal of this product:
Within the EU, this symbol indicates that this product should not be
disposed of with household waste. Waste equipment contains valuable
recyclable materials that should be recycled. Furthermore, the environment
or human health should not be polluted by uncontrolled waste disposal.
Please dispose of
Therefore, dispose of old appliances via suitable collection systems or send
the appliance for disposal to the place where you bought it. They will then
recycle the appliance.
I wish you much pleasure with this appliance.
Keep these instructions for use in a safe place !
