Alfresco ALX2-42 SZ User manual

ALX2-42SZ
BUILT-IN 42" BBQ GRILL WITH DUAL "U" BURNERS
SEAR-ZONE™, INTEGRATED ROTISSERIE MOTOR
AND LIGHTS
CREATED: 
LAST SAVED BY: »» adrian «« January 29, 2007 2:05:56 PM
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS ADRIAN CRISCI ALX2-42SZ BBQ UNIT - BUILT IN
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
500-0020 MANUAL
January 24, 2007 10:49:55 AM SHEET 1 OF 1
C:\Working\
ALX2-42SZ BBQ
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:


LAST SAVED BY: »» adrian «« April 30, 2007 3:49:41 PM
ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
7039 EAST SLAUSON AVENUE CREATED:
ALX2-42SZ BBQ UNIT - BUILT IN
ALX2-42SZ BBQ
DRAWING TITLE:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
500-0020 MANUAL-1
January 31, 2007 4:00:28 PM SHEET 1 OF 1
C:\Working\
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION
1 100-1066 FIREBOX COVER FOR ELECTRODE
2 100-1073 DUAL VALVE FIREWALL COVE
3 100-1083 U-BURNER BACK WALL BRACKET
4 100-1085 SEAR-ZONE™ BACK WALL BRACKET
5 100-1093 ROTISSERIE CHAIN COVER
6 100-1105 SEAR-ZONE™ GRILL - GREASE TROUGH
7 100-1106 SEAR-ZONE™ GRILL - HEAT SHIELD
8 100-1132 BRIQUETTE TRAY
9 100-1147 FRONT PANEL - 42" BBQ
10 100-1196 IGNITER MOUNTING PLATE RIGHT
11 100-1197 IGNITER MOUNTING PLATE LEFT
12 100-1212 ALX2-42 FIREWALL
13 200-0093 WASHER - PUSH LOCK 1/8" ID X 3/8" OD (FOR LOGO)
14 265-0005 BRIQUETTES - ALFRESCO CERAMIC (SET OF 24 PCS)
15 290-0031 LOGO - ALFRESCO
16 290-0038 BURNER - GRILL - "U" SHAPE
17 290-0052 ALFRESCO SEAR ZONE™ BURNER ASSEMBLY
18 290-0059 ROTISSERIE DRIP PAN
19 290-0096 FORK ASSEMBLY
20 290-0116 CHAIN - ANSI # 25 - ¼" PITCH - .13" Ø X 1/8" ROLLER
21 290-0124 GRILL 30" BBQ - 12¾" WIDE - SS
22 290-0157 GRILL 30" BBQ - 11¾" WIDE - SS
23 290-0158 SPEAR - ROTISSERIE - 42" - 2006 BBQ
24 510-0131 42" BBQ - GAS MANIFOLD SEAR-ZONE™
25 510-0134 SMOKER BURNER ASSEMBLY
26 510-0137 SMOKER TRAY ASSEMBLY
27 510-0144 SEAR-ZONE™ GRILL - 2006 BBQ
28 510-0152 42" BBQ - FIRE BOX ASSEMBLY
29 510-0154 42" BACK HOOD WITH RIM ASSEMBLY
30 510-0155 42" BBQ FRONT ASSEMBLY
31 510-0167 42" BBQ - GREASE TRAY ASSEMBLY
32 510-0168 WARMING RACK - 42" BBQ
33 510-0196 ALX2-42 FRONT HOOD - MAIN ASSEMBLY
34 510-0210A ALX2-42SZ ELECTRICAL COMPONENTS
9
6
33
29
27
22
14
4
3
8
17
19
23
32
18 11
2
16
20
5
7
13
15
10
30
26
31
24
25 34
28
21
1

BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1081 SMOKER TRAY 1
2 100-1082 SMOKER TRAY HANDLE 1
3 290-0135 HANDLE - 3/8"Ø X 3" L - TAPPED 1
4 200-0200 WASHER - # 8 - LOCK SPRING - SS 2
5 200-0083 8-32 X 1/4 - PAN HEAD - PHILIPS SCREW 2
24
5
3
1
LAST SAVED BY: »» adrian «« February 14, 2007 1:09:42 PM
SMOKER TRAY ASSEMBLY
ALX2 BBQ
ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
7039 EAST SLAUSON AVENUE C:\Working\ SHEET 1 OF 1
PROJECT TITLE:
DRAWING TITLE:
CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0137 MANUAL
October 18, 2006 10:10:12 AM
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:

LAST SAVED BY: »» adrian «« January 22, 2007 3:24:27 PM
42" BBQ - FIRE BOX ASSEMBLY
ALX2-42 BBQ
January 22, 2007 3:01:16 PM
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
7039 EAST SLAUSON AVENUE C:\Working\ SHEET 1 OF 1
PROJECT TITLE:
DRAWING TITLE:
ADRIAN CRISCI
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0152 MANUAL
CREATED:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0087 1/4" LOCK WASHER 8
2 200-0089 1/4-20 X 1/2 - HEX HEAD BOLT 8
3 510-0128 BBQ TRAY SUPPORT ASSY - RIGHT SIDE 1
4 510-0129 BBQ TRAY SUPPORT ASSY - LEFT SIDE 1
5 510-0219 ALX2-42 FIREBOX - WELDED PARTS 1
5
4
2
1
3

CREATED: 
LAST SAVED BY: »» adrian «« January 23, 2007 1:42:18 PM
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS ADRIAN CRISCI 42" BACK HOOD WITH RIM ASSEMBLY
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0154 MANUAL
January 23, 2007 1:21:46 PM SHEET 1 OF 1
C:\Working\
ALX2-42 BBQ
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1092 ROTISSERIE GEAR COVER 1
2 200-0079 8-32 X 3/4 - PAN HEAD - PHILIPS SCREW 2
3 200-0086 1/4-20 X 3/8 - TRUSS HEAD - PHILIPS SCREW 2
4 200-0111 SCREW 8-18 X ½ - SS - MMC# 92364A194 1
5 200-0148 SCREW 10-32 X 3/4" - FLAT HEAD - PHILIPS - 82° - SS 2
6 200-0166 SCREW 10-32 X ¼ Ø X ½ SHOULDER - SS 2
7 290-0119 ROLLER WHEEL - STAINLESS STL - ¾" Ø - 2
8 510-0139 ROTISSERIE GEAR ASSEMBLY 1
9 510-0218 42" BBQ - ROTISSERIE PANEL ASSY 1
10 510-0221 ALX2-42 BACK HOOD AND RIM - WELDED PARTS 1
1
9
2
2
6
6
10
7
5
4
3
8

PROJECT TITLE: DRAWING NO.:
COMMERCE, CA. 90040 CREATED:
42" BBQ - GAS MANIFOLD SEAR-ZONE™
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0157 MANUAL
7039 EAST SLAUSON AVENUE
DRAWING TITLE:
SUPERIOR EQUIPMENT SOLUTIONS ADRIAN CRISCI
January 30, 2007 10:21:19 AM SHEET 1 OF 1
C:\Working\
ALX2-42SZ BBQ
LAST SAVED BY: »» adrian «« January 30, 2007 11:48:35 AM

THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
NOTE:
CHANGE AGGORDING TO GAS
ORIFICE OR VALVE TO
SUPPLY. (NG OR LP)
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1100-0917ROTISSERIE GAS LINE EXTENSION - 3/8"Ø X 8" - SS 1
2 100-0914 ROTISSERIE GAS LINE (42"L x 3/8" Ø - SS. FLEX TUBE) 1
3 100-0917 SEAR ZONE™ GAS LINE (8"L x 3/8" Ø - SS. FLEX TUBE) 1
4 100-1067 SMOKER & SZ™ ORIFICE BRACKET 2
5 100-1156 30" BBQ SMOKER GAS LINE 1
6 200-0274 ELBOW 90°- CAST IRON - 1/2" FPT x 1/2" MPT 1
7 220-0151 COUPLING 3/8" x 3/8" - COMPRESSION - BRASS 1
8 220-0273 ELBOW 90° - 1/8" FPT x 3/16" COMP 2
9 220-0275 NIPPLE - 1/2" MPT X 3/8" MPT 1
10 220-0276 ELBOW 3/8" MPT x 1/8" FPT x 3/8" COMP 1
11 220-0277 NIPPLE 1/8"MPT x 1/16"MPT 1
12 220-0280 REGULATOR GAS - MAXITROL RV48CL440002 1
13 220-0293 ELBOW 1/4" FPT x 3/8" COMP 1
14 220-0341 MANIFOLD - 42" BBQ - 2006 MODEL 1
15 290-0030 KNOB BBQ - ALFRESCO "A" LETTER 5
16 290-0041 GAS VALVE - STRAIGHT - WITHOUT ORIFICES 2
17 290-0066 GAS VALVE - ANGLED - ORIFICE: INT= 0.95 mm / EXT=NONE 1
18 SEE NOTE GAS VALVE - ANGLED WITH ORIFICE >>> SEE NOTE 2
19 SEE NOTE ORIFICE - IR ROTISSERIE UNIT >>> SEE NOTE 1
20 SEE NOTE ORIFICE - SMOKER UNIT >>> SEE NOTE 1
21 SEE NOTE ORIFICE - SEAR ZONE™ >>> SEE NOTE 1
7
1
2
19
12
69
8
11
10
18
18
17
5
8
4
20
3
4
21
15
16
16
14
NG LP
PART N° PART N°
18 290-0064 290-0065
19 220-0285 220-0286
20 220-0287 220-0288
21 220-0289 220-0290
ITEM N°

14
3
4 2
1
5
2
3
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0073 10-32 - HEX NUT 2
2 200-0075 # 10 LOCK WASHER 2
3 200-0148 SCREW 10-32 X 3/4" - FLAT HEAD - PHILIPS - 82° - SS 2
4 290-0119 ROLLER WHEEL - STAINLESS STL - ¾" Ø - 2
5 510-0220 ALX2-42 GREASE TRAY - WELDED PARTS 1
ALX2-42 BBQ
C:\Working\ SHEET 1 OF 1
LAST SAVED BY: »» adrian «« January 23, 2007 11:22:30 AM

ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE
42" BBQ - GREASE TRAY ASSEMBLY
January 23, 2007 8:27:40 AM
510-0167 MANUAL
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:

2
3
4
1
5
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0087 1/4" LOCK WASHER 4
2 200-0091 HH- HD - 1/4-20 x 1 x .75 THREAD 4
3 290-0055 HANDLE BAR - 36" KNURLED 1
4 290-0063 HANDLE - END CA ASSEMBLY 2
5 510-0197 ALX2-42 FRONT HOOD - SKIN ASSEMBLY 1
CREATED:

LAST SA VED BY : »» adrian «« Tuesday, Novemb er 20, 2007 8:33:47 A M
COMMERCE, CA. 90040
DRAWING NO.:
ROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SU ERIOR EQUI MENT SOLUTIONS
ADRIAN CRISCI
ALX2-42 FRONT HOOD - MAIN ASSEMBLY
EQUI MENT SOLUTIONS, INC. IS ROHIBITED.
510-0196 MANUAL
Tuesday, January 23, 2007 1:57:46 M
SHEET 1 OF 1
C:\Working\
ALX2-42 BBQ
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE RO ERTY OF SU ERIOR EQUI MENT SOLUTIONS
INC. ANY RE RODUCTION IN ART OR AS A WHOLE
WITHOUT WRITTEN ERMISSION FROM SU ERIOR
DRA N BY:


LAST SAVED BY: »» adrian «« March 14, 2007 11:50:29 AM
ALX2-42SZ ELECTRICAL COMPONENTS
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
7039 EAST SLAUSON AVENUE ADRIAN CRISCI
ALX2-42SZ BBQ
C:\Working\
DRAWING TITLE:
CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0210 MANUAL
January 30, 2007 3:37:51 PM SHEET 1 OF 1
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
6
210-0200
REPLACEMENT CAP
REPLACEMENT LAMP
210-0317
12
210-0286
REPLACEMENT GLASS
4
7
8
1
9
5
13
10
2
1
1
11
3
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 210-0189 ELECTRODE - "L" SHAPED - MAIN BURNER 3
2 210-0192 ELECTRODE - DUAL TIP - IR BURNERS 1
3 210-0194 IGNITER MODULE - 4 POINTS (WITH CAP) 1
4 210-0195 IGNITER MODULE - 2 POINTS (WITH CAP) 1
5 210-0198 SWITCH - WEATHER BOOT & CAP 4
6 210-0331 ALX2-BBQs RIGHT LAMP ASSEMBLY WITH HARNESS 1
7 210-0333 ALX2-42 LEFT LAMP ASSEMBLY WITH HARNESS 1
8 210-0335 ALX2-BBQs LIGHT SWITCH WITH HARNESS 1
9 210-0338 ALX2-42 ROTISSERIE SWITCH WITH HARNESS 1
10 210-0340 SWITCH BBQ - IGNITER ONLY - OFF [ON] MOMENTARY 1
11 210-0344 ALX2-42SZ - IGNITER WIRE KIT 1
12 510-0200 ALX2 ROTISSERIE MOTOR ASSEMBLY & J-BOX 1
13 210-0340 SWITCH BBQ - IGNITER ONLY - OFF [ON] MOMENTARY 1

3
1
5
23
4
3
CREATED: 
LAST SAVED BY: »» adrian «« January 25, 2007 1:29:26 PM
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS ADRIAN CRISCI 42" BBQ - ROTISSERIE PANEL ASSY
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0218 MANUAL
January 23, 2007 1:43:24 PM SHEET 1 OF 1
C:\Working\
ALX2-42 BBQ
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1225 ROTISSERIE ELECTRODE COVER 1
2 100-1226 ROTISSERIE ELECTRODE BRACKET 1
3 200-0111 SCREW 8-18 X ½ - SS - MMC# 92364A194 3
4 210-0240 ELECTRODE - DUAL TIP - IR BURNERS 1
5 510-0222 ALX2-42 - ROTISSERIE PANEL - WELDED PARTS 1

JUMPER
L
N
~ 115 VAC - 50/60 Hz.
JUMPER
SWITCH
LIGHT
SWITCH
MOTOR
210-0302 ROTISSERIE
SOCKET G9
MODEL G940120
MOTOR
LIGHTS
(2) 120 VAC x 40W
TERMINAL BLOCK
G
LAST SA VED BY »» adrian «« Tuesday, Novem ber 20, 2007 2 50 41 PM
6 POLE TERMINAL WITH 90° QUICK TABS
SHEET 1 OF 1
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.
PROJECT TITLE
7039 EAST SLAUSON AVENUE
ADRIAN CRISCI
9/21/2006
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
DRAWING TITLE
CREATED:
ALX2-BBQ WIRING DIAGRAM
ALX2-BBQ
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:

HOW TO OBTAIN SERVICE
For service, please contact our Alfresco™ Gourmet Grills authorized service agency at:
[phone]
Please provide:
• Model Number
• erial Number (located under the drip pan)
• Gas Type
• Date of installation
• A brief description of the problem.
For all other Alfresco™ Gourmet Grill product inquiries please contact:
Alfresco Gourmet Grills. [phone] or
Customer ervice Department. [phone].
7039 East lauson Avenue [phone] (FAX)
Commerce, CA 90040.
Visit us on the WEB at: www.alfrescogrills.com
NOTES:
