AlienPro MV-200 User manual

alienpro.com.mx
MV-200
OPERATING MANUAL

1
www.alienpro.com.mx
Wireless Microphone Handheld Wireless Microphone Specifications
Simple truble shooting
Foreword
Features
6
www.alienpro.com.mx
Thank you for purchasing our wireless microphone.Please read
this instruction carefully before you operate the product.Please
keep this instruction after reading as a reference for the future.
This professional series wireless microphone system uses low
consumption discharging technique with a super sensitive VHF
high band frequency receiver and controlled with 15ppm crystal,
a put on and put off to hit noise and digital control circuit and resist
reverberation circuit.
* Wide frequency response---digital control circuit.Resist disturbance
effectively maintain standing by noises output to zero.
*Super silent function,low T.H.D.
* Hand-held microphone power level indicator.(The signal lamp
will blink continuously to signal replacement of battery.)
* With a wide range of up to 50m.
*A double-way channels designed to avoid interference.
* Uniform cardioid pick up pattern isolates the main sound source
and minimizes background noise.
* Effective,built-in spherical resisting wind and pop filter in
microphone system.
* Choose high quality pickup and components for goods effects.
* With audio compressing-expanding technology,the machine can
lower noises and increase dynamic range.
*Used in entertainment places such as on middle stage, karaoke
hall or at home.
Transmitting power: <30mW
Antenna: Hid antenna
Receiver: Dynamic cardioid type with uni-direction
Battery: AA x 2
Problem Remedy
1. Turn the power, No LED lights
on
2. No sound output, when RF LED
li ghts u p
3 . Wo rk i n g r a n g e ge t s s h o r t
4. Signal is not stable, and sound
qu a l i t y i s g et t i n g w o r se .
Battery is low or the same channel used
around near. Never use same channel
system closer.
Check if you have plug the adaptor to the
power outlet, or the connection is secure.
Check the volume knob or check the RCA
cable is connected with amplifier with
the unit.
Th e h i d a n t e n n a i s d i sc o n n e c t e d or t h e
ba t t e r y i s g e tt i n g l o w, o r t h e re c e i v e r i s
pl a c e d i n a w r o n g l o c at i o n . O r t h e re i s
strong magnetic fields around here.

www.alienpro.com.mx
25
www.alienpro.com.mx
Foreword
Safety Guidance
Installation
Receiver Specifications
Carrier's frequencies: VHF 174-270MHz
Frequency stability: ±0.005%
Modulation: FM
Deviation: 25KHz (Spectrum spreading technology)
Frequency response: 40Hz-20KHz
Signal/Noise ratio: >85dB
Dynamic range: >80dB
Dynamic distortion: <0.5%
Working covering range: 50 Meters (vary according to surroundings)
o o
Working temperature: -10 C to 50 C
Power source: DC12~18V
Power consumption: 2W
Signal/Noise ratio:>85dB
Sensitivity: 60dB S/N (12 dB u)
Mirror interference ratio: >70dB
Neighbor interference ratio: >70dB
Output level: 0-1V
READIN UIDANCE: Must read safety and operating guidance
before using this product.
STORING GUIDANCE: Keep this instruction in a safe place in
order to use it again as a reference in the future.
WARNING: Pay attention to the warning on operating this product.
USIN TORING: Don't place the product in a high electromagnetic
place, or in direct sunshine and in high temperature surroundings
not using for a long period, please pull out the power plug and with
draw the battery from the microphone.
CLEANING: Please pull out the power plug before you clean this
unit. Do not use any chemical gas or liquid.
POWER: The power of this unit is only available to the standard
on label listed, please confirm whether is can use in the voltage
range in your location.
MAINTENANCE: Please send to authorized dealers or qualified
personnel.
AUX BGM
KEY
0+1+2+3 +1 +2 +3 +4 +5 +6
dbL R
MUTE BBEL STEREO RVOCAL
PARTNER
VOCAL
CANCEL
DVD
+4+5+6
DVD A UX USB BGM AUTO
INPUT SEL ECTOR
SOUND MOD E
POWER
KEY CONTR OL
BALANCE TREBLE BA SS DELAY EC HO REPEAT TREBLE BASS MIC 1 VOL MIC2 VO L MIC3 VOL HEADPHO NE M IC 1 MIC 2 MIC3
MUSIC VOL
MIC MASTE R VOL
MUSIC MIC
USB
OFF
ON
AUXI NPUT
L RVIDEO
AM-828 MI XING A MPLI FIER
Power Mic 1 Mic 2 Mic3
Mic1 Mic2 Mic3 MicTreble Mic Bass Mic Echo
Music Volume
10 10 10 10
10
+10
-10 +10 -10
3DSou nd
On Off
KM-110 Kara oke Mix er
On Off
MicVo lume
Power amplifier
Mixer Player
DC Power adapter cable
Mic. Input Mic. Input
Mic. Input
Powe r Outlet
POWER
OFFON
1 2 3456 7 8 9 0
MIC1 MIC2 VOL 1 VOL2 ECHO BASS TREBLE
DOLBY
DIG I T A L
CD+G
MPEG-4
Playback
DVD MPEG -4 KARA OKE PLAYE R
DGX-10 6
SD/MMC
MINISD
USB
" to " cable
1414
1) Connect the DC POWER ADAPTER to the receiver s DC INPUT 12V,
the other end of DC POWER ADAPTER into the WALL OUTLET.
' then plug
2) Connect one end of a " TO " CABLE to the receiver s UNBALANCE AUDIO
OUTPUT (MIX) and the other end to a karaoke mixer, karaoke player or karaoke
power amplifier "microphone input. If you are using the BALANCE AUDIO OUTPUT,
use a XLR to XLR cable or XLR to " cable.
14
,

3
www.alienpro.com.mx
4
www.alienpro.com.mx
Caution
Receiver Descriptions
Handheld Microphone Operation
1. The position of antenna influences the effects of receiving so
the straight line distance must be the shortest from MIC to receiver
and no barriers between them.
2. Several receivers can be used at the same time,Please check
with the authorized dealers.
1. Install the battery correctly as per its polarity.
2. Hold the switch button for 1 second to turn on the power. Light
will turns green means microphone is now in working condition.
When it lights up green, then press switch button shortly, the
light will turn yellow, means microphone is in mute mode, no
sound will comes out from microphone. to go back to working
mode, press the switch button shortly again, the light will turn
green.When there is no light, it means the microphone power
off.
3. Please take away the battery if you do not use the system for a
long period.
Screen head
power lamp
swit ch
batt ery room
Low Battery
Led indicator
POWER Swi tc h
ON/ST.B/O FF
MIC/Line in
OPEN CLOSE
Battery C ov er
BackFront
7
12 6
34
5
34
5
6 7
1) Turn on the receiver by holding the button for 1 second.
2) Power operating indicator
3) Channel 1 operating indicator
4) Channel 2 operating indicator
5) Channel 2 antenna - Provide RF signal for the wireless
system.
6) DC power connection- Main power jack to power the system.
Conect to wall outlet.
7) Audio output jack - Output jack that are used for connecting to
amplifier, mixer or karaoke player. The receiver supports both
balance & unbalance Audio output.
