END PANEL
CONNECTION
INSTRUCTIONS


ENDPANELCONNECTION
ASSEMBLYINSTRUCTIONS








































PleaseTakenotethereisaLEFTHANDSIDEandaRIGHTHANDSIDEEndPanelIncludedinthisset.
Observethestickerlabelsonthepanels.







AttachingtheEndPanelsto:(Fridge,DoorandBBQModules)
Please Take note there is a LEFT HAND SIDE and a RIGHT HAND SIDE
End Panel Included in this set. Observe the sticker labels on the panels.
THIS END UP THIS END UP
LEFT PANEL RIGHT PANEL
Attaching the End Panels to
Fridge, Storage or BBQ Modules

2 | END PANEL CONNECTION INSTRUCTIONS
The pre aligned screw holes will
ensure that the stone top has an
offset of 30mm from the cabinet.
End Panel aligning with 30mm Offset Stone Top.
ASSEMBLING & ATTACHING
THE END PANELS
FIG. 1
Take note that the Stone Top and End Panel creates a 30mm overhang to
accommodate the door panels.
IMPORTANT - FIT END PANEL BEFORE STONE TOP.

END PANEL CONNECTION INSTRUCTIONS | 3
Align, Insert and Tighten the Barrel Bolts
with the Alen key Provided.
Please Note there are two Barrel Bolts that
needs to be inserted and tightened, front
and back.
FIG. 2
Attaching the End Panel to the FRIDGE MODULE.

&556789:;$58<$!:=$%6:<>$5@$58<$,+"4'!$@C$#)1.'!$$-)#1'! $
91:!E !
!
!
G.=,+H,%)/!I.$A !
J$D+H,%)/!I.$A !
!!





















 

































AttachingtheEndPaneltotheSINGLEorDOUBLEMODULE
AttachingtheEndPaneltotheBBQMODULE
FIG2

FIG3

Right-handView
Left-handView
Right-handView

FIG. 3
Right-hand View
Note: These barrel bolts are 15mm longer than standard.
Right-hand View
FIG. 4
Left-hand View
Attaching the End Panel to the SINGLE or DOUBLE MODULE.
Attaching the End Panel to the BBQ MODULE.
