SCHUNK iTENDO2 pad User instructions

Translation of Original Operating Manual
Assembly and Operating Manual
iTENDO²

Imprint
2 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 1522399
Version: 01.00|03/11/2022|en
Dear Customer,
Thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
Customer Management
Tel. [phone]
Fax [phone]
[email protected]
Please read the operating manual in full and keep it close to the product.

Table of Contents
Table of Contents
1 General.................................................................................................................... 5
1.1 About this manual ................................................................................................ 5
1.1.1 Presentation of Warning Labels ...............................................................5
1.1.2 Definition of Terms...................................................................................6
1.1.3 Applicable documents ..............................................................................6
1.2 Warranty .............................................................................................................. 6
1.3 Scope of delivery .................................................................................................. 6
1.4 Accessories ........................................................................................................... 6
2 Basic safety notes ................................................................................................... 7
2.1 Intended use......................................................................................................... 7
2.2 Not intended use.................................................................................................. 7
2.3 Constructional changes ........................................................................................ 7
2.4 Spare parts ........................................................................................................... 8
2.5 Environmental and operating conditions ............................................................. 8
2.6 Personnel qualification......................................................................................... 8
2.7 Personal protective equipment............................................................................ 9
2.8 Notes on safe operation ....................................................................................... 9
2.9 Transport ............................................................................................................ 10
2.10 Malfunctions....................................................................................................... 10
2.11 Disposal .............................................................................................................. 10
2.12 Fundamental dangers......................................................................................... 11
2.12.1 Protection during handling and assembly ..............................................11
2.12.2 Protection during commissioning and operation ...................................11
3 Technical data.........................................................................................................12
3.1 Product data ....................................................................................................... 12
3.2 Ambient conditions and operating conditions ...................................................13
3.3 Information on using the length adjustment screw ........................................... 13
3.4 Usable tool shank types...................................................................................... 13
4 Design and description............................................................................................14
4.1 Design ................................................................................................................. 14
4.2 Functional description ........................................................................................ 15
5 Assembly ................................................................................................................16
5.1 Basic information................................................................................................ 16
5.2 Assembling the product...................................................................................... 17
6 Operation ...............................................................................................................18
6.1 Basic information................................................................................................ 18
6.2 Clamping tool ..................................................................................................... 20
6.3 Unclamping tools................................................................................................ 21
301.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

Table of Contents
7 Maintenance ..........................................................................................................22
7.1 Basic information................................................................................................ 22
7.2 Intervals and tasks.............................................................................................. 23
7.2.1 Clean the clamping face .........................................................................23
7.2.2 Clean the product ...................................................................................24
7.2.3 Checking the clamping force ..................................................................24
7.2.4 Checking and lubricating the clamping screw ........................................25
8 Disassembly............................................................................................................26
8.1 Basic information................................................................................................ 26
8.2 Disassembling the product ................................................................................. 27
9 Storage ...................................................................................................................28
10 Disposal ..................................................................................................................29
11 EU Declaration of Conformity .................................................................................30
4 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

General
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
In addition to these instructions, the documents listed
under }1.1.3 [/6] are applicable.
NOTE: The illustrations in this manual are intended to provide a
basic understanding and may deviate from the actual version.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Dangers for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
NOTICE
Material damage!
Information about avoiding material damage.
501.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

General
6 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
1.1.2 Definition of Terms
The term "product" replaces the product name on the title page in
this manual.
1.1.3 Applicable documents
• General terms of business *
• Contractual agreements
The documents labeled with an asterisk (*) can be downloaded
from schunk.com.
1.2 Warranty
If the product is used as intended, the warranty is valid for 12
months from the ex-works delivery date under the following
conditions:
• Observe the applicable documents, }1.1.3 [/6]
• Observe the ambient conditions and operating
conditions, }2.5 [/8]
• Observe the specified maintenance instructions }7 [/22]
This does not include special agreements detailed in the warranty
and wearing parts. Wearing parts can also become worn through
appropriate use before the maximum number of clamping cycles
has expired. This includes all areas that come into contact with the
tool or the machine (clamping range and machine mount) and
sealing elements.
1.3 Scope of delivery
The scope of delivery includes
1 iTENDO²
1 Assembly and Operating Manual
1.4 Accessories
The following accessories for the product are available separately:
• Test shaft for monitoring the expansion rate
• Allen key for operating the clamping screw
• GZB-S intermediate sleeves for clamping several different shank
diameters
• GZB-S sleeve remover for removing intermediate sleeves

Basic safety notes
2 Basic safety notes
2.1 Intended use
• The product is used to clamp rotationally symmetric tools.
• The product may only be used and applied within the scope of
the information in the technical data, }3 [/12].
• The product is intended for industrial use.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Not intended use
The product is not being used as intended if, for example:
• The product is used with heat shrinking technology.
• Workpieces or similar are picked up and clamped.
• The information in the technical data is not observed when
using and operating the product }3 [/12].
• The clamping screw is actuated with a mechanical screwdriver.
• The product is used as a lifting tool.
• The minimum clamping depth is not observed.
• The clamping force control is not observed }7.2.3 [/24].
• The product is used in corrosive media.
• The maintenance and storage instructions are not
observed }7 [/22].
2.3 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.
701.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

Basic safety notes
8 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Use only original spare parts or spares authorized by SCHUNK.
2.5 Environmental and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction to the product's life span.
See also }3.2 [/13].
2.6 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the various
activities related to the product:
Qualified personnel Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.

Basic safety notes
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
• Wear heat-resistant protective gloves when handling hot
surfaces.
• Wear protective gloves and safety goggles when handling
hazardous substances.
• Wear close-fitting protective clothing and also wear long hair in
a hairnet when dealing with moving components.
2.8 Notes on safe operation
• The product must not be clamped without a tool above 25°C.
• Never combine multiple product extensions.
• Only use SCHUNK intermediate sleeves and always insert up to
the fixed backstop point. The use of intermediate sleeves can
reduce the transmittable torque.
• Long, projecting or heavy tools may only be clamped if the
speed of rotation is reduced according to the ambient and
operating conditions on site. The level of reduction is the
responsibility of the operator and must ensure safe operation of
the product.
• Maintain and service the product on a regular basis.
• Do not remove the air bleed screw (secured with pin or resin).
• All repair work must be performed by SCHUNK.
• The operational safety and function of the product must not be
impaired by external influences.
• Follow the country-specific applicable safety, accident
prevention, and environmental protection regulations for the
application field of the product.
901.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

Basic safety notes
10 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
2.9 Transport
Handling during transport
Incorrect handling during transport may impair the product's
safety and cause serious injuries and considerable material
damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• Secure the product against falling during transportation and
handling.
• Stand clear of suspended loads.
2.10 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.
2.11 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
In accordance with the Waste Electrical and Electronic Equipment
(WEEE) Directive, the following must be observed during disposal:
• This product may not be disposed of in household waste. It
must be taken to a collection point for material recovery and
recycling.

Basic safety notes
2.12 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety devices.
• Before commissioning the product, take appropriate protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• If the energy supply is connected, do not move any parts by
hand.
• Do not reach into the open mechanism or movement area of
the product during operation.
2.12.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Have all work carried out by appropriately qualified personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention rules.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
• Stand clear of suspended loads and do not step into their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.
2.12.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries
and even death.
• Take appropriate protective measures to secure the danger
zone.
• Never step into the danger zone during operation.
1101.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

Technical data
12 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
3 Technical data
3.1 Product data
General technical data
Maximum permissible tightening torque of the clamping
screw
13 Nm
Permissible cooling agents Compressed air, coolant, oil
Maximum permissible coolant pressure with internal
coolant supply
80 bar
Maximum permissible coolant pressure with external
coolant supply
20 bar
Radio transmission frequency band (ISM band) 2.4 GHz
Transmission power < 6 dB
Acceleration range of measurement ±100 g
Maximum permissible acceleration 10,000 g
Maximum operating time (battery life) with active radio
transmission
8 h
Maximum operating time (battery life) in standby mode 240 h (10 days)
Variant-specific technical data
Material number 1484050 1495389 1495390
Clamping diameter D1 20 mm 20 mm 3/4"
Base body diameter D2 42 mm 42.05 mm 44.5 mm
Machine mounting HSK-A 63 BT30 CAT40
Maximum permissible speed of rotation 30,000 RPM 30,000 RPM 30,000 RPM
Maximum transmittable torque* 330* Nm 330* Nm 310* Nm
Minimum clamping depth 41 mm 41 mm 41 mm
Maximum permissible radial force F on
the toolholder at 50 mm projecting
lengths
1,860 N 1,860 N 1,860 N
Tolerance tool shank h6 h6 h6
Projecting length L1 90 mm 90 mm 101.6 mm
* Tool shank minimum tolerance h6, tool shank oiled. NOTE: The
use of intermediate sleeves can reduce the transmittable torque.
The load limits of the spindle holder must be observed.

Technical data
3.2 Ambient conditions and operating conditions
The specified temperatures always refer to the product.
Operating temperature range +20°C to +50°C
Transport temperature range -10°C to +50°C
Storage temperature range +10°C to +30°C
Cleaning temperature range 0°C to +60°C
Clamping force check temperature range +20°C to +25°C
Maximum temperature, clamping without tool +25°C
3.3 Information on using the length adjustment screw
Maximum length adjustment dimension "X" 10 mm
NOTE: The length-setting screw is not available in all variants of
the product.
3.4 Usable tool shank types
1. Shank type according to DIN 1835-1 form A and DIN 6535 form HA
2. Shank type according to DIN 1835-1 form B and DIN 6535 form
HB (up to Ø 20 mm)
3. Shank type according to DIN 1835-1 form B and DIN 6535 form
HB (from Ø 25 mm)
4. Shank type according to DIN 1835-1 form E and DIN 6535 form HE
NOTE: Tool shanks with reliefs (forms 2, 3 and 4) can impair the
balancing grade and concentricity of the overall system.
1301.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

Design and description
14 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
4 Design and description
4.1 Design
1 Machine mounting
2 Clamping screw
3 iTENDO² toolholder
4 Charging contact
5 Projecting length L1
6 Clamping diameter D1
7 Base body diameter D2
8 Minimum clamping depth
9 Air bleed screw

Design and description
4.2 Functional description
This product clamps hydraulically by means of manual actuation.
The piston with stroke limitation is actuated via a clamping screw.
To achieve the full clamping force, the clamping screw must be
screwed in until it reaches the stop. The stroke limitation protects
the product against over-expansion.
The volume of oil that is squeezed out of the piston chamber is
pressed in measured amounts against the thin-walled expansion
sleeve. The resulting internal pressure presses radially against the
thin-walled expansion sleeve, causing the clamping range to
expand evenly along the entire active clamping length, uniformly
central to the middle axis. The tool is clamped.
Screwing back the clamping screw causes a reduction of the
pressure in the piston chamber and the expansion chamber. The
thin-walled expansion sleeve then returns radially to its exact
home position. The tool can be removed.
The electronics built into the product allows the detection of
vibrations during machining.
Using a compatible tablet and the iTENDO² app, the detected
vibrations can be displayed and recorded. The data is transmitted
via a wireless connection between the product and the tablet.
1501.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

Assembly
16 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
5 Assembly
5.1 Basic information
WARNING
Risk of injury due to incorrect assembly.
If assembled incorrectly, the product may be thrown out during
rotation, causing severe injuries.
•Regularly check the fastening of the product.
•Take appropriate protective measures to secure the danger
zone.
•Wear suitable protective equipment.
WARNING
Risk of injury if the product falls during transport, assembly or
disassembly.
Due to the oily surface required to preserve it, the product can
slip through your hands, resulting in injury.
•Take appropriate safety measures to prevent the product
from falling.
•Only install the product on machines with the appropriate
connection dimensions.
•Wear suitable protective equipment, especially protective
gloves.
WARNING
Risk of injury due to sharp edges and rough or slippery surfaces.
•Wear suitable protective equipment, especially protective
gloves.
CAUTION
Risk of crushing, impact and cutting when assembling and
disassembling the product.
•Do not reach between the product and machine.
•Wear suitable protective equipment, especially protective
gloves.
NOTICE
Risk of damage to the product.
•When transporting and handling the product, ensure that it is
not damaged by knocks, impacts, etc.

Assembly
5.2 Assembling the product
To ensure optimal machining results, the product must be
precisely positioned and secured on the machine interface.
NOTE: Only install the product on machines with the appropriate
connection dimensions. Observe the mounting instructions from
the manufacturer of the machine interface.
IMPORTANT!Before the product is assembled, the tool must be
fitted and clamped!
1. Charge the battery of the iTENDO². NOTE: Please refer to the
chapters "iTENDO² Power Plug" and "iTENDO² Charger" in the
corresponding operating manual of the iTENDO² complete
system.
2. Ensure that the tool is clamped }6.2 [/20].
3. Clean all interfaces on the product and machine.
4. Place the product on the machine interface in the correct
position and fit it as far as the stop.
5. Clamp the product according to the specifications of the
manufacturer of the machine interface.
1701.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

Operation
18 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
6 Operation
6.1 Basic information
WARNING
Risk of injury from clothing or hair being pulled into the
machine if caught on the product.
Loose clothing or long hair can get caught on the product and
drawn into the machine, resulting in serious injuries or even
death!
•Only wear tight-fitting clothing and a hairnet when working on
the machine and the product.
•Observe the applicable accident prevention regulations.
•Wear suitable protective equipment.
•Take suitable protective measures to secure the danger zone.
WARNING
Risk of injury and property damage due to the expansion sleeve
cracking.
If the expansion sleeve cracks, oil may be emitted at high
pressure and chips or broken pieces may be ejected, causing
severe injuries.
•Never heat the product in heat shrink devices; only perform
a tool change using the integrated clamping screw.
•Avoid knocking or banging the expansion sleeve.
•When the product is tensioned, do not exceed the maximum
permissible operating temperature.
•Only operate the product within the optimum operating
temperature range.
•Take suitable protective measures to secure the danger zone.
•Wear suitable protective equipment.
WARNING
Risk of injury due to leakage of highly pressurized oil.
If the air bleed screw is unscrewed when the product is clamped,
highly pressurized oil can escape, causing serious injury.
•Never unscrew the air bleed screw.
•Do not remove the air bleed screw locking device (pin or
resin).

Operation
WARNING
Risk of injury when the product is rotating, due to the possibility
of parts flying off.
•Comply with technical data.
•Ensure correct installation and seating of existing add-on and
functional components.
•Check clamping force regularly.
•Take appropriate protective measures to secure danger zones.
•Wear suitable protective equipment.
WARNING
Risk of injury due to the tool being flung out if the RPM is too
high or not suitable.
•Observe the technical data.
•Do not exceed the maximum RPM.
•Reduce the speed of rotation appropriately for strongly
protruding or balance-asymmetrical tools.
•Take suitable protective measures to secure the danger zones.
•Wear suitable protective equipment.
CAUTION
Risk of crushing, impact, and cutting when changing tools.
•Do not reach between the product and the tool when
changing tools.
•Wear suitable protective equipment, especially protective
gloves.
NOTICE
Risk of damage to the product.
If the product is not used as intended, the product may get
damaged.
•Only operate the clamping screw by hand.
•Observe the minimum clamping depth of the tool.
•The tool must be free of burrs and dirt on the shank.
•Do not adjust the tool length when the tool is clamped.
1901.00 | iTENDO² | Assembly and Operating Manual | en | 1522399

Operation
20 01.00 | iTENDO² | Assembly and Operating Manual | en | 1522399
6.2 Clamping tool
The product must be unclamped when loading the tool. Initial
tension inhibits loading and can damage the expansion sleeve.
IMPORTANT!The tools to be clamped must be deburred at the
surfaces that come into contact with the product, may not have
sharp contours and must be free of oil, grease and dirt.
When clamping the tool, the following points must be taken into
account:
• The clamping screw may only be actuated by hand.
• Do not combine multiple extensions (e.g. TENDO SVL).
• The product may not be clamped without a tool above 25°C.
• Only clamp approved tool shank types }3.4 [/13].
For clamping, proceed as follows:
1. Observe the technical data }3 [/12] and the marking on the
product.
2. Make sure that the product is in an unclamped state.
3. Clean clamping surfaces.
4. The tool length can be adjusted by screwing the length-setting
screw in or out. Observe the adjustment travel of the length-
setting screw }3.3 [/13]. NOTE:The length-setting screw is
not available in all variants of the product.
5. Insert the tool into the product in the correct position without
exerting too much force. CAUTION! The minimum clamping
depth }3 [/12] must not be undershot!
6. Screw the clamping screw in by hand until it reaches the stop.
Observe the maximum specified tightening torque }3 [/12].
7. Check that the tool is firmly in place.
8. Mount the product }5 [/16].
IMPORTANT!Safe clamping of the tool is only achieved when the
clamping screw is screwed in until it reaches the stop!
