Alfresco ALX2-56 User manual

ALX2-56 BFG
BUILT-IN 56" BBQ WITH TRIPLE GRILL BURNERS,
SEAR-ZONE™, DUAL ROTISSERIE BURNERS,
INTEGRATED ROTISSERIE MOTOR AND LIGHTS.
April 02, 2007 2:09:53 PM
ALX2-56 BFG BBQ
SHEET 1 OF 1

ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING TITLE:
C:\Working\
500-0030 MANUAL
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
ALX2-56SZ BFG BBQ
7039 EAST SLAUSON AVENUE
LAST SAVED BY: »» adrian «« April 02, 2007 2:48:50 PM
PROJECT TITLE:
CREATED:
DRAWING NO.:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:

18
14
33
27
8
10
22
5
30
29
21
25
11
26
6
3
4
2
16
17
24
20
9
23
7
13
32
31
15
1
19
28
March 30, 2007 3:13:18 PM
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
CREATED:
500-0030 MANUAL-1
ALX2-56 BFG BBQ
ALX2-56SZ BFG BBQ
LAST SAVED BY: »» adrian «« April 02, 2007 9:07:21 AM
7039 EAST SLAUSON AVENUE SHEET 1 OF 1
DRAWING TITLE:
PROJECT TITLE:

ADRIAN CRISCI
C:\Working\
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION
1 100-1066 FIREBOX COVER FOR ELECTRODE
2 100-1073 DUAL VALVE FIREWALL COVE
3 100-1083 U-BURNER BACK WALL BRACKET
4 100-1085 SEAR-ZONE™ BACK WALL BRACKET
5 100-1093 ROTISSERIE CHAIN COVER
6 100-1132 BRIQUETTE TRAY
7 100-1188 BFG FIREWALL
8 100-1189 56" BFG - FRONT PANEL
9 100-1196 IGNITER MOUNTING PLATE RIGHT
10 100-1197 IGNITER MOUNTING PLATE LEFT
11 100-1201 BFG SEARZONE™ HEAT SHIELD
13 200-0093 WASHER - PUSH LOCK 1/8" ID X 3/8" OD (FOR LOGO)
14 265-0005 BRIQUETTES - ALFRESCO CERAMIC (SET OF 24 PCS)
15 290-0031 LOGO - ALFRESCO
16 290-0038 BURNER - GRILL - "U" SHAPE
17 290-0052 ALFRESCO SEAR ZONE™ BURNER ASSEMBLY
18 290-0059 ROTISSERIE DRIP PAN
19 290-0096 FORK ASSEMBLY
20 290-0116 CHAIN - ANSI # 25 - ¼" PITCH - .13" Ø X 1/8" ROLLER
21 290-0124 GRILL 30" BBQ - 12¾" WIDE - SS
22 290-0176 ALX2-56 BFG ROTISSERIE SPEAR
23 510-0134 SMOKER BURNER ASSEMBLY
24 510-0137 SMOKER TRAY ASSEMBLY
25 510-0144 SEAR-ZONE™ GRILL - 2006 BBQ
26 510-0174 56" BBQ FRONT ASSEMBLY
27 510-0175 56" BBQ LX2 - GREASE TRAY
28 510-0181 ALX2-56BFG- FIREBOX ASSEMBLY
29 510-0184 BFG BACK HOOD + RIM ASSEMBLY
30 510-0186 ALX2-56 BFG FRONT HOOD
31 510-0193 ALX2-56 BFG WARMING RACK
32 510-0213 ALX2-56 BFG ELECTRICAL COMPONENTS
33 510-0225 ALX2-56 BFG MANIFOLD ASSEMBLY

BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1081 SMOKER TRAY 1
2 100-1082 SMOKER TRAY HANDLE 1
3 290-0135 HANDLE - 3/8"Ø X 3" L - TAPPED 1
4 200-0200 WASHER - # 8 - LOCK SPRING - SS 2
5 200-0083 8-32 X 1/4 - PAN HEAD - PHILIPS SCREW 2
24
5
3
1
LAST SAVED BY: »» adrian «« February 14, 2007 1:09:42 PM
SMOKER TRAY ASSEMBLY
ALX2 BBQ
ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
7039 EAST SLAUSON AVENUE C:\Working\ SHEET 1 OF 1
PROJECT TITLE:
DRAWING TITLE:
CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0137 MANUAL
October 18, 2006 10:10:12 AM
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:

ADRIAN CRISCI

LAST SAVED BY: »» adrian «« February 26, 2007 11:20:50 AM
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS 56" BBQ LX2 - GREASE TRAY
ALX2-56 BBQ
CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0175 MANUAL
February 26, 2007 11:17:18 AM C:\Working\
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
SHEET 1 OF 1
DRAWN BY:
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0073 10-32 - HEX NUT 2
2 200-0075 # 10 LOCK WASHER 2
3 200-0148 SCREW 10-32 X 3/4" - FLAT HEAD - PHILIPS - 82° - SS 2
4 290-0119 ROLLER WHEEL - STAINLESS STL - ¾" Ø - 2
5 510-0230 ALX2-56 - GREASE TRAY - WELDED PARTS 1
5
DETAIL A
SCALE 1 : 2
1
2
?3
5


LAST SAVED BY: »» adrian «« April 03, 2007 9:58:30 AM
ALX2-56BFG- FIREBOX ASSEMBLY
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
510-0181 MANUAL
ADRIAN CRISCI
ALX2-56 BFG BBQ
C:\Working\
7039 EAST SLAUSON AVENUE CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
April 03, 2007 8:46:42 AM SHEET 1 OF 1
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
3
4
2
5
2
1
1
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0087 1/4" LOCK WASHER 8
2 200-0089 1/4-20 X 1/2 - HEX HEAD BOLT 8
3 510-0128 BBQ TRAY SUPPORT ASSY - RIGHT SIDE 1
4 510-0129 BBQ TRAY SUPPORT ASSY - LEFT SIDE 1
5 510-0247 ALX2-56 BFG FIREBOX - WELDED PARTS 1

BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1092 ROTISSERIE GEAR COVER 1
2 100-1187 ROTISSERIE PANEL - CENTER MULLION 1
3 200-0079 8-32 X 3/4 - PAN HEAD - PHILIPS SCREW 4
4 200-0086 1/4-20 X 3/8 - TRUSS HEAD - PHILIPS SCREW 2
5 200-0111 SCREW 8-18 X ½ - SS - MMC# 92364A194 1
6 200-0148 SCREW 10-32 X 3/4" - FLAT HEAD - PHILIPS - 82° - SS 2
7 200-0166 SCREW 10-32 X ¼ Ø X ½ SHOULDER - SS 2
8 290-0119 ROLLER WHEEL - STAINLESS STL - ¾" Ø - 2
9 510-0139 ROTISSERIE GEAR ASSEMBLY 1
10 510-0185 30"- ROTISSERIE PANEL (LEFT SIDE ONLY) 1
11 510-0217 30"- ROTISSERIE PANEL ASSEMBLY 1
12 510-0248 ALX2-56 BFG BACK HOOD AND RIM - WELDED PARTS 1
510-0184 MANUAL
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
CREATED: SHEET 1 OF 1
C:\Working\
ALX2-56 BFG BBQ
BFG BACK HOOD + RIM ASSEMBLY
7039 EAST SLAUSON AVENUE April 03, 2007 11:43:44 AM
DRAWING TITLE:
PROJECT TITLE:
LAST SAVED BY: »» adrian «« April 03, 2007 3:10:11 PM

ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
3
7
8
6
4
5
19
12
10
11
2
3
7

C:\Working\

LAST SAVED BY: »» adrian «« April 03, 2007 1:14:39 PM
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS
ALX2-56 BFG BBQ
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED. 510-0185 MANUAL
CREATED:
ADRIAN CRISCI
April 03, 2007 1:12:05 PM
30" - ROTISSERIE PANEL (LEFT SIDE)
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
SHEET 1 OF 1
DRAWN BY:
5
3
4
2
1
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1225 ROTISSERIE ELECTRODE COVER 1
2 100-1226 ROTISSERIE ELECTRODE BRACKET 1
3 200-0111 SCREW 8-18 X ½ - SS - MMC# 92364A194 3
4 210-0240 ELECTRODE - DUAL TIP - IR BURNERS 1
5 510-0249 30" ROTISSERIE PANEL LEFT SIDE - WELDED PARTS 1

ALX2-30/30SZ/56BFG BBQ
30"- ROTISSERIE PANEL ASSEMBLY

COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS
LAST SAVED BY: »» adrian «« April 03, 2007 3:25:39 PM
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0217 MANUAL
CREATED: SHEET 1 OF 1
April 03, 2007 3:22:15 PM
ADRIAN CRISCI
C:\Working\
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
3
5
1
2
34
3
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1225 ROTISSERIE ELECTRODE COVER 1
2 100-1226 ROTISSERIE ELECTRODE BRACKET 1
3 200-0111 SCREW 8-18 X ½ - SS - MMC# 92364A194 3
4 210-0240 ELECTRODE - DUAL TIP - IR BURNERS 1
5 510-0250 ALX2-30 ROTISSERY PANEL - WELDED PARTS 1

4
2
4
1
5
3
2
4
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0087 1/4" LOCK WASHER 4
2 200-0091 HH- HD - 1/4-20 x 1 x .75 THREAD 4
3 290-0063 HANDLE - END CAP ASSEM LY 2
4 290-0089 HANDLE AR - 50" SMOOTH 1
5 510-0187 ALX2-56 FG OUSIDE SKIN 1
CREATED:

LAST SA VED Y: »» adrian «« T uesday, Novem ber 20, 2007 9:42:23 AM
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS
ADRIAN CRISCI
ALX2-56 BFG FRONT HOOD
EQUIPMENT SOLUTIONS, INC. IS PROHI ITED.
510-0186 MANUAL
Tuesday, April 03, 2007 9:27:31 AM
SHEET 1 OF 1
C:\Working\
ALX2-56 BFG BBQ
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRA N BY:

C:\Working\ SHEET 1 OF 1
March 30, 2007 8:45:51 AM
LAST SAVED BY: »» adrian «« March 30, 2007 10:11:02 AM

ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE
ALX2-56 BFG BBQ
510-0213 MANUAL
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
CREATED:
ALX2-56 BFG ELECTRICAL COMPONENTS
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
LAMP GLASS
210-0200
210-0317
REPLACEMENT PARTS
REPLACEMENT CAP
210-0286
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 210-0189 ELECTRODE - "L" SHAPED - MAIN BURNER 4
2 210-0192 ELECTRODE - DUAL TIP - IR BURNERS 1
3 210-0194 IGNITER MODULE - 4 POINTS (WITH CAP) 2
4 210-0198 SWITCH - WEATHER BOOT & CAP 4
5 210-0331 ALX2-BBQs RIGHT LAMP ASSEMBLY WITH HARNESS 1
6 210-0334 ALX2-56 BFG LEFT LAMP ASSEMBLY WITH HARNESS 1
7 210-0335 ALX2-BBQs LIGHT SWITCH WITH HARNESS 1
8 210-0339 ALX2-56 BFG ROTISSERIE SWITCH WITH HARNESS 1
9 210-0340 SWITCH BBQ - IGNITER ONLY - OFF [ON] MOMENTARY 2
10 210-0347 ALX2-56 BFG IGNITER WIRE KIT 1
11 510-0200 ALX2 ROTISSERIE MOTOR ASSEMBLY & J-BOX 1
2
11
10
1
1
6
5
8
1
10
3
1
7
9
4
9
10
3

NOTE:
ORIFICE OR VALVE TO CHANGE
ACCORDING TO GAS SUPPLY
(LP OR NG)
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-0913 30" BBQ SMOKER GAS LINE 1
2 100-0914 ROTISSERIE GAS LINE (42"L x 3/8" Ø - SS. FLEX TUBE) 1
3 100-0914 ROTISSERIE GAS LINE (42"L x 3/8" Ø - SS. FLEX TUBE) 1
4 100-0917 SEAR ZONE™ GAS LINE (8"L x 3/8" Ø - SS. FLEX TUBE) 1
5 100-0941 ROTISSERIE GAS LINE EXTENSION (24"L x 3/8" Ø - SS.) 1
6 100-0941 ROTISSERIE GAS LINE EXTENSION (24"L x 3/8" Ø - SS.) 1
7 100-1067 SMOKER & SZ™ ORIFICE BRACKET 2
8 200-0274 ELBOW 90°- CAST IRON - 1/2" FPT x 1/2" MPT 1
9 220-0151 COUPLING 3/8" x 3/8" - COMPRESSION - BRASS 2
10 220-0273 ELBOW 90° - 1/8" FPT x 3/16" COMP 2
11 220-0275 NIPPLE - 1/2" MPT X 3/8" MPT 1
12 220-0276 ELBOW 3/8" MPT x 1/8" FPT x 3/8" COMP 2
13 220-0277 NIPPLE 1/8"MPT x 1/16"MPT 1
14 220-0280 REGULATOR GAS - MAXITROL RV48CL440002 1
15 220-0293 ELBOW 1/4" FPT x 3/8" COMP 1
16 220-0349 MANIFOLD - ALX2-56" BFG 1
17 290-0030 KNOB BBQ - ALFRESCO "A" LETTER 7
18 290-0041 GAS VALVE - STRAIGHT - WITHOUT ORIFICES 3
19 290-0066 GAS VALVE - ANGLED - ORIFICE: INT= 0.95 mm / EXT=NONE 1
20 SEE NOTE GAS VALVE - ANGLED WITH ORIFICE >>> SEE NOTE 3
21 SEE NOTE ORIFICE - SMOKER UNIT >>> SEE NOTE 1
22 SEE NOTE ORIFICE - SEAR ZONE™ >>> SEE NOTE 1
23 SEE NOTE ORIFICE - IR ROTISSERIE UNIT >>> SEE NOTE 2
C:\Working\
ALX2-56 BFG
510-0225 MANUAL

March 23, 2007 2:16:35 PM
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
7039 EAST SLAUSON AVENUE
LAST SAVED BY: »» adrian «« March 23, 2007 3:20:17 PM
SHEET 1 OF 1
CREATED:
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
ALX2-56 BFG MANIFOLD ASSEMBLY
ADRIAN CRISCI
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
7
17
18
18
2
9
5
23 12
12
23
6
9
3
18
20
10
13
2111
14 8
10
71
20
16
15 22
NG LP
PART N° PART N°
20 290-0064 290-0065
21 220-0287 220-0288
22 220-0289 220-0290
23 220-0285 220-0286
ITEM N°

JUMPER
L
N
~ 115 VAC - 50/60 Hz.
JUMPER
SWITCH
LIGHT
SWITCH
MOTOR
210-0302 ROTISSERIE
SOCKET G9
MODEL G940120
MOTOR
LIGHTS
(2) 120 VAC x 40W
TERMINAL BLOCK
G
LAST SA VED B Y »» a drian «« Tuesday, N ovember 20, 200 7 2 50 41 PM
6 POLE TERMINAL WITH 90° QUICK TABS
SHEET 1 OF 1
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.
PROJECT TITLE
7039 EAST SLAUSON AVENUE
ADRIAN CRISCI
9/21/2006
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
DRAWING TITLE
CREATED:
ALX2-BBQ WIRING DIAGRAM
ALX2-BBQ
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:

THIS PAGE LEFT INTENTIONALLY BLANK

HOW TO OBTAIN SERVICE
For service, please contact our Alfresco™ Gourmet Grills authorized service agency at:
[phone]
Please provide:
• Model Number
• erial Number (located under the drip pan)
• Gas Type
• Date of installation
• A brief description of the problem.
For all other Alfresco™ Gourmet Grill product inquiries please contact:
Alfresco Gourmet Grills. [phone] or
Customer ervice Department. [phone].
7039 East lauson Avenue [phone] (FAX)
Commerce, CA 90040.
Visit us on the WEB at: www.alfrescogrills.com
NOTES:
