Alcatel 1677 SONET Link Instructions for use

1677 SONET Link
Installation Practices
PN 3EM13849AD 01
R05.00, Issue 01, May 2006

Alcatel 2002-2006 - All Rights Reserved
Printed in U.S.A.
THIS PRODUCT COMPLIES WITH D.H.H.S. RADIATION PERFORMANCE STANDARDS 21
CFR, 1040.10, FOR A CLASS 1 LASER PRODUCT.
DANGER
Invisible laser radiation is present when the optic connector is open. AVOID DIRECT
EXPOSURE TO BEAM.
WARNING
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case users will be required to correct the
interference at their own expense.
NOTICE
This manual applies to 1677 SONET Link R05.00 software. Release notes describing revisions to this
software may impact operations described in this manual.
This transfer of commodities, technology, or software, if from the United States, is an export in accordance
with the U.S. Export Administration Regulations. Diversion contrary to U.S. law is prohibited. The export or
re-export (further transfer) of such commodities, technology, software or products made from such
technology is prohibited without proper authorization(s) from the U.S. Department of Commerce or other
appropriate U.S. government agency(s).
All rights reserved. No part of this manual may be reproduced, translated, stored in a retrieval system, or
transmitted or distributed by any means, electronic or mechanical, by photocopying, recording, or otherwise,
without the written permission of Alcatel. Preparing derivative works or providing instruction based on the
material is prohibited unless agreed to in writing by Alcatel.
The product specification and/or performance levels contained in this document are for information
purposes only and are subject to change without notice. They do not represent any obligation on the part of
Alcatel. Such obligations will only be committed to in a written sales agreement signed by Alcatel.
DOCUMENTATION
Product documentation is available on Alcatel’s Online Support Documentation and Software web site at
http://www.alcatel.com/osds.
To offer comments on this documentation, visit Alcatel’s Online Support Documentation and Software web
site at http://www.alcatel.com/osds and select Online Services Helpdesk or write to the following address.
Alcatel
Attention: Doc Comment, MS OLXDV
3400 W. Plano Pkwy.
Plano, Texas 75075 USA

3EM13849AD
Issue 01, May 2006
© Alcatel 2002-2006 - All Rights Reserved i
ALCATEL PRACTICE
Standard
1677 SONET Link Installation Practices
Table of Contents
1677 SONET Link Installation Overview
1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Admonishments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Installing Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Method of Procedure (Optional, But Recommended) . . . . . . . . . . . . . . . . . 1-2
Installation Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Recommended Tools List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
2. SAFETY AWARENESS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Fan, Equipment Rack, and Equipment Cabinet Precautions . . . . . . . . . . . . 1-7
Electrical Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Laser Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
3. ELECTROSTATIC-SENSITIVE DEVICES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Electrostatic-Sensitivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Handling Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Repairing Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
4. PRODUCT SUPPORT INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
Product Documentation and Training. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
Technical Assistance Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19
Repair and Return Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20
Spare Parts and Replacement Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20
Service Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
Installation and Maintenance Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-23
Chart-1 Unpack and Inspect Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Chart-2 Prepare Floor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Chart-3 Install Racks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Chart-4 Install Overhead Rack Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
Chart-5 Route and Connect Frame-Ground Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Chart-6 Mount Filler Panels and Brackets to Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23

3EM13849AD
Issue 01, May 2006
Table of Contents
ii
Chart-7 Mount 1677 SONET Link Chassis and PDU-Quad in Rack. . . . . . . . . . . . . . . . . . . . . 2-27
Chart-8 Unseat Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Chart-9 Connect Power Cables Between PDU-Quad and 1677 SONET Link . . . . . . . . . . . . . 2-35
Chart-10 Route and Terminate Office Battery Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-37
Chart-11 Verify PDU-Quad Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-41
Chart-12 Verify PDU-Quad Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-49
Chart-13 Verify Frame Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-57
Chart-14 Verify Secondary Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-59
Chart-15 Install DS1 Splitter and Route Internal Clock Cables. . . . . . . . . . . . . . . . . . . . . . . . . . 2-67
Chart-16 Route and Terminate External Clock Cables to DS1 Splitter. . . . . . . . . . . . . . . . . . . . 2-71
Chart-17 Route External Clock Cables to TC Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-73
Chart-18 Install Fiber Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-79
Chart-19 Route Central Office OC-n Signal Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-83
Chart-20 Route Central Office GigE Signal Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-89
Chart-21 Mount 48-Port or 96-Port DS3/EC1 Connector Panel . . . . . . . . . . . . . . . . . . . . . . . . . 2-93
Chart-22 Route and Terminate Central Office DS3 and EC1 Signal Cables . . . . . . . . . . . . . . 2-105
Chart-23 Connect Office Alarm Wiring to 1677 SONET Link . . . . . . . . . . . . . . . . . . . . . . . . . . 2-111
Chart-24 Connect Data Terminal or Modem to 1677 SONET Link . . . . . . . . . . . . . . . . . . . . . . 2-113
Chart-25 Connect Local Area Network (LAN) Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-117
Chart-26 Test 1677 SONET Link Wiring Continuity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-121
Chart-27 Install Rear Kick Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-123
Chart-28 Install AC Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-125
Chart-29 Install Front Base Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-129
Chart-30 Install Electrical Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-131

3EM13849AD
Issue 01, May 2006
Table of Contents iii
Chart-31 Install Trim (Config Option 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-133
Chart-32 Install PDU-Quad Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-135
Chart-33 Verify Final Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-137
Installing MOS Modules
1. REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Installation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Service-clearance Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Electrical Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Equipment-rack Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
2. INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Unpacking and Inspecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Fiber-optic Jumper Cable Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Preventing ESD Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
19-Inch Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
23-Inch Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Fiber-optic Jumper Cable Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Installing a Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Planning the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Mounting the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Front-mounting the Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Mid-mounting a Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
4. INSTALLING AND ROUTING FIBER-OPTIC CABLES . . . . . . . . . . . . . . . . . . . . . 3-17
Cabling the MOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Selecting and Installing Fiber-optic Attenuators . . . . . . . . . . . . . . . . . . . . . 3-21

3EM13849AD
Issue 01, May 2006
Table of Contents
iv

3EM13849AD
Issue 01, May 2006
List of Figures v
1677 SONET Link Installation Practices
List of Figures
Figure 2-1. Manufacture Date Label (Equipment Shelf) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Figure 2-2. Danger and Manufacture Date Labels (Modules) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Figure 3-3. Electrostatic-Sensitive Sign . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Figure 1-1. Unpack 1677 SONET Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Figure 2-1. Rack Footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Figure 2-2. Rack (PN 1AD014120032). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Figure 2-3. Self-Drilling Anchor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Figure 2-4. Anchor Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Figure 3-1. Config Option 1 (Front) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Figure 3-2. Config Option 2 (Front) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Figure 3-3. Typical Overhead Uni-Strut Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Figure 4-1. Typical Overhead Rack Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Figure 7-1. Remove Shipping Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
Figure 7-2. ANSI Equipment Rack Screw-Hole Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-29
Figure 7-3. Align Chassis Bracket Mounting Holes with Equipment Rack Mounting Holes . . . . . . 2-30
Figure 8-1. System Module Interlock (Detail) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
Figure 8-2. Captive Thumbscrews (Detail) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
Figure 8-3. System Module Ejector Handles (detail) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Figure 9-1. PDU-Quad (Front View) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
Figure 9-2. 18RU Shelf Power Panel (Rear of Shelf) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
Figure 10-1. PDU-Quad (Front View) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-38
Figure 11-1. PDU-Quad (Front View) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-42

3EM13849AD
Issue 01, May 2006
List of Figures
vi
Figure 11-2. Frame Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-43
Figure 11-3. PDU-Quad (Rear View) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-44
Figure 12-1. PDU-Quad (Front View) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-50
Figure 12-2. PDU-Quad (Rear view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-51
Figure 13-1. 18RU Shelf Power Panel (Rear of Shelf) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-57
Figure 14-1. 18RU Shelf Power Panel (Rear of Shelf) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-59
Figure 14-2. PDU-Quad (Front View) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-60
Figure 14-3. BDFB to PDU QUAD Power Routing (Simplified Diagram) . . . . . . . . . . . . . . . . . . . . . 2-60
Figure 17-1. BITS Wire-Wrap Connection Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-74
Figure 17-2. 1677 SONET Link TC Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-75
Figure 18-1. Flex-Tube Holder Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-81
Figure 21-1. Chassis-Mounted 48-Port DS3/EC1 Connector Panel Kit . . . . . . . . . . . . . . . . . . . . . . 2-94
Figure 21-2. Cable-Tie Brackets Attached to Chassis-Mounted
48-Port DS3/EC1 Connector Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-95
Figure 21-3. 1677 SONET Link Rear Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-95
Figure 21-4. Rear Connector Access Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-96
Figure 21-5. Port-Identifier Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-97
Figure 21-6. Rack-Mounted 96-Port DS3/EC1 Connector Panel Kit . . . . . . . . . . . . . . . . . . . . . . . 2-100
Figure 21-7. Cable-Tie Brackets Attached to Rack-Mounted
96-Port DS3/EC1 Connector Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-101
Figure 21-8. Adapter Plate Brackets (23-Inch) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-102
Figure 21-9. Connector Panel/Adapter Plate Attached to
Equipment Rack (19-inch shown) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-103
Figure 21-10. Rear Chassis Connector Cables Attached to Connector Panel. . . . . . . . . . . . . . . . . 2-103
Figure 22-1. Typical DS3/EC1 Signal Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-109
Figure 24-1. Console Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-114

3EM13849AD
Issue 01, May 2006
List of Figures vii
Figure 24-2. Connect Data Terminal to TC Console Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-114
Figure 24-3. Connect Modem to TC Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-115
Figure 25-1. Locate TCs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-118
Figure 25-2. Locate 10/100Base-T Ethernet Connector on TC . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-119
Figure 28-1. AC Duplex Outlet Installation, Front Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-126
Figure 28-2. AC Duplex Outlet Installation, Rear Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-127
Figure 2-1. Unpacking Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Figure 3-1. ANSI/EIA-310-D or IEC Mounting Hole Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Figure 3-2. Typical Module Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Figure 3-3. Mounting Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Figure 3-4. Locate Front-Mounting Brackets on Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Figure 3-5. Locating Multiple Front-Mounting Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Figure 3-6. Install Cable Exit Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Figure 3-7. Install Mid Mounting Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Figure 3-8. Proper Mid Mount Bracket Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Figure 4-1. Installing Fiber-optic Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Figure 4-2. Installing Express Path Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Figure 4-3. Connecting OMB Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20

3EM13849AD
Issue 01, May 2006
List of Figures
viii

3EM13849AD
Issue 01, May 2006
List of Tables ix
1677 SONET Link Installation Practices
List of Tables
Table 15-A. Clock Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-69
Table 16-A. BITS Clock Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-72
Table 17-A. Clock Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-76
Table 17-B. Clock Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-76
Table 26-A. Continuity Test List From 1677 SONET Link Location To Office Location . . . . . . . . 2-122
Table 28-A. AC Duplex Outlet Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-125
Table 1-A. Environmental Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

3EM13849AD
Issue 01, May 2006
List of Tables
x

3EM13849AD
Issue 01, May 2006
1677 SONET Link Installation Overview 1-1
1677 SONET Link Installation Overview
1. INTRODUCTION
1.1 The 1677 SONET Link is a member of Alcatel's family of Synchronous
Optical Network (SONET) products. This manual provides installation
procedures for the 1677 SONET Link and its ancillary equipment. Here,
installation means to physically mount and secure the frame, chassis, and
ancillary items, as well as make all necessary power, ground, and office wiring
connections.
About This Manual
1.2 The 1677 SONET Link can be installed in a variety of configurations,
and installation may require various Alcatel-sourced ancillary equipment to
address site-specific requirements. For these reasons, this manual provides
information on installing individual pieces of equipment and installing frame
assemblies. Each step-by-step chart in this manual describes a different
installation procedure and, depending on customer selections, more than one
chart may be needed to complete the installation.
1.3 This manual provides step-by-step charts to help users perform tasks.
Each chart describes practices such as unpacking and inspection, facility
preparation, installing frame bus cabling, and actual equipment wiring. The
charts contain important introductory information that is essential to
understanding and completing the task properly. Procedures must be started
at step 1, and steps must be performed in the order given. Failure to do so may
cause unforeseen hazardous conditions.
Admonishments
1.4 To avoid hazardous conditions, observe the following admonishments:
DANGER Possibility of personal injury.
WARNING Possibility of equipment damage.

3EM13849AD
Issue 01, May 2006
1677 SONET Link Installation Overview
1-2
Installing Equipment
1.5 If the installation project matches a specific document, follow its
directions (including all cross-references).
Method of Procedure (Optional, But Recommended)
1.6 The person responsible for the installation, in cooperation with the
telco engineer and Central Office (CO) supervisor, should collect all essential
information to prepare the Method of Procedure (MOP). After the MOP is
prepared, it is submitted to CO management for approval. Work performed on
common equipment may require that activities be accomplished during
nonstandard working hours. This should be a joint decision between the CO
management, telco engineer, and installation personnel.
1.7 As a minimum, the following items should be addressed, mutually
understood, and agreed upon in establishing a MOP. This should be done
before the start of installation:
•Identify potential service-affecting hazards and risks imposed.
•Define installation methods, tools, and test sets to be used.
•Assign experienced personnel to the job.
•Identify protection/safety requirements of the equipment and tools.
•Determine the time during which the various steps of the work will be
performed and the equipment affected.
•Identify steps of the work that require prior notification of the CO
personnel or the telco engineer.
•Define procedures to follow and tests to make before additional or
modified equipment is connected to any working equipment.
•Develop steps the installer must take to disconnect any alarms
associated with the work.
•Define procedures to follow to ensure that the fuse designation and
fuse records are checked with the proper drawing before any fuse is
removed.
•Identify the time of day or night the removed equipment is to be
restored.

3EM13849AD
Issue 01, May 2006
1677 SONET Link Installation Overview 1-3
•Identify what measures can be taken to ensure that the equipment is
restored to service on time in case of unforeseen delays.
•Define steps of the work that require the presence of CO personnel.
•Identify tests applicable to wiring operations.
•Specify the space requirements (for example, storage and
administrative).
•When applicable, the MOP should include a restoration plan. This
restoration plan is a joint effort among CO personnel, installation
personnel, and the telco engineer.
1.8 The recommended sequence of events consists of the following steps:
•Install the frame, if applicable.
•Install the Power Distribution Unit, Quad Input (PDU-Quad), if
applicable.
•Install the 1677 SONET Link chassis.
1.9 In addition to suggested MOP content, the following items should be
mutually understood and agreed upon relative to using the MOP. This should
be done before the start of installation:
•All work is done during the hours specified in the MOP.
•The MOP is approved by the telco engineer and the CO personnel
before the installation start.
•After the MOP is adopted and approved, any deviation from the
procedure must be approved by the telco engineer and the CO
personnel.
•An approved copy of the MOP is available and posted for review at the
job site at all times.
Installation Tools
1.10 To properly install Alcatel SONET equipment, the following tools
should be available. Unique tools specific to a given task are listed in the
installation section covering that task. Other tools may be required to perform
special procedures as specified in instructions.

3EM13849AD
Issue 01, May 2006
1677 SONET Link Installation Overview
1-4
Recommended Tools List
1.11 Refer to the following list for recommended tools:
•1677 SONET Link reference manuals
•Safety glasses and ear protection
•Static protection accessories
– Strap, wrist ground, PN 055-9357-000
– Strap, heel, PN 055-9357-030
– ESD field service grounding kit, PN 126-3422-010
– Static booklet, PN 126-37442-010
•Rotary impact drill and associated drill bits
•Anchor setting tool (Redhead RT58 or equivalent)
•Level, 3 ft. length
•Pliers, needle-nose, 4 in.
•Diagonal cutters, 5 in.
•Screwdriver, standard 4 in.
•Screwdriver, standard 6 in.
•Screwdriver, Phillips, 6 in.
•Multi-stripper
•Scissors
•Wire-wrap gun, electric
•Wire-wrap bits/sleeves, 22 Ga., 24 Ga., 26 Ga.
•Hand unwrap tool
•Steel tape, 25 ft.
•Cable butting tool
•Cable stripper

3EM13849AD
Issue 01, May 2006
1677 SONET Link Installation Overview 1-5
•Cable cutters
•TY-wrap tool
•Wrenches, 3/8 in. to 15/16 in., open and box end combinations
•Extension cord, 50 ft.
•Hammer, claw
•Trouble lamp, insulated (for example, Duralamp brand)
•Stencil kit
•Socket set, 3/8 in. drive
•Tin snips
•Pinch bar
•Vacuum cleaner, High Efficiency Particulate Arrester (HEPA)
•Volt-ohm meter—Western Electric KS-14510, Triplet 630, or
equivalent
•Audible continuity checker—Ideal 61-030, Hunter Tools 2647, or
equivalent
•Optical power meter

3EM13849AD
Issue 01, May 2006
1677 SONET Link Installation Overview
1-6
Related Documentation
1.12 For additional system information, refer to the following related
documents:
•Unit Data Sheets (UDSs) in this manual
•1677 SONET Link Product Information manual (PN 3EM13848AD)
•1677 SONET Link Operation and Administration manual
(PN 3EM13851AD)
•1677 SONET Link Turn-Up manual (PN 3EM13850AB)
•1677 SONET Link Maintenance and Trouble Clearing manual
(PN 3EM13853AD)
•1677 SONET Link Commands and Messages manual
(PN 3EM13852AD)
•1677 SONET Link Engineering Support Documentation manual
(PN 3EM17362AB)
•1677 SONET Link Address and Location Guide (PN 3EM13854AB)

3EM13849AD
Issue 01, May 2006
1677 SONET Link Installation Overview 1-7
2. SAFETY AWARENESS
Fan, Equipment Rack, and Equipment Cabinet Precautions
2.1 When installing the equipment observe the following:
DANGER Possibility of personal injury. Keep fingers away from the rotating fan blades.
Pull the fan-tray by the thumbscrews only and wait for the fan blades to stop
spinning before attempting to remove the fan-tray completely from the
chassis.
DANGER Possibility of personal injury. The Alcatel 1677 SONET Link requires at least
three people to support, align, and attach it to an equipment rack. To prevent
equipment damage or personal injury, make sure help is available.
DANGER Possibility of personal injury. To prevent personal injury and equipment
damage due to unbalanced loading of the equipment rack or cabinet, make
sure the equipment rack or cabinet is properly secured to the floor, ceiling,
or other rigid structure before mounting the Alcatel 1677 SONET Link in it.
For approved methods of securing the equipment rack, read the equipment-
rack installation instructions or contact the equipment-rack manufacturer.
Electrical Precautions
2.2 Take appropriate safety precautions when performing procedures on
electrical equipment. Hazardous electrical potentials are present when system
power is on.
2.3 Some procedures in this manual require working with small
conductive objects, such as screwdrivers, fuses, washers, screws, and nuts.
When working on a chassis at the top of an equipment rack, a dropped object
that falls into a lower chassis can cause physical damage and electrical short
circuits. To prevent this, place a piece of paper or other cover over the lower
chassis to catch fallen objects. Remove the paper or other cover when work is
complete.
DANGER Possibility of personal injury. Install the Alcatel 1677 SONET Link in a
restricted-access area only. Entrance to a restricted-access area is intended
for qualified or trained personnel and access to it is controlled by a locked
barrier.
DANGER Possibility of personal injury. The chassis does not contain main overcurrent
protection devices. The user must provide circuit breakers or fuses and

3EM13849AD
Issue 01, May 2006
1677 SONET Link Installation Overview
1-8
disconnects between the power source and the Alcatel 1677 SONET Link.
Each power feed from a source (-48 V dc and Return) requires a 25-amp dc-
rated fast-trip circuit breaker or fuse and disconnect. Circuit breakers or
fuses must meet applicable local and national electrical safety codes and be
approved for the intended application.
DANGER Possibility of personal injury. Make sure to connect the node to a -48 V dc
source that is electrically isolated from the ac source and is reliably
connected to earth ground.
DANGER Possibility of personal injury. For personal safety, make sure to connect and
secure the installation site’s frame-ground (earth ground) wire to the frame-
ground terminal on the 1677 SONET Link before connecting any other wires
to the node.
DANGER Possibility of personal injury. A dc-power source provides high energy,
which can cause serious injury or equipment damage. Only Alcatel qualified
personnel should connect the dc power to the Alcatel 1677 SONET Link. To
prevent serious injury or equipment damage, make sure the power source
cables are de-energized before handling or connecting them to the node.
Laser Precautions
2.4 Verify that laser labels on equipment state that the system conforms
to all applicable standards of 21 CFR 1040.10. See figure 2-1 and 2-2. If there
are no danger labels, call the Alcatel Technical Assistance Center (TAC).
2.5 The invisible infrared radiation emitted by the fiber-optic transmitter
can cause eye damage. Observe local office procedures and the following
dangers:
DANGER Possibility of personal injury. The use of controls and/or adjustments, or the
performance of procedures other than those specified herein may result in
hazardous infrared radiation exposure.
DANGER Possibility of personal injury. Laser infrared radiation is not in the visible
spectrum; therefore, it is not visible to the naked eye or with laser safety
glasses. Although it cannot be seen, laser radiation may be present.
DANGER Possibility of personal injury. Never look directly into an unterminated
fiber-optic connector unless it is absolutely known that no optical power is
being emitted by the connector.
