4
Software Configuration
Logging into the system
Please access the system facilities via SSH using any text-mode
SSH client software.
Accessing the system via SSH
The Secure Shell (SSH) is an encrypted networking protocol,
allowing user to configure the device through Ethernet network.
Microsoft does not supply SSH tool, you can use alternative
program such as Tera Term Pro, which is licensed under GPL2.
The device is factory configured with the static IP address
192.168.1.1.
If the device is under a DHCP server, please check the assigned
IP address.
The Command Line Interface (CLI)
When logging into the system via terminal console in SSH or
RS-232, you will be presented with the login prompt. Use
'manager' and password 'friend' for logging into the system
for the first time. Entered password is not visible, and the
backspace key is not valid.
AT-WR4662n login: manager
Password:
After logging into the router you will be presented with the
ATI™ banner and command prompt, in example:
AA TTTTTTTTTTTTTTTTTT ooooo
AAAAA TTTTTTTTTTTTTTT oooooooo
AAAAAAAA TTTTTTTT I oooooo
AAAAAAAAAAA TTTTTTT IIIIIIIIII
AAAAAAA AAAAA TTTT IIIIIIIIII
AAAAAAA AAAAA T IIIIIIIIII
Copyright (C) 2012 Allied Telesis International
All Rights reserved.
AT-WR4662n>
The password entering Privileged Exec Mode is still 'friend';
it can be changed with enable password [NEW
PASSWORD] command in Config Mode. Please perform the
following guide.
AT-WR4662n>enable
Password:
AT-WR4662n#configure terminal
Enter configuration commands, one per line. End
with CNTL/Z.
AT-WR4662n(config)#enable password [NEW
PASSWORD]
AT-WR4662n(config)#
Input your preferred password in [NEW PASSWORD].
Commands available for each protocol are separated into
several modes arranged in a hierarchy. The command prompt
shows the identity name of the router and the current menu
level, in example:
AT-WR4662n>
AT-WR4662n#
AT-WR4662n(config)#
AT-WR4662n(config-if)#
The list of available commands at any menu level can be
obtained by entering the question mark '?',
AT-WR4662n>?
Clear Reset functions
Debug debugging functions
(see also ‘undebug’)
disable Turn off privileged mode command
enable Turn on privileged mode command
exit End current mode and down to previous
mode
help Description of the interactive help
logout Exit from EXEC
no Negate a command or set its defaults
quit Exit current mode and down to previous
mode
show Show command
terminal Set terminal line parameters
AT-WR4662n>
For further and more detailed information and for the full
command set, please refer to the AT-WR4600 Series manual;
it is available online at http://www.alliedtelesis.com/support/.
Quick Installation Guide | Wireless LAN
AT-WR4662n | High-Speed Mobility - Wireless Base Router
Acknowledgments Contacting Allied Telesis
This product includes software developed by the University of
California, Berkeley and its contributors. Copyright ©1982,
1986, 1990, 1991, 1993 The Regents of the University of
California. All rights reserved.
Main direct link is: http://www.alliedtelesis.com/support/ .
Where to Find Web-based Guides
The installation and user guides for all Allied Telesis products
are available on “Documentation” section. You can view the
documents online or download them onto a local workstation
or server.
This product includes software licensed under the GNU
General Public License available on:
http://www.gnu.org/licenses/gpl2.html Online, Email and Telephone Support
Source code for all GPL licensed software in this product can be
obtained from the Allied Telesis GPL Code Download Center
at: http://www.alliedtelesis.com/support/default.aspx
You can request technical support online by accessing the
“Support Center”. Our interactive support center is your link
to answers you need. Search our knowledge base, check
support tickets, learn about RMAs and contact technical
support.
Allied Telesis is committed to meeting the requirements of the
open source licenses including the GNU General Public License
(GPL) and will make all required source code available. Warranty
If you would like a copy of the GPL source code contained in
Allied Telesis products, please send us a request by registered
mail including a check for US$15 to cover production and
shipping costs and a CD with the GPL code will be mailed to
you:
For product registration and warranty conditions please visit
Allied Telesis website:
http://www.alliedtelesis.com/support/warranty/
Returning Products
GPL Code Request Products for return or repair must first be assigned a return
materials authorization (RMA) number. A product sent to
Allied Telesis without an RMA number will be returned to the
sender at the sender’s expense.
Allied Telesis Labs (Ltd)
PO Box 8011
Christchurch.
New Zealand To obtain an RMA number, refer to “Replacement Services”
section.
©2012 Allied Telesis Inc. All rights reserved. Sales or Corporate Information
You can contact Allied Telesis for sales or corporate
information through: http://www.alliedtelesis.com/contact.
This documentation is subject to change without notice. No
part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or any means electronic or
mechanical, including photocopying and recording for any
purpose other than the purchaser’s internal use without the
written permission of Allied Telesis, Inc.
Management Software Updates
New releases of software for our managed products are
available on Allied Telesis web site:
http://www.alliedtelesis.com/support/software/
Allied Telesis, AlliedWare Plus, EPSRing, SwitchBlade, and
VCStack are trademarks or registered trademarks in the United
States and elsewhere of Allied Telesis, Inc. Adobe, Acrobat, and
Reader are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other
countries. Additional brands, names and products mentioned
herein may be trademarks of their respective companies.
Tell Us What You Think
If you have any comments or suggestions on how we might
improve this or other Allied Telesis documents, please contact
us at http://www.alliedtelesis.com .
Safety Notice
Do not open service or change any component.
Only qualified technicians are allowed to service the equipment.
Observe safety precautions to avoid electric shock.
Check voltage before connecting to the power supply.
Connecting to the wrong voltage will damage the equipment.
