Alfresco AGBQ-42 User manual

19"
1 3/4"
CABINET FACE
TOP
13/16"
23"
13/16"
39"
BETWEEN RAILS
FRONT VIEW
LEFT END
FRONT VIEW CUT AWAY
TO SHOW RECEPTACLE
CUTOUT FOR LOUVERED
PANEL 130-1636
8 1/4"
36"
3 1/2"
8"
2"
15"
2X 1½" WIDE RAILS
SEE TOP VIEW
115V GFCI DUPLED
RECETACLE ON INSIDE
REAR WALL
FILE NAME: ARFG-42 CUTOUT
Cutout Details for: ARFG-42 & AGBQ-42
CUTOUT FOR LOUVERED
PANEL 130-1636
21 3/8"
42 1/2"
4 1/4"
15"
8"
2"
10 1/4"

TOP OF REFRIGERATOR
VIEW WITH ISLAND PARTIALLY CUT AWAY
REVEALING ARFG-42 MOUNTED INSIDE
INCORRECT VENTILATION
HOT AIR SHORT CYCLES
BACK INTO COLD AIR INTAKE
CAUSING HEAT BUILDUP
HOT AIR BLOCKED
FROM EXITING ISLAND
COLD AIR BLOCKED
FROM ENTERING
ISLAND
ARFG-42 VENTILATION REQUIRMENTS NOTE: THIS DOCUMENT MUST BE PRINTED IN COLOR.
FILE NAME: ARFG-42 Ventilation.pub Last revised: Sep. 19th 2007
An adequate source of fresh air must be provided, along with adequate
opening to exhaust hot air from the compressor and the island
TOP OF REFRIGERATOR
VIEW WITH ISLAND PARTIALLY CUT AWAY
REVEALING ARFG-42 MOUNTED INSIDE
INCORRECT VENTILATION
HOT AIR EXITS ISLAND
THROUGH SUPPLIED REAR
LOUVERED PANEL
COLD AIR BLOCKED FROM
ENTERING ISLAND - NO
LOUVER PANEL INSTALLED
NO CLOSE OFF - ALLOWING
HOT AIR TO SHORT CYCLE
BACK INTO AIR INTAKE
TOP OF REFRIGERATOR
COLD AIR ENTERS ISLAND
THROUGH SUPPLIED END
LOUVERED PANEL
HOT AIR EXITS ISLAND
THROUGH SUPPLIED REAR
LOUVERED PANEL
VIEW WITH ISLAND PARTIALLY CUT AWAY
REVEALING ARFG-42 MOUNTED INSIDE
CORRECT VENTILATION (PREFERRED)
TOP OF REFRIGERATOR
VIEW WITH ISLAND PARTIALLY CUT AWAY
REVEALING ARFG-42 MOUNTED INSIDE
CORRECT VENTILATION (ACCEPTABLE)
HOT AIR EXITS ISLAND
THROUGH SUPPLIED REAR
LOUVERED PANEL
CLOSE OFF AROUND END OF
REFRIGERATOR TO PREVENT
HOT AIR RETURNING TO UNIT
COLD AIR ENTERS INTAKE
FROM OTHER EXTERNAL
SOURCE IN LONGER ISLAND
