Alcatel one touch Pop STYLE 5022N User manual

1
5022N
Quick Reference Guide
For more information about how to use your mobile phone, please
visit www.alcatelonetouch.us to consult the FAQs.
ALCATEL ONETOUCH would like to thank you for your purchase.
Our goal is to provide you with a high-quality mobile communication
experience.
English - CJB1DH4ALAAA

2
www.sar-tick.com
This product meets applicable
national SAR limits of 1.6 W/kg. The
specific maximum SAR values can be
found in the RADIOWAVES section
of this user guide.
When carrying the product or using
it while worn on your body, either
use an approved accessory such as
a holster or otherwise maintain a
distance of 10 mm from the body to
ensure compliance with RF exposure
requirements. Note that the product
may be transmitting even if you are
not making a phone call.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when
holding your device near your ear while the loudspeaker
is in use.
Indice
1 Your mobile��������������������������������������������������������������������� 3
2 Text input ���������������������������������������������������������������������� 14
3 Phone call ���������������������������������������������������������������������� 16
4 Contacts ������������������������������������������������������������������������ 18
5 Messaging����������������������������������������������������������������������� 18
6 Email ������������������������������������������������������������������������������ 20
7 Getting connected�������������������������������������������������������� 21
8 Find my location using GPS satellites������������������������ 24
9 Data backup ������������������������������������������������������������������ 25
10 Factory data reset �������������������������������������������������������� 25
11 Applications & Internal storage���������������������������������� 26
12 Upgrade ������������������������������������������������������������������������� 27
Safety and use������������������������������������������������������������������������� 28
General information �������������������������������������������������������������� 38
Troubleshooting���������������������������������������������������������������������� 41

3
1 Your mobile ������������������
1�1 Keys and connectors
Headset connector
Micro-USB
connector
Back key
Home key
Recents key
Touch screen
Front Camera

4
Volume up
Volume down
Camera Flash/Flashlight
Power
key
Recents key
• Recent apps� Touch to open a list of thumbnail images
of apps you've worked with recently. Touch it to open
an app. Swipe it left or right to remove a thumbnail
from the list.
Home key
• From any application or screen, touch to return to the
Home screen.
• Touch and hold to open Google search.
• Double-click the home button to access the camera
application.
Back key
• Touch to go back to the previous screen, or to close
a dialog box, options menu, the notification panel, etc.

5
Power key
• Press: Lock the screen/Light up the screen.
• Press and hold: Show the popup menu to select from
Power off/Reboot/Airplane mode.
• Press and hold the Power key and Volume down key
to capture a screenshot.
• Press and hold the power key for at least 8 seconds to
force reboot or hold it longer to power off.
Volume Keys
• Under call mode, adjusts the earpiece or headset
volume.
• In Music/Video/Streaming mode, adjusts the media
volume.
• In general mode, adjusts the ringtone volume.
• Mutes the ringtone of an incoming call.
• In camera preview mode, press Volume up or down
key to enter burst shoot.

6
1�2 Getting started
1�2�1 Set up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Power off your
phone before inserting or removing the SIM card.
Place the SIM card with the chip facing downwards and slide it into
its housing. Make sure that it is correctly inserted. To remove the
card, press and slide it out.
For this phone, both SIM1 and SIM2 can support 2G and 3G
networks. If both of them are 3G SIM cards, only one card
can support 3G network.Your phone only supports micro-
SIM card. Do not attempt to insert other SIM types like mini
and nano cards, otherwise you may damage your phone.

7
Installing or removing the battery
Please power off your phone before removing the battery.
• Insert and click the battery into place, then close the cover.
• Unclip the cover, then remove the battery.
Installing or removing the microSD card
To install, insert the microSD card first, and then place it into the slot
with the gold contact facing down.To remove the external microSD
card, slide and take it out from the slot.
Charging the battery
Connect battery charger to your phone and plug into the socket.
If the battery is very low, there will be no indication that
power is being received until the charge is sufficient to show
the charging status bar. To reduce power consumption and
energy waste, once the battery is fully charged, disconnect
your charger from the plug; switch off Wi-Fi, GPS, Bluetooth
or background-running applications when not in use; reduce
the backlight time, etc.

8
1�2�2 Power on your phone
Hold down the Power key until the phone powers on. It will take a
few seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you should set the following
options: Language, Google Account, etc.
Even if no SIM card is installed,your phone will still power on and you
will be able to connect to a Wi-Fi network.
1�2�3 Power off your phone
Hold down the Power key from the Home screen until the phone
options appear, select Power off.
1�3 Home screen
You can move all of the items (applications, shortcuts, folders and
widgets) you use most frequently to your Home screen for quick
access.Touch the Home key to switch to the Home screen.
Touch to enter application list.
Status bar
• Status/Notification indicators
• Touch and drag down to open
the notification panel.
Touch an icon to open an application,
folder, etc.
Favorite tray applications
• Touch to enter the application.
• Touch and hold to move or
change applications.
Search bar
• Touch to enter text search screen.
• Touch to enter voice search screen.
The Home screen is provided in an extended format to allow more
space for adding applications, shortcuts, etc. Slide the Home screen
horizontally left and right to get a complete view.

9
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Touch and Hold
Touch and hold the item to enter the available options.
Drag
Place your finger on the screen to drag an object to another location.
Slide/Swipe
Slide the screen up and down to scroll through the applications,
images, web pages, etc.
Flick
Similar to swiping, but flicking makes it move quicker.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways to have a better view.
1�3�2 Status bar
From the status bar, you can see both phone status (to the right side)
and notification information (to the left side).

10
Status icons
GPRS connected Bluetooth is on
GPRS in use Connected to a
Bluetooth device
EDGE connected Speakerphone is on
EDGE in use Roaming
3G connected Headset connected
3G in use No SIM card installed
HSPA+ connected Vibrate mode
HSPA+ in use Battery is very low
Signal strength Battery is low
Wi-Fi is on Battery is partially
drained
Connected to a Wi-Fi
network Battery is full
Airplane mode Battery is charging
No signal GPS is on
Portable Wi-Fi hotspot
is on Connected to VPN
Alarm is set

11
Notification icons
New Gmail message Missed call
New Email message Call forwarding is on
New text or multimedia
message Song is playing
Problem with SMS or
MMS delivery Radio is on
New Google Hangouts
message Uploading data
New voicemail Download finished
Upcoming event An open Wi-Fi network
is available
Screenshot captured Phone is connected via
USB cable
Both USB tethering and
portable hotspot are on System update available
USB tethering is on
Carrier data use
threshold approaching
or exceeded
More notifications are
hidden

12
Touch and drag down the Status bar to open the Quick settings panel
or Notification panel.Touch and drag up to close it. When there are
notifications, you can touch them to access notifications directly.
Notification panel
When there are notifications, touch and drag down the Status bar
to open the Notification panel to read more detailed information.
Touch to clear all event–based
notifications (other ongoing
notifications will remain).
Touch to switch to the Quick settings
panel.
Quick settings panel
Touch and drag down the Notification panel or touch to open
the Quick settings panel. You can enable or disable functions or
change modes by touching the icons.
Touch to enter user screen.
Touch to access the Settings, where you
can set more items.

13
1�3�3 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by
creating a variety of patterns, PIN or password etc.
1�3�4 Personalize your Home screen
Add
You can long press a folder, an application, or a widget to activate the
Move mode and drag the item to any Home screen.
Reposition
Long press the item to be repositioned to activate the Move mode
and drag the item to the desired position and release.You can move
items both on the Home screen and the Favorite tray. Hold the icon
on the left or right edge of the screen to drag the item to another
Home screen.
Remove
Long press the item to be removed to activate the Move mode. Drag
the item up to the top of the icon.
Create folders
To improve the organization of items (shortcuts or applications) on
the Home screen, you can add them to a folder by stacking one item
on top of another.To rename a folder, open it and touch the folder’s
title bar to input the new name.
Wallpaper customization
Touch Settings on the applications screen then touch Display\
Wallpaper to customize wallpaper.
1�3�5 Volume adjustment
You can set the ringer, media and phone ringtone volumes to your
preference by pressing the Volume up/down key, or touching
Settings\Sound & notification\Alarm volume or Ring volume
to set the volume.
1�3�6 Application tab
Touch from the Home screen to enter the applications list.
To return to the Home screen, touch the Home key.

14
Consult recently-used applications
To consult recently-used applications, you can touch the Recents
key.Touch a thumbnail in the window to open the related application.
Touch one thumbnail and slide left or right to delete it.
2 Text input����������������������
2�1 Using Onscreen Keyboard
Onscreen Keyboard settings
Touch Settings\Language & input, touch the keyboard you want
to set up and a series of settings will become available for your
selection.
Adjust the Onscreen Keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen Keyboard
orientation. You can adjust it by changing the settings (Touch
Settings\Display\When device is rotated�
2�1�1 Android keyboard
Touch to switch
between numeric
keyboard and
alphabetic on MS.
Long press to
select symbols.
Touch to enter
text or numbers.
Touch to input comma;
Long press to show
input options.
Touch to switch
"abc/Abc" mode;
Long press to
switch "abc/ABC"
mode.

15
2�1�2 Swype keyboard
Press and hold to
open settings.Touch once to start a
new line.
Touch to input space.
Touch to enter text
or numbers.
Drag down the
Status bar to open
the notification panel
to switch keyboards.
Touch to switch
between symbol and
numeric keyboard.
Touch to switch
between "abc/
Abc" mode.Touch
& hold to switch
between "abc/
ABC" mode.
Switch keyboards from the messaging screen
On messaging screen, drag down the Status bar to open the
notification panel.
From the Notification panel, touch Select input method, you
can switch from Swype keyboard to Android keyboard or Google
Voice typing, etc.
2�2 Text editing
You can edit the text you have entered.
• Touch and hold or double touch the text you would like to edit.
• Drag the tabs to change the highlighted selection.
• The following options will show: Select all , Cut , Copy
and Paste .
• Touch the icon to go back without any action.

16
3 Phone call�����������������
3�1 Placing a call
To make a call when the phone is active, go to the Home screen and
touch the Phone icon in the Favorites tray.
Slide to access the
RECENTS and
CONTACTS.
Touch to display
keyboard.
Touch and
hold to access
voicemail.
Display the
suggested
number(s).
Enter the desired number from the keyboard directly and touch
to place the call or select a contact from CONTACTS or
RECENTS by sliding or touching tabs, then choose your target SIM
card to make the call.
The number you entered can be saved to Contacts by touching
and then touching Create new contact.

17
If you make a mistake, you can delete the incorrect digits by
touching .
To hang up a call, touch .
3�2 Answering or rejecting a call
When you receive a call:
• Slide the icon to the right to answer;
• Slide the icon to the left to reject;
• Slide the icon upwards to reject the call by sending a preset
message.
To mute the ringtone volume of an incoming call, press the Volume
up/down key.
3�3 Consulting your call History
You can access your call memory by touching RECENTS tab
from the Phone screen to see Missed calls, Outgoing calls and
Incoming calls.

18
4 Contacts �������������������
You can see and create contacts on your phone and synchronize
these with your Gmail contacts or other applications on the web
or on your phone.
4�1 Adding a contact
Touch the on the Home screen, then touch the icon in the
contacts list to create a new contact.
4�2 Synchronizing contacts in multiple
accounts
Contacts, data, or other information can be synchronized from
multiple accounts, depending on the applications installed on your
phone.
5 Messaging �����������������
You can create, edit, and receive SMS and MMS with this phone.
To open your Messaging, go to the Home screen and touch the
Messaging icon in the Favorites tray.
To check messages stored in your SIM card, touch the
icon from the Messaging screen,then touch Settings\Text
message (SMS)\Manage SIM card messages

19
5�1 Write message
On the message list screen, touch the new message icon to write
text/multimedia messages.
Touch to create a new message.
• Touch to see the whole message thread.
• Touch & hold to activate delete mode.
Sending a text message
Enter the mobile phone number of the recipient in the Type name
or number bar or touch to add recipients and touch the Type
text message bar to enter the text of the message.Touch the
icon to insert emotions or icons. When finished, touch to send
the text message.
An SMS of more than 160 characters will be charged as
several SMS. Specific letters (accent) will also increase the
size of the SMS.This may cause multiple SMS to be sent to
your recipient.
Sending a multimedia message
MMS enables you to send video clips, images, photos, animations,
slides, and sounds to other compatible phones and email addresses.
An SMS will be converted to MMS automatically when media files
(image, video, audio, slides, etc.) are attached or Subject or email
addresses added.

20
6 Email�������������������������
Other than your Gmail account, you can also set up external POP3
or IMAP email accounts in your phone.
To open Email, go to the Home screen and touch the Email icon in
the Favorites tray.
An email setup wizard will guide you through the steps to set up
an email account.
• Enter the email address and password of the account you want
to set up.
• Touch NEXT. If the account you entered is not provided by
your service provider in the phone, you will be prompted to go
to the email account settings screen to enter settings manually.
Alternatively, you can touch MANUAL SETUP to directly enter
the incoming and outgoing settings for the email account you are
setting up.
• Enter the account name and display name in outgoing emails.
• To add another email account, you can touch the icon and
Settings.Touch Add account to create.
To create and send emails
• Touch the icon from the Inbox screen.
• Enter recipient(s) email address (es) in the To field.
• If necessary, touch the icon beside To field to add Cc/Bcc to
add a copy or a blind carbon copy to the message.
• Enter the subject and the content of the message.
• Touch to add an attachment.
• Finally, touch to send�
• If you do not want to send the mail right away, you can touch the
icon and Save draft keys or touch the Back key to save a copy.
