Alcatel-Lucent Metrospan Edge 1692 User manual

Alcatel-Lucent
1692 Metrospan Edge
Versatile Wavelength Division
Multiplexing Solution for
Enterprise and Metro Access
Optical Transport Networks

2 Alcatel-Lucent 1692 Metrospan Edge
The Alcatel-Lucent 1692 Metrospan Edge (MSE) is a compact and
competitively priced wavelength division multiplexing (WDM) solution
designed for cutting-edge multiprotocol transport systems. In metro-
politan areas, the explosion of high-bandwidth services, such as triple
play, video, 3G mobile, storage area network (SAN) extension and
enterprise Gigabit Ethernet (GigE), has dramatically increased the
bandwidth required by telecom providers and vertical markets.
The Alcatel-Lucent 1692 MSE offers an excellent solution to meet this
challenge for service providers in metropolitan access networks, small
city core networks and private networks such as SANs. As the world
leader in optical networks, Alcatel-Lucent has deployed the Alcatel-
Lucent 1692 MSE in enterprise, core and access networks worldwide.

3Alcatel-Lucent 1692 Metrospan Edge
Customer Requirements
Today’s competitive environment places taxing
demands on service providers, forcing them to
drive down costs and reduce the complexity
of their networks and
operations. Bandwidth-
intensive services such as triple play, video, 3G
mobile, SAN extension and enterprise GigE,
are already placing greater demands on these
networks. The Alcatel-Lucent 1692 MSE targets
metro access service providers as well as vertical
markets, and enterprises. Using WDM, the
Alcatel-Lucent 1692 MSE allows service pro-
viders and enterprises to meet continually
increasing bandwidth requirements by increas-
ing the capacity of each available optical fiber.
In addition, the Alcatel-Lucent 1692 MSE
simplifies network planning, speeds up wave-
length provisioning and eases the overall
maintenance load required for enterprise
and metro access optical transport networks.
An Entirely Optical Network
The Alcatel-Lucent 1692 MSE is part of Alcatel-
Lucent’s vision for an entirely optical network:
a network that provides all the functions of the
SONET/SDH layer including routing, wave-
length add/drop and survivability. The various
protocols present in metropolitan areas benefit
by having the Alcatel-Lucent 1692 MSE as the
common platform upon which to develop con-
nectivity and protocol requirements. The
Alcatel-Lucent 1692 MSE includes the same
winning features as those of the Alcatel-Lucent
WDM product family but with key differentiators
that further reduce purchasing and operating
costs. Figure 1 illustrates both the central office
and the compact versions of the Alcatel-Lucent
1692 MSE in a metro WDM network.
Eth
Eth
GE
FC
GE
Eth
FC
Business
Access
Business
Campus
Enterprise
Branch
Backbone
Network
Metro Access 25 Gb/s
Low Capacity Ring Metro Access 25 Gb/s or 10 Gb/s
High Capacity Ring
Metro Access
2.5 Gb/s or 10 Gb/s
High Capacity Ring
Enterprise 25 Gb/s
Low Capacity Private Links
SAN
Services
SONETSONET
or GigE
ADSL
Backhauling
Mobile
Backhauling
LAN
Extension
Enterprise
Branch
FC
FC
Enterprise HQ
Figure 1. A Metro WDM Network

4 Alcatel-Lucent 1692 Metrospan Edge
A Cost-optimized System
The Alcatel-Lucent 1692 MSE is a
cost-optimized coarse WDM (CWDM)
transport system designed to meet the
requirements of enterprise and metro
access networks. This means that the
service provider or enterprise can start
with (and pay for) only the number of
channels and associated equipment
identified by short-term forecasts.
As the forecast moves forward in time
and as demand increases, the capacity
and number of wavelengths can be
increased. Alcatel-Lucent further
reduces its customers’ initial costs
by using small form-factor pluggable
(SFP) laser diode modules that do
not need to be purchased until the
appropriate fibers are lit or new wave-
lengths are added. Over time, the
1692 MSE can easily be upgraded
(in situ) to the 1696 Metrospan,
allowing the introduction of dense
WDM (DWDM).
In addition to these low-cost SFP
modules, the Alcatel-Lucent 1692
MSE uses a sophisticated optical
mux/ demux unit that eliminates
the need for an expensive wavelength
controller. This provides enterprises
and network operators with a low-
cost CWDM system, perfectly suited
to short-haul and medium-haul
applications.
The Alcatel-Lucent 1692 MSE not
only provides reliable transport of new
revenue generating services for metro-
politan markets, but also offers a
low-cost solution for cost-sensitive
metropolitan access networks and
private networks. The Alcatel-Lucent
1692 MSE is a low-cost CWDM trans-
port system. It uses laser diodes spaced
at 20 nm, thereby relaxing require-
ments for the optical mux/demux
unit, and reducing the cost of com-
ponents. With the wide wavelength
range of CWDM, generally no
amplifiers are required for ranges
less than 80 km.

5Alcatel-Lucent 1692 Metrospan Edge
Benefits and Features
BENEFIT FEATURE FUNCTION
Low real estate and power requirements Class-leading compact size, minimal electrical Three rack unit physical shelf size; optical
power requirements and minimal heat generation components require minimal power
Bandwidth scalability at optimized cost Modular, incremental upgrades plus the option Increasing capacity requirements are
to upgrade to the 1696 Metrospan, thereby allowing addressed using the same platform to
a mixture of CWDM and DWDM on the same platform a answer various bandwidth needs
Spare parts reduction Tunable transponders; SFP modules Transponder tuning or SFP swap-out allows
new wavelength assignments at minimal costs
Cost efficient transport of sub-rate traffic Sub-rate multiplexing and grooming Concentration reduces the required number
of optical channels per source signal
Simple network design and reduced Flexible, modular 4xAny and backplane architecture; Simplified hardware installation;
forecast criticality simplified upscaling easier upgrades as forecasts evolve
Key Features
The Alcatel-Lucent 1692 MSE:
• Optimizes the transport of a bundle of signals, groomed according to a synchronous-
compliant frame structure, using dedicated TDM transponders
• Supports rapid roll-outs of new services
• Transparently transports multiple protocols (SONET/SDH, SAN, IP, video)
on a single wavelength
• Provides optical layer protection (e.g., optical multiplexing section protection [OMSP]
and optical channel subnetwork connection protection [OCH-SNCP])
With so much functionality and scalability packed into a 3 rack unit (RU) (5¼ inch) compact
shelf, the Alcatel-Lucent 1692 MSE stands out from its competition. First, it is designed to
minimize initial CAPEX and support ever-growing traffic volumes on an incremental basis.
Second, its well-known and trusted 4xAny/2xGE-FC concentrators groom traffic and fill
transport pipes in a flexible and non-blocking manner. Third, native signals such as IP, IP
video, ATM and data are transported transparently to the end user with optical channel
protection/restoration safeguards. And fourth, class-leading scalability allows the Alcatel-Lucent
1692 MSE solution to grow to support sixteen discrete ITU wavelengths, enabling an unsur-
passed per-fiber bandwidth yield.
Table 1 lists the benefits, features and functions of the Alcatel-Lucent 1692 MSE.
Table 1. Alcatel-Lucent 1692 MSE Benefits, Features and Functions

6 Alcatel-Lucent 1692 Metrospan Edge
The Alcatel-Lucent 1692 MSE sup-
ports up to 16 wavelengths sustaining
variable-rate and fixed-rate optical
interfaces, capable of accepting a
broad range of data rates. Dedicated
TDM concentrators (4xAny card and
2xGE-FC card) are available to opti-
mize transportation of a bundle of
signals, groomed accordingly to a syn-
chronous frame structure. These cards
reduce the cost of each client service
and maximize optical channel usage.
The Alcatel-Lucent 1692 MSE’s
4xAny concentrator card can multi-
plex up to 4 low-speed client signals
(for example OC-3/12, ATM1/4, FE,
GE, FC etc.) to one OC-48 signal.
The 2xGE-FC card multiplexes
two GigE or FC signals using the
transparent-mapped generic framing
procedure (GFP-T) standard. A small
number of backup cards, (compact
in size and low in power consumption)
keep the operation, administration,
and maintenance (OAM) costs of
the Alcatel-Lucent1692 MSE low.
Tributary cards for the Alcatel-Lucent
1692 MSE have hot plug-and-play
optics; this permits customization of
the transponder, resulting in increased
flexibility of the product.
Technical Superiority

7Alcatel-Lucent 1692 Metrospan Edge
Fully scalable from two wavelengths
up to 16, the Alcatel-Lucent 1692
MSE allows service providers to
purchase only the capacity required
and then to increase capacity only
as consumer demand increases. That
is, as requirements change over time,
the system’s manageability and func-
tionality can be adapted in incre-
mental steps.
Adaptable solutions allow quick
reaction to rapidly changing market
conditions and ensure timely imple-
mentation of new services. The
Alcatel-Lucent 1692 MSE ensures
that combinations of very different
client services (SONET/SDH, SAN,
IP, video) can be transported trans-
parently on a single wavelength,
without the need to upgrade the
whole network; this shortens the
overall time-to-market and increases
the number of services that can be
delivered. Each wavelength can be
unidirectional or bidirectional. The
Alcatel-Lucent 1692 MSE tributary
cards feature hot plug-and-play optics,
so the user can customize provisioning
while the remainder of the NE is
under load.
Ultimate Scalability and Versatility

8 Alcatel-Lucent 1692 Metrospan Edge
The Alcatel-Lucent 1692 MSE sup-
ports point-to-point links and ring
networks with coarse optical add/drop
multiplexer (COADM) technology.
The terminal can support up to
16 wavelengths of unidirectional
transmission or 4 wavelengths of
one fiber bidirectional transmission.
The back-to-back terminal, which
normally is used as the hub node in
a ring network, can add/drop 16 wave-
lengths. The COADM node can
add/drop 1, 2 or 4 wavelengths for
unidirectional application, while
it adds/drops one channel for a one
fiber bidirectional application. There
are two types of CPE: one channel
CPEs and two channel CPEs; this
provides a cost-effective solution
when the remote network node has
only one channel.
Figure 2 shows a two fiber ring
network.
With the Alcatel-Lucent 1692 MSE,
data applications are easily implemented
and network expansions, based on
end-user demand, are simplified. Easy
to install, operate and maintain, the
Alcatel-Lucent 1692 MSE allows
enterprise and network operators
to simplify their overall deployment
process, directly improving both
CAPEX and OPEX. No amplification
is required for short-haul applications;
however if longer reaches are required,
electrical regeneration can be provided
for distances greater than 80 km.
With temperature-hardened compo-
nents, the Alcatel-Lucent 1692 MSE
can be installed in virtually any
network environment, from a
basement closet to a central office.
The Alcatel-Lucent 1692 MSE sup-
ports the following network topologies:
• Ring networks
• Point-to-point links
• CPE configuration in point-to-
point links
• CPE configuration in ring networks
Multiple Topologies and Configurations
Figure 2. Example of a Two Fiber Ring Network
OADM
GigE
OC-48OC-48
ESCON
OADM
CPE
Hub
OADM
OADM
CPE

9Alcatel-Lucent 1692 Metrospan Edge
The Alcatel-Lucent 1692 MSE provides a single, cost-optimized, managed solution
that supports different services, network topologies and traffic matrices, and is trans-
parent to protocols. It supports a mix of services with multi-rate tributaries and
pluggable optical interfaces, on both the client and WDM sides. Optical services
range from 125 Mb/s to 2.67 Gb/s. Compatible with 10 Gb/s services, the Alcatel-
Lucent 1692 MSE easily interfaces with all types of fiber and transmission
equipment, providing high flexibility through interfaces that are transparent
to the transmitted protocols.
The Alcatel-Lucent 1692 MSE is a robust platform offering signal restoration and
protection. Alcatel-Lucent believes that signal protection is necessary in all optical
transport systems, including applications in private networks and small core networks.
The Alcatel-Lucent 1692 MSE provides optical layer protection such as OMSP
and OCH-SNCP, which includes a 50 millisecond network recovery. For maintenance
purposes, it offers an integrated 8x8 switch on each transponder that enables electri-
cal protection and loopback operations on both the client side and the WDM side.
Simplified Provisioning, Guaranteed Reliability

10 Alcatel-Lucent 1692 Metrospan Edge
Summary
The Alcatel-Lucent 1692 MSE is a cost-effective CWDM
system intended for the metropolitan access and enterprise
markets to help providers deliver popular high-revenue,
bandwidth-intensive services, such as triple play, video,
3G mobile, SAN extension and enterprise GigE.
The Alcatel-Lucent 1692 MSE is able to multiplex up to
16 channels compatible with ITU G.694.2 CWDM grid
in a single network element (NE). It can be configured
as a terminal or optical add/drop multiplexer (OADM)
providing optical layer protection capabilities for both
point-to-point and ring topologies. It can be equipped
with the traffic concentrator 4xAny (multiplexes up to
four low-speed client signals into a 2.5 Gb/s SONET/SDH
signal) or 2xGE-FC (multiplexes two GigE or FC signals
using the GFP-T standard), reducing the cost of each
client service and maximizing optical channel usage.

11Alcatel-Lucent 1692 Metrospan Edge
Recognized World
Leader in Optical Networking
Alcatel-Lucent provides end-to-end communications solutions, allowing
service providers and enterprises to deliver any content type to any user type,
anywhere in the world.
Leveraging its long-term leadership in providing telecommunications network
equipment as well as its expertise in applications and network services,
Alcatel-Lucent enables its customers to focus on optimizing their service
offerings and revenue streams.
Alcatel-Lucent, as a recognized world leader in optical networking, is in a
unique position to help service providers navigate through current market
conditions. Its global reach and scale, combined with its local presence in
over 150 countries, has led to a deep understanding of global market dynamics
and the ability to anticipate local requirements.
Deployed extensively around the globe, the Alcatel-Lucent 1692 MSE provides
the flexibility and functionality required by today’s service providers and
enterprises, accelerating revenue generation and providing the dynamic
capabilities that combine to reduce operational expenses and improve
network performance.
For more information about our products and solutions, please visit
us on-line at www.alcatel-lucent.com

www.alcatel-lucent.com
Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other
trademarks are the property of their respective owners. The information presented is subject to change
without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein.
© 2007 Alcatel-Lucent. All rights reserved. WLN1103070824 (09)
