Alfresco ALX2-30 User manual

LAST SAVED BY: »» adrian «« October 24, 2006 9:56:28 AM
ALX2-30 SZ
ALX2-30 SZ BBQ
ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
7039 EAST SLAUSON AVENUE C:\Working\ SHEET 1 OF 1
PROJECT TITLE:
DRAWING TITLE:
CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
500-0018 MANUAL
October 16, 2006 3:40:31 PM
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
ALX2-30 SZ
BUILT-IN 30" BBQ GRILL WITH SEAR-ZONE™
INTEGRATED ROTISSERIE MOTOR AND LIGHTS

BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION
1 100-1065 FIREBOX COVER
2 100-1066 FIREBOX COVER FOR ELECTRODE
3 100-1073 DUAL VALVE FIREWALL COVE
4 100-1080 FRONT PANEL - 30" BBQ
5 100-1083 U-BURNER BACK WALL BRACKET
6 100-1085 SEAR-ZONE™ BACK WALL BRACKET
7 100-1093 ROTISSERIE CHAIN COVER
8 100-1105 SEAR-ZONE™ GRILL - GREASE TROUGH
9 100-1106 SEAR-ZONE™ GRILL - HEAT SHIELD
10 100-1109 U BURNER FIREWALL COVER
11 100-1132 BRIQUETTE TRAY
12 100-1211 ALX2-30 FIREWALL (NEW IGNITER MOUNT)
13 210-0189 ELECTRODE - "L" SHAPED - MAIN BURNER
14 210-0192 ELECTRODE - DUAL TIP - IR BURNERS
15 265-0005 BRIQUETTES - ALFRESCO CERAMIC (SET OF 24 PCS)
16 290-0031 LOGO - ALFRESCO
17 290-0038 BURNER - GRILL - "U" SHAPE
18 290-0052 ALFRESCO SEAR ZONE™ BURNER ASSEMBLY
19 290-0059 ROTISSERIE DRIP PAN
20 290-0061 ROTISSERIE FORK ASSEMBLY
21 290-0116 CHAIN - ANSI # 25 - ¼" PITCH - .13" Ø X 1/8" ROLLER
22 290-0123 SPEAR - ROTISSERIE - 30" - 2006 BBQ
23 290-0124 GRILL 30" BBQ - 12¾" WIDE - SS
24 510-0127 30" BBQ - FIRE BOX ASSEMBLY
25 510-0130 30" BBQ - GREASE TRAY ASSEMBLY
26 510-0131 30" BBQ - GAS MANIFOLD SEAR ZONE™
27 510-0134 SMOKER BURNER ASSEMBLY
28 510-0136 30" BBQ FRONT ASSEMBLY
29 510-0137 SMOKER TRAY ASSEMBLY
30 510-0144 SEAR-ZONE™ GRILL - 2006 BBQ
31 510-0145 WARMING RACK - 30" BBQ
32 510-0146 30" BACK HOOD WITH RIM ASSEMBLY
33 510-0188 ALX2 - IGNITER PLATE - RIGHT
34 510-0194 ALX2-30 FRONT HOOD - MAIN ASSEMBLY
35 510-0208 ALX2-30SZ ELECTRICAL COMPONENTS
28
25
29
23
10
26
13
17
5
7
33
27
13
34
32
19
30
16
15
9
11
8
18
6
35
14
2
1
20
22
20
31 24
12
3
4
21
PROJECT TITLE: DRAWING NO.:
COMMERCE, CA. 90040
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
500-0018 MANUAL-1
October 23, 2006 4:27:24 PM SHEET 1 OF 1
7039 EAST SLAUSON AVENUE
DRAWING TITLE:
SUPERIOR EQUIPMENT SOLUTIONS
CREATED: C:\Working\
ALX2-30 SZ
ALX2-30 SZ
ADRIAN CRISCI
LAST SAVED BY: »» adrian «« October 27, 2006 4:12:46 PM

THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:

1
5
2
1
4
3
2
1
12
2

LAST SAVED BY: »» adrian «« October 18, 2006 9:43:30 AM
C:\Working\
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
ADRIAN CRISCI
October 18, 2006 9:13:47 AM
30" BBQ - FIRE BOX ASSEMBLY
7039 EAST SLAUSON AVENUE CREATED:
ALX2-30 BBQ
510-0127 MANUAL
SHEET 1 OF 1
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0087 1/4" LOCK WASHER 8
2 200-0089 1/4-20 X 1/2 - HEX HEAD BOLT 8
3 510-0128 BBQ TRAY SUPPORT ASSY - RIGHT SIDE 1
4 510-0129 BBQ TRAY SUPPORT ASSY - LEFT SIDE 1
5 510-0205 ALX2-30 FIREBOX - WELDED PARTS 1

ADRIAN CRISCI

LAST SAVED BY: »» adrian «« October 18, 2006 11:08:21 AM
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS 30" BBQ - GREASE TRAY ASSEMBLY
ALX2-30 BBQ
CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0130 MANUAL
October 18, 2006 11:04:19 AM C:\Working\
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
SHEET 1 OF 1
DRAWN BY:
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0073 10-32 - HEX NUT 2
2 200-0075 # 10 LOCK WASHER 2
3 200-0148 SCREW 10-32 X 3/4" - FLAT HEAD - PHILIPS - 82° - SS 2
4 290-0119 ROLLER WHEEL - STAINLESS STL - ¾" Ø - 2
5 510-0206 ALX2-30 GREASE TRAY - WELDED PARTS 1
4
5
3
4
2
1
12
3

DRAWING TITLE:
ALX2-30 SZ BBQ
October 24, 2006 11:00:46 AM
30" BBQ - GAS MANIFOLD SEAR ZONE™
C:\Working\
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
SHEET 1 OF 1
7039 EAST SLAUSON AVENUE
510-0131 MANUAL
PROJECT TITLE: DRAWING NO.:
COMMERCE, CA. 90040
ADRIAN CRISCI
CREATED:
LAST SAVED BY: »» adrian «« October 24, 2006 1:41:38 PM

SUPERIOR EQUIPMENT SOLUTIONS
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
8
19
10
3
7
12
6
9
11 8
14
15
16
16
2
17
184
5
21
13
20
5
1
NOTE: ORIFICE OR VALVE TO
CHANGE ACCORDING TO GAS
SUPPLY. (NG OR LP)
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-0913 30" BBQ SMOKER GAS LINE 1
2 100-0914 ROTISSERIE GAS LINE (42"L x 3/8" Ø - SS. FLEX TUBE) 1
3 100-0917 ROTISSERIE GAS LINE EXTENSION - 3/8"Ø X 8" - SS 1
4 100-0917 SEAR ZONE™ GAS LINE (8"L x 3/8" Ø - SS. FLEX TUBE) 1
5 100-1067 SMOKER & SZ™ ORIFICE BRACKET 2
6 200-0274 ELBOW 90°- CAST IRON - 1/2" FPT x 1/2" MPT 1
7 220-0151 COUPLING 3/8" x 3/8" - COMPRESSION - BRASS 1
8 220-0273 ELBOW 90° - 1/8" FPT x 3/16" COMP 2
9 220-0275 NIPPLE - 1/2" MPT X 3/8" MPT 1
10 220-0276 ELBOW 3/8" MPT x 1/8" FPT x 3/8" COMP 1
11 220-0277 NIPPLE 1/8"MPT x 1/16"MPT 1
12 220-0280 REGULATOR GAS - MAXITROL RV48CL440002 1
13 220-0293 ELBOW 1/4" FPT x 3/8" COMP 1
14 220-0321 MANIFOLD - 30" BBQ - 2006 MODEL 1
15 290-0030 KNOB BBQ - ALFRESCO "A" LETTER 4
16 290-0041 GAS VALVE - STRAIGHT - WITHOUT ORIFICES 2
17 290-0066 GAS VALVE - ANGLED - ORIFICE: INT= 0.95 mm / EXT=NONE 1
18 SEE NOTE GAS VALVE - ANGLED WITH ORIFICE >>> SEE NOTE 1
19 SEE NOTE ORIFICE - IR ROTISSERIE UNIT >>> SEE NOTE 1
20 SEE NOTE ORIFICE - SMOKER UNIT >>> SEE NOTE 1
21 SEE NOTE ORIFICE - SEAR ZONE™ >>> SEE NOTE 1
NG LP
PART N° PART N°
18 290-0064 290-0065
19 220-0283 220-0284
20 220-0287 220-0288
21 220-0289 220-0290
ITEM N°

ALX2-30 BBQ
ADRIAN CRISCI SMOKER TRAY ASSEMBLY
LAST SAVED BY: »» adrian «« October 18, 2006 11:27:00 AM
C:\Working\
SUPERIOR EQUIPMENT SOLUTIONS
7039 EAST SLAUSON AVENUE October 18, 2006 11:10:12 AM
510-0137 MANUAL
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
CREATED:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
SHEET 1 OF 1
DRAWN BY:
5
3
24
1
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1081 SMOKER TRAY 1
2 100-1082 SMOKER TRAY HANDLE 1
3 290-0135 HANDLE - 3/8"Ø X 3" L - TAPPED 1
4 200-0200 WASHER - # 8 - LOCK SPRING - SS 2
5 200-0083 8-32 X 1/4 - PAN HEAD - PHILIPS SCREW 2

BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1092 ROTISSERIE GEAR COVER 1
2 200-0079 8-32 X 3/4 - PAN HEAD - PHILIPS SCREW 2
3 200-0086 1/4-20 X 3/8 - TRUSS HEAD - PHILIPS SCREW 2
4 200-0111 SCREW 8-18 X ½ - SS - MMC# 92364A194 1
5 200-0148 SCREW 10-32 X 3/4" - FLAT HEAD - PHILIPS - 82° - SS 2
6 200-0166 SCREW 10-32 X ¼ Ø X ½ SHOULDER - SS 2
7 290-0119 ROLLER WHEEL - STAINLESS STL - ¾" Ø - 2
8 510-0139 ROTISSERIE GEAR ASSEMBLY 1
9 510-0151 ALX2-30 BACK HOOD AND RIM - WELDED PARTS 1
10 510-0217 30"- ROTISSERIE PANEL ASSEMBLY 1

LAST SAVED BY: »» adrian «« October 20, 2006 11:18:24 AM
ADRIAN CRISCI
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
7039 EAST SLAUSON AVENUE CREATED:
30" BACK HOOD WITH RIM ASSEMBLY
ALX2-30 BBQ
DRAWING TITLE:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0146 MANUAL
October 18, 2006 2:59:20 PM SHEET 1 OF 1
C:\Working\
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
2
8
9
6
6
1
2
10
7
7
5
5
3
4
3

ALX2-30/30SZ/56BFG BBQ
30"- ROTISSERIE PANEL ASSEMBLY

COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
DRAWING TITLE:
7039 EAST SLAUSON AVENUE
SUPERIOR EQUIPMENT SOLUTIONS
LAST SAVED BY: »» adrian «« April 03, 2007 3:25:39 PM
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0217 MANUAL
CREATED: SHEET 1 OF 1
April 03, 2007 3:22:15 PM
ADRIAN CRISCI
C:\Working\
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
3
5
1
2
34
3
BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 100-1225 ROTISSERIE ELECTRODE COVER 1
2 100-1226 ROTISSERIE ELECTRODE BRACKET 1
3 200-0111 SCREW 8-18 X ½ - SS - MMC# 92364A194 3
4 210-0240 ELECTRODE - DUAL TIP - IR BURNERS 1
5 510-0250 ALX2-30 ROTISSERY PANEL - WELDED PARTS 1

BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 200-0087 1/4" LOCK WASHER 4
2 200-0091 1/4-20 X 1 HEX HEAD BOLT 4
3 290-0029 HANDLE BAR - 24" KNURLED 1
4 290-0032 HANDLE END - ½" SPACER 2
5 290-0035 HANDLE END - 90° ELBOW 2
6 510-0195 ALX2-30 FRONT HOOD - WELDED PARTS 1
1
2
1
4
5
3
6
4
5
1
2
1
2
2

LAST SAVED BY: »» adrian «« October 19, 2006 8:35:36 AM
ALX2-30 FRONT HOOD - MAIN ASSEMBLY
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
7039 EAST SLAUSON AVENUE ADRIAN CRISCI
ALX2-30 BBQ
C:\Working\
DRAWING TITLE:
CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
510-0194 MANUAL
October 19, 2006 8:31:30 AM
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
SHEET 1 OF 1
DRAWN BY:

BILL OF MATERIAL
NO. PART
NUMBER DESCRIPTION QTY.
1 210-0194 IGNITER MODULE - 4 POINTS (WITH CAP) 1
2 210-0198 SWITCH - WEATHER BOOT & CAP 3
3 210-0331 ALX2-BBQs RIGHT LAMP ASSEMBLY WITH HARNESS 1
4 210-0332 ALX2-30 LEFT LAMP ASSEMBLY WITH HARNESS 1
5 210-0335 ALX2-BBQs LIGHT SWITCH WITH HARNESS 1
6 210-0337 ALX2-30 ROTISSERIE SWITCH WITH HARNESS 1
7 210-0340 SWITCH BBQ IGNITER ONLY- OFF-[ON] MOMENTARY 1
8 210-0342 ALX2-30 SZ - IGNITION WIRING HARNESS (4 WIRE SET) 1
9 510-0200 ALX2 ROTISSERIE MOTOR ASSEMBLY & J-BOX 1

LAST SAVED BY: »» adrian «« October 25, 2006 8:44:32 AM
ALX2-30SZ ELECTRICAL COMPONENTS
SUPERIOR EQUIPMENT SOLUTIONS
COMMERCE, CA. 90040
DRAWING NO.:
PROJECT TITLE:
510-0208 MANUAL
ADRIAN CRISCI
ALX2-30 SZ BBQ
C:\Working\
7039 EAST SLAUSON AVENUE CREATED:
EQUIPMENT SOLUTIONS, INC. IS PROHIBITED.
October 25, 2006 8:34:56 AM SHEET 1 OF 1
DRAWING TITLE:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF SUPERIOR EQUIPMENT SOLUTIONS
INC. ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT WRITTEN PERMISSION FROM SUPERIOR
DRAWN BY:
# 210-0200
REPLACEMENT
4
3
8
7
5
6
2
2
2
1
9
IGNITER CAP
BATTERY 9 VDC
GENERIC
