Alcatel POP 3 5054S User manual

1
English - CJB35HEWFAAA
Quick Start Guide
Thank you for buying ALCATEL ONETOUCH 5054S.We hope you
will enjoy your high-quality mobile communication experience.
For more information about how to use your cellphone, please visit
www.alcatelonetouch.com to download the complete user manual.

TM
5054S

2
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen
at high volume levels for long periods. Exercise
caution when holding your device near your ear
while the loudspeaker is in use.
www.sar-tick.com
This product meets applicable national SAR
limits of 1.6 W/kg. The specific maximum SAR
values can be found on page 30 of this user
guide.
When carrying the product or using it while
worn on your body, either use an approved
accessory such as a holster or otherwise
maintain a distance of 15 mm from the body
to ensure compliance with RF exposure
requirements. Note that the product may
be transmitting even if you are not making a
phone call.
Table of Contents
1 Your mobile��������������������������������������������������������������������� 3
2 Text input ���������������������������������������������������������������������� 14
3 Phone call ���������������������������������������������������������������������� 15
4 Contacts ������������������������������������������������������������������������ 17
5 Messaging����������������������������������������������������������������������� 18
6 Email ������������������������������������������������������������������������������ 19
7 Getting connected�������������������������������������������������������� 20
8 Find my location using GPS satellites������������������������ 22
9 Data backup ������������������������������������������������������������������ 22
10 Factory data reset �������������������������������������������������������� 23
11 Applications & Internal storage���������������������������������� 23
12 Making the most of your phone���������������������������������� 24
Safety and use������������������������������������������������������������������������� 26
General information �������������������������������������������������������������� 35
Warranty��������������������������������������������������������������������������������� 36
Troubleshooting���������������������������������������������������������������������� 38

3
1 Your mobile ������������������
1�1 Keys and connectors
Micro-USB Connector
Front camera
Headset connector
Proximity &
Light Sensor
Home key
Touch screen
Back key
Menu key
LED indicator

4
Camera
Camera Flash/
Flashlight
Power key
Volume key
Back key
• Touch to go back to the previous screen, or to close
a dialog box, options menu, the notification panel, etc.
Home key
• From any application or screen, touch to return to the
Home screen.
• Long press to pop up Google search icon. Slide your
finger to the icon to open Google search.
Menu key
• Touch to view recently used applications.
• Touch to close any application.
• Touch the brush icon on the bottom of the screen to
close all applications.

5
Power key
• Press: Lock the screen/Light up the screen.
• Press and hold: Show the popup menu to select from
Power off/Restart/Airplane mode.
• Press and hold the Power key and Volume down key
to capture a screenshot.
• Press and hold the power key for 8 seconds to power
off or hold it for 10 seconds or more to force reboot.
Volume Keys
• In call mode, adjusts the earpiece or headset volume.
• In Music/Video/Streaming mode, adjusts the media
volume.
• In general mode, adjusts the ringtone volume.
• Mutes the ringtone of an incoming call.

6
1�2 Getting started
1�2�1 Set up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls.
Place the SIM card with the chip facing downwards and slide it into
its housing. Make sure that it is correctly inserted.To remove the SIM
card, pull and slide it out.
Your phone only supports micro-SIM card. Do not attempt
to insert other SIM types like mini and nano cards,
otherwise you may damage your phone.
Installing the microSD card
Place the microSD card with the chip facing downwards and slide it
into its housing. Make sure that it is correctly inserted.To remove the
microSD card, press and slide it out.

7
Charging the battery
To charge the battery, connect the charger to your phone and mains
socket.You can also charge your phone via a USB cable.
To reduce power consumption and energy waste, when the
battery is fully charged, disconnect your charger; switch off
Wi-Fi, GPS, Bluetooth or background-running applications
when not in use; reduce the backlight time, etc.
1�2�2 Power on your phone
Hold down the Power key until the phone powers on. It will take a
few seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you should set the following
options: Language, Date and time, etc.
Even if no SIM card is installed, your phone will still power on and
you will be able to connect to a Wi-Fi network, set up screen lock
and use some of the phone's features.
1�2�3 Power off your phone
Hold down the Power key from the Home screen until the phone
options appear, select Power off.

8
1�3 Home screen
You can move all of the items (applications, shortcuts, folders and
widgets) you use most frequently to your Home screen for quick
access.Touch the Home key to switch to the Home screen.
Touch to enter application list.
Status bar
• Status/Notification indicators
• Touch and drag down to open
the notification panel.
Touch an icon to open an application,
folder, etc.
Favorite tray applications
• Touch to enter the application.
• Long press to move or change
applications.
Search bar
• Touch to enter text search screen.
• Touch to enter voice search screen.
The Home screen is provided in an extended format to allow more
space for adding applications, shortcuts etc. Slide the Home screen
left and right to get a complete view.

9
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Long press
Long press the item to enter the available options.
Drag
Place and hold your finger on the screen to drag an object to
another location.
Slide/Swipe
Slide the screen up and down to scroll through the applications,
images, web pages, etc.
Flick
Similar to swiping, but flicking is faster.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw them
apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways to have a better view.
1�3�2 Status bar
From the status bar, you can view both phone status (to the right
side) and notification information (to the left side).

10
Status icons
GPRS connected No signal
GPRS in use Alarm is set
EDGE connected Bluetooth is on
EDGE in use Connected to a
Bluetooth device
3G connected Speakerphone is on
3G in use Roaming
HSPA (3G+) connected Headset connected
HSPA (3G+) in use No SIM card installed
HSPA+ connected Vibrate mode
HSPA+ in use Battery is very low
4G connected Battery is low
4G in use Battery is partially
drained
Signal strength Battery is full
Wi-Fi is on Battery is charging
Connected to a Wi-Fi
network GPS is on
Airplane mode

11
Notification icons
New Gmail message Missed call
New Email message Call forwarding is on
New text or multimedia
message Connected to VPN
Problem with SMS or
MMS delivery Song is playing
New Google Hangouts
message Radio is on
New voicemail Uploading data
Upcoming event Download finished
Screenshot captured Select input method
Both USB tethering and
portable hotspot are on
An open Wi-Fi network
is available
USB tethering is on Phone is connected via
USB cable
Portable Wi-Fi hotspot
is on System update available
More notifications are
hidden
Carrier data use
threshold approaching
or exceeded

12
Touch and drag down the Status bar to open the Quick settings panel
or Notification panel.Touch and drag up to close it.When there are
notifications, you can touch them to access notifications directly.
Notification panel
When there are notifications, touch and drag down the Status bar
to open the Notification panel to read more detailed information.
Touch to clear all event–based
notifications (other ongoing
notifications will remain).
Touch to switch to the Quick settings
panel.
Quick settings panel
Touch and drag down the Notification panel or touch to open
the Quick settings panel. You can enable or disable functions or
change modes by touching the icons.
Touch to enter user screen.
Touch to access Settings, where you can
set more items.

13
1�3�3 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by
creating a variety of patterns, PIN or password etc.
1�3�4 Personalize your Home screen
Add
You can long press a folder, an application, or a widget to activate
the Move mode and drag the item to any Home screen you prefer.
Reposition
Long press the item to be repositioned to activate the Move mode,
drag the item to the desired position and then release. You can
move items both on the Home screen and the Favorites tray. Hold
the icon on the left or right edge of the screen to drag the item to
another Home screen.
Remove
Long press the item to be removed to activate the Move mode,
drag the item up to the top of the icon, and release after the
item turns red.
Create folders
To improve the organization of items (shortcuts or applications) on
the Home screen, you can add them to a folder by stacking one item
on top of another. To rename a folder, open it and touch the folder’s
title bar to input the new name.
Wallpaper customization
Touch Settings on the applications screen then touch Display\
Wallpaper to customize wallpaper.
1�3�5 Volume adjustment
You can set the ringer, media and phone ringtone volumes to your
preference by pressing the Volume up/down key, or touching
Settings\Sound & notification\Media volume to set the volume.

14
2 Text input����������������������
2�1 Using Onscreen Keyboard
Onscreen Keyboard settings
Touch Settings\Language & input, touch the keyboard you want
to set up and a series of settings will become available for your
selection.
Adjust the Onscreen Keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen Keyboard
orientation. You can adjust it by changing the settings (Touch
Settings\Display\When device is rotated\Rotate screen
contents).
2�1�1 Keyboard
Touch to switch
between symbol and
numeric keyboard.
Long press to
select symbols.
Touch to enter
text or numbers.
Touch to input comma; touch
& hold to show input options.
Touch to switch
"abc/Abc" mode;
Touch & hold to
switch "abc/ABC"
mode.
2�2 Text editing
You can edit the text you have entered.
• Long press or double touch within the text you would like to edit.
• Drag the tabs to change the highlighted selection.
• The following options will show: Select all , Cut , Copy
and Paste .
• Touch the icon to go back without any action.

15
3 Phone call�����������������
3�1 Placing a call
To make a call when the phone is active, go to the Home screen and
touch the Call icon in the Favorites tray.
Touch to send
message to
the previewed
number.
Touch to call
the previewed
number.
Slide to access the
RECENTS and
CONTACTS.
Touch to hide/
display keyboard.
Display the
suggested
number(s).
Touch
and hold
to access
voicemail.
Enter the desired number from the keyboard directly and touch
to place the call or select a contact from CONTACTS or
RECENTS by sliding or touching tabs, then choose your target
contact to make the call.
The number you entered can be saved to Contacts by touching
and then touching Create new contact.

16
If you make a mistake, you can delete the incorrect digits by
touching .
To hang up a call, touch .
3�2 Answering or rejecting a call
When you receive a call:
• Slide the icon to the right to answer;
• Slide the icon to the left to reject;
• Slide the icon upwards to reject the call by sending a preset
message.
To mute the ringtone volume of an incoming call, press the Volume
up/down key or turn the phone over (when the Settings\
Gestures\Turn over to mute option is activated).
3�3 Consulting your call memory
You can access your call memory by touching RECENTS tab from
the Call screen to view full call history.

17
4 Contacts �������������������
You can view and create contacts on your phone and synchronize
these with your Gmail contacts or other applications on the web
or on your phone.
4�1 Adding a contact
Touch on the Home screen, then touch the icon in the
contacts list to create a new contact.
4�2 Importing, exporting and sharing
contacts
From the Contacts screen, touch the icon to open the options
menu, touch Import/Export, then select Import from SIM card,
Export to SIM card, Import from phone storage, Export to
phone storage or Share visible contacts.
To import/export a single contact from/to your SIM card, select
the contact you want to import/export, and touch the /icon
to confirm.
To import/export all contacts from/to your SIM card, touch the
icon and then the /icon to confirm.
You can share a single contact or contacts with others by sending the
contact's vCard to them via Bluetooth, Gmail, etc.
Touch a contact you want to share, touch the icon and Share
from the contact details screen, and then select the application to
perform this action.
4�3 Synchronizing contacts in multiple
accounts
Contacts, data or other information can be synchronized from
multiple accounts, depending on the applications installed on your
phone.

18
5 Messaging �����������������
You can create, edit and receive SMS and MMS with this phone.
To open Messaging, touch the Application tab from the Home screen,
then select Messaging.
To check messages stored in your SIM card, touch the
icon from the Messaging screen, then touch Settings\
Manage SIM messages.
5�1 Write message
On the message list screen, touch the new message icon to write
text/multimedia messages.
Touch to create a new message.
• Touch to view the whole message thread.
• Long press to activate delete mode.
Sending a text message
Enter the mobile phone number of the recipient in the To bar or
touch to add recipients and touch the Send message bar to
enter the text of the message.Touch the icon to insert emotions
or icons.When finished, touch to send the text message.
An SMS of more than 160 characters will be charged as
several SMS. Specific letters (accent) will also increase the
size of the SMS.This may cause multiple SMS to be sent to
your recipient.
Sending a multimedia message
MMS enables you to send video clips, images, photos, animations,
slides, and sounds to other compatible phones and email addresses.

19
An SMS will be converted to MMS automatically when media files
(image, video, audio, slides, etc.) are attached or Subject or email
addresses added.
6 Email�������������������������
Besides your Gmail account, you can also set-up external POP3,
IMAP or Outlook email accounts in your phone.
To access this feature, touch the Application tab from the Home
screen, then select Email.
An email setup wizard will guide you through the steps to set up
an email account.
• Enter the email address.
• Touch NEXT. If the account you entered is not provided by
your service provider in the phone, you will be prompted to go
to the email account settings screen to enter settings manually.
Alternatively, you can touch MANUAL SETUP to directly enter
the incoming and outgoing settings for the email account you are
setting up.
• Enter the account name and display name in outgoing emails.
• To add another email account, you can touch the icon and
Settings.Touch Add account to create.
To create and send emails
• Touch the icon from the Inbox screen.
• Enter recipient(s) email address (es) in the To field.
• If necessary, touch the icon beside To field to add Cc/Bcc to
add a copy or a blind carbon copy to the message.
• Enter the subject and the content of the message.
• Touch to add an attachment.
• Finally, touch to send�
• If you do not want to send the mail right away, you can touch the
icon and Save draft keys or touch the Back key to save a copy.

20
7 Getting connected �������
To connect to the Internet with this phone, you can use GPRS/
EDGE/3G/4G networks or Wi-Fi, whichever is most convenient.
7�1 Connecting to the Internet
7�1�1 GPRS/EDGE/3G/4G
The first time you turn on your phone with your SIM card inserted,
it will automatically configure your network service: GPRS, EDGE,
3G or 4G.
To check the network connection you are using, touch Settings\
More���\Mobile networks, and touch Access Point Names or
Network operators.
7�1�2 Wi-Fi
Using Wi-Fi, you can connect to the Internet when your phone is
within range of a wireless network.Wi-Fi can be used on your phone
even without a SIM card inserted.
To turn Wi-Fi on and connect to a wireless network
• Touch Settings\Wi-Fi.
• Touch the switch to turn on/off Wi-Fi.
• The detailed information of detected Wi-Fi networks is displayed in
the Wi-Fi networks section.
• Touch a Wi-Fi network to connect. If the network you selected is
secured, you are required to enter a password or other credentials
(you can contact the network carrier for details). When finished,
touch CONNECT.
7�2 Browser��������������������������������������
Using the Browser, you can enjoy surfing the Web.
To start browsing, touch the Application tab from the Home screen,
then select Browser.
