Alcatel 501 User manual

500
501
700
701
ONE TOUCH
COUVERTURE BE5 24/10/00 13:33 Page 1

USER’S
GUIDE
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 1

2
CONTENTS
Safety and precautions 4
1Your telephone 8
1 - 1 Keys 9
1 - 2 Status icons 10
1 - 3 Conventions used in this User’s Guide 11
2Getting started 12
2 - 1 Initial operation 12
2 - 2 Switching your phone on 14
2 - 3 Switching your phone off 15
2 - 4 Fitting the pocket clip 15
3First steps 16
3 - 1 Making a call 16
3 - 2 Receiving a call 16
3 - 3 Accessing your voice mail 17
3 - 4 Displaying your number 17
3 - 5 Accessing the functions and scrolling 18
3 - 6 Functions structure 19
3 - 7 Creating a directory file 21
3 - 8 Changing the ring tone 22
3 - 9 Reading your new short messages 23
4Directory 24
4 - 1 Accessing the directory 24
4 - 2 Creating a file 25
4 - 3 Options 27
4 - 4 Creating a new directory 28
4 - 5 Copying files 29
5Consult information 30
6Calls 32
6 - 1 Making a call 32
6 - 2 Receiving a call 34
6 - 3 During a call 35
7Call memory 38
7 - 1 Accessing the call memory and calling back 38
7 - 2 Options 39
8Short messages 40
8 - 1 Accessing short messages 40
8 - 2 Reading your short messages 41
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 2

3
8 - 3 Options 42
8 - 4 Writing a short message 43
8 - 5 Parameters 48
9Scheduler 50
9 - 1 Accessing the scheduler 50
9 - 2 Consulting your scheduler 50
9 - 3 Creating an appointment 51
9 - 4 Scheduling an alarm 52
9 - 5 Creating a task 53
9 - 6 Options 54
9 - 7 Description of scheduler icons 54
9 - 8 Configuring the scheduler 55
9 - 9 Advanced scheduler functions 56
10 Voice functions 58
10 - 1 Handsfree 58
10 - 2 Voice recognition 58
10 - 3 Voice memo 60
11 Mobile Internet 62
11 - 1 Accessing Internet services 62
11 - 2 Options 64
12 Calculator / Currency converter 66
12 - 1 Accessing the calculator and currency converter 66
12 - 2 Calculator 66
12 - 3 Currency converter 67
12 - 4 Currency selection 68
13 Menu 70
13 - 1 Services 70
13 - 2 Settings 75
13 - 3 Billing 80
13 - 4 Available memory 82
13 - 5 Security 83
14 Audios 84
14 - 1 Accessing the “Audios” function 84
14 - 2 Options 84
15 Personal key 86
15 - 1 Features offered by personal key 86
15 - 2 Setting the personal key 86
16 Warranty 88
16 - 1 Warranty 88
16 - 2 Information 90
17 Accessories 92
CONTENTS
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 3

4
SAFETY AND
PRECAUTIONS
We recommend that you read this chapter carefully
before use.
CONDITIONS OF USE
Switch the phone off before boarding an aircraft. Use could lead to legal action
against the user.
Switch the phone off when in health care facilities except in areas specified. Like
many other types of equipment now in regular use, mobile telephones can
interfere with other electric or electronic devices.
Persons with a medical device (such as a pacemaker, hearing aid, insulin pump)
should not carry the phone in a place close to the device.
When placing or receiving a call, persons with a pacemaker or hearing aid
should use the ear on the opposite side to the device.
Switch your phone off when near gas or flammable liquids.
Strictly obey all signs and instructions when in a fuel depot, service station,
chemical plant or any potentially explosive atmosphere.
Do not let small children use the phone without supervision.
Do not attempt to open or repair it yourself.
Do not expose the phone to unfavourable environmental conditions (humidity,
rain, ingress of liquid, dust, sea air, etc.)
Outside the manufacturer’s recommended operating temperature range
(-20° C +55° C), the legibility of the phone’s display may be impaired and the
battery may not work, though this is temporary.
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 4

5
CONDITIONS OF USE FOR BATTERIES:
Only use batteries, battery chargers and accessories approved by the
manufacturer. The manufacturer disclaims any liability for damage caused by
use of other batteries, chargers or accessories.
Before removing the battery from your phone, please make sure that the
phone is switched off.
Do not attempt to open the battery because it contains chemical substances.
Do not dispose of used batteries in household waste.
Batteries must be disposed of in accordance with locally applicable
environmental legislation.
Do not place battery in fire or in water.
Do not store above 60 ºC.
Do not allow + and - terminals to contact each other. Keep them away from
metal objects as nickel or coins.
Charge the battery in an area where the temperature is from 0º C to 45º C.
The battery discharges below -20º C and above 60º C.
The battery may discharge if it is not used for a sufficiently long period of time.
Do not let small children handle batteries without supervision.
SAFETY AND PRECAUTIONS
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 5

6
TRAFFIC SAFETY:
Remember to always check whether local legislation allows operation of a
mobile phone while driving a vehicle.
It is vital to connect the phone to an external antenna when it is used in a
vehicle. Electromagnetic waves may otherwise interfere with the vehicle
electronics.
Check that the antenna is mounted and located away from the driver and
passengers or separated from them by a metal screen (e.g. car roof).
We recommend that you park your car before using the phone. However if you
intend to use your phone while driving, you must use it connected to the “Full-
duplex handsfree vehicle kit” (cf. chapter entitled “Accessories”, page 92).
Electromagnetic waves from the telephone may interfere with the operation of
the car’s electronic systems such as anti-lock brakes (ABS), airbags, etc.
Check with your car dealer or car manufacturer that these systems are
adequately shielded from mobile phone RF energy before using it in the vehicle.
Always avoid placing the phone on the dashboard.
GENERAL INFORMATION:
As with all radio transceivers, your mobile phone emits electromagnetic waves.
This phone conforms to international regulations when used under normal
conditions and in accordance with the instructions contained herein.
There has been speculation about the safety of mobile phones.
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 6

7
SAFETY AND PRECAUTIONS
Several expert groups belonging to or having been appointed by official national
or international bodies have analysed all the existing publications and, to date,
have concluded that there is a lack of evidence as to any credible or convincing
hazardous effects of mobile phones on health.
These studies have, in particular, focused on the fact that mobile handsets
receive and emit electromagnetic waves via their antenna.
Experts from such organizations as the European Commission and the
International Commission on Non-Ionising Radiation Protection (ICNIRP) have
established thresholds on a handset’s emissions to the human body. The main
measurement standard is known as SAR (Specific Absorption Rate). ALCATEL
can formally state that all its GSM mobile phones generate a SAR that is
significantly below these thresholds.
Furthermore, ALCATEL actively supports national and international research
into this issue carried out by authoritative and independent organizations.
If you still have concerns on this issue, you may use your mobile phone with a
headset, or use the handsfree feature integrated in the phone and, while
driving, use the full-duplex handsfree vehicle kit (cf. chapter entitled
“Accessories”, page 92).
The part numbers of these accessories can be found in the “Accessories”
chapter on page 92.)
The manufacturer disclaims any liability for damage which may
result as a consequence of improper use or use contrary to the
instructions contained herein.
Icons and other illustrations shown in this User’s Guide are for information
only.
07/02/2000
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 7

8
Personal
key
Off-hook
MENU
Scroll
Confirm
Microphone
Flap (1)
Loudspeaker
Your
number
Voice mail
Activate
voice
functions
Delete
Lock keypad
(long keypress)
Switch on
Switch off
Hang up
(2)
YOUR TELEPHONE
06-09
2000
Network name
1
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 8

9
1
YOUR TELEPHONE
Switch on/switch off (long keypress)
Hang up (short keypress)
Off hook
Access call memory (Redial)
Access the MENU (directory, short messages, etc.)
Confirm an option
Volume control
Scroll to select an option
Delete (short keypress)
Return to standby screen (long keypress)
Lock the keypad (long keypress)
Use voice functions:
•Activate built-in “handsfree”
(short keypress during a call)
•Activate “voice recognition”
(short keypress in standby mode)
•Record “voice memos”
(long keypress in standby mode)
Your personal key
Display your number (long keypress)
(1) Flap (depending on your model): to open flap, press
button (2) on the left-hand side of the phone. You can also
go off hook by opening the flap and hang up by closing it.
1 • 1 Keys
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 9

10
Icons and other illustrations shown in this User’s Guide are for
information only.
Battery charge level.
Call forwarding activated: your calls are forwarded
(see Chapter 13, page 70).
Consult information: Consult your voice mail,
unanswered incoming calls, unread short messages and
voice memos.
Short message list (SIM card) is full: your terminal
cannot store any more messages. You must access the
short message list and delete at least one message.
Appointment scheduled. (See Chapter 9, page 55).
Signal strength indicator.
Icons displayed at the bottom of the screen:
Keypad locked.
Vibrating system activated. (See Chapter 14, page
85).
1 • 2 Status icons
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 10

11
1
YOUR TELEPHONE
You can use the scroll key to move between your
phone’s options in four directions: up, down, left,
right.
The following symbols are used in the text which follows:
Briefly press the centre of the scroll key to
confirm an option.
Move the scroll key left or right.
Move the scroll key up or down.
Use the keypad keys to enter digits and/or letters.
1 • 3 Conventions used in this User’s Guide
BE5 - ANGLAIS (FLASHER) 24/10/00 14:42 Page 11

12
Open the cover Slide the SIM card
into its compartment
Close the cover
Insert the battery Close the battery Click into place
You must insert your SIM card in order to use your phone.
2 • 1 Initial operation
Insert the SIM card
Fit the battery
GETTING STARTED
2
CLICK
BE5 - ANGLAIS (FLASHER) 24/10/00 14:43 Page 12

13
2
GETTING STARTED
Connect the battery
charger
Wait for the on-
screen indicator to
stop flashing
Disconnect the
battery charger
once charging is
complete
A beep will sound when charging begins.
It takes a few seconds before the charging indicator icon starts
to flash (charging time may be longer with a new battery, or
when the battery level is very low).
The mains socket-outlet must be close to the phone and easily
accessible.
When you first use your phone you must charge the
battery for approximately 3 hours.
Charge the battery
BE5 - ANGLAIS (FLASHER) 24/10/00 14:43 Page 13

14
PIN code?
____
06-09
2000
Network name
If you do not know your PIN code, please contact your
network operator.
Do not leave your PIN code near your phone and keep your
SIM card in a safe place when you are not using it.
Switch your
phone on
(long keypress)
Enter your
PIN code
Confirm Standby screen
You are prompted to enter the time and the date, enter new data
if necessary, then confirm by .
If cell broadcast messages are displayed, use the key to
browse through them in full or press the key to return to
the standby screen.
While the phone is searching for a network, <<<–>>> is
displayed (???-??? is displayed if your SIM card is rejected by the
network, in this case please contact your operator).
2 • 2 Switching your phone on
BE5 - ANGLAIS (FLASHER) 24/10/00 14:43 Page 14

15
2
GETTING STARTED
OK OK
The pocket clip helps you keep your telephone in your shirt
or jacket pocket.
The pocket clip is not designed to be worn on a belt.
Press the key (long keypress).
2 • 4 Fitting the pocket clip
2 • 3 Switching your phone off
This accessory is only available on certain models.
BE5 - ANGLAIS (FLASHER) 24/10/00 14:43 Page 15

16
FIRST STEPS
Dial the
number
Make the
call
Talk Hang up
Karine
Incoming call(1) Ta k e
the call
Talk Hang up
Flap (depending on your model): to open the flap, press the
button on the left-hand side of the phone. You can also
answer a call by opening the flap.
(1) The caller’s number or name is displayed if it is provided
by the network (check the availability of this service with
your operator).
In order to make or receive a call, you must switch your phone
on.
If you make a mistake, use the key to delete digits.
3 • 1 Making a call
3 • 2 Receiving a call
Hello
Hello
3
BE5 - ANGLAIS (FLASHER) 24/10/00 14:43 Page 16

17
3
FIRST STEPS
Voice mail
Call ?
(c) to cancel
Access voice mail
(long keypress)
Make the call
To use your voice mail abroad, contact your operator
before setting out on your trip.
The network provides a voice mail service to ensure that you
do not miss any calls: it works like an answering machine which
you can interrogate at any time.
If your operator’s voice mail access number is not shown, dial
the number that your operator supplied to you. To later modify
this number see the “Voice Mail” option in the “Menu”, page
75.
You can display your own number by pressing the key
(long keypress).
If your number is not displayed, enter it and confirm by pressing
the key.
To later modify it, see the “Your number” option in the
“Menu”, page 75.
3 • 3 Accessing your voice mail
3 • 4 Displaying your number
BE5 - ANGLAIS (FLASHER) 24/10/00 14:43 Page 17

18
Directory
Events
Select a function Confirm
Fr d rique
Hlne
Sophie
St phanie
The functions can be accessed from the standby screen by
pressing the key.
This takes you to the following screen:
You can scroll horizontally to the various icons:
To access all the proposed options, press .
3 • 5 Accessing the functions and scrolling
Accessing the functions
Directory
Choosing a function
Scrolling within a function
BE5 - ANGLAIS (FLASHER) 24/10/00 14:43 Page 18

19
3
FIRST STEPS
Directory:
Manage your phone numbers. For each name,
you can enter several phone numbers (home,
mobile, office, etc.).
You can create your own directories.
Consult information (Events):
Access your voice messages, unanswered
incoming calls, unread short messages and voice
memos.
Scheduler:
Manage your timetable by organizing all your
appointments and important events.
The information in the directory and scheduler can be
transferred to a computer by using the DATA/PC Sync kit
(cf. “Accessories”, page 93). For more information, visit our
website www.alcatel.com.
Press (short keypress).
Return to previous screen
Return to standby screen
Press (long keypress).
3 • 6 Functions structure
BE5 - ANGLAIS (FLASHER) 24/10/00 14:43 Page 19
