OPERATING MANUAL
LOG SPLITTER
LSH 370/4
LSH 520/5
443281_a 07 | 2021
UK

2 LSH 370/4 | LSH 520/5
01 LSH 370/4
1
2
3
4
5
678
9
10
11
12
13
14
15
16
17
02 LSH 520/5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

443281_a 3
03 LSH 370/4
1234
5
6
7
8
9
04 LSH 520/5
1234
5
6
7
8
9
10
11
12

4 LSH 370/4 | LSH 520/5
LSH 370/4
05
1
2
3 4
5
6
7
8
06
M6 x 16 2x
07
2x
08 09 M6 x 12 1x
M6 x 12 1x

443281_a 5
10
M6 x 12 1x
11 M6 x 12 1x
M6 x 12 1x
12
M6 x 12 1x
13
M6 x 12 1x
M6 x 12 1x
14
M6 x 12 1x
15
M6 x 12 2x
16
1

6 LSH 370/4 | LSH 520/5
LSH 520/5
17
2x
M8 x 55
2x
M8 x 25
18
2x
2x
M8 x 50
19
2x
ab
cd
20
M8 x 55 2x

443281_a 7
21
M6 x 12 1x
M8 x 50 1x
22
M6 x 12 1x
M8 x 12 1x
23 M6 x 12 1x
M6 x 12 1x
24
M6 x 12 1x
25
M6 x 12 1x
M6 x 12 1x 26
M6 x 12 1x
27
M6 x 12 2x
28 1
1

8 LSH 370/4 | LSH 520/5
29
a
b
c
M6 x 12 8x
30
LSH 370/4: M5 x 12
LSH 520/5: M5 x 12
11x
12x
LSH 520/5
31
M5 x 12 8x

443281_a 9
32
1
2
33
34
35
a
1
2
36
37 1
2
38
1
2

10 LSH 370/4 | LSH 520/5
LSH 370/4 LSH 520/5
39 40
41 42

443281_a 11
LSH370/4 LSH520/5
100,0 x 43,5 x 62,5cm 123,5 x 61,0 x 134,5cm
51kg 61kg
230V AC (+/- 10%)
50Hz (+/- 1Hz)
230V AC (+/- 10%)
50Hz (+/- 1Hz)
1500W, S3 40%
7,5A
2200W, S3 25%
9,6A
max. 4,0t max. 5,0t
50 – 250mm 50 – 250mm
130 – 370mm 200 – 520mm

12 LSH 370/4 | LSH 520/5
LSH370/4 LSH520/5
290mm 370mm
16,5MPa 20,6MPa
2,4l 3,5l
7,5/4,5cm/s 9,5/5,5cm/s
IP54 IP54
LpA = 78,8dB(A), K=3,0dB(A)
(unloaded)
LpA = 89,8dB(A), K=3,0dB(A)
(loaded)
LpA = 78,8dB(A), K=3,0dB(A)
(unloaded)
LpA = 89,8dB(A), K=3,0dB(A)
(loaded)
LwA = 93,1dB(A), K=3,0dB(A)
(unloaded)
LwA = 95,7dB(A), K=3,0dB(A)
(loaded)
LwA = 93,5dB(A), K=3,0dB(A)
(unloaded)
LwA = 96,0dB(A), K=3,0dB(A)
(loaded)
<2,5m/s2<2,5m/s2
+5°C – +40°C +5°C – +40°C
-25°C – +55°C -25°C – +55°C

443281_a 13

GB
14 LSH 370/4 | LSH 520/5
Translation of the original instructions for use
TRANSLATION OF THE ORIGINAL INSTRUCTIONS FOR USE
Contents
1 About these operating instructions .......... 14
1.1 Symbols on the title page................... 14
1.2 Legends and signal words ................. 15
2 Product description .................................. 15
2.1 Designated use .................................. 15
2.2 Possible foreseeable misuse ............. 15
2.3 Residual risks..................................... 15
2.4 Safety and protective devices ............ 15
2.4.1 Motor protection switch................ 15
2.4.2 Two-hand operation..................... 15
2.4.3 Protective cover........................... 15
2.4.4 Anchoring to the ground .............. 15
2.5 Symbols on the appliance .................. 16
2.6 Electrical requirements....................... 16
2.6.1 Mains connection......................... 16
2.6.2 Mains cable ................................. 17
2.7 Scope of supply.................................. 17
2.7.1 Scope of supply for LSH370/4
(03) .............................................. 17
2.7.2 Scope of supply for LSH520/5
(04) .............................................. 17
2.7.3 Scope of supply of protective
cover (05) .................................... 17
2.8 Product overview (01, 02) .................. 17
3 Safety instructions ................................... 18
3.1 Operator ............................................. 18
3.2 Personal protective equipment........... 18
3.3 Safety in the workplace ...................... 18
3.4 Safety of persons, animals and prop-
erty ..................................................... 18
3.5 Appliance safety................................. 18
3.6 Safety instructions relating to opera-
tion ..................................................... 19
4 Assembly ................................................. 19
4.1 Assembly for LSH370/4 (06 – 15) ..... 19
4.2 Assembly for LSH520/5 (17 – 27) ..... 19
4.3 Installing protective cover (29 – 31) ... 19
5 Start-up...................................................... 19
5.1 Setting up and connecting log splitter. 19
5.2 Inspect safety and protective devices. 19
6 Operation................................................... 20
6.1 Splitting a log (32 – 34)....................... 20
6.2 Removing a jammed log (35, 36) ....... 20
7 Maintenance and care............................... 20
7.1 Maintenance and care work ............... 20
7.2 Maintenance tasks.............................. 20
7.2.1 Sharpening of the splitting wedge 20
7.2.2 Checking and topping up hydrau-
lic oil(37, 38)................................ 20
8 Help in case of malfunction ....................... 21
9 Transport (39 – 42).................................... 22
10 Storage...................................................... 22
11 Disposal..................................................... 22
12 After-Sales/Service.................................... 23
13 Guarantee ................................................. 23
1 ABOUT THESE OPERATING
INSTRUCTIONS
■The German version is the original operating
instructions. All additional language versions
are translations of the original operating in-
structions.
■Always safeguard these operating instruc-
tions so that they can be consulted if you
need any information about the appliance.
■Only pass on the appliance to other persons
together with these operating instructions.
■Comply with the safety and warning informa-
tion in these operating instructions.
1.1 Symbols on the title page
Symbol Meaning
It is essential to read through these
operating instructions carefully be-
fore start-up. This is essential for
safe working and trouble-free han-
dling.

443281_a 15
Product description
Symbol Meaning
Operating instructions
To avoid electric shock, do not
damage or cut the power cable!
1.2 Legends and signal words
DANGER! Denotes an imminently danger-
ous situation which will result in fatal or serious
injury if not avoided.
WARNING! Denotes a potentially danger-
ous situation which can result in fatal or serious
injury if not avoided.
CAUTION! Denotes a potentially dangerous
situation which can result in minor or moderate
injury if not avoided.
IMPORTANT! Denotes a situation which can
result in material damage if not avoided.
NOTE Special instructions for ease of un-
derstanding and handling.
2 PRODUCT DESCRIPTION
2.1 Designated use
The log splitter is intended exclusively for splitting
perpendicularly cut logs. The dimensions of the
logs must not exceed the dimensions given in the
technical data.
Only one person may remain in the working area
of the log splitter, and the log splitter may be op-
erated only by one person.
This appliance is intended solely for use in non-
commercial applications. Any other use as well
as unauthorised conversions or modifications are
regarded as contrary to the intended use and will
result in voiding of the warranty as well as loss of
conformity; the manufacturer will thus decline any
responsibility for damage and/or injury suffered
by the user or third parties.
2.2 Possible foreseeable misuse
The following applications are expressly forbid-
den:
■Splitting of logs in which metal parts such as
nails, wire, staples, etc. are embedded.
■Operation by more than one person
■Operation in a potentially explosive atmo-
sphere
Use for any other purpose that the designated
use is forbidden.
2.3 Residual risks
Even during correct use of the appliance, there is
always a certain residual risk that cannot be ex-
cluded. Depending on the use, the following po-
tential risks may arise from the type and con-
struction of the appliance.
Danger of serious injury from:
■Shattering logs and flying pieces of wood
during splitting
■Falling logs
■Tipping of the appliance
2.4 Safety and protective devices
WARNING! Risk of injury. Defective and
disabled safety and protective devices can result
in serious injury.
■Have any defective safety and protective de-
vices repaired.
■Never disable safety and protective devices.
2.4.1 Motor protection switch
The motor protection switch switches off the mo-
tor if the log splitter is overloaded.
Do not deactivate the function of the motor pro-
tection switch.
If the motor protection switch has switched off the
log splitter, proceed as follows:
1. Disconnect the log splitter from the mains.
2. Determine the cause of the overload.
3. Allow the log splitter to cool down for several
minutes, then connect to the mains again.
4. Switch on the log splitter.
2.4.2 Two-hand operation
The log pusher moves only when the ON button
and control lever are actuated simultaneously.
This avoids the risk of the operator’s hands being
in the danger area.
2.4.3 Protective cover
The protective cover prevents the hands of the
operator or of another person getting into the
splitting area during the splitting process.
2.4.4 Anchoring to the ground
Anchoring to the ground prevents the log splitter
from tipping over and helps to avoid serious inju-
ries.

GB
16 LSH 370/4 | LSH 520/5
Product description
2.5 Symbols on the appliance
Symbol Meaning
Read the operating instructions be-
fore starting operation!
Wear hearing protection and protec-
tive eyewear!
Wear protective gloves!
Wear safety boots!
Do not remove or modify safety and
protective devices!
Do not dispose of hydraulic oil in
the countryside!
Protect the appliance from rain and
moisture!
Place logs into the log splitter and
do not hold!
Do not touch moving parts!
Keep your hands away from the
danger area!
Disconnect the appliance from the
mains before starting maintenance
work!
Keep third parties away from the
danger area!
Symbol Meaning
Risk of burns on hot surfaces! Do
not touch!
Caution: Mains voltage! Do not
open the appliance!
Loosen the vent plug before opera-
tion and tighten again after opera-
tion!
Lifting point for crane hook
Operate the appliance with both
hands!
2.6 Electrical requirements
2.6.1 Mains connection
DANGER! Risk of electric shock if the log
splitter is operated without residual current
circuit breaker. Operation of the appliance with-
out residual current circuit breaker in the mains
connection can result in serious injuries or even
death due to electric shock.
■Before connecting the appliance, check
whether the mains connection has a residual
current circuit breaker for a maximum leak-
age current of 0.03A.
■If you cannot be sure that a residual current
circuit breaker is installed: Use an additional
portable residual current device with switched
PE conductor.

443281_a 17
Product description
■AC 230V / 50Hz
■Minimum fusing of the mains connection =
16A
2.6.2 Mains cable
WARNING! Risk of injury from electric
shock. A defective mains cable can result in seri-
ous injuries due to electric shock.
■Ensure that the mains cable is not damaged
or severed.
■Use only rubber-sheathed cables of quality
H07RN-F according to VDE 0282 Part 14
with a conductor cross section of at least
2.5mm².
■The maximum permissible cable length is
10m. A longer cable impairs the motor power
and hence the performance and function of
the log splitter.
■Mains cable, mains plug and coupling socket
must be undamaged. A defective mains ca-
ble (e.g. with cracks, cuts, crushed or kinked
points in the insulation) must not be used.
■Repairs to the mains cable, mains plug and
coupling socket may only to be carried out by
qualified electricians.
■Do not expose plug connectors to moisture.
■If the mains cable is damaged, immediately
disconnect it from the mains.
2.7 Scope of supply
After unpacking, check that all the parts have
been delivered.
2.7.1 Scope of supply for LSH370/4 (03)
No. Component
1 Base unit
2 Bag with small parts
3 Operating instructions
4 Supporting struts (2x)
5 Supporting strut
6 Transport handle
7 Wooden rests (2x)
8 Base plate
9 Transport wheels (2x)
2.7.2 Scope of supply for LSH520/5 (04)
No. Component
1 Base unit
2 Bag with small parts
3 Operating instructions
4 Supporting struts (2x)
5 Supporting strut
6 Wooden rests (2x)
7 Front support legs (2x)
8 Front support foot
9 Rear support legs (2x)
10 Connecting strut
11 Transport wheels (2x)
12 Base plate
2.7.3 Scope of supply of protective cover
(05)
No. Component
1 Large top plate
2 Small top plate
3 Small plate for left
4 Small plate for back
5 Large plate for back
6 Plate for front
7 Connecting plates (2x)
8 Bag with small parts
2.8 Product overview (01, 02)
The log splitters consist of the following compo-
nents:
No. Component
1 Control lever for hydraulics
2 ON/OFF switch for electric motor
3 Mains cable
4 Vent plug
5 Oil drain plug with oil dipstick
6 Pull rod

GB
18 LSH 370/4 | LSH 520/5
Safety instructions
No. Component
7 Motor
8 Transport wheels
9 Log pusher or thrust plate
10 Work table or splitting rest
11 Splitting wedge
12 Protective cover
13 Wooden rests
14 Transport handle
15 Removal opening for split logs
16 Support foot with holes for anchoring
to the ground
17 Log guide
3 SAFETY INSTRUCTIONS
DANGER! Danger of fatal injury and dan-
ger of extremely severe injury! Lack of knowl-
edge of the safety instructions and operating in-
structions can lead to extremely serious and even
fatal injury.
■Observe all safety instructions and instruc-
tions for use in these operating instructions
as well the operating instructions which are
referred to before you start using the appli-
ance.
■Keep all supplied documents in a safe place
for future reference.
3.1 Operator
■Young people under 16 years of age and
people who do not know the operating in-
structions are not allowed to use the tool. Ob-
serve any country-specific safety regulations
regarding the minimum age of the user.
■Inexperienced operating personnel must be
instructed and trained in the operation of the
appliance.
■Do not operate the appliance if you are under
the influence of alcohol, drugs or medication.
3.2 Personal protective equipment
■Wear clothing and protective equipment in
accordance with the regulations in order to
avoid injury to the head and limbs as well as
to avoid hearing impairment.
■The clothing must be appropriate (tightly fit-
ting) and must not restrict movements. If you
have long hair, it is essential to wear a hair
net. Never wear loose items of clothing or ac-
cessories that can be pulled into the appli-
ance, e.g. scarves, loose-fitting shirts, long
neck chains.
■The personal protective equipment compris-
es:
■Hearing protection and protective eye-
wear
■Long trousers and sturdy shoes
■Protective gloves
3.3 Safety in the workplace
■Work only in daylight or under very bright arti-
ficial light.
■Ensure that the appliance is stable:
■Operate the appliance only on firm and
level ground.
■Anchor the appliance to the ground.
■Never expose the appliance to rain or snow.
Water entering the appliance can result in an
electric shock.
3.4 Safety of persons, animals and property
■Note that the user is responsible for acci-
dents and damage that may befall other per-
sons or their property.
■Use the appliance only for the purposes for
which it is intended. Any non-intended use
can lead to injury and property damage.
■Switch on the appliance only when there are
no other persons or animals in the working
area.
■Maintain a safe distance to persons or ani-
mals, or switch off the appliance if persons or
animals approach.
3.5 Appliance safety
■Use the appliance only under the following
conditions:
■The appliance is not soiled.
■The appliance show no signs of damage.
■All controls function properly.
■Do not overload the device. It is intended for
light work in the private sector. Overload can
lead to damage to the appliance.
■Never operate the appliance with worn or de-
fective parts. Always replace defective parts
with original spare parts from the manufactur-
er. If the appliance is operated with worn or

443281_a 19
Assembly
defective parts, guarantee claims against the
manufacturer are excluded.
■Repair work is only allowed to be carried out
by expert workshops or our service centres.
3.6 Safety instructions relating to operation
■Never leave the operational appliance unsu-
pervised.
■Clean the appliance after every use.
■Protect the appliance against unauthorised
access.
■The appliance may only be operated by one
person.
■Never move the appliance while the motor is
running.
■Disconnect the appliance from the mains for:
■Maintenance and cleaning work
■Adjustment work
■Transport
■Interruptions in work
■Faults
■During the splitting process, do not reach into
the splitting area and do not touch the split-
ting wedge.
4 ASSEMBLY
WARNING! Danger if assembly is not
carried out completely! Operation of an incom-
pletely assembled appliance can result in serious
injury.
■Only operate the appliance when it is fully as-
sembled.
■Check that all safety and protective devices
are in place and functioning correctly before
switching on.
4.1 Assembly for LSH370/4 (06 – 15)
Assemble the appliance in the order of the fig-
ures (06) to (15).
4.2 Assembly for LSH520/5 (17 – 27)
Assemble the appliance in the order of the fig-
ures (17) to (27).
4.3 Installing protective cover (29 – 31)
Assemble the protective cover in the order of the
figures (29) to (31).
5 START-UP
5.1 Setting up and connecting log splitter
WARNING! Danger of injury if the log
splitter tips over. A tipping log splitter can result
in serious injury and material damage.
■Set up the log splitter on firm and level
ground.
■Do not place any material under the log split-
ter to change its height or to try to increase
its stability.
1. Set up the log splitter horizontally and se-
curely so that it cannot tip over.
2. Anchor the log splitter to the ground at the
appliance leg using two suitable screws
(16/1, 28/1) and possibly dowels to prevent it
from tipping over.
3. Lay the mains cable in such a way that it can-
not be kinked, crushed or damaged in any
other way.
4. Open vent screw (01/4, 02/4) by roughly 1 –
2 turns so that the air can escape that is dis-
placed during operation by the heated and
expanding oil.
5. Insert the plug of the mains cable into the
power socket.
Note:To disconnect the appliance from the
mains power supply, pull out the plug again.
5.2 Inspect safety and protective devices
Always check before starting work:
1. Check the proper anchoring of the log splitter
to the ground and correct, if necessary.
2. Inspect the protective cover for damage. Re-
pair the protective cover, if damaged.
3. Inspect two-hand operation: Procedure, see
see chapter 6.1 "Splitting a log (32 – 34)",
page20. While the log pusher is moving, re-
lease either ON button or control lever. The
log pusher moves back to its starting posi-
tion.

GB
20 LSH 370/4 | LSH 520/5
Operation
6 OPERATION
WARNING! Risk of injury if operated by
more than one person. Operation of the appli-
ance by two or more persons can result in seri-
ous injuries.
■Operate the appliance only alone and never
reach into the splitting area during splitting.
■Keep other persons away and in particular
prevent them from reaching into the log that
is currently being split.
WARNING! Risk of injury from shattering
log. Stored hardwood, irregular branches, irregu-
lar logs and logs with a large number of knots
tend to shatter during splitting. Flying pieces of
wood can then cause serious injuries.
■Split only straight logs with a perpendicular
and straight cutting surface.
■Wear the prescribed protective clothing at all
times.
IMPORTANT! Damage due to incorrect use.
The appliance can be damaged or destroyed.
■Always place the log longitudinally and never
transversely into the log splitter.
■Never try to force a log to split by maintaining
the hydraulic pressure.
6.1 Splitting a log (32 – 34)
■Operate the log splitter only as illustrated in
figure (32).
■Never place the log at an angle on the log
splitter (33).
■Place only straight logs with a perpendicular
and straight cutting surface on the log splitter
(34).
CAUTION! Untidy working areas create a
risk of injury. Untidiness and logs lying around
pose a risk of tripping and slipping in the working
area.
■Store the logs to be split in a tidy pile.
■Immediately remove split logs and wood
chips from the working area.
1. Place the log lengthwise onto the log splitter
in such a way that the log is held by the log
guide.
2. With one hand, press and hold the ON button
(32/1) of the electric motor.
3. When the motor has reached its operating
speed, press control lever (32/2) completely
down with your other hand.
■The log pusher pushes the log against
the splitting wedge. The log is split.
4. When the ON button and control lever are re-
leased, the log pusher moves back into its
starting position.
6.2 Removing a jammed log (35, 36)
CAUTION! Risk of injury from a jammed
log flying out. If a jammed log flies out of the ap-
pliance, injuries can be caused and the appliance
may be damaged.
■Never try to free a jammed log using tools.
1. Take both hands away from the ON button
and control lever.
2. Allow the log pusher to come to a complete
standstill.
3. Push (35/a) a wooden wedge (35/1) under
the jammed log (35/2). Caution: Never try to
drive out the jammed log (36)!
4. Push the wooden wedge completely under
the jammed log using the log pusher.
5. If necessary, repeat with a larger wooden
wedge until the log is freed.
7 MAINTENANCE AND CARE
WARNING! Risk of injury during mainte-
nance work. Improper maintenance can result in
serious injury and damage to the appliance.
■Disconnect the appliance from the mains be-
fore starting maintenance work.
■Have repairs to the appliance carried out only
by qualified companies.
7.1 Maintenance and care work
Cleaning of the guideway
Clean the guideway of the log pusher at regular
intervals, particularly when splitting logs with high
resin contents.
7.2 Maintenance tasks
7.2.1 Sharpening of the splitting wedge
Sharpen the splitting wedge, when necessary,
using a suitable file.
7.2.2 Checking and topping up hydraulic
oil(37, 38)
Check the oil level every day and change the hy-
draulic oil after 1year or 150operating hours.
