alatech AP1000 User manual

2
2
1
I
G
D
A
J
G
D
A
L
KF
L
M
L
K
1
2
2
F
N
2
L
KF
1
L
OF
> 0.6 m
> 2 ft
> 0.6 m
> 2 ft
> 0.6 m
> 2 ft
> 0.6 m
> 2 ft
BF
H
C
F
×2 ×2 ×2×4 ×1 ×1 ×2×1 ×1 ×1×1×1
×4 ×4 ×4
Step2Step1
Step4Step3
Step6Step5
Step8Step7
Model
Dealer’s Stamp Customer Service
Assembled on
YYYY / MM /DD
Serial No.*
SN:
Manufacturer Add.:
No.405 Tongxin Road, Tongxiang
Economic Development Zone, Zhejiang,
China
TEL: [phone]
AssemblyParts /Labels • If you have any question or the equipment has any missing parts, please contact your distributor or dial in the customer service number on the
maintenance card.
• The equipment should be assembled by a least 2 persons. Do no attempt to pull up the bike with single arm because it is heavy.
Handlebar Horizontal
Adjustment knob
Saddle Horizontal
Adjustment Knob
Resistance Adjustment/ Brake
Saddle Vertical Adjustment Knob
Wheel Cover
Left Maintenance Cover
Stretching Boards
Rear Stabilizer Tube
Console
Handlebar
Bottle Holder
Handlebar
Adjustment knob
Pedal
Transportation Wheels
Front Stabilizer Tube
Adjustable Levelers
Heart rate monitoring systems may be
inaccurate. Over exercise may result
in serious injury or death. If you feel
faint stop exercising immediately.
Use the stationary training equipment
in a supervised environment.
●
●
WARNING
get more App
and Quick pair
D21P1003020001
樣張
Scan the QR Code on the back of your device to:
• Connect and pair with the APPs.
• Register the product.
• Download the most up-to-date operation guide.
Limited Product Warranty
You are given only one original copy of this warranty card please preserved it
properly.
1 If this product fails due to manufacturing reasons, we provide a 1-year
manufacturer's warranty from the date of purchase/assembled. (Except for
non-home users)
2 Please show this warranty card when requiring repair service.
3 If the warranty card is not stamped with the company seal (or dealer) or the
contract is incomplete, it may loss the warranty rights, the following
conditions are not within this limit:
• Submit original invoice or proof of purchase.
• Distribution document that can provide relevant proof of purchase.
4 Non-Warranty Repair Policy: (User needs to pay for the repairs.)
• If malfunction or damage is caused by improper use, disassembly and
modification.
• Due to normal wear and tear of consumptive parts such as the operation
panel of the console, pedal, saddle, belt, crank, brake pad, etc.
Placement of the Equipment
Please place the equipment on a level ground and avoid direct sunlight. Do not place it
outdoor, in the garage, open yard, humid, and/or ventilated places. For safety purpose,
please keep the equipment’s surrounding clear for 2 ft (0.6 Meters) on all four sides.
* Please be sure to have your model name and serial number ready
before calling the customer service.The model name and serial
number can be found on the right side near the rear end.
Use a cable tie to tie the cable with the
console stand to avoid damage or personnel
injury caused by accidentally pulling the
cord or hindrance of movement.
Cable Tie
E
Slide Gasket
K
Quick-Release Knob
L
Washer Ø25×Ø10×2t
D
Handlebar
M
Saddle
N
Pedal
O
Open-ended Wrench
F
6mm Hex Wrench or Allen Key
G
Rear Stabilizer Tube
J
Front Stabilizer Tube
I
Console and Mounting Fixed Plate
H
Socket Button Head Cap Screw M10 × 1.5 × 20L
AB
Cross Recessed Truss Screws M4 × 0.7 × 12L
C
Phillips Pan Head Screws M3 × 0.5 × 10L

KPH
MPH
Avg.
MAX.
rpm
SPEED
kcal
level
W
bpm
HR
Watt
FTP
0000
Exploded View
Partial enlarged view of G
Specification
• Size: L 1340×W 530×H 1060mm / L 52.7”×W 20.9”×H 41.7”
• Weight: 52 kg / 115 lb.
• Max. User's Weight: 159 kg / 350 lb.
• Applicable User's height: 150 to 200 cm / 5 ft 9 in to 7 ft 87 in
• Screen: 5”LCD Backlight LCD
• Brake System: Magnetic Resistance
• No. of Levels: 20 Levels
• Heart Rate Monitor: Via Bluetooth® or ANT+®wireless technology
Buttons
Press and hold for the Setting Menu.
Press for the Display Preference.
Previous Page.
Scrolling through the options.
Press and hold to reset. 1
Press to confirm.
Next page.
Scrolling through the options.
On-Screen Icon
During Sports Mode
Page indicator
Time
Distance
Calories
Resistance Level
Pedaling Rate
Speed
Power
Heart Rate 5
Target Rate
Maximum rate
Average rate
mi/h
km/h
Heart Rate Percentage
Status
Battery Status 2
Connectivity to the ANT+
Heart Rate Sensor
Connectivity to the Bluetooth
Heart Rate Sensor
Connectivity to mobile device
(appears when using the app) 3
HR Zone On
Watt Zone On
FTP ON (Watt)
Connect to Optical HR Watch 4
Notes
1 When the cadence is lower than 60 rpm, the
rear indicator will NOT be on. When the
cadence is higher than 60 rpm, it should
remain consistently bright and is charging
properly. If being left idle for 3 months or
longer, the battery will be drained and will not
function properly.
2 Press and hold at anytime can reset the
console display into default settings. Once
reset, data in your User’s Profile, such as
units, gender, age, height, weight, etc.
remains unchanged. Other settings will all
turn back to default.
3 The icon indicates the console is
connecting with the APP or compatible
Bluetooth device.
4 When the console is connected with ATTACUS
Optical Heart Rate Sports Watch or armbands,
you will see this icon followed by the last
four digits of the wearable’s serial number.
Ex. 0001.
5 Heart rate reading will only appear when the
console is connected to an external heart rate
device.
2PF290420080002, 2020/10 V0.8
At the end if its useful life please dispose of this article correctly and safely
(local refuse sites). Do not incinerate used batteries.
