AT-MCR12-xx
Power distribution chassis for up to 12
independently-operating, unmanaged,
standalone media, or bridging media
converters
Media Converter Flexibility
Supporting up to 12 Allied Telesis media
converters, the AT-MCR12 enables network
managers to use the MC1x family (10Mbps) or
MC10x family (100Mbps) media converters in
the same chassis.
Power Options
Apreinstalled AT-PWR4 power supply powers
the AT-MCR12, eliminating the need for multiple
power connections. Allied Telesis also offers an
optional hot swappable power supply to
eliminate downtime on the network.The unit
saves space in the wiring closet and minimizes
the number of power connections required.
Single-unit media converters can be removed
from the AT
-MCR12 and deployed individually in
order to accommodate network modifications.
By incorporating a backplane with 12 different
power entry modules integrated with the
printed circuit board, power is equally
distributed among all media converters whether
using one or two power supplies.
Rack-mount Design
Designed with a simple mounting system, each
individual media converter is plugged into the
back plane and secured with the included
mounting rail.
The rack-mount chassis includes two status
LEDs on the front panel indicating power
status.The top LED is titled PWR Aand the
bottom PWR B.The AT-PWR4 power supply in
the back panel has one LED for power. When a
redundant power supply is installed, a second
LED is visible.
The AT-MCR12 is configured with one of the
following power cords to meet regional
requirements for North America, Continental
Europe, or the United Kingdom.
Key Features
•Modular use with all standalone media and
bridging media converters
•Simple installation
•12 slot unit
•Optional redundant hot swappable power
supply ensures reliability
•Free technical support
AT-MCR12
Media Conversion Rack-mount Chassis
Allied T
elesis www.alliedtelesis.com

Technical Specifications
Status Indicators
Front Panel:
Power (2) One for each power supply installed
in back.
Indicates that the rack-mount chassis
has power.
Back Panel:
Quantity* One per power supply.
Power Indicates that the rack-mount chassis
has power.
*One AT-PWR4 power supply comes with the AT-MCR12.
Asecond power supply may be ordered separately.
Power Characteristics
Input voltage (auto-ranging):
Internal power supply
100-120V AC, 50/60Hz, 3.0A
200-240V AC, 50/60Hz, 1.5A
Environmental Specifications
Operating temp. 0°C to 40°C
Storage temp. -20°C to 70°C
Operating temp. 5% to 80% non-condensing
Physical Characteristics
Dimensions 44.4cm x 21.7cm x 13.2cm
(W x D x H) (17.49” x 8.56” x 5.18”)
Weight 9.5 lbs
Electrical/Mechanical Approvals
EMI FCC Class A, IC Class A
Safety UL, CSA, TUV, IEC 825-1, CE compliant
Ordering Information
AT-MCR12-xx
12 slot media converter chassis with AT-PWR4 power
supply.
Where x = 10 for 100-120v with US power cord
20 without a power cord
30 for 200-240v with UK power cord
50 for 200-240v with European power cord
80 for -48vDC power supply
AT-PWR4-xx
Optional redundant 80 watt, 12v internal universal power
supply
AT-PWR9
Optional redundant -48vDC power supply
Related Products
AT-MCR1-xx
1slot media converter chassis
AT-MCR12 |Media Conversion Rack-mount Chassis
