Alcatel-Lucent 7342 ISAM FTTU User manual

Alcatel-Lucent
7342 Intelligent Service
Access Manager (ISAM)
Fiber to the User (FTTU)

Alcatel-Lucent 7342 ISAM FTTU2
The Alcatel-Lucent 7342 ISAM FTTU enables IP
converged triple play services by offering maximum
bandwidth and QoS over fiber access. Its FSAN
standards compliant GPON implementation is
unmatched in features — 2.5 Gb/s bandwidth, 20 km
reach, ONT Management and Control Interface (OMCI),
and the most robust QoS for triple play services. The
Alcatel-Lucent 7342 ISAM FTTU integrates smoothly
with legacy voice and RF video networks, and allows
you to grow new service revenue and offer true
gigabit download speeds. With the Alcatel-Lucent
7342 ISAM FTTU, your can decrease OPEX for tech-
nical and service representatives, and reduce churn
with attractive service bundles, increasing ARPU
and decreasing subscriber acquisition cost.

3Alcatel-Lucent 7342 ISAM FTTU
Optical Broadband from the Broadband Leader
The Alcatel-Lucent 7342 Intelligent Services Access Manager (ISAM)
Fiber to the User (FTTU) system provides you with a 21st-century platform
for bundled services and offers a wide range of network applications, includ-
ing fiber access to residential and business subscribers, as well as subscribers
in multiple dwelling or tenant units (MDU/MTU). With the Alcatel-Lucent
7342 ISAM FTTU, you gain a long-term strategic advantage over your
competition. You can offer any service mix with increased reliability and
performance, while significantly lowering operational costs.
The Alcatel-Lucent 7342 ISAM
FTTU uses Full Service Access
Network (FSAN) standards compli-
ant gigabit passive optical network
(GPON) technology to multiplex
any mix of voice, video or data in
the central office (CO) onto a
single fiber that is terminated at
the subscriber’s premises. Each PON
line supports 2.5 Gb/s downstream
and 1.2 Gb/s upstream. In addition
to GPON performance, PON lines
can be extended up to 20 km with
32 subscribers per PON, or up to
64 subscribers per PON for shorter
distances.
As the foundation of a cost-effective
all-IP optical access network, the
Alcatel-Lucent 7342 ISAM FTTU
system supports next-generation
voice, data, and video services over
IP using Ethernet interfaces while
maintaining robust support for
legacy services, such as plain old
telephone service (POTS) and
radio frequency (RF) video.
The Alcatel-Lucent 7342 system
uses Alcatel-Lucent’s ISAM tech-
nology for intelligent IP-based
access, enabling reuse of network
deployment models and manage-
ment systems.
The Alcatel-Lucent 7342
ISAM FTTU system offers
a GPON solution with
unparalleled scalability, port
density, and performance.

4 Alcatel-Lucent 7342 ISAM FTTU
The Alcatel-Lucent ISAM technology is also designed
for wire-speed performance with cost-effective Ethernet
switching and enhanced Layer 2/Layer 3 functions.
The Alcatel-Lucent 7342 ISAM FTTU combines
ISAM performance with a comprehensive integrated
solution for fiber access. With this technology, you have
the flexibility to deliver RF video, IPTV, data, legacy
and next generation voice – as well as backhaul 2G, 3G
and WiMAX radio access, all on one platform. Just as
important, the Alcatel-Lucent 7342 ISAM FTTU is
managed by the same systems used for all Alcatel-Lucent
access products: the Alcatel-Lucent 5526 Access
Management System (AMS) in ANSI markets, or
the Alcatel-Lucent 5523 ADSL Work Station (AWS)
in ETSI markets.
Increase Service Revenue
Gaining a competitive edge often
means offering more services to
increase revenue and reduce churn;
however, your existing access net-
work is probably not designed to
deliver a full suite of services. The
Alcatel-Lucent 7342 ISAM FTTU
is a strategic access platform that
enables delivery of these and future
services. Offering a complete suite
of voice, data, and video can dra-
matically increase your top-line
revenue as shown in Figure 1.
50
200
150
100
0Local
ARPU (In U.S. Dollars)
Voice
Only
Voice
andData
Voice, Video
andData
LongDistance
Broadband
BasicVideo
Source: The Yankee Group, 2004
Digital Video
Premium Video
VoD
DVR
HDTV
Figure 1. Incremental Revenue from FTTU

5Alcatel-Lucent 7342 ISAM FTTU
Lower Operational Costs
Increasing revenue from new
services is only part of the value
offered by the Alcatel-Lucent 7342
ISAM FTTU solution. Service
providers are beginning to document
the operational savings achieved
with optical access networks. By
using passive elements, the fiber-
based Alcatel-Lucent 7342 ISAM
FTTU solution delivers cost savings
that can result in between 40 and
60 percent lower labor expenses
compared with using existing
copper networks. These savings
are achieved in reduced subscriber
contact associated with service
orders, trouble reporting, outside
plant operations, CO operations,
and network operations. As shown
in Figure 2, financial analysts see
the opportunity to reduce longer
term operating expenses with
capital investment in FTTU.
The high degree of integration and the passive nature
of the outside plant used in the Alcatel-Lucent 7342
ISAM FTTU solution greatly simplify network opera-
tions. Your service provisioning can be largely automated
because the network is designed to support a spectrum
of services from day one, which is not the case in today’s
copper networks. Services can be initiated and termi-
nated by your subscribers, saving labor costs that can be
used for other aspects of customer care, such as improv-
ing customer loyalty. In addition, because multiple
services are provided via a single network, customer care
can be much more effective and offer more up-selling
opportunities. This also decreases your churn, cutting
back on marketing costs for individual services and
order generation.
Retained
9%
Video
18%
HSD
28%
Op. Exp.
Savings
45%
Source: ARMISdatabase andBernstein Analysis
Figure 2. Incremental EBITDA from FTTU Build

6 Alcatel-Lucent 7342 ISAM FTTU
A Scalable Full-Service Solution
With the Alcatel-Lucent 7342 ISAM FTTU system, you also get the
best-in-class solution for deployment of GPON-compliant full service
access networks. The system is the result of years of R&D going back to
the mid-1990s. Indeed, Alcatel-Lucent is a leader in PON technology
development and has been instrumental in the work of the FSAN
Group and the standardization of optical access by the ITU-T.
The Alcatel-Lucent 7342 ISAM FTTU platform has throughput capacity
and operational enhancements unmatched by competitors. In addition
to using Alcatel-Lucent’s market-leading GPON technology, this platform
leverages Alcatel-Lucent’s leadership position in DSL and next-generation
DLC in two key ways:
• The 7342 ISAM FTTU uses the same Layer2/Layer3 technology
as the industry-leading ISAM platform for IP DSLAM
• The 7342 ISAM FTTU uses the same management system
(5526 Access Management System [AMS] in the ANSI markets
or 5523 ADSL Work Station [AWS] in the ETSI markets) as the
Alcatel-Lucent ISAM and Litespan platforms
Access Platform for
a Competitive Edge
The Alcatel-Lucent 7342 ISAM
FTTU platform provides you with
unmatched, scalable bandwidth
using GPON technology for video,
voice, legacy and high-speed data
services. Your services are delivered
using a single fiber with receive-and-
transmit wavelengths multiplexed
together — along with an optional
wavelength for downstream RF
video. FTTU enables you to deliver
high-revenue, next-generation
services today – cost-effectively
and efficiently.

7Alcatel-Lucent 7342 ISAM FTTU
Figure 3 illustrates the elements
of a complete Alcatel-Lucent 7342
ISAM FTTU end-to-end solution.
The solution includes a packet
optical line terminal (P-OLT),
located in the CO, that terminates
PON interfaces connected to many
outlying ONTs. The Alcatel-Lucent
FTTU solution includes four
different types of ONTs: Indoor
ONTs (ONT I-Series) for single
family homes; Outdoor ONTs
(ONT O-Series) for single family
homes and Small Office Home
Offices (SOHOs); Business ONTs
(ONT B-Series); and Low Profile
Multiple Dwelling/Tenant ONTs
for up to 12 living units or small
businesses (LP-MDU-ONTs).
The Alcatel-Lucent 7342 ISAM
FTTU solution supports longer reach
from the CO to the subscriber —
up to 20 kilometers (12.4 miles).
Each fiber terminated at the P-OLT
in the CO can be split using optical
splitters, which enables the 7342
to serve up to 64 ONTs located
at outlying subscriber sites. The
Alcatel-Lucent 7342 FTTU performs
service differentiation and traffic
flow prioritization in the ONT and
P-OLT. The solution grooms voice
traffic and forwards it to the PSTN
voice gateway — the GenBand G6
using GigE interfaces. Data traffic
is groomed and forwarded to a
broadband service aggregator (BSA)
7342 P-OLT WDM 1:64
Splitters
Internet
IPTV
5526 AMS/5523 AWS
GigE
10 GigE
20 km
GR303
7342
O-Series
ONTs
7342
LP-MDU
ONTs
7342
B-Series
ONTs
Class 5
Voice
IP/MPLSVPLS
Small/
Medium
Enterprises
Single
Family
Homes
MDU
with up
to 12 LUs
NGN Voice
7750 BSR
G6 VG
2.5 Gb/s
1.25 Gb/s
EDFA
R F Video
Optional
1310 nm
1490 nm
1550 nm
7450 BSA
Figure 3. Alcatel-Lucent 7342 ISAM FTTU in a Network
using multiple GigE and 10 GigE
interfaces. Traffic flow prioritization
is performed at all interfaces using
up to 8 queues for different service
types. Traffic flow grooming is per-
formed by using per service or per
subscriber virtual LANs (VLANs)
in the Alcatel-Lucent 7342 ISAM
FTTU and virtual private LAN
service (VPLS) instances in the
BSA. The VPLS instances are
terminated at the BSR, which is
connected to the IP routed network.

8 Alcatel-Lucent 7342 ISAM FTTU
For IPTV, the Alcatel-Lucent 7342 ISAM FTTU
supports the Internet group management protocol
(IGMP) proxy/snooping function within the P-OLT
and ONT, permitting dynamic multicast of video
channels. The GigE/10GigE interfaces at each P-OLT,
the GPON interfaces, and the ONTs receive and forward
IP video traffic using multicasting. In addition to IP
video, the Alcatel-Lucent 7342 ISAM FTTU system
includes an optional integrated RF overlay solution for
video services. A video optical line terminal (V-OLT)
is used to amplify the video signal using erbium-doped
fiber amplifiers (EDFAs) for transmission downstream.
Service Access
With the Alcatel-Lucent 7342 ISAM FTTU solution,
you can also deliver a full bundle of services — voice,
data, and video — over a single fiber cable to any
residential subscribers — for indoor or outdoor
deployment — whether these subscribers are living
in single family units (SFUs) or multi-dwelling units
(MDUs). Moreover Alcatel-Lucent ONTs are compliant
with ITU-T standards and managed through an ONT
management and control interface (OMCI).
The Alcatel-Lucent 7342 ONT O-Series is designed
to deliver triple play services to single-family home
owners and Small Office Home Office owners that need
a telco demarcation point outside the home or office.
The ONT O-Series is a temperature-hardened unit
ready for outdoor deployment with battery backup
for lifeline services. The SFU versions of the O-Series
include two or four POTS interfaces and one or two
Ethernet or Gigabit Ethernet interfaces and one optional
F connector for RF video. In addition, an optional
MOCA (Multimedia over Coax Alliance) interface is
included for Ethernet over existing coax home wiring.

9Alcatel-Lucent 7342 ISAM FTTU
The Alcatel-Lucent 7342 LP-
MDU-ONTs are designed to provide
services to residential subscribers
in MDUs, such as apartment build-
ings or multi-tenant units such as
business buildings. The ONT can
connect up to 12 subscribers over
telephone or Ethernet cables. Its
low profile (3.844” x 17.43” x 12”)
design is ideal for installation in
terminal rooms in a rack, closet,
or outdoor cabinet. Two different
versions of the LP-MDU-ONT can
be used depending on the in-build-
ing cable interface required. The
LP-MDU-V ONT provides VDSL2
interfaces over telephone wires and
the LP-MDU-G ONT provides
Gigabit Ethernet interfaces over
Category 5/6 wires. Both versions
include 24 POTS interfaces along
with a coax interface with high
launch power that you can use to
distribute RF video.
The Alcatel-Lucent 7342 ONT
I-Series is designed to deliver triple
play services to single-family homes.
I-Series ONTs can either be mount-
ed inside the home or placed free-
standing on a desk, and can be
equipped with a battery backup
for lifeline services. They include
two POTS interfaces for voice,
and up to two Ethernet or Gigabit
Ethernet interfaces for high-speed
data and one F connector for video.
The Alcatel-Lucent 7342 ONT-B
Series is designed to deliver triple
play services to businesses that
need a telco demarcation point
outside the business site. The
B-Series ONTs are temperature-
hardened and ready for outdoor
deployment with battery backup.
They include eight POTS inter-
faces for voice, and one Gigabit
Ethernet interface, two DS1 or EI
interfaces for TDM services, and one
optional F connector for RF video.
A scalable architecture, full GPON
standards compliance with unmatched
performance, IP multiservice, and a
common management system for all access
networks make the Alcatel-Lucent 7342
ISAM FTTU your most cost-effective optical
access solution on the market today.
The Alcatel-Lucent ONTs support
Internet gateway message protocol
(IGMP) snooping for Internet pro-
tocol television (IPTV) multicast,
and ITU-T H.248/session initiation
protocol (SIP) for voice loop
emulation and softswitch-based
voice services.

End-to-End Solution
10 Alcatel-Lucent 7342 ISAM FTTU
THE ALCATEL-LUCENT FTTU PRODUCT SUITE
CONSISTS OF THE FOLLOWING KEY COMPONENTS:
• Alcatel-Lucent 7342 Packet Optical Line Terminal (P-OLT)
• Alcatel-Lucent 7342 Indoor Optical Network Terminal
(ONT I-Series)
• Alcatel-Lucent 7342 Outdoor Optical Network Terminal
(ONT O-Series)
• Alcatel-Lucent 7342 Low Profile Multiple Dwelling Unit
Optical Network Terminal (LP-MDU-ONT)
• Alcatel-Lucent 7342 Business Optical Network Terminal
(ONT B-Series)
• Alcatel-Lucent 5526 Access Management System (AMS)
• Alcatel-Lucent 5523 ADSL Work Station (AWS)
• Alcatel-Lucent 5528 Web-Based Access Manager (WAM)
• Alcatel-Lucent FS3000 and FS5000 Platform
• Video Optical Line Terminal (V-OLT)
• Genband G6 Universal Media Gateways
The Alcatel-Lucent 7342 ISAM FTTU is part of a complete end-to-end
solution for optical broadband from Alcatel-Lucent. Leveraging our
leadership in broadband access, Alcatel-Lucent has developed a
solution with a robust feature set ideal for mass deployment. It uses
a cost-effective, standards-compliant passive optical network that
revolutionizes your access network infrastructure. It gives you a long-
term competitive edge and delivers a range of broadband services
to subscribers over a single optical fiber.

11Alcatel-Lucent 7342 ISAM FTTU
21st Century Access from a Leader in Access
Optical technology has been
successfully deployed within the
network core to increase capacity.
The access network — the “last
mile” — has remained a bottleneck,
limiting the deployment of new
services. Demand for broadband
services has resulted in DSL tech-
nologies being deployed on the
existing copper-based access net-
work to increase capacity. As
you look to the future, you want
optical technology in the last mile
to provide the assurance that your
networks will support your needs –
both today and tomorrow.
As new homes and communities
are built, or aged plants are refur-
bished, fiber access is becoming
the preferred choice for build-out
by traditional and alternative
carriers alike. Your capital invest-
ment is more than justified by the
long-term operational cost savings
and increased revenues gained while
leveraging an access network with
virtually limitless capacity.
Alcatel-Lucent understands your
access networks. Alcatel-Lucent
understands fiber optics. An
Alcatel-Lucent 7342 ISAM
FTTU solution, the world’s first
standards-compliant GPON system,
is sure to provide your network with
years of profitable service.
Global Market and
Technology Leadership
Alcatel-Lucent is the world leader
in access systems for both digital
subscriber line (DSL) and digital
loop carrier (DLC) equipment. With
over 25 years of access deployment
experience and a demonstrated
track record of successful broadband
deployment, Alcatel-Lucent remains
a proven choice for carrier-grade
access solutions. Alcatel-Lucent
has designed the 7342 ISAM FTTU
system to provide a future-proof
all-optical access solution to let
you offer any service mix your
subscribers demand while realizing
the benefits of increased reliability
and lower maintenance expenses.
Alcatel-Lucent has led the industry
from technology innovation to
standardization. It is a key member
of the ITU-T and FSAN standards
bodies and a major contributor to
the GPON standards. Alcatel-
Lucent’s innovation and expertise
demonstrate its commitment to
providing you with a long-term
strategic advantage in your access
network — the access network for
the next one-hundred years.

www.alcatel-lucent.com
Alcatel, Lucent, Alcatel-Lucent and Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other
trademarks are the property of their respective owners. The information presented is subject to
change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein.
© 2007 Alcatel-Lucent. All rights reserved. 23009 (06)
