ALLNIC AUDIO
AUT-8000
STEP-UP TRANSFORMER
Silver
OWNER’S MANUAL

ALLNIC AUDIO
AUT-8000 SILVER STEP-UP TRANSFORMER
Thank you for purchasing this Allnic Audio AUT-8000 SILVER Step-up
Transformer. We are certain your trust in Allnic Audio and its dealers
worldwide, as well as your appreciation for the sound of this high-quality
device, will be rewarded by its excellent operation for years to come.
Please read this entire manual before you connect the AUT-8000 SILVER
Step-up Transformer to the other components of your system.
Audiomentors
(Allnic Audio marketing company)
415, Daeduck Plaza
19-4 Sunae-dong, Bundang-gu,
Seongnam-si, Gyeonggi-do,
13595 S.Korea
Direct Telephone: [phone]
email: [email protected]
Website: www.audiomentors.co.kr
** Information and specifications for the Allnic Audio product
described in this manual are subject to change without notice.

TABLE OF CONTENTS:
INTRODUCING THE AUT-8000 SILVER STEP-UP TRANSFORMER
4
WHAT’S IN THE BOX?
5
SAFETY
5
CLEANING
Chassis
Connectors
5
INITIAL SET-UP
Location, Location, Location
Inputs
Outputs
6
6
6
OPERATION
7
WARRANTY
9
SPECIFICATIONS
10
FIGURES
11
Please read about SAFETY before you attempt to use the AUT-8000
SILVER STEP-UP TRANSFORMER - we care about our customers and the
equipment, and we want you to enjoy this product for a long time!

4
INTRODUCING THE AUT-8000 SILVER STEP-UP TRANSFORMER
The AUT-8000 Silver is Allnic Audio’s Step-up Transformer. Like all Allnic Audio
products, it uses Permalloy (iron and nickel alloy) for its transformer (step-up)
cores. Allnic is grateful to Mr. G.W. Elmen of Western Electric for inventing
Permalloy for transformer core use, and in so doing, providing an enormous service
to recorded music listeners everywhere.
The AUT-8000 Silver Step-up Transformer has the following features:
• Silver wire windings on the AUT-8000 Silver’s permalloy transformers and silver
connection wire throughout. Silver has the lowest electrical resistance of any
metal. It is 6% lower than that of copper. All electrical energy loss in a
transformer is a result of both coil loss and core loss. The AUT-8000 Silver’s
permalloy transformer cores wound with silver coils significantly reduce such
loss. This results in significant, clearly audible, enhanced information transfer
from the AUT-8000 Silver’s step-up MC transformers.
• Use of a five-sectioned sandwich winding method for the transformers reduces
leakage, inductance and capacitance. This significantly improves high frequency
response.
• Dual unbalanced (RCA) moving coil phono inputs. Two pairs of RCA inputs allow
the use of two tonearms with easy switching between them.
• Four step impedance selector. A single selector controls both channels
simultaneously, and provides resistances of 10K, 20K, 30K, and 47 K. This range
will accommodate almost any MC cartridge.
• Easy, push-button muting.
• The AUT-8000 Silver is relatively small and may be installed near the turntable,
allowing the use of interconnection cables that are as short as possible.
• The AUT-8000 Silver has been designed and manufactured to work most
synergistically with other Allnic Audio products, for example the Allnic phono-
stages and preamplifiers.
• As are all Allnic Audio products, the AUT-8000 SILVER is fully RoHS (EU Reduction
of Hazardous Substances regulation) compliant in construction and materials.

5
WHAT’S IN THE BOX?
Please check that the shipping box contains the following:
• One (1) Allnic AUT-8000 Silver Step-up Transformer – in natural aluminum or
black finish in accordance with your order
• One (1) Owner’s Manual
We advise that you keep the box and other packing materials that your AUT-8000
Silver came in. It will be useful if you sell your AUT-8000 Silver or in the unlikely event
you need to ship it for service.
SAFETY
• Pull cables by pulling the plug, not the cable.
• Do not attempt any repairs. Do not remove the units’ chassis covers without
specific authorization from Allnic Audio or its authorized representative.
• Keep the cables away from heat sources and liquids.
• Keep the unit away from liquids – do not allow any liquid to enter the interior of
the unit.
• When the unit is moved from a cold to a warm environment, allow sufficient time
for any condensation to evaporate.
• Do not remove the unit’s chassis cover without specific authorization from Allnic
Audio or its authorized representative.
• See the notes on “Location, Location, Location”.
CLEANING
A. Chassis
Use only a soft, lint-free cloth dampened slightly with water only (NO cleaning fluids!) to
clean the faceplate and chassis of the AUT-8000 Silver.
B. Connectors
You may use any good quality contact cleaner recommended for such applications to
clean the contacts from time to time, as you deem appropriate.

6
INITIAL SET-UP
A. LOCATION, LOCATION, LOCATION
• DO NOT cover the top of the AUT-8000 Silver.
• DO NOT subject the AUT-8000 Silver to knocks and shocks as you move it around.
This advice is meant particularly for those who may want to place the AUT-8000
Silver on after-market isolation feet or similar devices. Dropping one side of the
AUT-8000 Silver, or the whole unit, is not a good thing to do and damage incurred
by doing so will not be covered by warranty.
• DO NOT place the AUT-8000 Silver near any strong heat source.
• DO NOT place anything heavy on the AUT-8000 Silver.
• DO NOT allow rubber or vinyl materials to rest on the AUT-8000 Silver’s chassis for
long periods of time. This could discolour the metal.
• DO place the AUT-8000 Silver on a solid shelf or stand that is stable and not subject
to vibration or sudden shock.
• DO consider using high-quality inter-connects for both inputs and outputs. The
AUT-8000 Silver is a highly sensitive piece of electronic designed for neutrality and
will output what you put into it.
• DO try to place the AUT-8000 Silver away from major sources of RFI and EMI;
though well shielded, the AUT-8000 Silver will function best away from large power
transformers and other sources of such interference.
B. INPUTS
There are two (2) pairs of single-ended (RCA) inputs located in the centre of the chassis
rear plate. They are labelled MC 1 and MC 2 and are arranged in pairs horizontally, one
above the other. The left channel input connections are on the right when you are
facing the AUT-8000 Silver’s rear panel (on the left when you are facing the front of the
unit). The right channel input connections are on the left when you are facing the AUT-
8000 Silver’s rear panel (on the right if you are facing the front of the unit). Please see
Figure 1.
In the centre of the square cornered by the four RCA input connections on the rear of
the AUT-8000 Silver’s chassis is a screw type connector. This connector is the ground
connection for ground wires from cartridges and/or turntable. Please see Figure 1.
C. OUTPUTS
The AUT-8000 Silver is equipped with one pair of single-ended (RCA) outputs. The right
and left channel output connections are the left-hand (when facing the rear – see Figure
1) horizontally aligned pair of RCA connections and are labelled for the right and left

7
channels, with the right channel connector closest to the left edge of the panel (again,
when facing the rear panel and the opposite when facing the front panel).
OPERATION
Be sure you have turned the volume down or otherwise muted your preamplifier before
connecting the AUT-8000 Silver. Also, make sure all your connections are snug.
At this point, if you have not already done it, turn the impedance selector located in the
centre of the front panel to the resistance that, based on your cartridge’s specifications,
is most likely to work best with it. The impedance selector controls both channels and
the resistance scale is 10K ohms, 20K ohms, 30K ohms, and 47K ohms. See Figure 2.
Next, turn the two front panel gain selection switches to the gain that you think will
work for your moving coil cartridge. See Figure 2.
Each position on the +#dB gain scale on each channel’s front panel rotating selector
indicates an increase in gain and corresponds to a factor that relates to cartridge
millivolt output. The settings description below provides each +#dB setting and its
corresponding output factor increase. You should use identical gain settings for both
transformers to avoid channel imbalance.
The possible settings are:
• +22dB (13 X) Gain
• +26dB (20 X) Gain
• +28dB (26 X) Gain
• +32dB (40 X) Gain
Please see Table 1:
Table 1
AUT-8000 Silver
Impedance Combination Table
Impedance
Selector
Setting
T / R1.
Gain
1 / 13
+22dB
1 / 20
+26dB
1 / 26
+28dB
1 / 40
+32dB
10 K ohms
59
ohms
25
ohms
15
ohms
6.3
ohms
20 K ohms
118
ohms
50
ohms
30
ohms
22
ohms
30 K ohms
177
ohms
75
ohms
44
ohms
33
ohms
47 K ohms
278
ohms
117
ohms
70
ohms
52
ohms
1. Turn Ratio of MC Step-up Transformer and dB Gain

8
You may easily experiment with different combinations of impedance and gain settings
to find the one best suited for your cartridge.
From this point on, operation is straight-forward. Of course, always be sure you have
muted the AUT-8000 Silver and/or turned the volume down or otherwise muted your
preamplifier before changing gain or impedance on the AUT-8000 Silver’s front panel
selectors.
Also, always BE CAREFUL about differences in gain between your sources. Generally,
streamers, disc and tape players and tuners will have greater gain than phono stages,
with or without step-up transformers. That means the volume setting for listening to
your turntable might be too high for listening to radio, tapes, CDs or streaming.
In case of any failure, please contact your Allnic Audio representative.

9
WARRANTY
FOR WARRANTY SERVICE, PLEASE CONTACT YOUR
AUTHORIZED ALLNIC DEALER.
Except for the tubes, this Allnic Audio product is warranted against materials and
manufacturing defects only for two (2) years from date of purchase. The tubes in this
product are warranted against materials and manufacturing defects only for six (6)
months from date of purchase. Date of purchase is the date indicated on the invoice
issued by Allnic Audio or its authorized representative for original purchase of the new
product. The warranty does not cover any damage occurring during product shipment
at any time, nor any damage occurring as a result of any of this product’s owner’s or
owners’ negligence or willful mistreatment. Failure to operate or care for this product
in accordance with instructions in this manual will be deemed negligent. For the
warranty to be valid, this product must be returned first to Allnic Audio’s authorized
representative for warranty service prior to any unauthorized attempt to repair or
modify it. Any repair done to or modification of this Allnic Audio product at any time
performed without specific authorization from Allnic Audio or its authorized
representative will void the warranty. Allnic Audio and its authorized representatives
shall be the sole determiners of whether the warranty has been voided. Provided that
the warranty has not been voided, the warranty is transferable for the balance of the
original purchaser’s warranty period.
The warranty covers parts and labour only. If required for warranty service, shipping of
this product to and return to product owner from an authorized Allnic representative
will be at product owner’s sole cost. In the case of required factory warranty service,
shipping to Korea shall be at product owner’s sole cost. Provided that Allnic has
determined that the warranty is not void, Allnic will pay the cost of return shipping to
product owner. If Allnic determines that the warranty is void, return shipping to
product owner will be at product owner’s sole cost.
After expiry of the applicable warranty period or if the warranty is void, Allnic Audio
and its authorized representatives are not responsible for nor obligated in any manner
whatsoever to undertake, or to cover or reimburse the costs of any repairs or
modifications to this product.
The warranty does not cover and Allnic Audio and its authorized representatives are
not responsible for any incidental costs or damages to the person or property of
original purchaser, any subsequent owner of this product, or any third party occurring
as a result of any malfunction or misuse of this product however and whenever
caused.

10
SPECIFICATIONS
FOR THE ALLNIC AUDIO AUT-8000 SILVER STEP-UP TRANSFORMER
Inputs: MC (Moving Coil) unbalanced (RCA) × 2 pairs
Outputs: Unbalanced (RCA) × 1 pair
Ground: Screw Type x 1
Maximum Input
Level (Non-clipping): At 20Hz:
10 Times: up to 230mV
15 Times: up to 150mV
20 Times: up to 115mV
30 Times: up to 57mV
At 10kHz, for any ratio: more than 10V
At 1kHz, for any ratio: more than 10V
THD
(Total Harmonic
Distortion): Less than 0.025% at 1 kHz, +20 dB Gain
Dimensions: Net: 32 cm (12.6 in) (W)
11 cm (4.3 in) (H)
21 cm (8.3 in) (D)
Packed: 41 cm (16.2 in) (W)
20 cm (7.8 in) (H)
31 cm (12.2 in) (D)
Weight: Net: 3.81 Kg (8.63 lbs)
Packed: 4.9Kg (10.8 lbs)

11
FIGURES
Figure 1 – AUT-8000 Silver Rear Panel View
Figure 2 – AUT-8000 Silver Front Panel View
