All traffic solutions Shield User manual

Shield Quick Start Guide

Thank you for purchasing an All Traffic Solutions Shield Radar Speed Sign. This Quick

Start Guide will show you how to install, power up, and configure your new sign.

NOTE:If your purchase includes the Integrated Solar

option, please refer to either the ATS3 Trailer with

Integrated Solar Setup Guide or Pole Mounting Signs

with Integrated Solar Option that came with your sign and available on

www.alltrafficsolutions.com/support.

Before you begin

If you have a TraffiCloud subscription, the first thing you'll need to get started using

your Shield is to create a data collection Site in TraffiCloud. Each Site is configured

with a speed limit and the direction of moving traffic. They provide a way to keep

traffic data organized for reporting purposes. If necessary, you can also perform Site

setup after you install your Shield at a physical location. See "Creating a Site"in

Getting Started with TraffiCloud and Shield.

If you don't have a TraffiCloud subscription, you have several other options for Site and sign setup, as described in Step

4:Configuring the Shield locally on the next page.

Step 1:Unpacking the equipment

Upon receiving your new Shield, check to ensure that you have all of the items ordered. If you notice any damage or

missing items, contact ATS Technical Customer Support immediately.

Remove the Shield, batteries, charger, and other optional equipment from the boxes.

If your Shield includes batteries, they should be fully charged before deployment, as explained in Step 2:Charging the

batteries on the next page. Shield signs can accommodate up to two lithium batteries internally. Although only one

battery is required, two batteries are recommended to increase average sign runtime. Without a solar panel,

continuous runtime with two batteries is typically between 7 and 10 days.

For all steps involving batteries, repeat for the second battery as necessary.

To remove the batteries:

A. Place the Shield face down on a flat surface and remove the mounting bracket by unlocking the lock with the

supplied key and lifting up on the bottom of the bracket. Then pull to remove.

B. Next, remove the battery compartment cover by removing the thumb screws. Set the key, bracket, and thumb

screws aside.

C. Slide the battery or batteries out of the battery compartment, as shown in [Figure 1] below.

D. Disconnect the connectors, as shown in [Figure 2] below.

[Figure 1] Slide the battery [Figure 2] Disconnect/connect

Step 2:Charging the batteries Page 2 All Traffic Solutions

Step 2:Charging the batteries

If your Shield includes batteries, it arrives with the batteries partially charged and they need to be fully charged

before deployment.

WARNING:RISK OF ELECTRIC SHOCK ANDDAMAGE TO EQUIPMENT The charger is not intended for

outdoor use. Only charge and store the batteries in a controlled environment.

A. Connect a battery to the charger.

B. Plug the charger cable into a power outlet. The light on the charger displays red while charging and changes to

green when charging is nearly complete. A charge can take up to 7 hours for the 12V 11.5 Ah LFP battery and

11 hours for the 12V 16.5Ah LFP batteries supplied with the sign.

C. When the indicator on the battery charger turns green, repeat for the second battery if applicable, and then

proceed to the next step.

D. Disconnect the battery from the charger.

Step 3:Installing the charged batteries

Follow these steps to install the charged batteries.

CAUTION:Use only the SHORT (3/8"-length) thumb screws to fasten the battery covers. Do NOT use the

longer (3/4"-length) thumb screws supplied for the Your Speed faceplate, as they are too long and can

cause damage to your sign.

A. Place the Shield face down on a flat surface and remove the mounting bracket and battery cover.

B. Connect the battery wiring harness to the connector inside the battery compartment, as shown in [Figure 2] on

the previous page.

C. Tuck the connector into the space in the top of the battery compartment.

D. Holding the connector in place, slide the battery into the compartment.

E. Replace the cover and fasten it down using the SHORT(3/8"-length) thumb screws.

Step 4:Configuring the Shield locally

If you have a TraffiCloud subscription, you should use this step only to power on your Shield, and instead configure

the Shield online, setting the sign display options, creating messages, and setting up alerts. and assigning a Site. It's

best to perform sign setup in advance, so that your traffic data is captured in TraffiCloud immediately. See the

Getting Started with TraffiCloud guide for your sign.

If you don't have a TraffiCloud subscription, you can do any of the following (see details next page)to perform initial

Shield configuration locally, either at your office or after the sign is mounted at the roadside.

Use the Shield mode buttons

»You can configure the Shield using the Speed Limit and Display Mode buttons.

Use the TraffiCloud Mobile app for Android

»You can configure the Shield locally using the TraffiCloud Mobile app for Android over a Bluetooth connection.

Use TraffiCloud Sign Manager

»You can also configure the Shield locally using TraffiCloud Sign Manager for Windows over the included

USBconnection or optional Bluetooth.

NOTE:Before attempting a Bluetooth connection, make sure the option was purchased for your

equipment.

All Traffic Solutions Page 3 Step 4:Configuring the Shield locally

To power up the Shield:

»Power up the Shield by pressing the Power button on the back, inside the mounting channel.

The Shield will go through start-up and self-check sequences. Once the self-check is complete, the sign is

fully operational. A green LED on the top-left corner flashes every 10 seconds to indicate when the sign is

powered on.

To set up the Shield using the onboard buttons:

A. Press the Speed Limit button until the desired value displays. The first button press displays the

current speed limit.

B. Verify or set the display mode on the Shield. The default is Constant for the Shield.

C. To change the mode, press the Display Mode (or Display Settings) button until the desired mode displays

on the sign.

For details about sign modes, see "Shield Display Modes" on the next page.

NOTE:To reduce the risk of tampering, the buttons deactivate five minutes after you power on the sign.

To reactivate them, press the Power button, wait a few seconds, and press it again.

To configure the Shield using the TraffiCloud Mobile app for Android:

If you purchased an Android tablet from us, the TraffiCloud Mobile app has been pre-

installed. If you have your own Android device, you can purchase a TraffiCloud Mobile

perpetual license from ATS and then download the app from the Google Play Store. Using

the app you can control a wide range of tasks, such as downloading traffic data, setting

the speed limit and display mode, creating Sites, and checking battery power.

To connect with the app, do the following:

A. Sign into the TraffiCloud Mobile app on your Android device using your

TraffiCloud credentials.

B. Scan for your Shield. You can connect to any ATS device registered to your account

within Bluetooth range. Only one connection is permitted at a time.

C. Use the Bluetooth pairing code "ATS" to connect to your Shield.

To configure the Shield using TraffiCloud Sign Manager for Windows:

A. First, for TraffiCloud Sign Manager for Windows installation details, please see the TraffiCloud Start-Up

Instructions included with your shipment and available from our Technical Customer Support page at

https://www.alltrafficsolutions.com/support/. For details about using TraffiCloud Sign Manager for Windows,

in the application, click Help > Software User’s Manual.

B. Then, do one of the following:

lPlug the supplied USB-A-to-mini B cable into the back of the sign and then into your computer. The

mini-B port is located above the buttons inside the sign's mounting channel, or

lConnect to the Shield over the optional Bluetooth connection (use pairing code "ATS"). Once the device

is paired, run TraffiCloud Sign Manager and select Bluetooth under the Connection menu.

Step 5:Installing the Your Speed sign attachment Page 4 All Traffic Solutions

Shield Display Modes

Here are the sign modes available with the Shield if you use the Display Mode button on the sign:

Shield

modes Description

cConstant: The Shield continuously displays vehicle speeds as each vehicle passes, changing the speed

display as the vehicle speed changes. Constant is the default (recommended) setting.

cS Constant with strobe: The same as constant, however vehicles exceeding the Speed Limit set in the

sign by 1mph (or1 kph) trigger the Violator Alert strobe (if equipped). TraffiCloud subscribers typically

set the strobe option to 10-15 mph (16 to 24 kph)above the Speed Limit set in the sign.

bBlinking: The Shield blinks slowly, displaying changing speeds as the vehicle passes. TraffiCloud

subscribers typically set the blink option to 10mph (16 kph)above the Speed Limit set in the sign.

bS Blinking with strobe: The Shield blinks constantly, and the Violator Alert strobe (if equipped) flashes

when the sign detects a vehicle exceeding the Speed Limit by 1mph (or1 kph). TraffiCloud subscribers

can set the blinking and strobe options separately, with blinking typically set at 10 mph (16 kph)above

the speed limit, and the strobe at 10-15 mph (16 to 24 kph)above the Speed Limit set in the sign.

dE Demo: The Shield displays a simulation of vehicle approach speeds, from higher to lower, temporarily

ignoring actual traffic readings.

oF Display Off: The Shield collects traffic and status data, but the display is turned off. This mode, also

referred to as "stealth mode", is recommended for performing traffic studies at a Site.

Step 5:Installing the Your Speed sign attachment

To save packing space, the Your Speed sign attachment ships in the transport position.

To set the sign attachment in the deployed position:

A. Remove the 3/4" (19 mm)Torx bolts (wrench included) and washers from the Your Speed

sign attachment and set them aside. If there is no concern about tampering, you can use

the long thumb screws in place of the Torx bolts.

B. Reposition the Your Speed sign attachment above the Shield display.

C. Place a washer over each hole in the sign bracket and push the Torx bolts through the

holes in the Your Speed sign attachment and the brackets and frame, as shown.

D. Reinstall the fasteners to finish installing the Your Speed sign attachment.

All Traffic Solutions Page 5 Step 6: Mounting the Shield

Step 6: Mounting the Shield

Use the instructions in this step for details about mounting the Shield.

To install the Shield mounting bracket:

A. If you are mounting the Shield on a round pole, thread two stainless steel banding straps

(not included)through the sign mounting bracket, and then tighten the bracket and straps

around the pole. Thread the ends of each banding strap together and then tighten them

onto the pole.

B. If you are mounting the Shield on a U-shaped or square pole, bolt the sign mounting bracket

to the pole using the supplied carriage bolts or U bolts and wing nuts.

The wing nuts will be concealed inside the back of the sign to prevent tampering.

To mount the Shield:

Before you mount the Shield, make sure it's turned on. See Step 4:Configuring the Shield locally on

page2.

A. Set the top channel on the back of the Shield onto the tab at the top of the mounting

bracket.

B. Rotate the Shield down until it's flush with the bracket.

C. Push the locking pin up to lock the Shield into place.

Contacting Technical Customer Support

For support for your All Traffic Solutions products,

»visit the Technical Customer Support page at https://www.alltrafficsolutions.com/support/,

»send email to [email protected], or

»call 1-866-366-6602, Option 2 anytime between 8:00 a.m. and 6:00 p.m. Eastern Time, Monday to Friday.

Technical documentation and training

If you have a TraffiCloud subscription, please visit our ATS Start-Up Guides page at

https://www.alltrafficsolutions.com/get-started/ for links to the most recent versions of our technical

documentation, including the Getting Started with TraffiCloud series. If you don't have a subscription, please visit the

Technical Customer Support page.

Please contact Technical Customer Support to discuss your TraffiCloud training options. For online training

resources, please visit our TraffiCloud Training Videos Hub at https://flow.alltrafficsolutions.com/hub-training-

video-trafficloud-0-0-0-0.

Table of contents

Other All Traffic Solutions Digital Signage manuals

All Traffic Solutions

All Traffic Solutions SpeedAlert 24 User manual

All Traffic Solutions

All Traffic Solutions SpeedAlert 24 User manual

All Traffic Solutions

All Traffic Solutions InstAlert 24 User manual

All Traffic Solutions

All Traffic Solutions InstAlert 18 User manual

All Traffic Solutions

All Traffic Solutions SpeedAlert 18 User manual

All Traffic Solutions

All Traffic Solutions SpeedAlert 18 User manual

All Traffic Solutions

All Traffic Solutions ATS 3 User manual

All Traffic Solutions

All Traffic Solutions InstAlert 18 User manual

All Traffic Solutions

All Traffic Solutions SpeedAlert18 User manual

All Traffic Solutions

All Traffic Solutions InstAlert 18 User manual

All Traffic Solutions

All Traffic Solutions Shield User manual

All Traffic Solutions

All Traffic Solutions InstAlert 18 User manual

Popular Digital Signage manuals by other brands

LG M4214TG owner's manual

LG 47VL10 owner's manual

LG 72WS70MS-B user guide

LG 65SM5D owner's manual

LG WP400 Easy setup guide

Dynascan

Dynascan DS861LR4 user manual

LG 55EW5TK-A.AUS owner's manual

KeyWest Technology

KeyWest Technology BREEZE installation guide

XtendLan

XtendLan XL-DSP-183C user guide

Classic Exhibits

Classic Exhibits SEGUE DESIGNS MOD-1363 Assembly

WebDT

WebDT 515A Basic operation guide

Samsung

Samsung IWJ Series user manual

LG 55EJ5D Easy setup guide

LG 75XS4G owner's manual

LG 49UH7J owner's manual

NCR

NCR SelfServ 90 Kit instructions

LG 65SE3KD owner's manual

LG 86TN3F owner's manual
