All LED AL-HBNSF150 User manual

!
PLEASE READ
BEFORE USE!
This product supplied with a limited 5 year guarantee, subject to terms and conditions.
The manufacturer will not be deemed liable or held responsible for any damages caused
by faults or manufacturing defects that may be present in any of its products or the misuse
or incorrect installation of this device Your statuatory rights are not affected.
ALL-LED USA LLC
12035 34th St N, Suite 2
St Petersburg
FL 33716 USA
Website: www.all-ledusa.com
Email: [email protected]
Technical Specifications
Product Code AL-HBNSF150/50
Power 150W
Input Current 1.65A
Input Voltage AC100-277V
Frequency 50/60Hz
ENSURE POWER SUPPLY IS OFF WHEN HANDLING ANY ELECTRICAL EQUIPMENT.
INSTALLATION GUIDE
AL-HBNSF150/50
Safety & Warnings
• This High Bay Washdown is within the input voltage range: 100-277VAC, 50/60Hz.
• If input voltage exceeds this range, it may cause tube failure. Please be sure to operate under
correct input voltage.
• Ensure ambient operating temperature of (-) 20
0
C through 50
0
C
• Using this High Bay Washdown in temperature outside of this range will reduce the High Bay
Washdown lifespan.
• Make sure to turn off power before starting the installation process.
Attention
• IP rating: IP65. Can work under wet locations.
• Please keep the High Bay Washdown away from any corrosive substance. When you clean it,
please use damp or dry cloth.
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION
LEAVE A COPY FOR THE USER /MAINTENANCE ENGINEER FOR FUTURE REFERENCE
WARNING RISK OF ELECTRIC SHOCK
• Disconnect power before performing installation or maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label information.
• Make all electrical grounded connections in accordance with the latest edition of the National Election
Code and all applicable local code requirements.
• If the supply wire is damaged. It must be replaced by the manufacturer or its service agent or a similar
qualified person in order to avoid a hazard.
• All wiring connections should be capped with UL approved wire connections
WARNING CAUTION
• Do not dispose of electrical appliance as unsorted municipal waste, use seperate collection facilities.
• If electrical appliances are disposed of in landfill or dumped hazardous substances can be damaging to
health and well-being.
• Contact your local government for information regarding collection system available.
• This device is not intended for use with emergency exit fixtures or emergency exit lights.
• To reduce the risk of electrical shock, do not remove cover and caps, fitting must be grounded.
• No user-serviceable parts inside.
• Do not use when enclose is broken.
• To prevent wiring damage or abrasion does not expose wiring to edges of sheet metal or sharp objects.
WARNING RISK OF BURNS
• Do not exceed maximum wattage on luminaire label.
• Follow all manufacturer’s warnings and recommendations for the driver type, mounting position, methods,
replacements and recycling.
WARNING RISK OF FIRE
• Keep any combustable and other materials that can burn away from the luminaire.
• Incorrect installation may result in electrical shock or a risk of fire.

Product Dimensions
ENSURE POWER SUPPLY IS OFF WHEN HANDLING ANY ELECTRICAL EQUIPMENT.
Dimmable Connection
1. Turn off the Power
2. Make sure the Dimmer used is 1-10V Dimmning Compatible.
3. Connect Black wire to L, white wire to N and green wire to E.
Installation Instructions
1. Cut off the power supply
2. Rotate the bolt clockwise to lock it in place
3. Hang the light using appropriate fittings
Connection Method
1. Turn off the Power
2. Connect DC Wire
3. Connect Black wire to L, white wire to N and green wire to E.
5.26"
7.38"
Ø17.42" The Installation must be carried out by a qualified electrician.
WARRANTY
This product has a warranty of period of 5 years from the date of purchase. The warranty is invalid
in the case of improper use , installation, tampering and removal of the Q.C. date label, installation
in an improper working environment or installation not according to the current edition of the
National Electric Code. Should this product fail during the warranty period it will be replaced free
of charged, subject to correct installation and return of the faulty unit. All-LED USA LLC does not
accept responsibility for any installation costs associated with the replacement of this product.
All-LED USA LLC recerves the right to alter specications without prior notice.
This step can be omitted
if with non-dim driver
