PDAT System Exclusive …………………………………………………………………………………………………………Page 2
ALESIS PDAT SYSTEM EXCLUSIVE
The PDAT responds to all Alesis system exclusive ADAT commands, as well as MIDI Machine Control (MMC)
commands. In addition, the PDAT also responds to and sends out Alesis system exclusive PDAT commands to access
functions that may or may not be addressed by PDAT or MMC commands.
Note: There may be some overlap in commands. For example, setting a locate address may be done using MMC,
ADAT Sysex or PDAT Sysex commands.
The PDAT has the following MIDI System Exclusive format:
F0H Start-of-Exclusive
00H 00H 0EH Alesis manufacturer ID
16H PDAT product ID
aaH Device id# (0..7EH, 7FH=all)
bbH Opcode (0..7FH)
data Data
F7H End-of-Exclusive

PDAT System Exclusive …………………………………………………………………………………………………………Page 3
OPCODES
Note: 1) Items in parentheses,{}, can be repeated multiple times
2) Items in square brackets, [], are optional, depending upon preceding info
01H - Write Parameter
F0H 00H 00H 0EH 16H <dev#> 01H {<param#> [<sub-param>] <data>}F7H
<param> - If = 0, then function bit to follow in sub-param position
- If <> 0, then this value is the user parameter number
<sub-param> - User bit parameter (range 0..13h)
<data> - For User Parameters, see Parameter Table
- For Sub-Parameters, 0=disabled and 7Fh=enabled
Parameters (general user parameters)
See Table 1
Sub-Parameters (user function bit parameters)
00 All Safe Enable
01 All Input Enable
02 Auto Input Enable
03 Auto Play Enable
04 Rehearse Enable
05 Online Enable
06 Auto AUX Routing Enable
07 Format Safe Enable
08 Format Enable
08 SMPTE Chase Enable
0A Internal Generator Enable
0B Tape Offset Enable
0C Track Delay Enable
0D Pre-Roll Enable
0E Post-Roll Enable
0F Auto Return Enable
10 Auto Record Enable
11 Fast Wind Mode Enable
12 Mute Audio Enable
13 CADI Connect Status (1=connected)
02H - Read Parameter
F0H 00H 00H 0EH 16H <dev#> 02H 06H {<param#> [<sub-param>]}F7H
<param> - 00 = bit parameter to follow in sub-param position
Response:
F0 00 00 0E 16 <dev#> 02H 07H {<param#> [<sub-param>] <data>} F7
03H - Jog Command
F0H 00H 00H 0EH 16H <dev#> 03H <data-1> <data-2> F7H
<data-1> - 000000ba a = jog speed<7>, b = direction (0=fwd, 1=rew)
<data-2> - jog speed<6..0>
04H - Control Pause Tension
F0H 00H 00H 0EH 16H <dev#> 04H F7H

PDAT System Exclusive …………………………………………………………………………………………………………Page 4
05H - Search Switch Toggle
F0H 00H 00H 0EH 16H <dev#> 05H <data> F7H
<data> - search switch status (0=disable, 7Fh=enable)
06H - Master Search Mode
F0H 00H 00H 0EH 16H <dev#> 06H <data> F7H
<data> - master search mode status (0=master not in search mode, 7Fh=master in search mode)
Information Query/Response Commands
07H - PDAT Software Version Inquiry
F0H 00H 00H 0EH 16H <dev#> 07H F7H
• Request PDAT software version
Note: For compatibility purposes, the PDAT also responds to the ADAT software version request with its ADAT
software version equivalent (currently 4.03).
Response: F0 00 00 0E 14 <dev> 44 <versionH> <versionL> F7
<versionH> - 0aaaaaaa = integer part (0..99)
<versionL> - 0bbbbbbb = fractional part (0..99)
08H - PDAT Miscellaneous Info
F0H 00H 00H 0EH 16H <dev#> 08H 06H F7H
• Request miscellaneous PDAT information
Response: F0 00 00 0E 16 00 08H 07H <data-1> <data-2> F7
<data-1> = 0gfedcba where a = AUX record track status
b = AUX input track status
c = TC Track record track status
d = TC Track input track status
e = Online ADAT slave status
f = Transport/system error status
g = Transport task active status
<data-2> = 000000ba where a = Digital input presence
b = I/O card presence
09H - Slave Query
F0H 00H 00H 0EH 16H <dev#> 09H 06H F7H
• Request number of ADATs connected
Response: F0 00 00 0E 16 00 09H 07H <# of ADATs> F7
<# of ADATs> - 0..16
0AH - Timecode Query
F0H 00H 00H 0EH 16H <dev#> 0AH 06H <type> F7H
<type> - 0 = Search Master TC Request search master resting timecode
<type> - 1 = Tape TC Request tape tc (TC Track) timecode
Response: F0 00 00 0E 16 <dev#> 0AH 07H <type> <timecode>F7
<type> = same as requested
<timecode> =32-bit timecode converted to 7-bit MIDI data bytes

PDAT System Exclusive …………………………………………………………………………………………………………Page 5
Data Transfer Commands
10H - MIDI Sysex Dump
F0H 00H 00H 0EH 16H <dev#> 10H 06H <type> F7H
<type> - 0 = all
• Request dump of all user parameters
Response: F0 00 00 0E 16 <dev#> 10H 07H <type> <byte count> <data>F7
<type> - 0 (complete user parameter dump = 1964 data bytes)
<data> - 8 MIDI data bytes output for every 7 data bytes
a7 a6 a5 a4 a3 a2 a1 a0 transfer as 00 a6 a5 a4 a3 a2 a1 a0
b7 b6 b5 b4 b3 b2 b1 b0 00 b5 b4 b3 b2 b1 b0 a7
c7 c6 c5 c4 c3 c2 c1 c0 00 c4 c3 c2 c1 c0 b7 b6
d7 d6 d5 d4 d3 d2 d1 d0 00 d3 d2 d1 d0 c7 c6 c5
e7 e6 e5 e4 e3 e2 e1 e0 0 e2 e1 e0 d7 d6 d5 d4
f7 f6 f5 f4 f3 f2 f1 f0 0 f1 f0 e7 e6 e5 e4 e3
g7 g6 g5 g4 g3 g2 g1 g0 0 g0 f7 f6 f5 f4 f3 f2
0 g7 g6 g5 g4 g3 g2 g1
11H - MIDI Software Dump
F0H 00H 00H 0EH 16H <dev#> 11H <type> [data] F7H
<dev#> always = 7FH
<type> can be:
04 Meg Flash Boot segment data without interleaved checksum
14 Meg Flash Code segment data without interleaved checksum
24 Meg Flash Boot segment data with interleaved checksum
34 Meg Flash Code segment data with interleaved checksum
48 Meg Flash Boot segment data without interleaved checksum
58 Meg Flash Code segment data without interleaved checksum
68 Meg Flash Boot segment data with interleaved checksum
78 Meg Flash Code segment data with interleaved checksum
If <type> is 0,1,4, or 5 (data without interleaved checksum) then [data] is:
<#data bytes> <24 Bit Address> <data byte 1> .. <data byte N>
.. .. .. ..
<#data bytes = 2> <24 Bit Address = 0> <checksum word>
where: <#data bytes> is sent as a single byte greater than 0 but less than 128.
<24 Bit Address> is sent as 6 nibble-ized data bytes. For example, address 123456H is sent as
01H 02H 03H 04H 05H 06H. MSB first.
<data byte> is sent as 2 nibble-ized data bytes. For example, data 98H is sent as 09H 08H.
MSB first. <data byte> is repeated for <#data bytes>.
<checksum word> is sent as 4 nibble-ized total checksum bytes. Note <#data bytes> must equal
2. <24 Bit Address> must equal 0.
Repeat the <#data bytes> <24 Bit Address> <data byte 1> .. <data byte N> sequence for programming of
additional flash locations. Note that the <24 Bit Address> specifies the start of programming location for
the specified <data byte>’s. Always complete the end of the transmission with the checksum sequence
above.
If <type> is 2,3,6, or 7 (data with interleaved checksum) then [data] is:
<#data bytes> <24 Bit Address> <data byte 1> .. <data byte N> <checksum>
.. .. .. .. ..

PDAT System Exclusive …………………………………………………………………………………………………………Page 6
<#data bytes> <24 Bit Address> <data byte 1> .. <data byte N> <checksum>
where: <#data bytes> is sent as a single byte greater than 0 but less than 128.
<24 Bit Address> is sent as 6 nibble-ized data bytes. For example, address 123456H is sent as
01H 02H 03H 04H 05H 06H. MSB first.
<data byte> is sent as 2 nibble-ized data bytes. For example, data 98H is sent as 09H 08H.
MSB first. <data byte> is repeated for <#data bytes>.
<checksum> is sent as 2 nibble-ized checksum bytes.
The checksum is the sum of the previous <data byte> sequence mod 256.
Repeat the <#data bytes> <24 Bit Address> <data byte 1> .. <data byte N> <checksum> sequence for
programming of additional flash locations. Note that the <24 Bit Address> specifies the start of
programming location for the specified <data byte>’s.
12H - Tape Data
F0H 00H 00H 0EH 16H <dev#> 12H <type> F7H
<dev#> device
<type> can be:
0Prepare data to save to tape
1Initiate a save data to tape
Action Commands
16H - Locate
F0H 00H 00H 0EH 16H <dev#> 16H <loc#> F7H
<loc#> - 0..99=locate 0.. locate 99
17H - Inject Tape
F0H 00H 00H 0EH 16H <dev#> 17H F7H
18H - Enter Deck Standby
F0H 00H 00H 0EH 16H <dev#> 18H F7H

PDAT System Exclusive …………………………………………………………………………………………………………Page 7
Parameter Table
Parameter Name <param> <data> Comments
VU Peak Hold Mode101h 0..2
0 = No Peak Hold
1 = Momentary
2 = Continuous
VU Peak Hold Time102h 0 .. 99 Amount of time the peak pixel is held on
VU Decay Time103h 0 .. 99 Amount of time it takes each VU pixel to decay
VU Meter Scale104h 0..1
0 = Normal
1 = Fine dB
VU meter scale
VU Fine Headroom105h 2..22 dB Amount of headroom for Fine dB scale
Digital Source106h 0..2
0 = ADAT Optical
1 = Track Copy
2 = I/O Card (only valid if I/O card
detected)
Input Select Bitmap207h bitmap (0=analog input, 1=digital input)
Analog Routing108h 0..2
0 = one-to-one
1 = half and half
2 = odd-even
[1..8 à1..8]
[1..4 à5..8]
[chan 1 à1,3,5,7 and chan 2 à2,4,6,8]
ADAT Optical Source209h optical source bitmap (1=source channel)
Track Copy Source20Ah track copy source bitmap (1=source channel)
AES/EBU Source20Bh AES/EBU source bitmap (1=source channel)
AUX Track Source20Ch AUX source bitmap (1=source channel)
Pre-Roll Time10Dh 0..25
Post-Roll Time10Eh 0..25
Loop Start Point10Fh 0..99 Loop start locate number
Loop End Point110h 0..99 Loop end locate number
Auto Punch-In Point111h 0..99 Auto Punch-In locate number
Auto Punch-Out Point112h 0..99 Auto Punch-Out locate number
Locate Address 13h <loc #> <32-bit timecode>
<loc #> = 0..99
<32-bit timecode> = MIDI data format 5
Locate Name 14h <loc #> <8-character ASCII>
<loc #> = 0..99
<8-character ASCII> = <left-most>
..<rt-most>
Format Type115h 0..1
0 = 16-bit
1 = 20-bit
Track Delay Value316h [<track #> <value>]
<track #> = 0..7
<value> = 0..8160 samples
Tape Offset Value517h 32-bit sample

PDAT System Exclusive …………………………………………………………………………………………………………Page 8
Parameter Name <param> <data> Comments
SMPTE Offset Value718h Signed SMPTE format
Chase Mode119h 0..1
0 = Continuous
1 = Once
Flywheel Amount21Ah 0..150 frames à<msb> <lsb>
<msb> = 0aaa aaaa (bit 0..6)
<lsb> = 0bbb bbbb (bit 7..13)
# of frames to flywheel when chasing SMPTE
Park Ahead51Bh 32-bit timecode (samples) Distance to stop ahead of last good SMPTE In
Internal Gen Mode11Ch 0..1
0 = Free-run
1 = Play/Rec
Int Gen Start Reference11Dh 0..2
0 = ABS Time
1 = TC Track
2 = User Set
Int Gen ABS Offset61Eh 32-bit timecode
When Start Ref = ABS Time, current ABS Time
plus this offset gives the starting timecode
Int Gen User Set Start61Fh SMPTE time format
Int Gen User Bits520h 8 hex characters
Varispeed421h -300..200 cents (FED4 ..00C8)
MIDI Device ID222h 0..127 (127 = 7Fh = All Call)
MMC Output023h 0..1
0 = MMC output disabled
1 = MMC output enabled
MTC Output024h 0..1
0 = MTC output disabled
1 = MTC output enabled
Dig Output Format125h 0..3
0 = 20-bit
1 = 16-bit
2 = 16-bit dithered
3 = Dig Thru mode (pass DigIn to DigOut)
One-button Record026h 0..1
0 = One-button record disabled
1 = One-button record enabled
Direct Input Monitor027h 0..1
0 = ADC/DAC
1 = Direct input
TC Output Level128h 0..30 (divide by 10 to get volts)
Fwd/Rew SMPTE Out029h 0..1
0 = SMPTE output in fwd/rew disabled
1 = SMPTE output in fwd/rew enabled
Search Enable Mode02Ah 0..1
0 = Normal
1 = Button only

PDAT System Exclusive …………………………………………………………………………………………………………Page 9
Parameter Name <param> <data> Comments
Locate Before Play02Bh 0..1
0 = Disabled
1 = All slaves located to master before play
Mute Until Locked02Ch 0..1
0 = Each unit unmutes once it is in sync
1 = Units mute until master sees all locked
Dynamic Punch02Dh 0..1
0 = Punch using Play/Record buttons only
1 = Punch from track enable buttons allowed
Track Group Enable02Eh 0..1
0 = Track enable group buttons inactive
1 = Track enable group buttons active
Track Enable Group buttons are on the CADI
Unthread Timeout12Fh 1..20 minutes
Crossfade Time130h 0..31
Remote Source131h 0..2
0 = ADAT Sync
1 = MIDI
2 = RS-422 (Sony 9-pin protocol)
This allows the user to select which remote
source is in control when Online is enabled.
Online Control Mode132h 0..1
0 = Remote Only
1 = Remote and Local
This allows the user to select whether front
panel and LRC (both considered Local) are
allowed when Online is enabled.
Tape Counter Mode133h 0..2
0 = SMPTE
1 = ABS Time
2 = RELATIVE
Reference Counter
Mode134h 0..4 0 = SMPTE IN
1 = LOC PT
2 = TAPE TC
3 = INT GEN
4 = OFFSET
Displays current SMPTE Input
Displays current locate address
Displays TC Track of loaded tape
Displays the Internal Generator
Displays the SMPTE or Tape Offset
Clock Source135h 0..6
0 = Internal
1= Video
2 = ADAT
3 = I/O Card
4 = Word
5 = SMPTE
6 = Optical
Sample Rate136h <0..3> range 0..1 (0=48K, 1=44.1K)
<4..7> range 0..2 (0=no pull-up/down,
1=pull-up, 2 = pull-down)
SMPTE Rate137h 0..5
0 = 24 fps
1 = 25 fps
2 = 29.97 fps
3 = 29.97 DF
4 = 30 fps
5 = 30 DF

PDAT System Exclusive …………………………………………………………………………………………………………Page 10
Parameter Name <param> <data> Comments
Timecode Source138h 0..1
0 = Internal
1 = External
Chase Reference139h 0..1
0 = ABS Time
1 = Tape TC Track
Pitch Mode13Ah 0..1
0 = Fixed
1= Variable
RMD Error Enable03Ch 0..1
0 = RMD Error LEDs inactive
1 = RMD Error LEDs active
RMD = Remote Meter Bridge
Yellow error LED indicates interpolation errors
Red error LED indicate transport/system errors
Digital Scan Enable03Dh 0..1
0 = Digital scan disabled
1 = Digital scan enabled No audio while jog/shuttle Hear digital audio (scrub) while in jog/shuttle
Digital Scan Level13Eh 0..7
0= -42 dB, 1= -36 dB, 2= -30 dB, 3= -24dB
4= -18 dB, 5= -12 dB, 6= -6 dB, 7= 0 dB
Pseudo Master13Fh 0..15 = device ID of the pseudo master 0 = ID1 = no pseudo master
RS-422 Trk Arm Enable
0
40h 0..1
0 = RS-422 track arming disabled
1 = RS-422 track arming enabled Ignore RS-422 Edit Preset command
RS-422 Track Mapping141h 0..1
0=no mapping
1=odd/even
Mapping options for 2-track Edit Preset
1 à1, 2 à2
1à1,3,5,7 and 2 à2,4,6,8

PDAT System Exclusive …………………………………………………………………………………………………………Page 11
MIDI Data Format Types
0Bit Parameter
- Normal data format: 0 or 1
- MIDI data format: 0 (disabled) or 7Fh (enabled)
1Byte Parameter with max value less than 80h
- Normal data format: 0 a6 a5 a4 a3 a2 a1 a0
- MIDI data format: <0 a6 a5 a4 a3 a2 a1 a0>
2Byte Parameter with max value greater than or equal to 80h
- Normal data format: a7a6 a5 a4 a3 a2 a1 a0
- MIDI Data Format: <0 a6 a5 a4 a3 a2 a1 a0><0 0 0 0 0 0 0 a7>
3Word Parameter with max value less than 4000h (214 )
- Normal data format: 00b5 b4 b3 b2 b1 b0a7 a6 a5 a4 a3 a2 a1 a0
- MIDI Data Format:<0 a6 a5 a4 a3 a2 a1 a0> <0 b5 b4 b3 b2 b1 b0a7>
4Word Parameter with max value greater than or equal to 4000h (214 )
- Normal data format: 00b5 b4 b3 b2 b1 b0a7 a6 a5 a4 a3 a2 a1 a0
- MIDI Data Format: <0 a6 a5 a4 a3 a2 a1 a0> <0 b5 b4 b3 b2 b1 b0a7>
5Long Parameter
- Normal data format: d7 d6 d5 d4 d3 d2 d1 d0c7 c6 c5 c4 c3 c2 c1 c0 b7 b6 b5 b4 b3 b2 b1 b0a7 a6 a5 a4 a3 a2 a1 a0
- MIDI Data Format: <0 a6 a5 a4 a3 a2 a1 a0><0 b5 b4 b3 b2 b1 b0a7><0 c4 c3 c2 c1 c0 b7 b6><0 d3 d2 d1 d0c7 c6 c5><0 0 0 0 d7 d6 d5
d4>
6SMPTE Parameter
- Normal data format: hr:min:sec:frm
- MIDI Data Format: <hour> <min> <sec> <frm>
<hour> = 000hhhhh range=0..23
<min> = 00mmmmmm range=0..59
<sec> = 00ssssss range=0..59
<frm> = 000fffff range=0..29
7SMPTE Parameter
- Normal data format: hr:min:sec:frm:sfrm:smp
- MIDI Data Format: <sign/hour> <min> <sec> <frm> <sfrm> <smp>
<sign/hour> = 00shhhhh where s=0: positive, s=1:negative and hhhhh range=0..23
<min> = 00mmmmmm range=0..59
<sec> = 00ssssss range=0..59
<frm> = 000fffff range=0..29
<sfrm> = 0xxxxxxx range=0..99
<smp> = 000yyyyy range=0..19
