AT-9800 Series Switch
Hardware Reference
AT-9812T V2
AT-9816GB V2
AT-RPS9000
AT-PWR9000

AT-9800 Series Switch Hardware Reference
Document Number C613-03059-00 REV F.
© 2003-2007 Allied Telesis, Inc. All rights reserved. No part of this publication may be
reproduced without prior written permission from Allied Telesis, Inc.
Allied Telesis, Inc. reserves the right to change specifications and other information in
this document without prior written notice. The information provided herein is subject
to change without notice. In no event shall Allied Telesis, Inc. be liable for any
incidental, special, indirect, or consequential damages whatsoever, including but not
limited to lost profits, arising out of or related to this manual or the information
contained herein, even if Allied Telesis, Inc. has been advised of, known, or should have
known, the possibility of such damages.
All company names, logos, and product designs that are trademarks or registered
trademarks are the property of their respective owners.

Hardware Reference 3
C613-03059-00 REV F
Contents
Models Covered By This Reference .................................................................... 4
Hardware Overview .......................................................................................... 4
Switch Overview ......................................................................................... 4
AT-9800 Series Switch Models .................................................................... 5
Switch LEDs ...................................................................................................... 7
RS-232 Terminal Port (ASYN0) ........................................................................... 9
Gigabit Interface Converters (GBICs) ............................................................... 10
Memory Options ............................................................................................. 11
CompactFlash Card .................................................................................. 11
Content Addressable Memory (CAM) ....................................................... 13
Dual In-line Memory Modules (DIMMs) ..................................................... 13
Cables ............................................................................................................ 14
RS-232 Terminal and Modem Cables ........................................................ 14
Cables for RJ-45 Ethernet LAN Interfaces .................................................. 15
Cable Guidelines ...................................................................................... 16
Redundant Power Supply (RPS) ....................................................................... 17
AT-RPS9000 Specifications ....................................................................... 18
AT-TFTP Server ................................................................................................ 19
Using Windows Terminal and Windows Hyperterminal .................................... 20
Switch Startup ................................................................................................ 23
To log In ................................................................................................... 23
To access help .......................................................................................... 24
Startup Procedure .................................................................................... 24
Test Facility ..................................................................................................... 26
Testing Ethernet LAN Ports ....................................................................... 27
Troubleshooting .............................................................................................. 29
Check these first ...................................................................................... 29
Common problems and how to solve them .............................................. 29
Restricted Procedures ...................................................................................... 31
Installing CAM ......................................................................................... 31
Testing CAM ............................................................................................ 33
Installing DIMM ........................................................................................ 34
Testing DIMM ........................................................................................... 35
Diagnostics ..................................................................................................... 37
For More Information ...................................................................................... 38

4AT-9800 Series Switch
C613-03059-00 REV F
Models Covered By This Reference
This Hardware Reference includes information on the following products:
■AT-9812T V2
■AT-9816GB V2
■AT-RPS9000 and AT-PWR9000
Hardware Overview
This section provides details about the physical characteristics of AT-9800
Series switches.
Switch Overview
Developed to meet the exceptionally high performance demands of high end
applications, AT-9800 Series switches deliver hardware-based low-latency
high-bandwidth wire speed Layer 2 and 3 switching, in a robust 1.5U platform.
With GBIC and 10/100/1000BASE RJ-45 port options bridging traditional
copper/fibre divides, and hardware expansion options such as CompactFlash,
CAM and DIMM, the AT-9800 Series is a versatile and powerful switching
solution for rapidly evolving networks.
Dimensions ■Height: 66mm, plus 5.5 mm if the rubber feet are used
■Width: 440mm, excluding rack-mounting brackets
■Depth: 360mm
■Weight: Not more than 6.6 kg, depending on model and excluding power
cord
Mounting System ■1.5U rack mounting
Environmental
Conditions
■Operating temperature range: 0 to 40º C (32 to 104º F)
■Storage temperature range: -25 to 70º C (-13 to 158º F)
■Relative humidity range: 5 to 95% non-condensing
LEDs ■Port and System status LEDs
■For a complete list of LEDs and their functions, see “Switch LEDs” on
page 7.
Power Supply Unit AC models
■Universal 100–240 VAC, 50–60 Hz input
■Redundant DC Power connection
DC models
■48 VDC (40–60 VDC is acceptable)
■Accepts positive or negative earthing (grounding)

Hardware Reference 5
C613-03059-00 REV F
Maximum Current
Loads
AC models
■Maximum continuous current draw: 2.2A at 220V, 4.3A at 110V
■Maximum inrush current (cold start at 25º C/77º F): 60A at 220V, 30A at
110V
DC models
■Maximum continuous current draw: 4.0A at -40V
Switching Core ■Application-Specific Integrated Circuit (ASIC) switch chip
■Non-blocking L2 and L3 IP Switching
■40 k-entry forwarding address database (expandable to 232 k-entries with
LineCAM)
■64MByte RAMBUS packet buffer
Processing Core ■300MHz RISC Processor
■128MBytes Synchronous DRAM, expandable to 256MByte with DIMM
■16MBytes of fixed flash
■CompactFlash slot for hot swappable expansion of flash up to 512MBytes
■512kBytes of Non-volatile SRAM (NVRAM)
■Battery backed real time clock (RTC)
■32/66MHz PCI bus
■Silicon ID chip storing serial number, board ID, and MAC address
Asynchronous Serial
Port
■Up to 115kbps
■Universal Asynchronous Receiver Transmitter (UART)
■Standard DB9 female RS-232 connector
■Hardware-flow control
AT-9800 Series Switch Models
This section provides hardware descriptions for individual switch models.
AT-9812T V2 Key features are:
■12 10BASE-T/100BASE-TX/1000BASE-T ports (RJ-45 connectors)
■4 1000BASE-X ports (GBIC slots)
■Unrestricted 1000BASE-T GBIC use
■CompactFlash slot
■DIMM socket for expansion of Synchronous DRAM
■CAM socket for expansion of the forwarding address database
■Compatible with AT-PWR9000 RPS systems (AC models only)
■Auto-negotiating Layer 3 Managed Switch
■AC or DC PSU options

6AT-9800 Series Switch
C613-03059-00 REV F
AT-9812T front panel
AT-9816GB V2 Key features are:
■16 1000BASE-X ports (GBIC slots)
■Unrestricted 1000BASE-T GBIC use
■CompactFlash slot
■DIMM socket for expansion of synchronous DRAM
■CAM socket for expansion of the forwarding address database
■Compatible with AT-PWR9000 RPS systems (AC models only)
■Layer 3 managed switch
■AC or DC PSU options
AT-9816GB front and rear panels
STATUS
RESET
FAULT
PWR
RPS
13
15
14
16
1
7
2
8
3
9
4
10
5
11
6
12
13 14
15 16 1 2 3 4 5 6 7 8 9 10 11 12
RS-232
TERMINAL PORT
L/A
D/C
L/A
D/C
L/A
GBIC
L/A
GBIC
ASYN0
1000BASE-X GBIC
10BASE-T / 100BASE-TX / 1000BASE-T
ACT
1000M
L/A
ACT
10/100M
COL
FULL DUP
HALF DUP
D/C
FAULT
ACTLINK / FULL DUP
L/A
ACT
LINK / HALF DUP
DISABLED
ENABLED
GBIC
GBIC BASE-T
AT-9812T V2 Multi-Layer Gigabit Switch
PORT ACTIVITY
CLASS 1
LASER
AC INPUT
100-240V HZ 50/60 AMPS 5.0/2.5
RPS INPUT VDC A Max
16
16
0.5
+3.3
+5
+12
COMPACT FLASH
ACTIVITY
AC Power AT-RPS9000 RPS Connector Compact FLASH
STATUS
RESET
FAULT
PWR
RPS
1
9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
12345678
910111213141516
RS-232
TERMINAL PORT
L/A
GBIC
L/A
GBIC
ASYN0
1000BASE-X GBIC
PORT ACTIVITY
L/A
LINK / FULL DUP ACTIVITY
LINK / HALF DUP ACTIVITY
L/A
L/A
ENABLED DISABLED FAULT
GBIC
L/A
L/A
GBIC
AT-9816GB V2 Layer 3 Fast Ethernet Switch

Hardware Reference 7
C613-03059-00 REV F
Switch LEDs
The following LEDs report operations and faults on AT-9800 switches:
■System LEDs
■AT-9812T port and GBIC LEDs
■AT-9816GB GBIC LEDs
System LEDs
AT-9812T
port and GBIC LEDs
LED State Function
PWR (Power) Green The switch is receiving power
Fault Red The switch or management software is
malfunctioning
1 Flash A switch fan has failed or is operating below the
recommended speed
2 Flashes If RPS monitoring is enabled, an RPS fan has
failed or is operating below the recommended
speed
3 Flashes If an RPS is connected, the switch’s PSU (Power
Supply Unit) has failed
4 Flashes If RPS monitoring is enabled, the RPS PSU has
failed
5 Flashes If RPS monitoring is enabled, an RPS is not
connected or is not operational
6 Flashes The temperature sensor located immediately
adjacent to the switch chip has exceeded the
recommended threshold of 60 degrees Celsius
RPS (Redundant Power
Supply)
Green An RPS is connected to the switch and is receiving
power
CompactFlash Activity
(Rear panel)
Green The CompactFlash memory is active. Do not eject
the flash memory module.
LED State Function
GBIC L/A
(Link activity)
Green A 1000Mbps link is open. The link is operating in
full duplex mode.
Flashing green 1000Mbps full duplex activity is occurring
Amber A 1000Mbps link is open. The link is operating in
half duplex mode.
Flashing amber 1000 Mbps half duplex activity is occurring
GBIC Green A GBIC is installed and enabled
Amber A GBIC is installed but has not been recognised
Flashing amber A GBIC is installed and enabled, but a Tx fault is
occurring
BASE-T L/A
(Link activity)
Green A 1000 Mbps link is open
Flashing green 1000 Mbps activity is occurring
Amber A 10/100 Mbps link is open
Flashing amber 10/100 Mbps activity is occurring

8AT-9800 Series Switch
C613-03059-00 REV F
AT-9816GB
GBIC LEDs
BASE-T D/C
(Duplex/collision)
Green The port is operating in full duplex mode
Amber The port is operating in half duplex mode
Flashing amber Collisions are occurring
LED State Function
LED State Function
GBIC L/A
(Link activity)
Green A 1000 Mbps link is open. The link is operating
in full duplex mode.
Flashing green 1000 Mbps full duplex activity is occurring
Amber A 1000 Mbps link is open. The link is operating
in half duplex mode.
Flashing amber 1000 Mbps half duplex activity is occurring
GBIC Green A GBIC is installed and enabled
Amber A GBIC is installed but has not been recognised
Flashing amber A GBIC is installed and enabled, but a Tx fault is
occurring

Hardware Reference 9
C613-03059-00 REV F
RS-232 Terminal Port (ASYN0)
The RS-232 ASYN0 terminal port is used to connect the switch to a
management device for initial configuration and switch management tasks.
This allows the switch software to be accessed from a terminal, a PC running
terminal emulation software, or from a remote location via a modem
connection. You can also use ASYN0 to establish a network connection from a
remote site using SLIP and a modem.
ASYN0 has a DCE female socket. This allows the use of a straight-through
cable when connecting the switch to a terminal or PC. Output from the show
asyn command will, however, still have a DTE perspective. The DTE pin layout
is shown in the following figure and table.
Pin Role
2TXD
3RXD
4CD
5GND
6DTR
7CTS
8RTS
9(Notused)
Pin 9 Pin 6
Pin 5 Pin 1
DB9 Female Pin View

10 AT-9800 Series Switch
C613-03059-00 REV F
Gigabit Interface Converters (GBICs)
GBICs are removable gigabit port converters for switches that have GBIC bays.
GBICs allow users to interchange port types to meet changing network
requirements. GBICs can be purchased when a switch is purchased, or can be
purchased separately as needed.
The following GBICs have been tested and approved for use with AT-9800
Series switches:
■Allied Telesis AT-G8T, 1000BASE-T, 100m
■Allied Telesis AT-G8SX, 550m SX
■Allied Telesis AT-G8LX10, 10km LX
■Allied Telesis AT-G8LX25, 25km LX
■Allied Telesis AT-G8LX40, 40km LX
■Allied Telesis AT-G8LX70, 70km LX
For the latest list of approved GBICs, contact your authorised Allied Telesis
distributor or reseller, or visit www.alliedtelesis.com/support/software.
For information on installing GBICs, see the AT-9800 Series Switch Quick
Install Guide.
Any combination of copper and fibre GBICs can be installed in the AT-9812T
and AT-9816GB switches.
Important RX and TX terminal locations on SC fibre GBIC ports are the reverse
of RX and TX terminal locations on fixed SC fibre ports. When looking at an SC
fibre GBIC from the front, the RX terminal is on the left and the TX terminal is
on the right.
GBIC 1000BASE-T Auto-Negotiation
1000BASE-T GBICs support only 1000 Mbps full duplex connections. Although
1000BASE-T GBICs will participate in auto-negotiation processes, they will
only advertise 1000 Mbps. Half duplex, 10BASE-T, and 100BASE-TX modes are
not supported.
While 1000BASE-T GBICs will auto-negotiate at the copper Ethernet level, the
ports will behave as if in fixed 1000 Mbps full duplex mode. This is because the
SERDES connection used by GBIC ports makes the auto-negotiation invisible
to the switch, and so prevents a successful link negotiation.
When a 1000BASE-T GBIC is inserted into a GBIC slot, the port’s auto-
negotiation capability is disabled. This means that the port speed may not be
set to "auto-negotiate". If the port has been configured to auto-negotiate (by
default or by command) prior to the GBIC’s insertion, then this configuration is
overridden for as long as the GBIC remains in place.

Hardware Reference 11
C613-03059-00 REV F
Memory Options
The following memory expansion options are available:
■CompactFlash Card
■Content Addressable Memory (CAM)
■Dual In-line Memory Modules (DIMMs)
CompactFlash Card
AT-9800 Series switches have a CompactFlash slot on their rear panel.
CompactFlash cards increase the flash memory available for file storage.
CompactFlash files can be manipulated using the command line interface. Any
type of data, including releases, patches, GUIs and configurations can be stored
on CompactFlash cards. However, release, patch, and GUI files cannot be run
directly from CompactFlash. These files must be loaded into either NVS or
on-board flash. CompactFlash functionality is supported by Software Version
2.5.1 and later.
Important Anyone with a compliant reader can read CompactFlash cards so
do not keep sensitive data on them.
The following CompactFlash cards have been approved for use with AT-9800
Series switches:
■AT-CF032A-00 32MB CompactFlash card
■AT-CF128A-00 128MB CompactFlash card
For the latest list of approved CompactFlash cards, contact your authorised
Allied Telesis distributor or reseller, or visit www.alliedtelesis.com/support/
software.
Important AT-9800 Series switches support only CompactFlash cards with a
maximum hardware access time of 100 nanoseconds.
Installing and removing a CompactFlash card
CompactFlash cards can be inserted into the CompactFlash slot at any time. It
takes approximately two seconds for an inserted card to be initialised. The
following CLI message confirms that the card has been inserted:
Info (1106257): Compact flash card inserted.
The following message confirms that the card is ready to use:
Info (1106268): Compact flash card initialisation successful.
The following message means that the CompactFlash card is not compatible
with the switch:
Info (3106300): Compact flash card initialisation
unsuccessful.
Important When data is being written to or read from the card, the
CompactFlash Activity LED on the rear panel of the switch is green. Do not
remove the card when it is active or you will corrupt the data. Wait until the LED
is off before ejecting the card.

12 AT-9800 Series Switch
C613-03059-00 REV F
Testing a CompactFlash card
To display information about the basic state of a CompactFlash card, including
card size, file count and serial number, insert the card and enter the command:
show cflash
To display cluster ranges on a card, insert the card and enter the command:
show cflash test
The following figure is an example of output from the show cflash test
command when no test is running.
To test a card, insert the card and enter the command:
enable cflash test start=startnumber end=endnumber
where startnumber and endnumber are positive integers within a cluster range.
The endnumber must be higher than the startnumber. Cluster ranges are
displayed in the output of the show cflash test command.
The test software will read the file allocation table and display a list of free
sectors. Sectors can be tested as single sectors or as a range. The test will consist
of a write/read/verify cycle.
To stop the test, use the command:
disable cflash test
To display the test status while a test is in progress, use the command:
show cflash test
The following is example output from the show cflash test command when a
test is running.
Error messages are displayed when a file write fails. Failure could be due to the
card being removed or an error in the card.
Clusters available for testing
Ranges:
[42645--61944]
Number of free clusters = 19300
Number of ranges = 1
Number of used clusters = 42645
Test Progress
Starting cluster = 700
Ending cluster = 1700
Current cluster = 1185
Passed clusters number = 485
Passed sectors number = 1940
Failed clusters number = 0
Failed sectors number = 0
Used Clusters encountered = 0
Duration................ 4417 ms

Hardware Reference 13
C613-03059-00 REV F
Content Addressable Memory (CAM)
AT-9800 Series switches ship with 40 k-entries of CAM, as standard. This
memory is divided into three fixed allocations:
■8 k for MAC address tables
■4 k for VLAN entries
■28 k for all other L2/L3 tables , such as IP route entries
CAM can be expanded through the purchase and installation of lineCAM.
LineCAM is a 192 k-entry plug-in module that extends the Layer 2/Layer 3
forwarding database from 40 k to 232 k. One lineCAM module can be installed
in each AT-9800 series switch.
When lineCAM is installed, the memory allocations are:
■8 k for MAC address tables
■4 k for VLAN entries
■220 k for all other L2/L3 tables
LineCAM can be ordered as a pre-installed item when purchasing a switch, or
can be purchased separately. For more information, contact your authorised
Allied Telesis distributor or reseller.
To check how much CAM is installed, use the command:
show switch
For information on installing CAM, see “Restricted Procedures” on page 31.
Dual In-line Memory Modules (DIMMs)
Synchronous DRAM for AT-9800 Series switches is provided by a single
DIMM. Two memory sizes are supported, 128 MBytes and 256 MBytes.
Warning Only Allied Telesis supplied DIMMs are tested and approved for use
with AT-9800 Series switches. Using DIMM that has not been tested and
approved may cause unreliable operation and will invalidate the switch’s
warranty.
To check how much DIMM is installed, use the command:
show switch
For information on installing DIMMs, see “Restricted Procedures” on page 31.

14 AT-9800 Series Switch
C613-03059-00 REV F
Cables
This section describes how to construct management, test, and network cables
for use with the switch’s RS-232 (ASYN0) and RJ-45 interfaces.
RS-232 Terminal and Modem Cables
The terminal and modem cables described in this section are:
■RS-232 DB9 male to female terminal cable
■RS-232 DB9 male to male modem cable
Figures in this section show pin wiring diagrams to connect a standard VT100
compatible terminal or modem to ASYN0.
RS-232 DB9 male to
female terminal
cable
Notes:
(1) →Output from switch; ←Input to switch.
(2) Cable version 1.0.
DB9MDB9Fsw
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Cable
Pin 9 Pin 6
Pin 5 Pin 1
DB9 Female Pin View
Pin 6 Pin 9
Pin 1 Pin 5
DB9 Male Pin View
DB9 Male
(to switch/DCE)
DB9 Female
(to PC/terminal/DTE)
Not connected
→ (TXD)
← (RXD)
← (CD)
(GND)
→ (DTR)
← (CTS)
→ (RTS)
← (RING)
(DCD)
(RXD)
(TXD)
(DTR)
(GND)
(DSR)
(RTS)
(CTS)
(RING)

Hardware Reference 15
C613-03059-00 REV F
RS-232 DB9 male to
male modem cable
For more information on pin assignments for the RS-232 port, see “RS-232
Terminal Port (ASYN0)” on page 9.
Cables for RJ-45 Ethernet LAN Interfaces
A twisted pair cable with four pairs and RJ-45 connectors must be used for
10BASE-T/100BASE-TX/1000BASE-T (10/100/1000BASE) connections.
Caution Do not plug a phone jack into an RJ-45 switch port because you could
damage the switch. Use only twisted pair cables with RJ-45 connectors.
Pin assignments Each pair of twisted pair cables is identified by related colours. For example,
one wire might be red, and the related wire would be red-and-white stripe. An
RJ-45 connector must be fitted to both ends of the cable. The following diagram
shows RJ-45 connectors and the pin layout.
Notes:
(1) →Output from switch; ←Input to switch
(2) Cable version 1.0.
DB9MDB9Fsw
3 (TXD)
2 (RXD)
1 (DCD)
5 (GND)
4 (DTR)
8 (CTS)
7 (RTS)
9
6 Not connected
1
2
3
4
5
6
7
8
9
Cable
Pin 9 Pin 6
Pin 5 Pin 1
DB9 Male Pin View
Pin 6 Pin 9
Pin 1 Pin 5
DB9 Male Pin View
DB9 Male
(to switch/DCE)
DB9 Male
(to modem/DCE)
Not connected
→ (TXD)
← (RXD)
← (CD)
(GND)
→ (DTR)
← (CTS)
→ (RTS)
(RING)
1
8
1
8
RJPIN

16 AT-9800 Series Switch
C613-03059-00 REV F
1000BASE straight
through cable
For 1000BASE network connections, all four pairs are used and the cable is
wired in a straight-through configuration. You can also use this cable with the
software test facility, to test 1000BASE network ports. The following table lists
pin assignments for a 10/100/1000BASE-T RJ-45 four pair straight-through
cable.
1000BASE crossover
cable
For 1000BASE test cables, all four pairs are used and the cable is wired in either
a crossover or straight-through configuration. The following table lists pin
assignments for a 10/100/1000BASE-T RJ-45 four pair cross-over cable.
Cable Guidelines
The following table lists port, connector, and cable combinations for AT-9800
Series switches and GBICs.
1. Refer to the IEEE 802.3 standards for further cable information.
End 1 End 2
Pin Pair Pin Pair
1 Pair 1+ 1 Pair 1+
2 Pair 1- 2 Pair 1-
3 Pair 2+ 3 Pair 2+
6 Pair 2- 6 Pair 2-
4 Pair 3+ 4 Pair 3+
5 Pair 3- 5 Pair 3-
7 Pair 4+ 7 Pair 4+
8 Pair 4- 8 Pair 4-
End 1 End 2
Pin Pair Pin Pair
1 Pair 1+ 1 Pair 2+
2 Pair 1- 2 Pair 2-
3 Pair 2+ 3 Pair 1+
6 Pair 2- 6 Pair 1-
4 Pair 3+ 4 Pair 4+
5 Pair 3- 5 Pair 4-
7 Pair 4+ 7 Pair 3+
8 Pair 4- 8 Pair 3-
Model Port Type
Connector
Type Cable Type1
Maximum
Cable Length
AT-9812T 10BASE-T/
100BASE-TX/
1000BASE-T
RJ-45 CAT5
CAT5E
100 to 150m
200m
AT-9816GB 1000BASE-X Varies with
GBIC
Refer to
documentation
with GBIC
Refer to
documentation
with GBIC

Hardware Reference 17
C613-03059-00 REV F
Redundant Power Supply (RPS)
Redundant Power Supply (RPS) units enhance network reliability by
providing backup coverage for switch Power Supply Units (PSUs).
AT-9800 Series switches have an RPS connector on the rear panel. The
connector allows the switch to be connected to an AT-RPS9000 system. The
AT-RPS9000 must be purchased separately.
The AT-RPS9000 is a chassis that holds up to four removable AT-PWR9000
power units. Each AT-PWR9000 power unit can provide redundant power to
one AT-9812T or AT-9816GB switch. When fully loaded, the AT-RPS9000
chassis can support up to four switches.
The AT-RPS9000 chassis has two AC power inlets. Each inlet supplies two
bays, and therefore two AT-PWR9000 units and two switches.
Rear panel of the AT-RPS9000.
The pin layout and functions of the RPS connector on the rear panel of AT-9800
Series switches are shown in the following figure and table.
AC INPUT A
AC INPUT
100-240V HZ 50/60 AMPS 5.0-2.5
AC INPUT B
AC INPUT
100-240V HZ 50/60 AMPS 5.0-2.5
RPS OUPUT A1 RPS OUPUT A2 RPS OUPUT B1 RPS OUPUT B2
OUTPUT VDC A Max
16
16
0.5
+3.3
+5
+12
OUTPUT VDC A Max
16
16
0.5
+3.3
+5
+12
OUTPUT VDC A Max
16
16
0.5
+3.3
+5
+12
OUTPUT VDC A Max
16
16
0.5
+3.3
+5
+12
AT-RPS9000
AC Input A
(For RPS output A1 & A2) AC Input B (For RPS output B1 & B2)
RPS Output A1 RPS Output A2 RPS Output B2RPS Output B1
Power Switches
A1 A2 A3
6 7 8 9 10
1 2 3 4 5

18 AT-9800 Series Switch
C613-03059-00 REV F
AT-RPS9000 Specifications
Dimensions ■Height: 67 mm, plus 5.5 mm if the rubber feet are used
■Width: 440 mm, excluding rack-mounting brackets
■Depth: 360 mm
■Weight: 6.76 kg with one AT-PWR9000 installed, 10.21 kg with four
AT-PWR9000 power units installed
Mounting System ■1.5U rack mounting
Environmental
Conditions
■Operating temperature range: 0 to 40º C (32 to 104º F)
■Storage temperature range: -25 to 70º C (-13 to 158º F)
■Relative humidity range: 5 to 95% non-condensing
LEDs ■AC supply to RPS
■RPS fan, PSU, and connection fault, located on AT-9800 Series switches
■RPS is supplying power to switch, located on AT-9800 Series switches
■For LED descriptions, see “Switch LEDs” on page 7
Controls ■Individual power switch for each PWR bay
■Power switches recessed to prevent unintentional operation
AC Power Supply ■Universal 100–240 VAC, 50–60 Hz input
DC Output ■+3.3VDC/16A
■+5VDC/16A
■+12VDC/0.5A
Pin Number Function
A1 5VDC In
A2 Return (ground) for 5VDC In, 3.3VDC In, and 12VDC
A3 3.3VDC In
1 Ground to indicate RPS is present
2 Remote Sense (RS) +3.3VDC
3 +12VDC In
4 RPS Fan Signal
5 Return (ground) for 5VDC In, 3.3VDC In and 12VDC
6 Remote Sense (RS) +5VDC
7 Return (ground) for +3.3VDC and +5VDC Remote Sense (RS)
8 +12VDC In
9NotUsed
10 Return (ground) for 5VDC In, 3.3VDC In and 12VDC

Hardware Reference 19
C613-03059-00 REV F
AT-TFTP Server
This section explains how to access and use the AT-TFTP Server. Use AT-TFTP
server to download software upgrades to your switch, and transfer
configuration files to and from your switch.
To use AT-TFTP Server, follow these steps.
1. If AT-TFTP Server has not yet been installed:
Install it now from the AT-9800 Series Switch Documentation and Tools
CD-ROM.
Select AT-TFTP Server from the Start > Programs > Allied Telesis >
AT-TFTP Server menu.
2. To set preferences for the AT-TFTP Server:
Select "Options" from the File menu to display the "Set Preferences" dialog
box.
The "Default file transfer directory" field specifies the directory that
AT-TFTP Server will read from or write to for file requests that do not
include a directory specification.
To prevent unauthorised access to private directories, enter a path name in
the "Restrict to directory" field. AT-TFTP Server will use only the specified
directory, even if file requests contain references to other directories.
Select "Read only" to prevent files being written to the PC. To use the PC to
archive scripts created using the create config command, select "Read
Write".
Make any required changes and click "OK".
3. To load a file from AT-TFTP Server to the switch:
On a terminal connected to the RS-232 terminal port (ASYN0), use the
command:
load method=tftp file=filename server=ipadd dest=flash
where filename is the name of the file to download and ipadd is the IP
address of the PC running AT-TFTP Server.

20 AT-9800 Series Switch
C613-03059-00 REV F
4. To save a TFTP Server log:
Select "Save As" from the File menu.
TFTP requests are logged to the AT-TFTP Server main window.
Using Windows Terminal and Windows
Hyperterminal
You can use a PC running terminal emulation software as the manager console,
instead of a terminal. There are many terminal emulation applications
available for PCs, but the most readily available are the Terminal and
HyperTerminal applications included in Microsoft Windows 98, 2000, and
XP Professional. In standard Windows installations, HyperTerminal is
available from the Communications submenu.
The key to successful use of terminal emulation software with the switch is to
configure the software and switch with matching communications parameters.
The following procedure can be applied to most terminal emulation programs.
Dialog boxes in the procedure are from Windows 2000 and XP Professional.
To configure Windows HyperTerminal for 2000 and XP Professional
1. Start the program in Windows by doing one of the following:
• Select Programs > Accessories > Communications > HyperTerminal.
• Double-click the Hypertrm.exe icon.
2. In the Connection Description dialog box:
• Enter a name for the connection, such as Admin.
• Select an icon from the scrollable list and click the OK button.
