Allied Telesis AT-6102 User manual

AT-6102
IEEE 802.3af Universal
Multi-voltage PoE Splitter
Installation and User Guide
PN 613-000635 Rev A

AT-6102 Installation and User Guide 2
Electrical Safety and Emissions Standards
Standards: This roduct meets the following standards.
U.S. Federal Communications Commission
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Safety and Electromagnetic Emissions Certifications
EMI/RFI and Immunity: FCC Part 15 Class B; FCC Part 15B, 15C, and 15E Certified; EN
55022/CISPR 22 Class B; ; EN 301 893; EN 300 328; EN 301 489
Transmitter EMC; Canada IC; CE Mark emission/immunity; CE Marked
(compliant with RTT&E, EMC, LVD Directives); C-Tick; GOST
Electrical Safety: UL 60950-1, CSA C22.2 No. 60950-1-03 (CULUS), EN60950-1, EN
60593-IP53; GOST
Co yright © 2006 Allied Telesis, Inc.
All rights reserved. No art of this ublication may be re roduced without rior written ermission from Allied Telesis, Inc.
Microsoft and Internet Ex lorer are registered trademarks of Microsoft Cor oration. Netsca e Navigator is a registered trademark of Netsca e
Communications Cor oration. All other roduct names, com any names, logos or other designations mentioned herein are trademarks or
registered trademarks of their res ective owners.
Allied Telesis, Inc. reserves the right to make changes in s ecifications and other information contained in this document without rior written
notice. The information rovided herein is subject to change without notice. In no event shall Allied Telesis, Inc. be liable for any incidental,
s ecial, indirect, or consequential damages whatsoever, including but not limited to lost rofits, arising out of or related to this manual or the
information contained herein, even if Allied Telesis, Inc. has been advised of, known, or should have known, the ossibility of such damages..

AT-6102 Installation and User Guide 3
Contents
Electrical Safety and Emissions Standards...................................................................................2
Safety and Electromagnetic Emissions Certifications ..............................................................2
Contents ......................................................................................................................................3
Figures...................................................................................................................................3
Preface ........................................................................................................................................4
Purpose of This Guide............................................................................................................4
How This Guide is organized ..................................................................................................4
Document Conventions ..........................................................................................................4
Where to Find Web-based Guides..........................................................................................4
Contacting Allied Telesis ..............................................................................................................5
Online Support .......................................................................................................................5
Email and Telephone Support.................................................................................................5
Returning Products.................................................................................................................5
Sales or Corporate Information ...............................................................................................5
Management Software Updates..............................................................................................5
Tell Us What You Think..........................................................................................................5
Chapter 1.....................................................................................................................................6
Introduction ............................................................................................................................6
Features.................................................................................................................................6
Hardware description..............................................................................................................6
Package Content....................................................................................................................7
Chapter 2.....................................................................................................................................8
Installation..............................................................................................................................8
Specifications .........................................................................................................................8
Figures
Figure 1: AT-6102 typical application..........................................................................................6
Figure 2: The Data In & Data Out/Power Out ports .....................................................................6
Figure 3: Power LED Indicator....................................................................................................7
Figure 4: DIP Switch...................................................................................................................7
Figure 5: Package content..........................................................................................................7

AT-6102 Installation and User Guide 4
Preface
Purpose of This Guide
This guide is intended for network administrators who are responsible for installing and maintaining
the AT-6102 IEEE 802.3af PoE Splitter.
How This Guide is organized
This guide contains the following chapters and appendices:
Chapter 1 Introduction: describes the features, functions, LEDs, and ports on the
equipment.
Chapter 2 Installation: describes how to install the equipment.
Specifications: provides equipment specifications.
Document Conventions
This guide uses several conventions that you should become familiar with before you begin to install
the roduct:


 Note
A note provides additional information. Please go to the Allied Telesis website
www.alliedtelesis.com for the translated safety statement in your language.
Warning
A warning indicates that performing or omitting a specific action may result in bodily injury.
Caution
A caution indicates that performing or omitting a specific action may result in equipment
damage
or loss of data.
Where to Find Web-based Guides
The installation and user guides for all Allied Telesis products are available in portable document
format (PDF) on our web site at http://www.alliedtelesis.com/. You can view the documents
online or download them onto a local workstation or server.

AT-6102 Installation and User Guide 5
Contacting Allied Telesis
This section provides Allied Telesis contact information for technical support as well as sales and
corporate information.
Online Support
You can request technical support online by accessing the Allied Telesis Knowledge Base:
http://www.alliedtelesis.com/kb/. You can use the Knowledge Base to submit questions to our
technical support staff and review answers to previously asked questions.
Email and Telephone Support
For Technical Support via email or telephone, refer to the Support & Services section of the Allied
Telesis web site: http://www.alliedtelesis.com/support/.
Warranty
For product registration and warranty conditions please visit Allied Telesis website:
http://www.alliedtelesis.com/support/warranty/
Returning Products
Products for return or repair must first be assigned a return materials authorization (RMA) number.
A product sent to Allied Telesis without an RMA number will be returned to the sender at the
sender’s expense.
To obtain an RMA number, contact Allied Telesis Technical Support through our web site:
http://www.alliedtelesis.com/support/.
Sales or Corporate Information
You can contact Allied Telesis for sales or corporate information through our web site:
http://www.alliedtelesis.com/. To find the contact information for your country, select Contact Us
-> Worldwide Contacts.
Management Software Updates
New releases of management software for our managed products are available from either of the
following Internet sites:
•Allied Telesis web site: http://www.alliedtelesis.com/support/software/
•Allied Telesis FTP server: ftp://ftp.alliedtelesis.com/
If you prefer to download new software from the Allied Telesis FTP server from your workstation’s
command prompt, you will need FTP client software and you must log in to the server. Enter
“anonymous” for the user name and your email address for the password.
Tell Us What You Think
If you have any comments or suggestions on how we might improve this or other Allied Telesis
documents, please contact us at http://www.alliedtelesis.com.

AT-6102 Installation and User Guide 6
Cha ter 1
Introduction
Thank you for purchasing the AT-6102 IEEE 802.3af PoE Splitter.
The Power over Ethernet Splitter allows a network device that is not POE capable to be remotely
powered through an 802.3af compliant line. The following figure shows how Power over Ethernet
Splitter works.
Non PoE devices
AT-
6102
AT-6101
Figure 1: AT-6102 typical application
Features
•IEEE802.3af compliant
•Short circuit protection
•Delivering power and data to equipment
•5V, 7.5V, 9V & 12V DC User selectable output voltage
•Plug-and-Play
•Light weight and compact size
•Easy table top and wall mounting
•Self-sticking Velcro strips for attaching to powered device
•For Wireless AP, Bluetooth AP, IP Camera, VoIP Telephones and any other remote power
feeding application
•Regulated output voltage
•RoHS and WEEE compliant
•CE, FCC, GOST, C-Tick Approved
•UL Listed
Hardware description
The Power over Ethernet Splitter has three connection ports, one LED indicator, and a Dipswitch
for voltage adjusting.
•Data In port: It is a RJ-45 Ethernet interface port for connection to an 802.3af compliant data
and power source like a POE injector or a POE capable LAN Switch.
•Data Out port: It is a non detachable 315mm long cable terminated with an RJ-45 plug. It
carries the Ethernet signal to the powered device.
Figure 2: The Data In & Data Out/Power Out ports

AT-6102 Installation and User Guide 7
•Power Out port: It supports two types of power cable – Inner dimension 5.5 x 2.0mm, length
360 mm and 5.5 x 2.5 mm, length 360mm. Both cables are included in the POE Splitter
package. The Power Out port is capable of feeding 5V, 7.5V, 9V or 12V DC power to the
device.
•LED indicator: one Power LED indicator for the system unit. It is located on the topside of the
Power over Ethernet Splitter
Figure 3: Power LED Indicator
•Dipswitch: It allows the user to select the output DC voltage among four different values 5V,
7.5V, 9V and 12V. The POE Splitter comes factory set at 5V. Before changing the output
voltage level the POE Splitter must be switched off disconnecting the POE RJ-45 cable from
the Data In port.
Figure 4: DIP Switch
Package Content
Check your router package for the following items. If an item is missing or damaged, contact your
Allied Telesis sales representative for assistance.
1 x PoE Splitter
1 x DC Power Jack 5.5 x 2.0 mm, length 360 mm
1 x DC Power Jack 5.5 x 2.5 mm, length 360 mm
1 pair of self sticking Velcro Strips
This Installation and User Guide
Figure 5: Package content

AT-6102 Installation and User Guide 8
Cha ter 2
Installation
To install the Power over Ethernet Splitter, please follow the following steps in this exact order:
1. Select on the POE Splitter an output Voltage compatible with the device to be powered. Be
aware that Voltage DIP switch is factory set on 5V. When you change voltage by DIP
switching to different voltage, the Power over Ethernet Splitter must be in power off status.
2. Connect the Data In port on the Power over Ethernet Splitter to a PoE capable LAN Switch or
to the Data Out port of a POE Injector.
3. Choose the power cable (Internal Diameter 2.0mm or 2.5mm) and plug it into the Power Out
port on the Power over Ethernet Splitter.
4. Plug in the other end of the PoE Splitter’s power cable to the device to be powered (Access
Point, VoIP Phone, IP Camera …).
5. Connect the Data Out RJ-45 plug of the PoE Splitter to the powered device (Access Point,
VoIP Phone, IP Camera, …)
Specifications
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3af Power over Ethernet
Power jack diameter 2 power cables with straight plug
Plug dimensions: 5.5 x 2.0mm, 5.5 x 2.5mm length 360mm each
Adjust Switch 4 segments switch for output voltage select.
Data In & Power In
Connector
Data and Power in pin usage :
Power : 4 & 5(V+), 7 & 8 (V-) ; 1,&2(V+), 3&6(V-)
Data :1 & 2, 3 & 6
Data Out Connector Data only out: 1 x RJ-45, Data pin 1,2,3,6
Power Out Connector
Power out jack: 5V, 7.5V, 9V, 12V (User Adjustable)
Maximum feeding current: 2.0A@5V
Maximum output power: 10W
Network Cables
10BASE-T: 2 or 4-pair UTP/STP Cat.3, 4,5 cable EIA/TIA-568 100-ohm
(100m)
100BASE-TX: 2 or 4-pair UTP/STP Cat.5 cable EIA/TIA-568 100-ohm
(100m)
LED System: power (green)
Power Input DC 48V
Operating conditions Temperature Range: 0°C~ 40°C
Humidity: 90% (non-condensing)
Storage conditions Temperature Range: 0°C~ 70°C
Humidity: 90% (non-condensing)
Dimension 80mm x 55mm x 26mm (L x W x H) (main device only)
EMI & Safety
certifications CE, FCC, UL, GOST, C-Tick
Other Certifications /
Markings WEEE, RoHS
