Aladdin Temp-Rite PD2WNH Manual

250 East Main Street, Hendersonville, TN 37075
1-800-888-8018 or 615-537-3600
Fax [phone]
www.aladdintemprite.com
®
Plate Dispenser
Manual P/N 11687
Rev. F 02/14/2023 INSTALLATION, OPERATION & SERVICE MANUAL
(Unheated) PD2WNH
PD3WNH
Vadclin Te11p-Rite ... better by degrees.
/f/addin
7emp-Rfte

Copyright © 2012 Aladdin Temp-Rite®
Changes may be made to the information in this document without notication.

FOR PARTS & SERVICE CALL 1 [phone]
3
CONTENTS
Plate Dispenser (Unheated) Installation, Operation
& Service Manual
I. INTRODUCTION 4
II. RECEIVING INSPECTIONS 5
III. SAFETY 6
III. INSTALLATION / OPERATION / CLEANING 6
INSTALLATION 6
OPER ATION 6
CLEANING 7
IV. TROUBLESHOOTING 7
V. PARTS LIST 8
VI . WARRANTY & LIABILITY 10

Plate Dispenser (Unheated) Installation, Operation
& Service Manual
FOR PARTS & SERVICE CALL 1 [phone]
4
I. INTRODUCTION
Aladdin Temp-Rite Plate Dispensers are available in two well and three well models. These
units are designed specically for use with a wide variety of 9” (22.9 cm) diameter plates. They
are perfectly suited for use with the Heat On Demand advantage system, since plates do not
need to be heated for this system to maintain proper hot food temperatures.
These dispensers can also be used with the Aladdin Convet-Rite III or Convect-Rite Prime cook
chill rethermalization systems where plates are heated by the rethermalization process.
STANDARD FEATURES:
● Individual eld adjustable, self - leveling stainless steel lifts, easily removable for cleaning
● Four 5” swivel casters, two with brake, for smooth and early maneuverability
● Convenient push/pull handle
● Lightweight with small foot print
● Side opening provide stack height visibility
● NSF listed
● Non marking plastic bumper
Model PD2WNH PD3WNH
# of wells 2 3
Length 36.8” (93.5 cm) 53.125” (134.9 cm)
Width 17.6” (44.7 cm) 17.6” (44.7 cm)
Height 39” (99 cm) 39” (99 cm)
Weight 112 lbs (50.8 kg) 168 lbs (76.2 kg)

FOR PARTS & SERVICE CALL 1 [phone]
5
II. RECEIVING INSPECTIONS
Your Aladdin Plate Dispenser is factory tested for performance and is free from defects
when shipped. The utmost care has been taken in packaging this product to protect against
damage in transit.
You should carefully inspect your Plate Dispenser to assure that no damage has occurred in
transit. However, if damage is detected see the following damaged goods policy. Under no
circumstances may a damaged unit be returned to Aladdin Temp-Rite without rst obtaining
written permission (return authorization). No credit will be issued for claims not reported to
Aladdin within ten (10) business days from receipt of shipment.
ALADDIN DAMAGED GOODS POLICY
There are two types of damaged merchandise:
● Visual Damage ● Concealed Damage
Visual Damage – When the product being received is visibly damaged.
1. Receiver should not accept merchandise with visual damage.
2. Receiver must sign delivery receipt “refused merchandise due to damage” and specify
damage.
3. Receiver should call Aladdin Customer Service immediately after refusal.
4. Carrier will notify Aladdin Trafc Department and a claim will be led.
5. Carrier will send acknowledgement of claim within 7 days after receiving.
Concealed Damage – When damaged merchandise cannot be externally detected.
Any receiving operation should be looking for this type of damage. Sometimes,
however, depending on the type of product, it is almost impossible to notice.
1. Merchandise must not be removed from point of delivery and all packaging must be kept
intact.
2. Receiver must contact Aladdin Customer Service to report damage.
3. Aladdin trafc department will request inspection based on the dollar value of the cargo.
4. Aladdin trafc department will le a claim based on the ndings of the inspection.
Failure to comply with these policies will result in the customer’s responsibility to le
claims.

Plate Dispenser (Unheated) Installation, Operation
& Service Manual
FOR PARTS & SERVICE CALL 1 [phone]
6
III. SAFETY
III. INSTALLATION / OPERATION / CLEANING
If you know how to correctly install, operate, clean, and service the Plate Dispenser your satisfaction
with the equipment will be increased and safety will be enhanced. In accordance with generally
accepted product safety labeling guidelines the following three signal words are used throughout
this manual to alert you to potential hazards and to tell you how to avoid them.
The purchaser/user has the best knowledge and is in the best position to determine the operating
conditions, appropriateness of the product for the operating environment, and safe use of the
product. Aladdin Temp-Rite does not warrant, implied or expressly, that the product is t for a
particular use or operating environment.
WARNING: The word "Warning" identies a potentially hazardous situation which, if not avoided
COULD result in death or serious personal injury.
CAUTION: The word "Caution" identies a potentially hazardous situation which, if not avoided MAY, result in
minor or moderate injur y. The word "Caution" may also be used to aler t against unsafe practices
and property damage only accidents.
"Important" is used to identify installation, operation, or maintenance information which is
important but not hazard related.
ii
Installation
Remove all packaging material from exterior.
Check for any damage. See section II Receiving Inspections.
Operation
Do NOT stack plates after the dispenser has bottomed out
Do NOT stack stainless steel pellet bases in this unit
Avoid bumping dispenser into doors or obstacles
ii
□
□

FOR PARTS & SERVICE CALL 1 [phone]
7
III. INSTALLATION / OPERATION / CLEANING IV. TROUBLESHOOTING
Plate capacity
Aladdin Sales
codes
Aladdin Part
Number Description Springs per Well
Total Capacity
2 well 3 well
J300 11635 9” Ivory Eaton 8120 180
J361 10910 9” Mauve/Grey Eaton 8120 180
J461 29405 9” Blue/Mauve Eaton 8120 180
J561 29553 9” Teal/Teal Eaton 8120 180
J700 98482 9” Bright white 8120 180
J100 99772 9” Presentations 8120 180
CLEANING
● Clean any debris from the casters or the lift mechanisms
● Use warm water with a mild detergent and a soft cloth, then dry
● Using a high pressure sprayer or cart wash machine for cleaning will void the warranty
CAUTION! - Harsh chemicals and insufciently diluted sanitizer will damage stainless steel
surfaces. Never use cleaning agents that contain phosphates or chlorides. These chemicals
will cause permanent damage to stainless steel nishes and void equipment warranty.
Complaint Problem Solution
Unit does not roll easily debris in caster clean caster housing and caster
Plates don’t descend properly too many springs detach one spring at a time on diagonal
corners of the lift mechanism until unit
works as desired
Plates are too low not enough
springs
attach one spring at a time on diagonal
corners of the elevator until unit works as
desired
springs may be
worn out
replace spring(s) see parts list

Plate Dispenser (Unheated) Installation, Operation
& Service Manual
FOR PARTS & SERVICE CALL 1 [phone]
8
V. PARTS LIST
NOTE: 2 well and 3 well dispenser service parts are common
#PN Description
PD2WNH
(2 well)
PD3WNH
(3 well)
110238 bolt, 1/4-20 x 1” Phillips head truss SS 2 2
211710 bolt, carriage ,1/4”-20 x 0.625” SS 16 16
393052 bumper, corner 4 4
414519 caster, 5” swivel 2 2
514520 caster, 5” swivel with brake 2 2
692520 lift mechanism assy 2 3
711315 handle 1 1
899540 nut ange, 1/4-20, SS 16 16
939260 nut, acorn 1/4-20 2 2
10* 35188 rivet, SS 1/8” x 5/16” - -
11 98059 screw, 10-32 x 3/4” pan head SS 16 16
12* 12405 spring, 4”, SS - -
13 28331 washer, lock 0.25” SS 2 2
14* 10816 lift mechanism bushing - -
15* 10638 lift mechanism rod - -
16a 12756 two well side panel 2-
16b 12720 three well side panel -2
17 12722 panel end with handle 1 1
18 12721 panel end 1 1
19 113 09 top panel 23
20 12723 plate guard bracket 46
* item not shown
I I I I

FOR PARTS & SERVICE CALL 1 [phone]
9
1
7
13 9
2
8
5
4
11
3
6
17
16
18
19
20
::
. .
.
....._ .._.
~ . -- ....._ .._. ....._ ._..,.. .
~ .. .. .
0 0

Plate Dispenser (Unheated) Installation, Operation
& Service Manual
FOR PARTS & SERVICE CALL 1 [phone]
10
VI . WARRANTY & LIABILITY
ALADDIN TEMP-RITE®
EQUIPMENT
LIMITED WARRANTY
Effective August, 2012
Aladdin Temp-Rite® (“ATR”) warrants to the original purchaser that the equipment listed below shall be free from
defects in material and workmanship under normal use for the applicable warranty term set forth below. ATR’s
obligation under this warranty is limited to the repair or replacement, at the sole option of ATR, of any part which
upon inspection and examination by ATR or its authorized agent is found to be defective. A written description
detailing the nature of the claimed defect, together with the equipment claimed to be defective if required by ATR,
must be delivered to ATR or its authorized agent within 30 days of discovery of the claimed defect (but in no
event later than 30 days after the expiration of the applicable warranty term).
EQUIPMENT
WARRANTY TERM
PARTS LABOR
PD2WNH 1 Year 90 Days
PD3WNH 1 Year 90 Days
*The warranty term commences 30 days after the date of ATR’s invoice for the equipment.
THE WARRANTIES AND REPRESENTATIONS OF ATR CONTAINED HEREIN ARE EXPRESSLY IN LIEU OF,
AND THE BUYER WAIVES, ANY AND ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND ANY OTHER
REMEDIES AGAINST ATR, WHETHER BASED UPON CONTRACT, NEGLIGENCE, STRICT LIABILITY OR
OTHERWISE. ATR SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES OR
ECONOMIC LOSS OF ANY NATURE (INCLUDING WITHOUT LIMITATION LOSS OF REVENUES AND/OR
PROFITS) THAT MAY BE CLAIMED TO RESULT FROM ANY NEGLIGENCE OR BREACH OF WARRANTY
OR CONTRACT BY ATR.
Exceptions and Exclusions
This warranty is issued only to the original purchaser, and is not transferable and applies only to the products
installed within the United States of America, its territories and Canada. During the term of any labor warranty,
ATR will pay all pre-approved shipping charges incurred in returning defective equipment to ATR and labor
costs incurred in the removal and reinstallation of such equipment. Contact ATR before returning any defective
equipment or otherwise performing any warranty repairs. ATR assumes no liability for any work or repair
performed without its prior approval. After the expiration of any labor warranty, the original purchaser is
responsible for all shipping charges incurred in returning defective equipment to ATR and labor for removing and
reinstalling such equipment. ATR shall not be responsible for the replacement of expendable items like lamps
and fuses or product failure resulting from normal wear and tear, improper installation, misuse, sabotage, abuse,
neglect, accident, unauthorized alterations to repair, or other factors beyond the control of ATR. Neither this
warranty, nor the liability of ATR may be modied or extended by action of any agent, distributor or other person
or by custom or practice.
CALL ATR TOLL FREE AT 1-800-888-5426 IF YOU HAVE ANY QUESTIONS ABOUT THIS WARRANTY OR
YOUR ATR PRODUCT.

FOR PARTS & SERVICE CALL 1 [phone]
11
