2 AT-8600 Series Switch
AT-8600 Installation & Safety Guide
Document Number C613-000083 REV H
© 2006-2011 Allied Telesis Inc. All rights reserved. No part of this publication
may be reproduced without prior written permission from Allied Telesis Inc.
Allied Telesis Inc. reserves the right to change specifications and other
information in this document without prior written notice. The information
provided herein is subject to change without notice. In no event shall Allied
Telesis Inc. be liable for any incidental, special, indirect, or consequential
damages whatsoever, including but not limited to lost profits, arising out of or
related to this manual or the information contained herein, even if Allied Telesis
Inc. has been advised of, known, or should have known, the possibility of such
damages.
All company names, logos, and product designs that are trademarks or
registered trademarks are the property of their respective owners.

Installation & Safety Guide 3
Table of Contents
Models Covered by this Guide ...................................................................................... 4
Package Contents ............................................................................................................. 4
Selecting a Site ................................................................................................................... 5
Installing the Switch ......................................................................................................... 6
Connecting the Switch .................................................................................................. 10
Checking LEDs ................................................................................................................ 13
Obtaining Documentation and Resources ............................................................... 18
Standards .......................................................................................................................... 19
Safety ................................................................................................................................. 20
Sicherheit .......................................................................................................................... 21
Sikkerhed .......................................................................................................................... 23
Veiligheid ........................................................................................................................... 24
Sécurité ............................................................................................................................. 25
Turvallisuus ....................................................................................................................... 26
Norme di Sicurezza ........................................................................................................ 28
Sikkerhet ........................................................................................................................... 29
Segurança .......................................................................................................................... 30
Seguridad .......................................................................................................................... 32
Säkerhet ............................................................................................................................ 33

4 AT-8600 Series Switch
Models Covered by this Guide
This document includes information about the following switches:
■AT-8624T/2M 24-port 10BASE-T/100BASE-TX
■AT-8624PoE 24-port 10BASE-T/100BASE-TX
■AT-8648T/2SP 48-port 10BASE-T/100BASE-TX
You can download updates to this document from www.alliedtelesis.com/
support.
Package Contents
The following items are shipped with each switch. Contact your authorised
distributor or reseller if any are damaged or missing.
■One AC power cord
■One power cord retaining clip
■One serial cable for connecting the switch to a terminal or PC
■One 19-inch rack-mount kit
■One AT-8600 Series Installation & Safety Guide (which includes statutory and
safety information)
■One warranty card
Preinstalled AT-A65 expansion modules
You can order the AT-8624T/2M or AT-8624PoE switches with two AT-A65
expansion modules included. These will already be installed in the expansion
bays of the switch.
For technical specifications for the AT-A65 expansion module, see the AT-A65
Expansion Module Installation and Safety Guide available from
www.alliedtelesis.com/support/software.

Installation & Safety Guide 5
Selecting a Site
Before you install the switch, review the following considerations about its
location.
■The switch requires an ambient temperature range of 0 º C to 40º C
(32º F to 104º F).
■There should be adequate airflow around the switch and its vents.
■The site should be dust-free and without moisture.
■Humidity can be from 5% to 80% non-condensing.
■You need a reliable and earthed (grounded) power supply source, preferably
dedicated and filtered.
■Cabling must not be exposed to sources of electrical noise, such as radio
transmitters, broadband amplifiers, power lines, electric motors, and
fluorescent fixtures.
■Switch ports are suitable for connection to intra-building or non-exposed
cabling is required.
■Related network devices can be connected to the switch but cannot exceed
maximum cable lengths specified in the Hardware Reference.
■You may need to remove cabinet doors to accommodate cords and cables.
■Ensure easy access to the switch’s power and cable connections.

6 AT-8600 Series Switch
Installing the Switch
Ports on the switch are suitable only for connections within buildings (intra-
building) and with cables unexposed to the outside.
Before you begin
■Read the safety information.
For your well-being and that of the equipment, read the safety information in
this document. You can also download this document from the
Documentation and Tools CD-ROM or from www.alliedtelesis.com/support/
software.
■Verify the package contents if you have not already done so.
See “Package Contents” on page 4. If any items are damaged or missing,
contact your authorised distributor or reseller.
■Gather necessary tools and equipment:
• Phillips #2 screwdriver to loosen the blanking plate, if any
• 4 sets of rack-mount screws and nuts, and a suitable screwdriver
To install a DC version of the PSU, you need an appropriate DC power
source, DC supply cable, ring connectors, and a crimp tool.
■Choose a suitable operating location.
You can install the switch either in a 19-inch rack, on a flat bench, or against
a wall. Follow the guidelines in “Selecting a Site” on page 5 to choose a
location.
■To ensure rack-mounted installations are earthed for compatibility with
Network Equipment Building System (NEBS), do the following:
• Remove non-conductive coatings, such as lacquer and enamel, from the
rack rail where hardware will contact it. Also remove coatings from
unplated connectors, braided strap, and bus bars, and bring them to a
bright finish. Then coat them with an antioxidant before connecting
them. During installation, thread-forming screws with star washers may
be used for this purpose
• All bare conductors must be coated with an appropriate antioxidant
compound before making crimp connections.
Warning Both AC and DC versions of this equipment must be earthed through
the power cables provided.

Installation & Safety Guide 7
Procedure
1. If you have any optional expansion modules, install them first.
The AT-8600 Series switches support the AT-A45/xx, AT-A46, AT-A47, and
AT-A65 expansion modules. Install them by following the instructions in the
relevant guide:
•AT-A65 Expansion Module Installation and Safety Guide for the AT-A65
module only.
•AT-A45/xx Series, AT-A46, and AT-A47 Expansion Modules Installation Guide
for the other expansion modules.
These instructions ship with individual expansion modules, and are also
available from www.alliedtelesis.com/support/software.
Note that if you insert or remove a module when the switch is already
powered on, you must restart the switch before you can use the module.
2. Place the switch in its operating location.
If installing the switch in a rack:
• Remove the rubber feet on the bottom of the switch with a flat-head
screwdriver.
• Attach the two rack-mounting brackets to the switch with the screws
provided in the rack-mount kit.
3. Mount the switch in the rack using rack-mount screws
Note that the screws are not provided with the switch.
4. Install any SFPs.
You can install optional SFP (Small Form-factor Pluggable) modules into the
AT-8648T/2SP.
Warning Do not look into the optical ports of SFP cables or transceivers.
Invisible laser radiation may be emitted from disconnected fibres or
connectors.
In both SFP ports, the SFP transceivers must be inserted with the release
lever hinge at the bottom. Use the following figure as a guide.

8 AT-8600 Series Switch
.
Slide the transceiver into the SFP socket, and firmly press it until it engages.
To remove it, first release it by gently pulling the release lever, and then pull
it out of the socket. Never force a transceiver into or out of a socket.
When an SFP is installed into one of the two SFP ports, that SFP port takes
precedence over its corresponding 10/100/1000T port. When the SFP is
removed, the 10/100/1000T port is once again active.
5. Check the supply voltage and the switch’s rated voltage
AT-8600 Series switches are fitted with a universal main power supply that
functions from100–240 VAC and 50–60 Hz.
Specific power supply requirements for the model are on the rear or
underside of the switch. If the supply is outside the acceptable range, the
switch may not operate or may be damaged.
6. Apply AC power to the switch.
Plug the power cord into the AC power connector. This is on the switch’s
rear panel, as shown in the below figures.
Figure 1: AT-8624T/2M front and rear panel with AC power inlet
AT-8600_sfp_shaded
release lever
hinge
1 3 5 7 9 11 13 15 17 19 21 23
2 4 6 8 1012141618202224
LINK
MODE
LINK
MODE
FAULT
RPS
MASTER
PWR
13 57 911
2 4 6 8 10 12
13 15 17 19 21 23
14 16 18 20 22 24
26
COL
100
FULL
ACT
AT-8624T/2M Layer 3 Fast Ethernet Switch
MODE RS-232
TERMINAL PORT
STATUS
25

Installation & Safety Guide 9
Figure 2: AT-8624PoE front and rear panel with AC power inlet
Figure 3: AT-8648T/2SP front and rear panel with AC power inlet
7. Check that the PWR LED on the switch’s front panel is green.
If the PWR (power) LED fails to light, refer to the AT-8600 Series Hardware
Reference for troubleshooting information.
8. Connect the data cables.
Make sure each cable connection is secure. The switch can now process
basic Layer 2 switching functions.
1 3 5 7 9 11131517192123
2 4 6 8 10 12 14 16 18 20 22 24
FAULT
RPS
MASTER
PWR
MODE
1357911
2 4 6 8 10 12
13 15 17 19 21 23
14 16 18 20 22 24
STAT U S
26
RS-232
TERMINAL PORT
COL HALF DUP FULL DUP
ACT100 LINK 10 LINK ACT
PD ON MAX CURRENTPD ERR
AT-8624POE Layer 3 Fast Ethernet Switch
25
SFP
50
STATUS
49
LINK 49R MODE
LINK 50R MODE
LINK
LINK
MODE
COL
SPD
FDX
ACT
FLT
MSTR
RPS
PWR
CLASS 1
LASER PRODUCT
DO NOTSTARE
INTOBEAM AT-8648T/2SP Layer 3 Fast Ethernet Switch

10 AT-8600 Series Switch
Connecting the Switch
Some configuration is necessary to enable the switch’s advanced switching
capabilities. This is achieved via the Command Line Interface (CLI). On the
AT-8624T/2M, you can also use the Graphical User Interface (GUI).
Using the CLI to configure a switch
1. Connect a terminal or PC to the terminal port (ASYN0).
Using the supplied RS-232 DB9 serial straight-through cable, connect your
terminal or PC to the RS-232 port:
• For the AT-8624T/2M and AT-8624PoE, the RS-232 port is on the front
panel.
• For the AT-8648T/2SP, the RS-232 port is on the back panel.
2. Set the communication parameters on your terminal or terminal emulation
program to:
• Bit rate: 9600
• Data bits: 8
•Parity:None
• Stop bits: 1
• Flow control: None
3. Log in.
After the switch has booted, the login prompt appears. If it does not
appear, press the Enter key several times.
When the switch starts for the first time, it automatically creates an
account with manager privileges. The account has the login name manager
and the password is friend.
At the login prompt, enter the login name and password:
Login: manager
Password: friend
The switch’s command prompt appears, and you can now use the CLI to
configure the switch.
4. Change the password.
A manager account left with the default password is a serious security risk.
Remember the new password as there is no way to retrieve it if it is lost.
To change the account password, use the set password command.

Installation & Safety Guide 11
5. Configure online help.
Before using online help, you must configure the help file by using the
command:
set help=<filename>.hlp
Help files have an HLP extension. To see a list of help files loaded on your
switch, use the command:
show files=*.hlp
6. Configure the switch.
Refer to the Software Reference for more information about configuring
the software. Alternatively, if you do not know the command syntax, use
any of the following to help you:
• To display a list of help topics, use the help command.
• To display help on a specific topic, use the help <topic>command.
• To display a list of valid options, type a question mark or press the Tab
key at the end of a partial command.
• To complete a parameter after you have typed enough letters to
uniquely match the desired one, press the Tab key.
7. Save the configuration.
Save your configuration to a new file by using the command:
create config=<filename>.cfg
Then set the switch to load this file when it restarts by using the command:
set config=<filename>.cfg
For information about configuring the software, see the AT-8600 Series Software
Reference.
Using the GUI to configure the AT-8624T/2M switch
This section describes how to establish a connection to the AT-8624T/2M switch
through the GUI so you can configure it before installing it in your LAN.
1. Select a PC to use and identify its subnet.
You can browse to the switch from any PC that is running a supported
operating system with a supported browser installed. JavaScript must be
enabled. If you are using a toolbar or plug-in on your browser to block pop-
ups, disable it while using the GUI. The GUI displays detailed configuration
options and information in pop-up windows.

12 AT-8600 Series Switch
2. Connect the PC to the switch.
Use an Ethernet cable to connect an Ethernet card on the PC to any one of
the switch ports.
You can browse to the router through any VLAN, as long as you give that
VLAN an IP address. These instructions assume you are using vlan1. All
switch ports belong to vlan1 by default.
3. Access the switch’s command line interface.
Access the CLI from the PC, as described in the previous section, “Using
the CLI to configure a switch” on page 10.
4. Enable IP.
enable ip
5. Assign the vlan1 interface an IP address in the same subnet as the PC.
add ip interface=vlan1 ip=ipaddress mask=mask
6. Save the configuration and set the switch to use it on bootup.
create config=your-name.cfg
set config=your-name.cfg
7. On the PC’s web browser, bypass the HTTP proxy server, if necessary.
8. Point your Web browser at IP address for vlan1.
9. At the login prompt, enter the user name and password.
User Name: manager <the default>
Password: friend
The System Status page is displayed. Select options from the sidebar menu
to configure and manage the switch.
For context-sensitive online help, click the Help button at the top of the
sidebar menu or on any pop-up page.

Installation & Safety Guide 13
Checking LEDs
The following tables outline how the switch and expansion modules report faults
and operational activities. Expansion modules are optional and can be purchased
separately.
Use the Mode Select button to toggle the Mode LEDs to the desired state.
Toggling the Mode Selection button does not affect the normal operations of the
switch.
System LEDs
LED State Description
FAULT Off Switch operation is normal.
Red The switch or management software is
malfunctioning.
1 flash A switch fan has failed.
3 flashes The main PSU has failed and the RPS is now
providing power.
4 flashes The RPS Monitor is set to ON, and the RPS
is not functioning, either because it has failed
or has been switched off.
5 flashes The RPS Monitor is set to ON, but the RPS
is not connected.
7 flashes For the AT-8624T/2M and AT-8624PoE
switches: An expansion module has been
inserted or removed while the switch is
powered on.
MASTER Off This LED is not supported.
RPS Green An optional redundant power supply is
connected to the switch.
Off There is no optional redundant power
supply connected to the switch.
PWR Green The switch is receiving power and the
voltage is within the acceptable range.
Off The switch is not receiving power.

14 AT-8600 Series Switch
Link and Mode LEDs for the AT-8624T/2M switch
LED State Description
LINK Off There is no link between the port and the
end-node.
Green A valid link has been established between
the port and the end-node.
Mode - COL Off No data collisions are occurring on the
port.
Flashing Green Data collisions are occurring on the port.
Mode - 100 Off The port is operating at 10 Mbps.
Green The port is operating at 100 Mbps.
Mode - FULL Off The port is operating in half-duplex
mode.
Green The port is operating in full-duplex
mode.
Mode - ACT Off There is no activity on the port.
Flashing Green There is activity on the port. It is
transmitting and/or receiving data.

Installation & Safety Guide 15
Link and Mode LEDs for the AT-8624PoE switch
LED State Description
L/A Status
(Top LED)
Off There is no link between the port
and the end-node.
Green The port is operating at 100 Mbps.
Flashing Green There is activity on the port. It is
transmitting and/or receiving data
at 100 Mbps.
Red The port is operating at 10 Mbps.
Flashing Red There is activity on the port. It is
transmitting and/or receiving data
at 10 Mbps.
Mode LEDs
(Bottom LED)
Off Either DC Mode or PoE Mode.
D/C Mode Off There is no link between the port
and the end-node.
Green The port is operating in full duplex
mode.
Red The port is operating in half-duplex
mode.
Flashing Red The port is operating in half-duplex
mode and data collisions are
occurring on the port.
PoE Mode Off There is no powered device
detected.
Green The end-node is a powered device
and the port is providing power to
it.
Red The port is experiencing a problem
providing PoE to the end-node.
Flashing Red The port is connected to a
powered device but providing
power to it would exceed the
maximum PoE power budget of the
switch.

16 AT-8600 Series Switch
Link and Mode LEDs for the AT-8648T/2SP switch
LED State Description
LINK Off There is no link between the port
and the end-node.
Green A valid link has been established
between the port and the end-
node.
Mode - COL Off No data collisions are occurring on
the port.
Flashing Green Data collisions are occurring on
the port.
Mode - SPD Off The port is operating at 10 Mbps.
Green The port is operating at 100 Mbps.
Mode - FDX Off The port is operating in half-duplex
mode.
Green The port is operating in full-duplex
mode.
Mode - ACT Off There is no activity on the port
Flashing Green There is activity on the port.

Installation & Safety Guide 17
SFP and 10/100/1000Base-T LEDs for the AT-8648T/2SP switch
LED State Description
LINK Off There is no link between the port
and the end-node.
Green A valid link has been established
between the port and the end-
node.
Mode - COL Off No data collisions are occurring on
the port.
Flashing Green Data collisions are occurring on
the port.
Mode - SPD Off The port is operating at 10/100
Mbps.
Green The port is operating at 1000
Mbps.
Mode - FDX Off The port is operating in half-duplex
mode.
Green The port is operating in full-duplex
mode.
Mode - ACT Off There is no activity on the port
Flashing Green There is activity on the port.

18 AT-8600 Series Switch
Obtaining Documentation and Resources
The complete document set for the AT-8600 Series switches includes:
■This Installation & Safety Guide, which also provides safety and statutory
information for the AT-8600 Series switch and its expansion options.
■The AT-8600 Series Hardware Reference, which provides detailed information
on the switch unit and its hardware features.
■The AT-8600 Series Software Reference, which provides detailed information
on configuring the switch unit and its software.
■The AT-A65 Expansion Module Installation and Safety Guide which outlines the
procedure for installing the AT-A65 expansion module and provides
technical specifications for the module.
■The AT-A45/xx Series, AT-A46, and AT-A47 Expansion Modules Installation Guide,
which outlines the procedure for installing these expansion modules, and
provides technical specifications for the modules.
You can download these documents and updates from
www.alliedtelesis.com/support/software.
You need Adobe®Acrobat®Reader®software to view, search, or print these
documents. You can download it from www.adobe.com.
Other resources
How-To Notes describe a range of standard Allied Telesis solutions, and include
technical tips and guides to configuring specific hardware and software features.
You can download the latest How-To Notes from
www.alliedtelesis.com/resources/literature/howto.aspx.
MIBs supported by Allied Telesis products can be downloaded from
www.alliedtelesis.com/support/software.
Microsoft®Visio®stencils for Allied Telesis products can be downloaded from
www.alliedtelesis.com/resources/images/visio.aspx.
AT-TFTP Server for Windows is a TFTP (Trivial File Transfer Protocol) server for
transferring software versions, configuration scripts and other files between a
PC and the switch. You download AT-TFTP Server from
www.alliedtelesis.com/support/software.
Contacting us
With locations covering all of the established markets in North America, Latin
America, Europe, Asia, and the Pacific, Allied Telesis provides localized sales and
technical support worldwide. To find the representative nearest you, visit us on
the Web at www.alliedtelesis.com.

Installation & Safety Guide 19
Standards
Where applicable, the products in this document meet the following standards:
Category Approval Agency and Requirement
UL60950-1
CAN/CSA-C22.2 No. 60950-1-03
EN60950-1
EN60825-1
Electromagnetic Compliance FCC CFR47 Part 15 Class A
EN55022 Class A
EN61000-3-2
EN61000-3-3
VCCI Class A
AS/NZS CISPR22 Class A
Immunity EN55024
U.S. Federal Communications Commission
RADIATED ENERGY
Note: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with this instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Canadian Department of Communications
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
