Description
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
2
1. Description
1.1 Function
Digital input module MV110-16DN is an expansion module with 16 digital inputs.
The module has the following functions:
–Connecting peripheral devices with digital outputs
–Interpretation of digital signals
–Pulse counter (see 1.2)
–RS485 network state diagnostics
–Generating corresponding fault and alarm signals
–Slave in Modbus network
The module supports Modbus RTU, Modbus ASCII protocols with automatic protocol
identification.
The module is to be configured using ‘M110 Configurator’ software via RS485-USB inter-
face adapter IC4 (not included). The latest version of the configuration software is availa-
ble for download on www.akytec.de.
1.2 Counter function
The module also has the ability to use all of its inputs as fast 16 bit counters with a count-
ing frequency of up to 1 kHz. The minimum pulse width is limited to 0.5 ms. Pulses of
higher frequency or of shorter duration are ignored. The counter is responsive to any
rising edges.
When switching off power, the actual count state remains retained in permanent memory.
The counter is set to 0, if it has been reached an overflow, and counting continues.
The module has a debouncing function. This function can be activated for each input by
setting tin.c (debouncing filter) to "On" when making configuration of device parameters
(see Table 5.1). The function is recommended at signal frequencies up to 90 Hz and if
the duty cycle is 50% and more.
1.3 RS485 network
I/O modules of Mx110 series use common standard RS485 for data exchange. RS485
serial interface is based on two-wire technology and half-duplex mode. Protocols Modbus
RTU, Modbus ASCII and akYtec are supported. The network consists of a master device
and can contain up to 32 slave devices. The maximum length is 1200 m. The number of
slave devices and the network length can be increased using a RS485 interface repeater.
Devices are connected to a network according to linear (bus) topology. It means that the
line goes from the first device to the second one, from the second one to the third one,
etc. Star connections and spur lines are not allowed.
Line reflections always occur at the open bus ends (the first and the last node). The high-
er the data transmission rate, the stronger they are. A terminating resistor is needed to
minimize reflections. Experience proves that the most efficient practice is to use terminat-
ing resistors of 150 ohm.
The module can be used as slave devices only. Master device can be PLC, PC with
SCADA software or control panel.
1.4 Construction
─Enclosure: Plastic, grey, for wall and DIN rail mounting
─Terminal strips: 2 extractable terminal strips with 20 screw terminals each
─LED „POWER“: power supply
─LED „RS-485“: blinks when exchanging data at serial port
─LED „FAULT“: lights up when the data exchange process on serial port is bro-
ken
─16 LEDs „INPUTS“: light up, when at relative input is 1

Description
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
3
Fig. 1.1 Front View
Dimensions are shown in Appendix A.
Under the cover on the front panel of the module there are three jumpers (refer to Fig.
4.1):
─X2 Factory settings recovery (see 6)
─X3 Service function
─X1 Hardware write protection of permanent memory (see 4.1.1)
All 3 jumpers are not inserted as supplied.
432
10 11 12
14 15 16
876
1
5
9
POWER
RS-485
FAULT
INPUTS
INPUTS
MV110-24.16DN
13

Specifications
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
4
2. Specifications
Table 2.1 General technical data
Power supply
24 (20…28) V DC
Power consumption, max.
6 W
Inputs
Digital
16
Analog

Outputs
Digital

Analog

RS485 interface
Connection
D+, D-
Protocols
Modbus RTU / ASCII, akYtec
Baud rate
2.4…115.2 kbit/s
Data bits
7, 8
Parity
even, odd, none
Stop bits
1, 2
Dimensions
63 x 110 x 75 mm
Weight
approx. 240 g
Material
plastic
Table 2.2 Technical data of inputs
Property
MV110-16DN
Input signal
Switch contact
NPN/PNP
Galvanical isolation
1500 V, in groups of 4
Pulse frequency, max.
1 kHz
Pulse length, min.
0.5 ms
Integrated voltage source
24±3 V
Current, max.
8.5 mA (with 27 V)
Logical „1“, min.
4.5 mA
Logical „0“, max.
1.5 mA
Lead resistance, max.

2.1 Environmental conditions
The module is designed for natural convection cooling. It should be taken into account
when choosing the installation site.
The following environment conditions must be observed:
─clean, dry and controlled environment, low dust level
─closed non-hazardous areas, free of corrosive or flammable gases
Table 2.5 Environmental conditions
Condition
Permissible range
Ambient temperature
-20…+55°C
Transportation and storage
-25…+55°C
Relative humidity
up to 80% (at +25°C, non-condensing)
IP code
IP20
Altitude
up to 2000 m above sea level

Safety
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
5
3. Safety
Explanation of the symbols and keywords used:
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, could
result in minor or moderate injury.
►
NOTICE
NOTICE indicates a potentially harmful situation which, if not avoid-ed, may re-
sult in damage of the product itself or of adjacent objects.
3.1 Intended use
The device has been designed and built solely for the intended use described in this
guide, and may only be used accordingly. The technical specifications contained in this
guide must be observed.
The device may be operated only in properly installed condition
Improper use
Any other use is considered improper. Especially to note:
─This device should not be used for medical devices which receive, control or other-
wise affect human life or physical health.
─The device should not be used in an explosive environment.
─The device should not be used in an atmosphere with chemically active substance

Installation
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
6
4. Installation
WARNING
Improper installation
Improper installation can cause serious or minor injuries and damage the de-
vice. Installation must be performed only by fully qualified personnel.
–The module is designed for DIN rail mounting in a control cabinet or for wall mount-
ing.
–The mounting enclosure must provide a clean, dry and controlled environment. For
further requirements refer to the subchapter 2.3.
–The device has been designed for natural convection cooling. Make sure that the
cabinet provides sufficient clearance for natural convection.
4.1 Wiring
WARNING
Dangerous voltage
Electric shock could kill or seriously injure.
All electrical connections must be performed by a fully qualified electrician.
Ensure that the mains voltage matches the voltage marked on the nameplate!
Ensure that the device is provided with its own power supply line and electric
fuse!
►
NOTICE
Switch on the power supply only after the wiring of the device has been com-
pletely performed.
–Electrical connections are shown in Fig. 4.1 and pin assignments are shown in Table
4.1.
–Connection variants for different signal types are shown in Fig. 4.2 –4.4.
–Connect power supply to the 24V / 0V terminals.
–The maximum conductor cross-section for power supply is 1.5 mm2
►
NOTICE
EMC-safety
Signal cables should be routed separately or screened from the supply cables.
Only shielded cable may be used for data transmission and signal lines.
Shield in the control cabinet for best electromagnetic immunity recommended.
–Connect the RS485 line to the terminals D+ and D-.
–Use twisted pair cable for RS485 connection. The length of the line should not ex-
ceed 1200 m.
4.1.1 Hardware write protection of permanent memory
The data in permanent memory may be lost because of strong electromagnetic interfer-
ences or similar conditions.
The jumper X1 (hardware write protection) makes it possible to avoid data loss.
The following steps are required:
–Switch off the power supply
–Open the cover on the front panel of the module (see Fig. 4.1)
–Put the jumper X1 in the position “closed”
Thereby the following is to observe:
–To change the configuration parameters, the jumper X1 must be removed again.
–As long as jumper X1 is put, the input counter will be reset after any power loss.
4.1.2 MV110-16DN
To the input of type DN can be connected:
–potential-free contacts
–NPN transistor outputs with open collector

Installation
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
7
–PNP transistor outputs
When connecting the following is to observe:
The inputs of the module MV110-16DN are galvanically isolated in groups of 4 (1...4,
5...8, 9...12, 13...16). When connecting the sensors, use only to the group related com-
mon negative terminal, please:
–inputs DI1…DI4 –terminal SS1
–inputs DI5…DI8 –terminal SS2
–inputs DI9…DI12 –terminal SS3
–inputs DI13…D16 –terminal SS4
Fig. 4.1 Electrical connections of MV110-16DN
Table 4.1 Terminal assignment of MV110-16DN
No
Connection
Description
No
Connection
Description
1
0 V
Power supply
13
D-
RS485 D-
2
24 V
Power supply
14
D+
RS485 D+
3
DI1
DI1
15
DI9
DI9
4
DI2
DI2
16
DI10
DI10
5
DI3
DI3
17
DI11
DI11
6
DI4
DI4
18
DI12
DI12
7
SS1
Input voltage 1-4
19
SS3
Input voltage 9-12
8
DI5
DI5
20
DI13
DI13
9
DI6
DI6
21
DI14
DI14
10
DI7
DI7
22
DI15
DI15
11
DI8
DI8
23
DI16
DI16
12
SS2
Input voltage 5-8
24
SS4
Input voltage 13-16
Connection variants for different signal types are shown in Figures 4.2 –4.4.

Installation
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
8
Fig. 4.2 Connection of switch contacts to the MV110-16DN
Fig. 4.3 Connection of 3-wire sensors with NPN transistor outputs to the MV110-16DN
Fig. 4.4 Connection of 3-wire sensors with PNP transistor outputs to the MV110-16DN

Configuration
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
9
5. Configuration
►
NOTICE
Before starting
Before switching on, make sure that the device has been kept at the specified
ambient temperature (-20... +55 ° C) for at least 30 minutes.
Parameters of the module can be read, edited and saved with ‘M110 Configurator’ soft-
ware. The full list of parameters is shown in the Table 5.1.
Module has to be configured first before operating in RS485 network.
The following steps are required:
–Install M110 Configurator on the PC.
–The module should be connected to USB port of the PC over a USB/RS485 adapter
(not included). Connect the D+/D- terminals of the module with the D+/D- contacts of
the adapter.
–Connect the power supply to 24V/0V terminals of the module.
–Turn on the power supply.
–Run the Mх110 Configurator.
If the factory settings of the module have not been changed, the connection to the mod-
ule is automatically established, the module automatically recognized, its configuration
parameters read out and an appropriate configuration mask open.
If it does not happen, parameters of the configurator have to be changed.
Table 5.1 Configuration parameters
Name
Parameter
Valid value
Meaning
Default set-
tings
Common parameters
dev
Device
Up to 8 symbols
MV110-16D
ver
Firmware version
Up to 8 symbols
manufactur-
er
Network parameters
bPS
Baud rate, kbit/s
0
2.4
9.6
1
4.8
2
9.6
3
14.4
4
19.2
5
28.8
6
38.4
7
57.6
8
115.2
LEn
Data bits *
0
7
8
1
8
PrtY
Parity *
0
none
none
1
even
2
odd
Sbit
Stop bits *
0
1
1
1
2
A.Len
Address bits
0
8
8
1
11
Addr
Device address
1…247
16
t.out
Time-out, s
0…600
0
Prot
Protocol
0
akYtec
0
1
Modbus RTU
2
Modbus ASCII
Rs.dL
Response delay, ms
0…45
2
Output parameters
Tin.C
Debouncing filter
0
off
0
1
on

Configuration
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
10
* Invalid network parameter combinations:
–prty=0; sbit=0; len=0
–prty=1; sbit=1; len=1
–prty=2; sbit=1; len=1

Operation
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
11
6. Operation
In the operation mode the module is controlled by a network Master in Modbus network.
In addition, the input states and counter states can be read out and the counter states
can be set to 0 (see 6.1).
Modbus functions 03, 04 for reading and 16 for writing can be used.
6.1 Input and counter status
The input status can be read out as a bitmask. The corresponding Modbus registers can
be taken from the table 6.1. The least significant bit of the mask corresponds to the
input 1.
To reset the counter, write 0 to the corresponding register.
6.2 Fault condition
If the data exchange on the serial port is interrupted (i. e. there is no command from the
master within the time specified by the parameter t.out), the following applies:
–LED FAULT flashes.
–Once a request from the master device comes, the display ‘refreshes’.
–If t.out parameter is set to 0, ‘Fault Condition’ is not defined.
6.3 Memory addressing
All variables and parameters in the Table 6.2 are of the type UNIT16.
R –read access
W –write access
Table 6.1 Modbus register
Parameter
Unit
Access
Address
hex
dec
Time-out, s (t.out)
1..600
RW
0030
0048
Input status bitmask
0..65535
R
0033
0051
Counter status of the input 1
0..65535
RW
0040
0064
Counter status of the input 2
0..65535
RW
0041
0065
…
…
…
…
…
Counter status of the input 16
0..65535
RW
004F
0079

Factory settings restoration
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
12
7. Factory settings restoration
If the communication between the module and PC cannot be established and network
parameters of the module are unknown, the default network settings should be restored.
The following steps are required:
─Turn off the power supply
─Remove the front cover of the module
─Insert the jumper X2. Module will operate with the default network parameters, the
user settings remain stored.
─Turn on the power supply again
WARNING
Dangerous voltage
Electric shock could kill or seriously injure.
The voltage on some components of the circuit board can be danger-ous! Direct
contact with the circuit board or penetration of a foreign body in the enclosure
must be avoided!
–Run M110 Configurator
–In the window ‘Connection to device’ enter the values from the Table 7.1 or click the
key ‘Use factory settings’ (see Fig. 7.1)
Fig. 7.1 Start window of configuration software
–Click ‘Connect’ to establish the connection with factory settings
–The main window of the Configurator opens. Saved user parameters of the module
can be read now (see Fig. 7.2).
–Open folder ‘Network parameters’ and note the user network parameters

Factory settings restoration
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
13
Fig. 7.2 Main window of M110 Configurator
–Close M110 Configurator
–Turn off the power supply
–Take out the Jumper X2
–Close the front cover
–Turn on the power supply again
–Start M110 Configurator
–Enter the noted network parameters
–Click ‘Connect’
The module is now ready for operation.
Table 7.1 Network factory settings
Parameter
Name
Default
Baudrate
bPS
9600
Data bits
LEn
8
Parity
PrtY
none
Stop bits
Sbit
1
Address bits
A.Len
8
Address
Addr
16
Response delay, ms
Rs.dL
2

Maintenance
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
14
8. Maintenance
The maintenance includes:
–cleaning of the housing and terminal blocks from dust, dirt and debris
–check the device fastening
–checking the wiring (connecting leads, fastenings, mechanical damage)
The device should be cleaned with a damp cloth only. No abrasives or solvent-containing
cleaners may be used. The safety information in section 3 must be observed when carry-
ing out maintenance.

Transportation and storage
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
15
9. Transportation and storage
Pack the device in such a way as to protect it reliably against impact for storage and
transportation. The original packaging provides optimum protection.
If the device is not taken immediately after delivery into operation, it must be carefully
stored at a protected location. The device should not be stored in an atmosphere with
chemically active substances.
Permitted storage temperature: -25...+55 °C
►
NOTICE
Transport damage, completeness
The device may have been damaged during transportation.
Check the device for transport damage and completeness!
Report the transport damage immediately to the shipper and akYtec GmbH!

Scope of delivery
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
16
10.Scope of delivery
–Module MV110-24.16DN 1
–Short guide 1

Appendix A. Dimensions
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
17
Appendix A. Dimensions
Fig. A.1 External dimensions
Fig. A.2 Wall mounting dimensions
75
63
11
0
55
102

Appendix A. Dimensions
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
18
Fig. A.3 Replacement of terminal blocks
