alkitronic EF Series User manual

Operation and
Maintenance Manual
Electric Torque Multiplier
Serie EF
EF

2
Operation and Maintenance Manual
Foreword
Congratulations on your purchase of an alkitronic® electric
torque multiplier. This high quality product sets unique
international standards and satises high safety levels. In
order to preserve these features, your assistance by regular
maintenance is required. Please read this operation and
maintenance manual carefully and observe the following
information and instructions:
Maintenance and repair of the alkitronic® electric torque
multiplier must be performed by the alki TECHNIK GmbH
or certied workshops adequately trained and instructed
by alki TECHNIK GmbH.
Improper maintenance may endanger your health and
damage the unit. In addition, non-compliance of any
above items will void all warranty claims!
This operation and maintenance manual includes basic
information and instructions which must be observed dur-
ing operation and maintenance. The operator must read
and understand the basic precautions before operation
or performing maintenance. It must always be available
on site.
This operation and maintenance manual applies only to
the alkitronic® electric torque multiplier.
Do not only observe the“Safety instructions”mentioned in
“Denition of symbols“, but also all other special instruc-
tions and hints in other sections.
Denition of Symbols
Safety instructions, which by non-compliance
may result in personal injury or death.
Safety instructions, which by non-compliance
may result in damage to the alkitronic® electric
torque multiplier, its functions or the environ-
ment.
Information for proper and safe operation.
Practical advice and information to make work
easier.
Content Table Page
A Reception Control and Packaging 3
B General Description 3
B1 Model Description 3
1. Technical Data 4
2. Safety Instructions 4
2.1 Intended use 4
2.2 Operators responsibilities 4
2.3 Possible hazards 4
3. Operation 5
3.1 Placing tool in operation 5
3.2 Preparing for bolting 5
4. Electric Operation 6
4.1 Operation unit EF - all models 6
4.2 Operating area with OLED display 6
4.3 Overview bolting programs (Modes) 6
4.4 Bolting programs 7
4.4.1 Bolting according to the torque method 7
4.4.2 Bolting according to the combined torque/angle
procedure (option) 8
4.4.3 Bolting according to the combined torque/angle
procedure - Premium 9
4.4.4 Bolting with specication of turns 10
4.4.5 Documentation bolted joint and Bluetooth
activation 11
4.4.6 The alkitronic® APP 12
4.4.7 Error messages in the alkitronic® EF
operating area 15
5. Mechanic Operation 16
5.1 Handles and Operating Handles 16
5.1.1 Mounting Operating Handle 16
5.2 Remote Control (FB-EF) 17
5.3 Tightening and loosening 18
5.3.1 - Models with axiale drive 18
5.3.2 - Models with radial-/tangential drive 19
6. Ending or Interrupting the Work 20
7. Functional and Operational Tests 20
7.1 Optical and mechanical inspection 20
8. Service / Storage / Maintenance 20
8.1 Accessories change 20
8.2 Storage 21
8.3 Taking out of operation 21
8.4 Maintenance intervals 21
9. Technical Notes 21
10. Acoustic Emission and Vibration 21
11. Declaration of Conformity 22
12. Appendix 22

3
electric torque multipliers
alkitronic® EF-S - torques up to 42,000 Nm (30,980 ft.lbs).*
alkitronic® EF-A angletoolsforrestrictedaccess- high operat-
ing comfort. Torques up to 9,800 Nm (7,230 ft.lbs).*
Models with OLED-Display, menu guidance and bolting pro-
grammes as for example torque/angle procedure.
All models with overload protection.
B 1 Model Description
alkitronic® electric torque multiplier with axial drive.
The 360 degree rotating handle ensures comfortable opera-
tion. Robust motor housing of an aluminium alloy.
* approx. values / torque values are dependent on model
alkitronic® EF-SG
Constructively integrated reaction absorber, torques
up to 3,780 Nm (2,790 ft.lbs)*
alkitronic® EF-R/ EF-SG with radial-/tangential gearing e.g.
for use with spindles or long threaded bolts in plate heat
exchangers. Robust motor housing of aluminium. All models
with overload protection.
alkitronic® EF-R
Torques up to 3,780 Nm (2,790 ft.lbs)*
A Reception Control and Packaging
Visually inspect all components for possible
dam age. If shipping damage is found, notify the
forward ing alkitronic® Partner immediately. Re-
turn components and alkitronic® electric torque
multiplier in original package to avoid additional
damage. Therefore, please keep the packaging.
B General Description
alkitronic® electric torque multiplier are strength power-
operated torque multipliers for continuously tightening or
loosening heavy duty bolt connections.
The torque multiplier turns o with achievement of a de-
manded value or nal torque.
The drive is done by a maintenance-free, low-wear syn-
chroniced motor without brushes and excellent eciency,
large torque range and high assembly speed.
Consistent torque accuracy in all international power sup-
plies. Precise shut-off torque at operation with voltage-
controlled portable generators.

4
Operation and Maintenance Manual
1. Technical Data
Supply voltage / frequency 100 V - 253 V / 45 Hz - 66 Hz
Nominal power max. 1,400 W
Ambient temperature -20OC to +50O C / -4OF to +122OF
Repeat shut-o accuracy ± 2%
Housing Protection category I, IP-code 20
2. Safety Instructions
2.1 Intended use
alkitronic® electric torque multipliers are designed to tighten
or loosen heavy duty bolt connections continuously. Do
not use the torque multiplier for any other purpose than
its intended use. For other applications please consult alki
TECHNIK GmbH.
2.2 Operators responsibilities
The operator must have read and understood the instructions
of this operation and maintenance manual before using or
servicing the alkitronic® electric torque multiplier. Minimum
age of the operator must be 18 years.
Operation and service may not be performed, if the con-
cerned person does not understand purpose, consequences
and precise performance of each procedure. For questions
regarding the safety measures and areas of application, your
alkitronic® Partner will be pleased to assist.
Improper operation, incorrect application, abuse
or use by unqualied personnel may be hazardous
to other persons, operator, torque multiplier and
other property.
The operator is responsible to third parties within
the work area. Keep children and bystanders away
while operating the torque multiplier.
Do not operate alkitronic® electric torque mul-
tipliers in explosive atmospheres, such as in the
presence of ammable liquids, gases, or dust. For
operation outdoors or in humid rooms, observe
the relevant regulations.
Non-authorized alterations and modications of
the torque multiplier are not permitted.
2.3 Possible hazards
Maintain the alkitronic® electric torque multiplier.
Check breakage of parts/accessories, damaged
power supply cord and any other condition that
may affect the tool operation. In case of dam-
ages the torque multiplier must immediately be
inspected by a qualied technician for electrical
safety and mechanical defects (repairs may only
be performed by authorized personnel).
alkitronic® STA
Standard adaptor, for a smaller
spanner width (AF).
alkitronic® STA
Standard adaptor
Reaction pin
Reaction pin
alkitronic® accessories
for torque multiplier
with axial drive.
alkitronic® accessories
EF-R / EF-SG torque multiplier
alkitronic® accessories
For each fastening the original
accessories.
alkitronic® STACO
Standard socket
alkitronic®STABI
Standard con-
nector
alkitronic® DMA
Torque reaction
absorber

5
electric torque multipliers
All safety and mechanical defects must be resolved
before resuming operation.
For the avoidance of electric shocks or malfunctions
admitted and accordingly marked extension cords
are to be used outside only.
3. Operation
Prior to electric power connection, it must be
ensured that the indicated technical data on the
tool type plate as well as in the operation manual
corresponds with the power supply and environ-
mental conditions. Deviating values could lead to
malfunctions or severe damages.
All alkitronic® electric torque multipliers are deliv-
ered with a three-wired power cord with ground
conductor. A possible exchange of the power cord
plug (caused by nationally different electricity
supply or net plugs) may be performed only by an
authorized electrician. See appendix “Replacing
the power cord plug“.
alkitronic® electric torque multipliers must not
be damp, neither operated nor stored in moist or
humid environment. Otherwise an additional rain
protection must be provided on site.
In case of machine malfunction or loss of electricity
immediately switch o power button and discon-
nect the plug from the power source.
3.1 Placing tool in operation
alkitronic® STACO/STABI/STA/DMA (specic nuts, connectors,
adaptors and reaction absorbers) available as accessories, are
needed in accordance with a specic bolt joint.
The torque multiplier must be disconnected from
the power source before making any adjustments
or changing accessories.
• Accessories may be placed on the tool drive side. Make
sure every part is placed correct and secured (in compli-
ance with item 3.2 Preparing for bolting).
• Replace worn or damaged accessories immediately. F or
replacement use original alkitronic® accessories only.
This rule will reduce the risk of malfunction and serious
personal injury.
alkitronic® STABI
3
8
alkitronic® STACO
2
6
7
1
4
3.2 Preparing for bolting - Models with axial gearing
• Place the alkitronic® electric torque multiplier on a at
surface.
• If the DMA is secured with a safety screw - screw out safety
screw completely (the position of the screw can vary de-
pendent on type).
• Insert DMA reaction absorber (1) onto toothing (4),
• screw in safety screw completely again - the DMA is se-
cured.
DMA Safety screw
DMAR Safety ring (accessories)
alkitronic® DMA
• Put STACO / STABI (2)/(3) on square drive (both boreholes,
adaptor and square must correspond),
• insert safety pin (7), secure with rubber ring (6).
• STABI: screw in safety screw (8) completely.
For a DMA without safety screw a safety ring DMAR is obtai-
nable as accessory. The safety ring prevents the DMA from
loosening and can be put additionally on the toothing and
be screwed together.

6
Operation and Maintenance Manual
4. Electric Operation
4.1 Operating unit (all alkitronic® EF.. Models)
Power switch
On/O
(Luminous
button)
Direction
of rotation CW
Metal pushbutton
Direction of rotation CCW
Handle
Operating
handle
Operating handle
For special applications are
two convenient operating handles
included in delivery and
can be installed if required.
Direction of rotation pushbuttons for tap and continuous
operation
The operation of one of these buttons (see drawing above)
makes it easier to place the alkitronic® EF... on a bolt or nut
as well as the preturning.
If the button is pressed down, the bolting process starts;
when it is release, the bolting process stops.
The torque multiplier shuts o precisely when reaching the
required torque or value.
Decrease value / line down
Mode selection / input conrmation
Increase value / line up
4.2 Operating area with OLED display
Key-Symbols
4.3 Overview bolting programs (Modes)
Mode Description
M 1 Bolting according to the torque method, automatic
release with adjustable angle degrees.*
Already included in the scope of delivery.
Optional programs:
M 2 Bolting according to the torque/angle method,
automatic release function with presettable angle
degrees. *
M 2
Premium Additional adjustable torque limits
M 3
Bolting with presetting of revolutions and adjustable
torque limitation.
M 4 Bolting parameters according to individual customer
requirements.
M 5 Documentation of the bolting operations (target/
actual status recording for each bolting operation
performed).
Bluetooth transmission via alkitronic® APP.
* Caused by high torsional force it is often impossi-
ble repositioning the torque multiplier on the next
screw joint. Therefore use the automatic release
function to relieve stresses within the multiplier.
The setting of angle degrees enables a “run free“
of the reaction absorber DMA.
Bolting programs
e.g. Mode 1
Torque
Release angle
Unit
„run“ is displayed as soon
as the motor is
running

7
electric torque multipliers
4.4.1 Bolting according to the torque method
Settings mode 1 - with/without automatic release function
4.4 Bolting programs
Step 1
If no automatic release function is desired,
set release angle to„0“.
Remove the torque multiplier, place it on
the next bolt/nut and continue with the
bolting process.
Set nal torque
Set bolting method
Set release angle
Conrm
Conrm
Conrm
Conrm resp. the acknowledgment is automatically.
Start Screen
Once the values have been checked -
start bolting process.
Successful bolting is signaled by
„OK“.
“nOK”signalisation ashes (faulty
bolting).
Check the setting values. Repeat the bolting
operation, observing the relevant regulations for
the bolting operation, e.g. use new bolts or new
bolting material.
Step 2
Step 3
After a short time, the display jumps
to the next image (example).
Correction procedere:
push key and return
to step 1.
Application description:
Bolted connections are bolted with a torque specication and monitored at the same time. During the bolting process, the currently applied
torque is always shown on the display and reaching the SET value is signaled by an „OK“. The maximum actual torque applied is stored. If
required, an automatic release angle can be set.This function enables a fast, secure“run free“ of the DMA and also relieves torsional stresses
within the torque multiplier.
Note on the procedure for the loosening angle:
This is not intended for loosening a bolt/nut, here
only the release of tension between the torque
multiplier and the bolted joint is established!
*
*
The setting steps of the
torque values are in incre-
ments of 10 Nm (10 ft.lbs).

8
Operation and Maintenance Manual
4.4.2 Bolting according to the torque/angle method (option)
Settings mode 2 - with / without automatic release function
Step 1
If no automatic release function is desired,
set release angle to„0“.
Remove the torque multiplier, place it on
the next bolt/nut and continue with the
bolting process.
Set Pre-torque
Set bolting method
Set release angle
Set angle of rotation
Correction procedere:
push key and return to
step 1.
Conrm
After a short time, the display jumps
to the next image (example).
Conrm
Conrm
Conrm
Conrm resp. the acknowledgment is automatically.
Start Screen
Once the values have been checked -
start bolting process.
Successful bolting is signaled by
„OK“.
“nOK”signalisation ashes (faulty
bolting).
Possible causes: The angle of rotation was not reached. The
torque output of the alkitronic® EF is not sucient for the bolted
joint. Check the setting values. Repeat the bolting operation,
observing the relevant regulations for the bolting operation, e.g.
use new bolts or new bolting material. verwenden.
Step 2
Step 3
Step 4
Note on the procedure for the loosening angle:
This is not intended for loosening a bolt/nut, here
only the release of tension between the torque
multiplier and the bolted joint is established!
Application description:
Bolted connections are tightened using a torque specication and additional rotation angle specication and at the same time monitored.
In the torque specication, the currently applied actual torque is shown in the display. When the preset target torque value is reached, the
torque multiplier automatically switches to the rotation angle function (the pushbotton must remain permanently activated).
The currently measured rotation angles are shown in the display and upon reaching the preset angle of rotation, an„OK“ is shown in the display.
The maximum applied actual torque and the actual rotational angle are stored and evaluated with an„OK“ or„nOK“ in the display.
*
*
The setting steps of the
torque values are in incre-
ments of 10 Nm (10 ft.lbs).

9
electric torque multipliers
4.4.3 Bolting according to the torque/angle method - Premium
Settings mode 2 PREMIUM - torque limitation min / max. and with / without automatic release function
Step 1
If no automatic release function is desired,
set release angle to„0“.
Limitation of max. torque
Remove the torque multiplier, place it on
the next bolt/nut and continue with the
bolting process.
Set Pre-torque
Set bolting method
Set Torque max.
Set Torque min.Limitation:
Limitation:
Set release angle
Set angle of rotation
Correction procedere:
push key and return to
step 1.
Conrm
Aftera short time,the displayjumps
to the next image (example).
Conrm
Conrm
Conrm
Conrm
Conrm
Conrm resp. the acknowledgment is automatically.
Start Screen
Once the values have been checked -
start bolting process.
Successful bolting is signaled by
„OK“.
“nOK”signalisation ashes (faulty
bolting).
Possible causes: The angle of rotation was not reached.
Termination due to exceeding the torque limit. The torque output
of the alkitronic® EF is not sucient for the bolted joint.
Check the setting values. Repeat the bolting operation, observing
the relevant regulations for the bolting operation, e.g. use new
bolts or new bolting material. verwenden.
Step 2
Step 3
Step 4
Step 5
Step 6
Note on the procedure for the loosening angle:
This is not intended for loosening a bolt/nut, here
only the release of tension between the torque
multiplier and the bolted joint is established!
Application description:
The bolting process is identical to mode 2, but a minimum and maximum torque value can be stored to protect the bolt/nut or the bolting
process in general from overload and damage. The bolting process in the torque/rotation angle method is monitored and simultaneously
limited with an adjustable minimum and maximum torque. The maximum selectable value corresponds to the maximum power range of the
respective machine. If this torque value is exceeded during the bolting process, the process is aborted and evaluated with an„nOK“ in the display.
*
*
The setting steps of the
torque values are in incre-
ments of 10 Nm (10 ft.lbs).

10
Operation and Maintenance Manual
4.4.4 Bolting with specication of turns
Settings Mode 3
Step 1
Remove the torque multiplier, place it
on the next bolt/nut and continue with
the bolting process.
Set
torque limitation
Set
bolting method
Set
revolutions
Correction procedere:
push key and return to
step 1.
Conrm
After a short time, the display jumps
to the next image (example).
Conrm
Conrm
Conrm resp. the acknowledgment is automatically.
Start screen
Once the values have been checked -
start bolting process.
The SET number of revolutions
reached is signaled by„OK“.
“nOK”signalisation ashes (faulty
bolting).
Possible causes:
Exceeding the torque limit or the torque output of the alkitronic®
EF is not sucient for the bolted joint. Check the setting values.
Repeat the bolting process in compliance with the relevant regula-
tions for the bolting process.
Step 2
Step 3
Application description:
A certain number of revolutions is specied for the output drive. The torque limiter monitors the process at the same time.
The currently measured number of revolutions is shown in the display. As long as the pushbutton is held down, the alkitronic® EF counts the
revolutions already made until the set number of revolutions is reached.
It is possible to pause the output. The currently measured number of revolutions is stored temporarily. When the pushbutton is pressed again,
the counter continues to run until the SET number of revolutions is reached.
Note:
However, the temporary storage is deleted when the mode is changed or the device is restarted.
When the number of revolutions is reached, the process is evaluated with an„OK“ in the display then recorded. If the set torque limit is
exceeded, the process is aborted and a„nOK“ is shown then saved.
*
*
The setting steps of the
torque values are in incre-
ments of 10 Nm (10 ft.lbs).

11
electric torque multipliers
4.4.5 Documentation bolted joint and Bluetooth activation
Settings Mode 5
Step 1
Set program
Correction procedere:
push key and return
to step 1.
Conrm
After a short time, the display
jumps to the next image (example).
Possibilities for data evaluation:
• In modes 1, 2 and 3, all bolting actions are documented
Contents of the CSV le:
• ID - consecutive number for each stored tightening
• Mode - mode used
• Target / actual values - used target values and
measured actual values
• Status - Assessment of target / actual values for
tightening status (SUCCESSFUL / ERROR)
Application description:
Selecting mode 5 activates the Bluetooth interface and enables transmission. Provided Bluetooth is activated on the smartphone
In the alkitronic® App, the relevant bolting cases for documentation can be narrowed down by selecting the desired download period
(download from: date / time).
Up to 500 stored bolting joints can be downloaded with the associated alkitronic® App and sent by e-mail in the form of a CSV le.
This makes the bolting data available in tabular form for analysis and documentation.
In the CSV le, under the column„actual torque”you can nd
the nal torque of the rotation angle function of mode 2. This
value is used for the direct determination of an emerging
torque range, for example for the use of test and development
purposes in the bolting application.
CSV data set: Example mode 1 (ID33-35) with 3 bolted connections, target MD in Nm and release angle 5°.
Example of mode 2 (ID36-38) with 3 bolts, target MD, min,max MD in Nm, target angle and release angle 5°.
ID Mode Timestamp Status ActualTorque TargetTorque MinTorque MaxTorque ActualAngle TargetAngle ActualTurn TargetTurn Actual Release.angle Target Release.angle
33 12020-05-29F13:21:38.016Z OK 298 301 ---- ---- ---- ---- ---- ---- 5 5
34 12020-05-29F13:22:38.016Z nOK 420 301 ---- ---- ---- ---- ---- ---- 0 5
35 12020-05-29F13:22:38.016Z OK 302 301 ---- ---- ---- ---- ---- ---- 5 5
36 22020-05-29F13:24:38.016Z nOK 270 140 200 250 50 50 ---- ---- 0 5
37 22020-05-29F13:25:38.016Z OK 244 140 200 250 50 50 ---- ---- 5 5
38 22020-05-29F13:25:38.016Z OK 235 140 200 250 50 50 ---- ---- 5 5
• In mode 2, the resulting maximum torque can also be
reproduced during use in rotating angle application
*
*
M
D
= Torque
Legend:
Pre-Torque Angle of Rotation Release Angle
Mode 2 Premium M
D
Limitation
>
The Bluetooth interface
on the phone/pad must
be activated.

12
Operation and Maintenance Manual
4.4.6 The alkitronic® APP
Quick guide: Screens and selection of operating
Settings
Collection
of user data
Log in
Language
selection
The screen views may
differ from the images
shown here, depending
on the smartphone used.
1
31.1
2.1
Torque multiplier
choice *
2 2 2
*) To pair or search for an alkitronic®
EF... torque multiplier, the Bluetooth
interface on the phone/pad must be
activated.
You can find the alkitronic® app download in
the App Store (Apple) or Play Store (Android).

13
electric torque multipliers
When tapping the CSV icon, the
displayed bolted joint data (Screen
5.2) will be exported in a CSV data
record.
Note:
After transferring the data, this
overview is no longer displayed.
After theTorque Multiplier has been
selected (Screen 4), all machine
and production-related data can
be called up.
5.1
4.1
5.25
4
CSV Icon

14
Operation and Maintenance Manual
7.1
6.1
7
6
Display of the alkitronic® torque
multiplier - specific properties
(screen 7.1).
Calibration certicate
With this function, the alkitronic® EF...-
specic certicate can be transferred to
the smartphone (as a supplement for
the bolted joint documentation). As
soon as the button is pressed, the cam-
era function opens.This can be used to
scan the QR code of the alkitronic® EF..
or the supplied calibration certicate.

15
electric torque multipliers
4.4.7 Error messages in the alkitronic® EF operating area
Temperature errors cannot be reset using the “M” button.
Resetting is done automatically when temperature thresholds
fall again below the limit.
To assure safe operation various temperature levels of the
torque multiplier are controlled. A switch-o during a bolting
process is however possible if the preset max. temperature
limits are exceeded.
Reactions
A - TEMP Error:
The bolting process is blocked/cancelled.
B - TEMP Warning during bolting:
Finish the bolting process in progress.
C - TEMP Warning prior to a bolting process:
The bolting process is blocked until the tempera-
ture is back to normal.“TEMP”warning will then no
longer show.
Error messages are always displayed ashing and inversely.
Error message as
hexadecimal gure
General error Message
Error display electrical
supply
General error display
excessive temperature
Errors can be reset by using the “M” button, pro-
vided the cause is eliminated. If this fails, your
alkitronic® partner will be pleased to help you.
Please take a note of the error code and report it
to our customer service.
Warning initiated due to faulty power/voltage supply or
frequency.
E.g. by undervoltage or overvoltage (<100 V or >253 V).
TEMP-warning display
„TEMP“ warning is ashing
Service warning, see
8.4 Maintenance intervals
Under excessive use/high loads or in case of many
operation hours we recommend that calibration
and service is carried out at shorter intervals
than the recommended 12 months. In this case
a service warning appears in the display. You can
acknowledge the message with the “M” button.
From this time on the information is shown at
every restart of the torque multiplier.
General warnings

16
Operation and Maintenance Manual
OT
UT
B
S
GS
BS
T
Assembly description ( use allen keys A/F 3mm and A/F 4mm) :
Remove the cover cap from the socket (B). Fasten the ange
on the lower housing part (UT) to the EF housing using the
two allen screws (BS). The pushbutton (T) should already
be screwed to the upper part of the housing (OT). The plug
(S) with the pushbutton cables must be connected to the
socket (B) (make sure it is firmly seated). Screw the upper
part of the housing (OT) to the lower part of the housing
(UT) using the two housing allen screws (GS). Proceed in
the same order when mounting the 2nd operating handle.
5. Mechanic Operation
5.1 Handles and Operating Handles
Model-specic handles and operating handles are included
in the scope of delivery for safe, convenient tool guidance.
They can be mounted as required at the intended attach-
ment points using the enclosed mounting material incl.
tools.
Operating
handle
Handle
For safealkitronic®torque multiplier handlingsuch
as transport a.s.o. Handles must always be used.
5.1.1 Mounting Operating Handle
Operating handlesareequipped withapushbuttontoenable
convenient operation. They are not used to transport the
alkitronic®torque multiplier and are still only permitted for
usewithcertainalkitronic® types-seebelow,table„Overview
of handles and operating handles“.
Handle with possible xing points
Handle also
180º rotated usable
Type alkitronic®EF-S 250 EF-S 300 EF-S 400 EF-S 600 EF-S 800 EF-S 1000 EF-S 2000 EF-S 4000
Handle (Standard) nnnnnn---- ----
Operating handle (Standard) nnnnn---- ---- ----
Type alkitronic®EF-A 400 EF-A 600 EF-A 800 EF-A 1000
Handle (Standard) nnnn
Operating handle ---- ---- ---- ----
Type alkitronic®EF-R Type alkitronic®EF-SG
Handle nHandle n
Operating handle ---- Operating handle ----
Overview of Handles:
Only the handle marked with a dot is approved for use on
the corresponding EF ... type is approved.
Which handles are used with the corresponding alkitronic®
EF types is shown below in the table „Overview of handles“
Use an
allen key
(A/F 4 mm)

17
electric torque multipliers
5.2 Remote Control (FB-EF)
To start up the remote control, connect the plug on the
FB-EF cable to the socket (BF) on the alkitronic® EF control
panel. The remote control panel and EF torque multiplier
are identical in terms of operation and functions.
BF
Typ alkitronic®EF-S 2000 EF-S 4000
FB-EF (Standard) n n
FB-EF (Option)
Typ alkitronic®EF-R EF-SG
FB-EF (Standard)
FB-EF (Option) n n
Typ alkitronic®
EF-S 250 EF-S 300
FB-EF (Standard)
FB-EF (Option) n n
Typ alkitronic®EF-S 400 / EF-A 400 EF-S 600 / EF-A 600 EF-S 800 / EF-A 800
EF-S 1000 / EF-A 1000
FB-EF (Standard)
FB-EF (Option) nnnn
During operation, the item 5.3 Operation Tight-
ening and Loosening (from page 18) must be
observed.
If the alkitronic® EF is only operated via the FB-
EF, make sure that the tool is mechanically safe
and stable at the place of use. It must always be
ensured that the EF torque multiplier is ready to
be switched o.
Equipment with the remote control (FB-EF)

18
Operation and Maintenance Manual
incorrect
correct
Correct torque
reaction point in
marked area only
incorrect
Operation steps alkitronic® EF-S / EF-A
• Connect the torque multiplier to the power supply.
• Place the alkitronic® torque multiplier with alkitronic®
STACO/STABI completely on bolt/nut.
• The DMA or torque-on recipient of the torque multiplier
must be at the same height as the socket/adaptor to take
the reaction moment.
• A sure, stable counter-mount (2) must be ensured.
• Always keep the torque multiplier in axis line to the bolt
during bolting process.
Parameters are already set:
• Push power switch and start bolting process.
• The drive stops when achieving the desired torque or
value. Switch off machine and place on next bolt/nut.
Place on the next bolt/nut alkitronic® EF-S / EF-A
• If the automatic release function is not set and the
torque multiplier is not removable of the bolted joint
(torsional forces caused):
Release the torque multiplier by changing the direction
of rotation and briey press the ccw button until the
DMA (reaction arm) is free.
• For Information:
When loosening the bolted connection, up to 20%
higher torque (loosening torque) may be required.
• Switch o machine and place EF multiplier on next bolt/
nut and start bolting process.
2
1
Never place your hand or ngers between the DMA
and support point to avoid injuries by bruises!
Bolting
direction
Reaction
moment
Always place STACO/STABI completely on the bolt/
nut. Provision of a safe and stable counter mount-
ing is essential. For individual DMA solutions, your
alkitronic® Partner will be pleased to assist you.
In addition, non-compliance of any above items
will void all warranty claims.
Improper bolting connection or incorrect reaction
support may cause:
- Strain breakage in STACO / STABI adaptors,
bearing or output square drive;
- Bruises or even life-threatening injuries (parts
splintering o);
- “Shut-o“ torque failures.
5.3 Tightening and loosening
Safety hints
Comply with all applicable local, state and national
electrical and safety regulations.
Always carry out a function inspection and safety
check - no working with damaged parts!
Keep your hair, clothing, and gloves away from
moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts (alkitronic® DMA/
STACO/STABI/STA).
Maintain a safety distance when tightening bolts or
nuts. Do not leave the torque multiplier unattended
during use. A rapid“switch o”in case of emergen-
cy must be always ensured.
Keep proper footing and balance at all times. This
enables better control of the torque multiplier in
unexpected situations.
5.3.1 Tightening and loosening - Models with axial drive
Directions of rotation

19
electric torque multipliers
Do not retighten the nut/bolt.
Because the preset torque is exceeded and it
can lead to damage to the torque multiplier
or to the bolt / threaded bolt.
Do not retighten the nut/bolt.
Because the preset torque is exceeded and it
can lead to damage to the torque multiplier
or to the bolt / threaded bolt.
5.3.2 Tightening and loosening - alkitronic® EF-R / EF-SG
When using alkitronic® EF-R models the reaction
pin (4) must be put completely into the receiving
device. Otherwise there is a danger of case break-
age and a risk of serious personal injury.
The output drive of the alkitronic® EF-R and/or
EF-SG takes place via a xed width across at (AF).
For the reduction to smaller spanner openings an
alkitronic®STA (3) is necessary. For proper operat-
ing use alkitronic® accessories only!
alkitronic® ..R Models alkitronic® ..SG Models
alkitronic® STA
(4) Reaction pin
3
alkitronic® torque multiplier
with radial gearing (...R)
1
alkitronic® torque multiplier
with tangential gearing (...SG)
2
Operation steps
• Always place alkitronic® EF-R / EF-SG completely on the
bolt/nut.
• A sure, stable counter-mount (Fig. 1/1)/(Fig. 2/2) must be
ensured.
• Always note during the bolting process:
- keep the alkitronic® EF-R multiplier in a 90 degrees
angle to the bolt (Fig. 1).
- keep the alkitronic® EF-SG multiplier in parallel line to
the bolt (Fig. 2).
• Push power switch and start bolting process.
• The drive stops when achieving the desired torque or
value. Switch o machine and place on next bolt/nut.
Fig. 2
Fig. 1
• Active automatic release function
This function enables a fast, secure “run free“ of the DMA
and also relieves torsional stresses within the multiplier.
• Place EF... multiplier on next bolt/nut and start bolting process.
• End of the bolting process
If the bolting process was error-free („OK“ - shown in the
display), conrm the process.
• Remove the EF... torque multiplier , another bolting process
can be started.
See also operation steps:Procedere“Place on the
next bolt/nut alkitronic® EF-S / EF-A” (page 18)
Application release function: This is not intended for
loosening a bolt/nut. Use the automatic release func-
tion only to release tension inside the
EF multiplier.

20
Operation and Maintenance Manual
Markedsupporting-pointsorsupporting-
surfaces are particularly dangerous areas.
Fig. 3
7. Functional and Operational Tests
7.1 Optical and mechanical inspection
Check for intactness regulary, power cord and
plug, display and operating elements, gear box,
drive element, housing and accessories (e.g. reac-
tion absorber DMA, adaptors). Before further use
of the torque multiplier, damaged parts should
be properly repaired or replaced. Serious dam-
ages and many accidents are caused by poorly
inspected tools.
In causes of performance loss, strong gear noises
or recognisable heavy damages a repair is to be
carried out immediately. In the event of repairs
the alkitronic® torque multiplier (in original pack-
age) must be sent to the appropriate alkitronic®
Partner or directly to alki Technik GmbH.
The following operation and service requests should be
strictly observed!
8. Service / Storing / Maintenance
8.1 Accessories change
Note item “3.2 Preparing for bolting“ and carry out
the described steps in reverse order.
6. Ending or Interrupting the Work
alkitronic® electric torque multiplier
- Switch o and disconnect the cord plug from
the power socket.
- Do not abuse the power cord. Never use the
cord for carrying, pulling or unplugging the
tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
- Place the torque multiplier on a at and dry
surface, avoid soiling and/or blockage of the
ventilating openings.
alkitronic®electric torque mul-
tiplier with radial gearing
alkitronic®electric torque
multiplier with tangential
gearing
Safety instructions when pulling together plate packs on
heat exchangers.
Do not reach between end plates and support
bolts or gearbox (Fig. 3). Only touch the torque
multiplier by the handle. There is a considerable
risk of injury (crushing) if this is not observed.
