ALLPOWER APC4004 User manual

Compressor w/Nailgun
2
Table of Contents
Topic Page
Safety Guidelines - Definitions 3
Hazard Warnings 4
Additional Warnings 14
Compressor 16
Finish Nailer 27
Troubleshooting 33
Service & Repair 36
General Parts Listing 37
Limited Warranty 38
WARNING! READ AND UNDERSTAND ALL SAFETY PRECAUTIONS IN
THIS MANUAL BEFORE OPERATING. FAILURE TO COMPLY WITH
INSTRUCTIONS IN THIS MANUAL COULD RESULT IN PERSONAL
INJURY, PROPERTY DAMAGE, AND/ OR VOIDING OF YOUR
WARRANTY. ALL POWER AMERICA WILL NOT BE LIABLE FOR ANY
DAMAGE BECAUSE OF FAILURE TO FOLLOW THESE INSTRUCTIONS.

Owner’s Manual
3
Safety Guidelines - Definitions
This manual contains important information that you need to know and
understand in order to protect YOUR SAFETY and to PREVENT
EQUIPMENT PROBLEMS. The following symbols help you recognize this
information. Please read the manual and pay attention to these sections.
Save These Important Safety
Instructions!
Read and understand all of these safety instructions. Be
sure to retain them for future use.
WARNING! WARNINGS INDICATE A CERTAINTY OR STRONG
POSSIBILITY OF PERSONAL INJURY OR DEATH IF INSTRUCTIONS
ARE NOT FOLLOWED.
CAUTION: CAUTIONS INDICATE A POSSIBILITY OF
EQUIPMENT DAMAGE IF INSTRUCTIONS ARE NOT
FOLLOWED.
Note: Notes give helpful information.
WARNING! IMPROPER OPERATION OR MAINTENANCE OF THIS
PRODUCT COULD RESULT IN SERIOUS INJURY AND PROPERTY
DAMAGE. READ AND UNDERSTAND ALL WARNINGS AND OPERATING
INSTRUCTIONS BEFORE USING THIS EQUIPMENT. WHEN USING AIR
TOOLS, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED TO REDUCE THE RISK OF PERSONAL INJURY.

Compressor w/Nailgun
4
Hazard Warnings
Dust
These chemicals may include (but are not limited to) the following:
z Lead from lead-based paints
z Crystalline silica from bricks and cement and other masonry products
z Arsenic and chromium from chemically-treated lumber
Your risk from these exposures varies, depending on how often you do this
type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, always wear
MSHA/NIOSH approved, properly fitting face masks or respirators when
using such tools.
Always follow basic safety precautions when using air tools to reduce the
risk of personal injury.
Bursting
Rust can weaken the tank. Drain the condensed water from the tank after
each use to reduce rusting. If a leak is detected in the tank, replace the tank
immediately. Do not weld, drill or modify the air tank of this compressor.
Welding or modifications on the air compressor tank can severely impair
tank strength and cause an extremely hazardous condition. Welding or
modifying the tank in any manner will void the warranty.
Check the manufacturer’s maximum pressure rating for air tools and
accessories. Compressor outlet pressure must be regulated so as to never
exceed the maximum pressure rating of the tool. Relieve all pressure
through the hose before attaching or removing accessories.
Do not adjust the pressure switch or relief valve for any reason. Doing so
voids all warranties. They have been preset at the factory for the maximum
pressure of this unit. Personal injury and/ or property damage may result if
the pressure switch or the relief valve are tampered with.
Do not use plastic or pvc pipe for compressed air. Use only galvanized steel
pipe and fittings for compressed air distribution lines.
WARNING! SOME DUST CREATED BY POWER SANDING, SAWING,
GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES
CONTAINS CHEMICALS KNOWN TO THE STATE OF CALIFORNIA TO
CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.

Owner’s Manual
5
Hazard Warnings (cont’d)
Risk of Eye or Head Injury
What could happen:
z Air powered equipment and power tools are capable
of propelling materials such as fasteners, metal chips,
saw dust, and other debris at high speed, which could
result in serious eye injury.
z Compressed air can be hazardous. The air stream
can cause injury to soft tissue areas such as eyes,
ears, etc. Particles or objects propelled by the stream
can cause injury.
z Tool attachments can become loose or break and fly
apart propelling particles at the operator and others in
the work area.
How to prevent it:
z Always wear ANSI approved Z87.1 safety glasses with side shields.
z Never leave operating tool unattended. Disconnect air hose when tool is
not in use.
z For additional protection, use an approved face shield in addition to
safety glasses.
z Make sure that any attachments are securely assembled.
z Never point any nozzle or sprayer toward a person or any part of the
body. Equipment can cause serious injury if the spray penetrates the
skin.

Compressor w/Nailgun
6
Hazard Warnings (cont’d)
Risk of Fire or Explosion
What could happen:
z Abrasive tools such as sanders and grinders, rotating
tools such as drills, and impact tools such as nailers,
staplers, wrenches, hammers, and reciprocating saws
are capable of generating sparks which could result in
ignition of flammable materials.
z It is normal for the compressor motor and pressure
switch to produce sparks while operating. If sparks
come into contact with vapors from gasoline or other
solvents, they may ignite, causing fire or explosion.
z Exceeding the maximum pressure rating of tools or
accessories could cause an explosion resulting in
serious injury.
How to prevent it:
z Never operate tools near flammable substances such as gasoline,
cleaning solvents, etc.
z Work in a clean, well ventilated area free of combustible materials.
z Never use oxygen, carbon dioxide or other bottled gases as a power
source for air tools.
z Use compressed air regulated to maximum pressure at or below the
rated pressure of any attachments.
z Never connect to an air source that is capable of exceeding 200 psi.
z Always verify prior to using the tool that the air source has been
adjusted to the rated air pressure range.
z Never spray flammable liquids in a confined area. Do not spray where
sparks or flame are present.
z Do not smoke while spraying.
z Keep compressor as far from spray area as possible.

Owner’s Manual
7
Hazard Warnings (cont’d)
Risk of Hearing Loss
What could happen:
z Long term exposure to noise produced from the
operation of air tools can lead to permanent hearing
loss.
How to prevent it:
z Always wear ANSI S3.19 hearing protection when using a compressor.
Risk to Breathing/Inhalation
Hazard
What could happen:
z Abrasive tools such as grinders, sanders, and cut-off
tools generate dust and abrasive materials which can
be harmful to human lungs and respiratory system.
z Some materials such as adhesives and tar contain chemicals whose
vapors could cause serious injury with prolonged exposure.
How to prevent it:
z Always wear MSHA/NIOSH approved, properly fitting face mask or
respirator when using such tools. Read all instructions and be sure that
your respirator mask will protect you.
z Always work in a clean, dry, well ventilated area.
z Never directly inhale the compressed air produced by a compressor. It is
not suitable for breathing purposes.
z Be certain to read all labels when you are spraying paints or toxic
materials, and follow the safety instructions.

Compressor w/Nailgun
8
Hazard Warnings (cont’d)
Risk of Injury
What could happen:
z Tools left unattended, or with the air hose attached
can be activated by unauthorized persons leading to
their injury and/or injury to others.
z Air tools can propel fasteners or other materials
throughout the work area.
z A wrench or key that is left attached to a rotating part
of the tool increases the risk of personal injury.
z Using inflator nozzles for duster applications can
cause serious injury.
z Air tools can become activated by accident during
maintenance or tool changes.
z Air tools can cause the work-piece to move upon
contact leading to injury.
z Loss of control of the tool can lead to injury to self or
others.
z Poor quality, improper, or damaged tools such as
grinding wheels, chisels, sockets, drills, nailers,
staplers, etc., can fly apart during operation,
propelling particles throughout the work area causing
serious injury.
z Fasteners could ricochet or be propelled causing
serious injury or property damage.
z Improperly maintained tools and accessories can
cause serious injury.
z There is a risk of bursting if the tool is damaged.
z The compressor unit starts automatically. Serious
injury could occur from contact with moving parts.

Owner’s Manual
9
Hazard Warnings (cont’d)
Risk of Injury (cont’d)
How to prevent it:
z Remove air hose when tool is not in use and store tool in secure location
away from reach of children and or untrained users.
z Use only parts, fasteners, and accessories recommended by the
manufacturer.
z Keep work area clean and free of clutter. Keep children and others away
from work area during operation of the tool.
z Keep work area well lit.
z Remove adjusting keys and wrenches before turning the tool on.
z DO NOT use inflator nozzles for duster applications.
z Remove air hose to lubricate or add grinding attachments, sanding
discs, drills, etc. to the tool.
z Never carry the tool by the hose.
z Avoid unintentional starting. Don’t carry hooked-up tool with finger on
trigger.
z Repair servicing should be done only by an authorized service
representative.
z Use clamps or other devices to prevent movement.
z Never operate tool while under the influence of drugs or alcohol.
z Don’t overreach. Keep proper footing and balance of all times.
z Keep handles dry, clean and free from oil and grease.
z Stay alert. Watch what you are doing. Use common sense. Do not
operate tool when you are tired.
z Always use tool attachments rated for the speed of the power tool.
z Never use tools which have been dropped, impacted or damaged by
use.

Compressor w/Nailgun
10
Hazard Warnings (cont’d)
Risk of Injury (cont’d)
z Use only impact grade sockets on an impact wrench.
z Do not apply excessive force to the tool. Let the tool perform the work.
z Never point discharge of tool at self or others.
z Do not pull trigger unless tool contact safety device is against work
surface.
z Never attempt to drive fasteners into hard surfaces such as steel,
concrete, or tile.
z Take care to avoid driving a fastener on top of another fastener.
z Position tool carefully so that fasteners will be delivered to the proper
location.
z Use only accessories identified by the manufacturer to be used with
specific tools.
z Maintain the tool with care.
z Keep a cutting tool sharp and clean. A properly maintained tool, with
sharp cutting edges reduces the risk of binding and is easier to control.
z Check for misalignment of binding or moving parts, breakage of parts,
and any other condition that effects the tool’s operation. If damaged,
have the tool serviced before using.
z Use of an accessory not intended for use with the specific tools
increases the risk of injury to persons.
z Always shut off the compressor, remove the plug from the outlet, and
bleed all pressure from the system before servicing the compressor, and
when the compressor is not in use.
z Do not operate the unit with the shroud removed.

Owner’s Manual
11
Hazard Warnings (cont’d)
Risk of Electric Shock
What could happen:
z Using air tools to attach electrical wiring can result in
electrocution or death.
z Improper electrical connections can result in fires,
electrocution, or death.
z This tool is not provided with an insulated gripping surface. Contact with
a “live” wire makes exposed metal tool parts “live”, resulting in possible
electrocution or death.
z Fasteners coming in contact with hidden electrical wiring could cause
electrocution or death.
How to prevent it:
z Never use nailer/staplers to attach electrical wiring while energized.
z Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if
your body is grounded.
z Thoroughly investigate the work piece for possible hidden wiring before
performing work.
z A licensed electrician in accordance with all local and national codes
must install all wiring.
z Never use an electric air compressor outdoors when it is raining or on a
wet surface, as it may cause an electric shock.

Compressor w/Nailgun
12
Hazard Warnings (cont’d)
Risk of Entanglement
What could happen:
z Tools containing moving elements or driving other
moving tools (grinding wheels, sockets, sanding
discs, etc.) can become entangled in hair, clothing,
jewelry, and other loose objects, resulting in injury.
How to prevent it:
z Never wear loose fitting clothes, or apparel which contains loose straps
or ties, etc. which could become entangled in moving parts.
z Remove any jewelry, watches, identifications, bracelets, necklaces, etc.
which might become caught by the tool.
z Keep hands away from moving parts. Tie up or cover long hair.

Owner’s Manual
13
Hazard Warnings (cont’d)
Risk of Cut or Burns
What could happen:
z Tools which cut, shear, drill, staple punch, chisel, etc.
are capable of causing serious injury.
z The pump and manifold generate high temperatures.
How to prevent it:
z Keep the working part of the tool away from hands and body.
z Do not touch the pump, manifold or transfer tube while the pump is
running. Allow them to cool before handling or servicing.
z Keep children away from the compressor at all times.

Compressor w/Nailgun
14
Additional Warnings
Finish Nailer
z Keep fingers away from trigger when not driving fasteners to avoid
accidental firing.
z Choice of triggering method is important. Read all pertinent directions in
this manual for approved triggering options.
z Never point tool at yourself or others in work area.
z Never use oxygen or other bottled gasses. Explosion may occur. Never
use combustible gases or any other reactive gas as a power source for
this tool: explosion and serious personal injury could result.
z Use clean, dry, regulated, compressed air at 70 to 120 PSI (4.8 to 8.3
bar). Never connect tool to any pressure that could potentially exceed
200 PSI (13.7 bar).
z Always use an air hose that is rated for a maximum working pressure of
at least 150 PSI (10.3 bar) or 150% of the maximum system pressure,
whichever is greater.
z Connect the tool to the air supply hose with a coupling that automatically
removes all pressure from the tool when the coupling is disconnected.
z Disconnect the tool from the air supply hose before doing tool
maintenance, clearing a jammed fastener, leaving the work area,
moving tool to another location, or handing the tool to another person.
z Never use a tool that is leaking air, has missing or damaged parts, or
that requires repair. Make sure all screws and caps are securely
tightened.
z Never use tool if safety, trigger, or springs are inoperable, missing, or
damaged. Do not alter or remove safety, trigger, or springs. Make daily
inspections for free movement of both the trigger and safety mechanism.
z Do not use the tool without its safety warning label. If the label is
missing, damaged or unreadable, contact your All Power America Service
Center for a replacement.
z Only use parts, fasteners and accessories approved by All Power America.
z Connect the tool to the air supply before loading fasteners to prevent a
fastener from being fired during connection. The tool driving mechanism
may cycle when tool is connected to the air supply.

Owner’s Manual
15
Additional Warnings (cont’d)
Finish Nailer (cont’d)
Always assume that the tool contains fasteners.
No horseplay. Respect the tool as a working
implement.
Operator and bystanders must wear hard hats to
safeguard against possible injuries.
Do not load fasteners with the trigger or safety
depressed, to prevent unintentional firing.
Remove your finger from the trigger when not
driving fasteners. Never carry the tool with a
finger on the trigger. The tool will fire a fastener if
the safety is bumped while the trigger is
depressed.
Only fire fasteners into the work surface; never
into materials too hard to penetrate.
Grip the tool firmly to maintain control while
allowing the tool to recoil away from work surface
as the fastener is driven. If the safety element is
allowed to recontact the work surface before the
trigger is released, an unwanted fastener will be
fired.
Do not drive fasteners on top of other fasteners
or with the tool at too steep an angle. Fasteners
can ricochet causing personal injury.
Do not drive fasteners close to the edge of the
work piece. The work piece may split, allowing
the fastener to fly free or ricochet and cause
personal injury.
FOR CONTACT ACTUATION TOOLS ONLY, Do
not use on scaffoldings or ladders or for tasks in
which changing location involves the use of
scaffoldings, stairs, ladders, and the like. Do not
use for specific tasks transportation safety
systems or vehicles and wagons.
Only use All Power America approved fasteners.

Compressor w/Nailgun
16
Compressor
This air compressor pump is capable of running continuously. However, to
prolong the life of your air compressor, it is recommended that a 50%-75%
average duty cycle be maintained; that is, the air compressor pump should
not run more than 30-45 minutes in any given hour.
General operation
Depending on the CFM draw of the tools being operated, your new air
compressor can be used for operating paint sprayers, air tools, grease
guns, air brushes, caulking guns, sandblasters, inflating tires and plastic
toys, spraying weed killer and insecticides, etc. An air pressure regulator is
usually necessary for most of these applications.
How it works
To compress air, the pistons move up and down in the cylinder. Air enters
through the valve inlet on the down stroke and the discharge valve remains
closed. Air is compressed on the up stroke. The inlet valve closes and the
compressed air is forced out through the discharge valve, through the
check valve, and into the air receiver.
Working air is not available until the compressor has raised the air receiver
pressure above that required at the service connection. The air inlet filter
openings must be kept clear of obstructions, which could reduce the air
compressor’s air delivery.
Item Value
Peak horsepower 1.5HP
Tank Capacity 2 Gallons
Voltage/Frequency/Amp 120V/60Hz/10
CFM Delivery at 90 PSI 2.4 CFM
Maximum Pressure 115 PSI

Owner’s Manual
17
Compressor (cont’d)
Electrical Requirements
Grounding requirements
The cord set and plug with this unit contains a grounding pin. This plug
MUST be used with a grounded outlet. Do not modify the plug provided. If it
does not fit the available outlet, a correct outlet should be installed by a
qualified electrician.
Make sure the outlet being used has the same configuration as the
grounded plug. DO NOT USE AN ADAPTER.
Inspect the plug and cord before each use. Do not use if there are signs of
damage.
If these grounding instructions are not completely understood, or if you are
in doubt as to whether the compressor id properly grounded, have the
installation checked by a qualified electrician.
Repairs to the cord set or plug MUST be made by a qualified electrician.
WARNING! IN THE EVENT OF A SHORT CIRCUIT, GROUNDING
REDUCES THE RISK OF SHOCK BY PROVIDING AN ESCAPE WIRE
FOR THE ELECTRIC CURRENT. THIS AIR COMPRESSOR MUST BE
PROPERLY GROUNDED. THE OUTLET BEING USED MUST BE
INSTALLED AND GROUNDED IN ACCORDANCE WITH ALL LOCAL
CODES AND ORDINANCES. IMPROPER GROUNDING CAN RESULT IN
ELECTROCUTION.

Compressor w/Nailgun
18
Compressor (cont’d)
Electrical Requirements (cont’d)
Extension cords
Using extension cords is not recommended. The use of extension cords will
cause voltage to drop, resulting in power loss to the motor and overheating.
Instead of using an extension cord, increase the working reach of the air
hose by attaching another length of hose to its end. Attach additional
lengths of hose as needed. If an extension cord must be used:
z Use a 3-wire extension cord that has a 3-blade grounding plug and a 3-
slot receptacle that will accept the plug on the product
z The extension cord must be in good condition
z The extension cord must be no longer than 50 feet
z 14-gauge (AWG) or larger. (Wire size locations as gauge number
decreases. 12 AWG and 10 AWG may also be used. (DO NOT USE 16
OR 18 AWG.)
Voltage and circuit protection
This air compressor can be operated on a 15 amp circuit if the following
conditions are met:
z Voltage supply to the circuit must comply with the National Electrical
Code.
z The circuit is not used to supply any other electrical needs.
z Extension cords comply with the above specifications.
z The circuit must be equipped with a 15-amp circuit breaker or 15 amp
time delay fuse. Time delay fuses should be marked “D” in Canada and
“T” in the US.
If any of the above conditions cannot be met, or if the operation of the
compressor repeatedly causes interruption of the power, it may be
necessary to operate it from a 20 amp circuit. It is not necessary to change
the cord set.

Owner’s Manual
19
Compressor (cont’d)
Installation and location
Locate the compressor in a clean, dry, well-ventilated area. The compressor
should be located 12 to 18 inches from a wall or any other obstruction that
might interfere with the air flow through the fan blade belt wheel. Place the
compressor on a firm, level surface. The air compressor is designed with
heat dissipation fins that allow for proper cooling. Keep the fins or other
parts that collect dirt or dust clean. A clean compressor runs cooler and
provides longer service. Do not place rags, containers or other materials on
top of the compressor.
Controls
Become familiar with these controls before operating the unit.
z ON/AUTO/OFF Switch: Turn this switch ON to provide automatic power
to the pressure switch and OFF to remove power at the end of each use.
z Pressure Switch: The pressure switch automatically starts the motor
when the air tank pressure drops below the factory-set “cut-in” pressure.
It stops the motor when the air tank pressure reaches the factory-set
“cut-out” pressure.
z Safety Valve: If the pressure switch dies not shut off the air compressor
at its “cut-out” pressure setting, the safety valve will protect against high
pressure by “popping out” at its factory-set pressure (slightly higher than
the pressure switch “cut-out” setting).
z Tank Pressure Gauge: The tank pressure gauge indicates the reserve
air pressure in the tank.
z Outlet Pressure Gauge: The outlet pressure gauge indicates the air
pressure available at the outlet side of the regulator. This pressure is
controlled by the regulator and is always less than or equal to the tank
pressure.
z Regulator: Controls the air pressure shown on the outlet pressure
gauge. Turn regulator knob clockwise to increase pressure and
counterclockwise to decrease pressure.
z Universal Quick-Connect Body: The universal quick-connect body
accepts the three most popular styles or quick-connect plugs: industrial,
automotive (Tru-flate), and ARO. One hand push-to-connect operation
makes connections simple and easy.

Compressor w/Nailgun
20
Compressor (cont’d)
Controls (cont’d)
z Cooling system: This compressor contains an advanced design
cooling system that includes an engineered fan that blows air through
the vent holes in large amounts.
z Air Compressor Pump: Compresses air into the air tank. Working air is
not available until the compressor has raised the air tank pressure
above that required at the air outlet.
z Drain Valve: The drain valve is located at the base of the air tank and is
used to drain condensation at the end of each use.
z Check Valve: When the air compressor is operating, the check valve is
open, allowing compressed air to enter the air tank. When the air
compressor reaches “cut-out” pressure, the check valve closes, allowing
air pressure to remain inside the air tank.
