ALCO UtiliStool User manual

A
Stool Seat
1 Unit
C
Gas Lift Bellows
1 Unit
D
5-Star Base
1 Unit
E
Casters
5 Units
B
Gas Lift
1 Unit
CAUTION:
1. Do not use this stool as a step ladder.
2. Check for loose screws and tighten them every 6 months.
AL-81860 UtiliStool
WEIGHT CAPACITY: 250 lbs.
Parts Listing
04.29.2014
E
D
B
C
A
STOP
Assembly Instructions:
Tools Needed: Philips Head Screwdriver
Please read all instructions before assembly.
Step 1: Insert Casters (E) into 5-Star Base (D).
If you are assembling a model with a Foot Ring please proceed to
subsequent pages for drafting kit assembly instructions.
Step 2: Insert Gas Lift (B) into 5-Star Base (H).
Step 3: Cover Gas Lift (B) with Gas Lift Bellows (C).
Step 4: Carefully place Stool Seat (A) onto the Gas Lift (B),
aligning the holes. Press down on Stool Seat (A)
to secure onto 5-Star Base (D).
STOP

Parts Listing
D
12” Extension Tube
1 Unit
C
9” Extension Tube
1 Unit
A
Circular Foot Rest
1 Unit
B
Tension Knob
1 Unit
Gas Lift
Chair Seat
Chair Base
A
C / D
B
AL-81860 Drafting Kit Assembly
STOP
Assembly Instructions
Please read all instructions before assembly.
Prior to assembly, select only one Extension Tube
for desired Height
9” Extension Tube will change seat height from 24”-28”
12” Extension Tube will change seat height from 27-31”
Step 1: Slide the Circular Foot Rest (A) over the smaller
tapered end of your chosen Extension Tube (C / D).
Step 2: Screw in Tension Knob (B) and tighten to lock
Foot Rest (A).
Step 3: Place the tapered end of Extension Tube (C / D)
into your Chair Base.
Step 4: Insert bottom of Gas Lift Cylinder into the top
end of the Extension Tube (C / D).
Step 5: Place the Chair Seat onto the Gas Lift by
inserting top of Gas Lift into the hole in the
Seat Mechanism.
Step 6: Press down firmly to secure the chair.
Note: Save the left over extension tube for future use.
