Aktobis WDH-898MD User manual

MODEL:WDH-898MD
WDH

I. FEATURES
The Intelligent Dehumidifier uses Peltier technology
(no compressor) which makes it light and quiet. It is perfect
for small rooms. Poor ventilation causes musty odour and
fungus in wardrobes, Iarder, etc. The Intelligent Dehumidifier
eliminates this problem by keeping them free of unwanted
moisture.
(1) On/Off button
(2) ‘On’ Green LED
(3) ‘Full’Yellow LED
(4) Air inlet
(5) Removable water tank
(6) Dry air outlet
(7) Handle
(8) DC power socket
(9) Rubber feet
(10) AC/DC switching mode power supply
(11) DC power jack
(12) AC plug with power cord
(Plug type is subject to market)
(13) Water displacement hole
(14) Float switch
To avoid electric shock. Do not open. There are no user-
serviceable parts inside.
Any repair work must be done by qualified technician
appointed by our distibutors.
Specifications are subject to change for improvement
without prior notice.
2
NAMESANDFUNCTIONOFPARTS
5
9
10
12
11
1
4
7
8
13
14
6
2
3

III. CONNECTION
II. SPECIFICATIONS
1. After removing the packaging materials, there
should be 2 items:
a.
Intelligent Dehumidifier
b. AC/DC switching mode power supply
2. Plug the DC power jack (11) of the switching mode power supply to
the DC Power socket(8), then connect the AC plug(12) of the
switching mode power supply to the appropriate main socket.
Press the “On/Off” button (1) to “On” position, The Intelligent
Dehumidifier will begin to operate. The green LED will be
turned on. Listen and feel for the air blowing from dry air
outlet. [as Fig.1]
TO switch off the unit, press “On/Off” button (1) to Off”
position, the Intelligent Dehumidifier will be turned off. [as Fig.2]
3
6Amp
72W
223mm(W)×351mm(H)×181mm(D)
750
IV. REMOVABLEWATERTANK
When the water tank is full, with approximately 1.5 litre of
water collected, the unit will be switched off automatically
and the “Yellow” LED(3) will be on.[as Fig.3]
To remove the water tank, first switch off the Intelligent
Dehumidifier, press “On/Off” button to the “Off” position.
Then, remove the water tank from the unit and pour the
water out to the toilet or bathroom. Put the water tank
back into the unit. To continue dehumidifying, press the
“On/Off” button to “On” position again.
4
Fig.3
Fig.1 Fig.2

VI. CAUTIONS
1. After having finished using the Intelligent Dehumidifier,
the user should switch the unit off by pressing the
“On/Off” button to “Off” position.
2. Avoid using the AC/DC switching mode power supply
in wet or damp place. Position it in areas where the
air ventilation is good.
3. Keep the front inlet grill and the side outlet free from
air blocking materials such as clothing, plastic bag
or paper.
4. If the unit has been properly connected and no power
is flowing, have the AC/DC switching mode power supply
checked by a qualified electrician.
5. Always keep the unit at an up-right position to avoid
water leakage.
6. The thumb should be placed at the top centre of the
unit while lifting by the Handle(7), to avoid tilting. At the
same time, the other hand should be holding the base
to secure the unit.[as Fig.4]
56
Before cleaning the unit, turn off the Intelligent Dehumidifier
and unplug the AC plug from the main socket first. Use
a piece of soft cloth to clean the surface of the product
or use a brush to wipe the dust off the grills of the air
inlet(4) and air octlet(6).
V. CLEANING
Fig.4Fig.4
