Akyga AK-ND-69 User manual

AK-ND-69 - user manual
/ak-nd-69
www.akyga.com
>80%
Short description of the product
The product is compatible with the applicable national and European requirements.
What is in the box?
- AK-ND-69 power supply
- Short user manual
Symbols explanation:
There is a risk of losing health or life (e.g. by electic shock).
There is a particular danger connected with service.
Important tips and information.
Product accordance with the EU directive 2002/96/EC. The symbol of the crossed out basket
placed on the product means that the marked product can not be disposed of with other
household waste. After use, the product must be return to collection point for used electical and
electronic equipment or to the seller. Appropriate segregation of rubbish for subsequent
processing, recovery or descrution contributes to avoiding negative effects on the environment
and health, and also allows the recovery of raw materials from which the product is made.
p. 1
The CE standard description on the product is the manufacturer's declaration that the marked
product meets the requirements of the directive so-called The "New Approach" of the European
Union (EU). For security and certification (CE) reasons, the device can not be rebuild or change
in any way. In the reason of using the power supply for other purposes than those described,
the product may be demaged. The incorrect use may also cause hazard such as short-circuits,
burns, electric shocks, etc. Read the users manual carefully and keep it for later use. The product
could be share to third partie only with the user manual included.
The Akyga AK-ND-69 power supply is used he to deliver power to HP notebook with direct current. T
45 W power supply is compatible with all 19.5 V/2.31 A nootebooks models with 4.5 x 3.0 mm + pin plug.
A set of protectors OVP, OTP, OPP, SCP, OCP and the soft start technology provides safe and stable
work of both power supply and powered device.
The power consumption of powering nootebook can not exceed the power supply nominal current.
The product is adapted to supply voltage in the range of 100-250V, 50/60Hz.
EC
BOX
Ecological Solutions
GREEN
notebook power supplies
The RoHS mark on the product is the manufacturer's declaration that the marked product meets
the requirements of the EU Restriction of Hazardous Substances (2002/95/EC) directive, which
aims to reduce the amount of hazardous substances penetrating into the environment from
electrical and electronic waste.

AK-ND-69 - user manual
p. 2
Safety Precautions
WARNING! Product heats up during operation. To reduce the risk of burns or overheating the power
supply, do not place it in restricted ventilation area. Also, do not allow the working power supply to touch
soft surface such as pillows, blankets or clothing. The power supply meets the limits on the surface
temperatures available to the user, as defined in the International Standard for Safety of Information
Technology Equipment (IEC 60950).
Connecting notebook whose demanded power is greather than power of the power supply, can cause
battery failure or even damage (burn) of power supply.
An electrostatic discharge occurs when two object touch each other, for example, an electric
charge that occurs when user touch metal door handle after walking on a carpet . Discharging
electrostatic charges from fingers or other electrostatic conductors can damage electronic
components. To avoid damaging the computer, abstain from touching electrical outlets, wires and
electonic circuits. The user’s contact with electronic components should be kept to a minimum.
The II protection class device. It provides protection against electric shock against direct and
indirect contact, and thanks to the additional isolation it is not necessary to connect the device
case with the protective earth conductor.
The device is intended only for domestic use, indoors.
The manufacturer of the product is not responsible for damage or insults caused in effect
of disobey the safety instructions and informations contained in these user manual.
źConnection of the power supply to electricity is done by connecting cable with the IEC C6 plug
to power supply with IEC C5 connector and then connecting appropriate plug to grounded
electrical outlet.
źShort-circuiting the current connection is prohibited.
źProduct and power cord should not be touched with moist or wet hands under no
circumstances.
źIf the product has been damaged, does not work properly or has been stored for a long period
of time in bad or unfavorable conditions, safe operation of the device is not possible. It is
essential to stop using the product and to protect it against re-use for security purposes.
źThe product operation in adverse conditions is not allowed. Adverse conditions are primarily:
exposure to direct sunlight, high or very low ambient temperatures, strong vibrations, high
humidity, surrounds of gases, dusts or flammable and aggressive liquids.
źBefore connecting the adapter to the mains socket, make sure that the voltage specified on the
power supply matches voltage supplied to the household socket.
źMake sure that the power cord is not crushed, bent, twisted, rubbed against sharp edges or
mechanically loaded in any other way. Avoid thermal load of the cable - in particular keep away
from heat sources (such as stoves, radiators, fireplaces).
źIt is forbidden to apply the mechanical load to the product - strong shocks, impacts, dropping or
crushing may cause its damage.
źPower cords should be laid in such a way as to eliminate the risk of stumbling or hooking over.
źIts forbidden to modify the power cord. In the case of modifications, the cable may be
damaged, causing threats to life, health and property.
źKeep the product and the packaging out of range of children and animals. The package
includes a foil that child could choke while playing.
notebook power supplies

AK-ND-69 - user manual
p. 3
źMains plug should be disconnect from power socket if the product is not in use for a long time.
źWhen disconnecting the power cord from the socket and from the device, do not pull on the
cord, but only on the part of the cable plug provided for this purpose.
źIn case of any doubts regarding operation, safety or connection of the product, please contact
the manufacturer or a qualified specialist for this purpose.
źAll maintenance, adjustment and repair work on the product may only be carried out by a
qualified person in a specialist facility.
Problem
Cause
Solution
A laptop connected to an
electrical outlet via
power supply does not
work
No mains voltage
źCheck the mains fuses
źCheck the correct connection of
the power supply to the mains
socket
The power supply is
overloaded
źDisconnect the power supply
from the laptop, check the
correctness of the current
parameters
There is a suspicion of a
product defect
źStop using and contact the
seller
A laptop connected to an
electrical outlet via
power adapter does not
charge the battery or
displays a message
about the non-genuine
charger
The power supply does
not correspond to the
current parameters
źDisconnect the power supply
from laptop and check if current
parameters are correct
źContact with seller
Removing the most common problems
notebook power supplies
3. Connect the power supply connector to the nootebook.
4. Turn on the notebook.
2. Connect power cord to the electrical socket.
1. Select and connect the appropriate connector to power supply.
Preparing the Power Supply for Use:
Cleaning the power supply
źDo not use abrasive or chemical cleaners.
źUse soft and antistatic cloth for cleaning the power supply.
Disconect the power supply from the electrical socket and connected devices before cleaning.

AK-ND-69 - user manual
p. 4
Technical specfication
Product manufacturer: Akyga Europe sp. z o.o.
ul. Wrocławska 1c
52-200 Suchy Dwór
notebook power supplies
Product code:
Supply voltage:
Output voltage and amperage:
Maximum power:
Efficiency:
OVP (over voltage protection) :
OCP (over current protection) :
OPP (overpower protection) :
OTP (over temperaturre protection) :
SCP (short circuit protection) :
Soft start:
Power inlet:
Output connector:
Compilance with standards:
EAN code :
AK-ND-69
100-250V, 50/60Hz
19.5 V / 2.31 A
45 W
>80%
Yes
Yes
Yes
Yes
Yes
Yes
IEC C6
4.5 x 3.0 mm + pin
CE, FCC, RoHS
5901720135810
