Alcatel ONE TOUCH Y600A0 User manual

ONE TOUCH Y600A0
Quick Start Guide
CJB17K0ALAAA

1
Safety and use __________
We recommend that you read this chapter carefully before using this device. The manufacturer disclaims any liability for damage, which may
result as a consequence of improper use of this device or of use contrary to the instructions contained herein.
Do not switch on your device when its use is prohibited or when using the device may cause interference or danger.
Follow rules or regulations in hospitals and health care facilities. Switch off your device near medical apparatus.
Switch off your device in an aircraft. The device may cause interference to aircraft control signals.
Switch off your device near high-precision electronic devices. The device may affect the performance of these devices.
Do not attempt to disassemble your device or its accessories. Only qualified personnel are allowed to service or repair
the device.

2
Do not place your device or its accessories in containers with a strong electromagnetic field.
Do not place magnetic storage media near your device. Radiation from the device may erase the information stored on
them.
Do not subject your device to high temperatures or use it in a place with flammable gas such as a petrol station.
Keep your device and its accessories away from children. Do not allow children to use your device without guidance.
Only use approved batteries and chargers to avoid the risk of explosion.
Observe the laws or regulations on device use. Respect others’ privacy and legal rights when using your device.
It is recommended that the equipment only be used in an environment where the temperature is between -10℃and 50℃and humidity is
between 10% to 90%.

3
1. Overview
ONE TOUCH Y600 is a portable wireless router, providing a simple way to share 3G with any Wi-Fi embedded device.
1.1 Package contents
●ONE TOUCH Y600 ● USB cable ● Quick start guide
● USB Wall charger ● Car Charger*● USB Adapter*
● USB Cradle charger *
Note: *depending on your region and market.

4
1.2 Application

5
1.3 Device overview
Number Description
①Power on/off Key
②WPS Key
③Reboot Button
④
Charging Pin
①
②
③
④
⑤
⑥
⑦

6
⑤SIM Card Cover
⑥OLED screen
⑦Micro USB Interface
Use the device’s 3 buttons as follows:
Button Description
①Power On/Off Long press to turn on/off the device
Short press to put the OLED screen in either active or sleep mode.
②WPS Long press to turn on WPS
Short press to display SSID and password
③Reboot Long press to reboot the device if the system freezes.

7
1.4 Turning on the device
Step 1: Push down on the SIM Card cover and install your SIM card as indicated on the device.
Step 2: Press the Power On/Off button

8
1.5 Screen display
The screen display is interpreted as follows:
1 Network Signal (dynamic graphic symbol )
2 Network type (3G+/3G/2G)
3 SMS status (full, unread, incoming)
4 Connection status(connected and disconnected )
5 Wi-Fi (number of user connected/WPS connection)
6 Battery level (dynamic graphic symbol when charging)
7 Name of the network registered

9
Screen description:
Category Icon Display
Signal Strength
From 1 bar to excellent signal strength
Network type : EDGE/GPRS : UMTS/HSDPA/HSUPA : HSPA+
SMS status : SMS is available
: Unread SMS
: SMS full
Connection Status connected
