Allmatic B.RO MINI 1CH User manual

ITA ENG FRA ESP DEU POR 1/2
6-1620051 rev5 02/10/2020
ENG
1
2
B.RO MINI 1CH
Selector for power
supply
3
12-24
Vac/dc
Code Rolling Code
Max transmiers 1000
Power supply 12-24 Vac/Vdc
Consumpon 45mA dc - 85mA ac @12V
50mA dc - 100mA ac @24V
Channels 1 (immediate or on me)
Frequency 433.92 MHz
Unobstructed range 80-250 m*
Relay contact 1A a 30 Vdc / 0.5A a 42.4 Vac
Temperature -10 ... +55°C
*The range is inuenced by the type of transmier, antenna and
radio interferences
Miniaturize receiver Rolling Code, 1 channel with dry contact relay output 1A a 30 Vdc / 0.5A a 42.4 Vac.
Power supply 12-24 Vac/dc, frequency 433.92Mhz.
1. Select the power supply with the jumper and power up the receiver.
2. Press the learning buon. The LED will light up.
3. Press the buon of the transmier you want to memorize. The LED will blink 2 mes for the correct learning.
Repeat the procedure to memorize other transmiers.
The receiver memorize only one buon for every transmier. In case of learning of a second buon of the same
transmier, the receiver will remove the rst buon learnt.
COM NO
Antenna
Learning buon
SignalingLED
Radio module
DESCRIPTION
LEARNING OF TRANSMITTERS
The funconing modalies of the relay are two::
1. IMMEDIATE: the relay is acve as long as the radio signal is it as well, and the relay output is closed as long
the transmier buon is pressed.
2. ON TIME: the relay, once acvated, is acve for a programmable me from 1 seconds up to 60 seconds.
In order of selecng the required funconing modality, proceed as follow:
1. Press and keep pressed the learning buon for more than 10 seconds.
2. When the LED blinks fast, it is possible to release the buon. In this moment the me is set to 0 seconds
(immediate funconing).
3. Press and release the learning buon to increase the me of acvaon of the relay. Each me you press
and subsequent release, the LED blinks one me and the me is increased by 1 second, unl a maximum
of 60 seconds.
4. Press and keep pressed the learning buon for more than 5 seconds.
5. When the LED blinks, it is possible to release the buon. The me has been memorized.
During phase 3, aer 20 seconds of inacvity, the receiver exits from the funcon, by meout, without
saving sengs and it will be set the immediate funconing.
MODALITY AND SELECTION OF THE FUNCTIONING
Compable from rmware version RXM1C01

ITA ENG FRA ESP DEU POR
2/26-1620051 rev5 02/10/2020
ENG
5
4
DISPOSAL OF THE PRODUCT
This product is an integral part of the automaon, and therefore, they must be disposed of together. As for the installaon operaons, at the end
of the life of this product, the dismantling operaons must be performed by qualied personnel. This product is made from dierent types of
materials: some can be recycled, others must be disposed of. Please inform yourselves on the recycling or disposal systems provided for by the laws
in force in your area, for this category of product.
CAUTION! – some parts of the product can contain pollung or dangerous substances which, if dispersed in the environment, may cause
serious harm to the environment and human health. As indicated by the symbol at the side, it is forbidden to throw this product into
domesc refuse. Therefore, follow the “separated collecon” instrucons for disposal, according to the methods provided for by local
regulaons in force, or redeliver the product to the retailer at the moment of purchase of a new, equivalent product.
CAUTION! – the regulaons in force at local level may envisage heavy sancons in case of abusive disposal of this product.
1. Cut power of the receiver.
2. Press and keep pressed the learning buon of the receiver while giving power again.
3. When the LED goes o it is possible to leave the buon. The receiver has been reset.
RESET
GUARANTEE
In compliance with legislaon, the manufacturer’s guarantee is valid from the date stamped on the product and is restricted to the repair or free
replacement of the parts accepted by the manufacturer as being defecve due to poor quality materials or manufacturing defects. The guarantee
does not cover damage or defects caused by external agents, faulty maintenance, overloading, natural wear and tear, choice of incorrect product,
assembly errors, or any other cause not imputable to the manufacturer. Products that have been misused will not be guaranteed or repaired.
Printed specicaons are only indicave. The manufacturer does not accept any responsibility for range reducons or malfuncons caused by
environmental interference. The manufacturer’s responsibility for damage caused to persons resulng from accidents of any nature caused by our
defecve products, are only those responsibilies that come under Italian law.
1. Go near the receiver.
2. Press and keep pressed the hidden buon of the transmier you want to remove.
3. Without releasing the hidden buon press the rst buon of the transmier.
4. The LED on the receiver will blink 4 mes. When the LED goes o, transmier is removed.
Do not make this procedure if near other receivers/automaons, this procedure will remove the transmier
from every system into the range.
REMOVE A TRANSMITTER
Compable from rmware version RXM1C01
