Allied Vision U3-PCIE1XG322-13 User manual

V1.0.2
Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2023-May-31
USB3 VISION ACCESSORIES
USB 3.2 Host Adapter
U3-PCIE1XG322-13
User Guide

2USB 3.2 Host Adapter U3-PCIE1XG322-13 User Guide V1.0.2
Read before use
Read before use
EN - English
Safety
Before using the product, read these safety instructions. Observe the warnings at
all times. Use the product only as stated in the Intended use on page 17.
Intended use
Intended use of Allied Vision product is the integration into vision systems by
professionals. All Allied Vision product is sold in a B2B setting.
