AlfrescoPlus APSFM User manual















SINGLE/DOUBLEFRIDGEMODULE
ASSEMBLYINSTRUCTIONS






































SINGLE / DOUBLE
FRIDGE MODULE
ASSEMBLY
INSTRUCTIONS
04014 - 09/20

2 | SINGLE/DOUBLE FRIDGE ASSEMBLY INSTRUCTIONS
WARNING! – THIS IS A PERMANENT
CONNECTION SYSTEM!
WHAT’S NEEDED?
Tools Required:
• Soft Sided Hammer (Not Included)
• Philips head screwdriver (Not Included)
• Allen Keys x 2 (Included)
WHAT’S IN THE BOX?
Box 1 of 2 = Bench-top
Box 2 of 2 = Panels
PARTS INCLUDED:
WHITE PANELS with Frames x 4
HARDWARE
• Bolt Pack x 1
• Allen keys x 2
Essential TIP: Ensure you have a stable flat surface or
workbench to work from. The most ideal height to assemble
the module is waist height. The workbench should be at
least 1.8m (W) x 1m(H) x 0.7m(D) in size.

SINGLE/DOUBLE FRIDGE ASSEMBLY INSTRUCTIONS | 3
!
FRIDGE CABINET LAYOUT DIAGRAM
FIG. 1

4 | SINGLE/DOUBLE FRIDGE ASSEMBLY INSTRUCTIONS

































































FIG2

FIG3

FIG4

FIG5

FIG. 2 FIG. 3
FIG. 4 FIG. 5

SINGLE/DOUBLE FRIDGE ASSEMBLY INSTRUCTIONS | 5
STONE TOP PLACEMENT
The frame and stone top is pre-assembled for your ease of assembly.
NOTE: The Stone Top is deeper than the cabinet to allow for services.
IMPORTANT: Assemble and level your kitchen modules, fit your End Panels
and then align your tops before fixing.
ESSENTIAL TIP: Ensure the frames and stone table are positioned on a
stable flat surface to ensure alignment.
CAUTION:The stone table is very heavy, and a 2-person lift is required.
The pre aligned screw holes
will endure that the stone top
has an offset of 30mm from
the cabinet.

6 | SINGLE/DOUBLE FRIDGE ASSEMBLY INSTRUCTIONS
Screw Point, Pre drilled Alignment holes. Screw Point, Pre drilled Alignment holes.

SINGLE/DOUBLE FRIDGE ASSEMBLY INSTRUCTIONS | 7
After the stone has been securely
placed, the thumb screw feet can
be height adjusted to make sure
the cabinet aligns horizontally with
the other cabinets.
FIG. 7

For any queries or assistance call:
Customer Service
Australia Only
1300 174 876
[e-mail]
Hours of operation:
Monday to Friday 8am - 5pm
Do not return to place of purchase
Keep your purchase receipt, this will be required to
make any claims under the warranty.
