USER GUIDE
WIFI FLOOD SENSOR WITH
TEMPERATURE MEASUREMENT
Shelly® Flood by Allterco Robotics is intended to be placed
in a room/area in order to be aware of liquid leakage, and
monitor the temperature. Shelly Flood is battery powered,
with battery life up to 18 months. Shelly may work as a
standalone device or as an accessory to a home automa-
tion controller.
Battery Type:
3V DC - CR123A
Battery Life:
Up to 18 months
Electrical consumption:
• Static ≤5uA
• Awake ≤250mA
Temperature measurement range:
-40°C ÷ 60 °C (± 1°C)
Working temperature:
-40°C ÷ 60 °C
Dimensions (HxWxL):
70x19x19 mm
Radio protocol:
WiFi 802.11 b/g/n
Radio signal power:
1mW
Frequency:
2400 – 2500 MHz;
Operational range:
• up to 30 m outdoors
• up to 15 m indoors
Complies with EU standards:
• RE Directive 2014/53/EU
• LVD 2014/35/EU
• EMC 2004/108/WE
• RoHS2 2011/65/UE
Specications
Installation Instructions
CAUTION! Before beginning the installation please read
the accompanying documentation carefully and completely.
Failure to follow recommended procedures could lead to
malfunction, danger to your life or violation of the law. All-
terco Robotics is not responsible for any loss or damage in
case of incorrect installation or operation of this device.
CAUTION! Use the Device only with batteries which com-
ply with all applicable regulations. Inappropriate batteries
may cause a short circuit in the Device, which may damage it.
CAUTION! Do not allow children to play with the device,
especially with the Power Button. Keep the devices for re-
mote control of Shelly (mobile phones, tablets, PCs) away
from children.
Control your home with your voice
All Shelly devices are compatible with Amazons’ Alexa and
Googles’ assistant. Please see our step-by-step guides on:
https://shelly.cloud/compatibility/Alexa
https://shelly.cloud/compatibility/Assistant
Device „Wake Up“
To open the device, twist the top and bottom part of the
case counter clockwise.
Press the Button. The LED should ash slowly. This means
that Shelly is in AP mode. Press the Button again and the
LED will turn off and Shelly will be in „sleep“ mode.
LED States
• LED ashing slowly - AP Mode
• LED ashing quickly - STA Mode (No Cloud)
• LED still - STA Mode (Connected to Cloud)
• LED ashing quickly - FW Update (while in STA mode and
connected to Cloud)
Factory Reset
You can return your Shelly Flood to its Factory Settings by
pressing and holding the Button for 10 seconds. Upon suc-
cessful factory reset the LED will ash slowly.
Additional Features
Shelly allows control via HTTP from any other device, home
automation controller, mobile app or server.For more infor-
mation about the REST control protocol, please visit:
www.shelly.cloud or send a request to [email protected]
MOBILE APPLICATION FOR SHELLY®
The Shelly Cloud mobile application
Shelly Cloud gives you opportunity to control and adjust all
Shelly® devices from anywhere in the world. The only thing
you need is connection to the Internet and our mobile appli-
cation, installed on your smartphone or tablet. To install the
application please visit Google Play or App Store.
Registration
The rst time you open the Shelly Cloud mobile app, you
have to create an account which can manage all your
Shelly® devices.
Forgotten Password
In case you forget or lose your password, just enter the
e-mail address you have used in your registration. You will
then receive instructions on how to change your password.
WARNING! Be careful when you type your e-mail address
during the registration, as it will be used in case you forgot
your password.
After registering, create your rst
room (or rooms), where you are
going to add and use your Shelly
devices. Shelly Cloud allows easy
control and monitoring using a mo-
bile phone, tablet or PC.
Device Inclusion
To add a new Shelly device, connect it to the power grid
following the Installation Instructions included with the
Device.
Step 1
Place your Shelly Flood in the room where you want to use it.
Press the Button - the LED should turn on and ash slowly.
WARNING: If the LED does not ash slowly, press and
hold the Button for at least 10 seconds. The LED should
then ash quickly. If not, please repeat or contact our cus-
tomer support at: suppor[email protected]
Step 2
Choose “Add Device”.
In order to add more devices later, use the Menu at the top
right corner of the main screen and click “Add Device”.
Type the name and password for the WiFi network, to which
you want to add Shelly.
Step 3
- If using iOS: you will see the following screen (g. 4)
On your iOS device open Settings > WiFi and connect to the
WiFi network created by Shelly, e.g. ShellyFlood-35FA58.
- If using Android (g. 5) your phone will automatically scan
and include all new Shelly devices in the WiFi network, that
you dened.
Upon successful Device Inclusion to the WiFi network you
will see the following pop-up:
Step 4:
Approximately 30 seconds after discovery of any new de-
vices оn the local WiFi network, а list will be displayed by
default in the “Discovered Devices” room.
Step 5:
Select Discovered Devices and choose the Shelly device you
want to include in your account.
Step 6:
Enter a name
for the De-
vice. Choose
a Room, in
which the de-
vice has to be
positioned.
You can choose an icon or upload a picture to make it easier
to recognize. Press “Save Device”.
Step 7:
To enable connection to the Shelly Cloud service for remote
control and monitoring of the Device, press “yes” on the
following pop-up.

The Embedded Web Interface
Even without the mobile app Shelly can be set and con-
trolled through a browser and connection of a mobile phone
or tablet.
Abbreviations used:
Shelly-ID – consists of 6 or more characters. It may include
numbers and letters, for example 35FA58.
SSID – the name of the WiFi network, created by the device,
for example ShellyFlood-35FA58.
Access Point (AP) – in this mode in Shelly creates its own
WiFi network.
Client Mode (CM) – in this mode in Shelly connects to an-
other WiFi network.
Installation/Initial inclusion
Step 1
Place Shelly in the room where you want to use it. Open it
and press the Button. The LED should ash slowly.
To open the device, twist the top and bottom part of the
case counter clockwise.
CAUTION! If the LED does not ash slowly, press and
hold the Button for 10 seconds. Upon successful factory
reset, the LED will ash slowly.
Step 2
When the LED is ashing slowly, Shelly has created a WiFi
network, with name such as ShellyFlood-35FA58. Connect
to it.
Step 3
Type 192.168.33.1 into the address eld of your browser to
load the web interface of Shelly.
General - Home Page
This is the home page of the em-
bedded web interface. Here you
will see information about:
• Current Temperature
• Current Flood detection status
• Current battery percentage
• Connection to Cloud
• Present time
• Settings
Sensor Settings
Temperature Units: Setting for change of the temperature units.
• Celsius
• Fahrenheit
Temperature Threshold: Dene the temperature Threshold
in which Shelly Flood will “wake up” and send status. The
value can be from 1° up to 5° or you can disable it.
Internet/Security
WiFi Mode-Client: Allows the device to connect to an available
WiFi network. After typing the details in the elds, press Connect.
WiFi Mode-Acess Point: Congure Shelly to create a Wi-Fi
Access point. After typing the details in the elds, press
Create Access Point.
Restrict Login: Restrict the web interface of Shely with a
Username and Password. After typing the details in the re-
spective elds, press Restrict Shelly.
SNTP Server: You can change the default SNTP server. En-
ter the address, and click Save.
Advanced Developer Settings: Here you can change the
action execution:
• Via CoAP (CoIOT)
• Via MQTT
Cloud: You can Activate/Deactivate the connection to Shelly
Cloud.
ATTENTION: To reset the device, press and hold the But-
ton for at least 10 seconds. Upon successful factory reset,
the LED will ash slowly.
Settings
Time Zone and Geo-location: Enable or Disable the auto-
matic detection of Time Zone and Geo-location. If Disabled
you can dene it manually.
Firmware Upgrade: Shows present rmware version. If a
newer version is available, you can update your Shelly by
clicking Upload to install it.
Factory reset: Return Shelly to its factory settings.
Device Reboot: Reboots the device.
Device Info: Shows your device ID.
In Client Mode shows also your WiFi network name and WiFi
signal strength.
Shelly Devices Settings
After your Shelly de-
vice is included in the
app, you can control
it, change its settings
and automate the
way it works. To en-
ter the details menu
of the device, click on
it’s name.
From there you may
control the device, as
well as edit its appearance and settings.
Sensor settings
Temperature Units:
Setting for change of the
temperature units.
• Celsius
• Fahrenheit
Temperature Threshold:
You can dene the tem-
perature Threshold in which
Shelly Flood will “wake up”
and send status. The value
can be from 0.5° up to 10°,
or you can disable it.
Mute:
Use this to mute the sound,
when Shelly Flood detects
leakage.
Internet/Security
WiFi Mode - Client: Allows the device to connect to an avail-
able WiFi network. After typing the details in the respective
elds, press Connect.
WiFi Mode - Access Point: Congure Shelly to create a Wi-
Fi Access point. After typing the details in the respective
elds, press Create Access Point.
Restrict Login: Restrict the web interface (IP in the Wi-Fi
network) of Shely with a Username and Password. After typ-
ing the details in the respective elds, press Restrict Login.
Settings
Firmware Update
Update the rmware of Shelly, when a new version is re-
leased.
Time Zone and Geo-location
Enable or Disable the automatic detection of Time Zone and
Geo-location.
Factory Reset
Return Shelly to its factory default settings.
Device Information
Here you can see the:
• Device ID - Unique ID of Shelly
• Device IP - The IP of Shelly in your Wi-Fi network
• Device Type – The type of your Shelly device
• WiFi Name – The name of the WiFi network to which Shelly
is connected
• WiFi Signal – The signal strength of the WiFi network to
which Shelly is connected
Edit Device
From here you can edit:
• Device Name
• Device Room
• Device Picture
When you are done, press Save Device.
Modes:
•Alarm mode* - In this mode,
Shelly Flood will activate the
sound alarm when it detects
any leakage, and will send
notication every 5 minutes.
•Rain Mode - In this mode,
Shelly Flood will only send
notication once leakage is
detected, and second time
when the leakage is not
present.
*This is the default mode of Shelly
Flood.
Battery Life Recommendations
For the best battery life we recommend you the following
settings for Shelly Flood:
Sensor settings
• Temperature Threshold: 1°
Set a static IP address in the Wi-Fi network for Shelly from
the ebmedded web interface. Go to Internet/Security ->
Sensor settings and press on Set static IP address. After
typing the details in the respective elds, press Connect.
Keep Shelly at the best distance possible to the Wi-Fi router.
CE certication
This device was tested for typical body-worn operations. To
comply with RF exposure requirements, a minimum separa-
tion distance of 0mm must be maintained between the us-
er’s body and the handset, including the antenna. Third-par-
ty belt-clips, holsters, and similar accessories used by this
device should not contain any metallic components. Body-
worn accessories that do not meet these requirements may
not comply with RF exposure requirements and should be
avoided. Use only the supplied or an approved antenna.
This device in compliance with the essential requirements
and other relevant provisions of Directive 2014/53/EU. All
essential radio test suites have been carried out.
1. CAUTION: risk of explosion if battery is replaced by an
incorrect type. Dispose of used batteries according to the
instructions.
2. The device complies with RF specications when the de-
vice used at 20mm form your body.
RF power
Function Operation
Frequency
Max RF output
power:
Limit
WIFI
802.11B/G/N
(HT20,HT40)
2.4G
802.11b/g/n
(20MHz):
2412~2472MHz;
802.11n
(40MHz):
2422~2462MHz
dBm 20 dBm
(RoHSII Directive)
Manufacturer: Allterco Robotics EOOD
Address: Soa, 1407, 103 Cherni vrah Blvd.
Tel.: [phone]
E-mail: [email protected]
http://www.Shelly.cloud
The Declaration of Conformity is available at:
https://Shelly.cloud/declaration-of-conformity/
Changes in the contact data are published by the Manufac-
turer at the ofcial website of the Device:
http://www.Shelly.cloud
The User is obliged to stay informed for any amendments of
these warranty terms before exercising his/her rights against
the Manufacturer.
All rights to trademarks She®and Shelly®, and other intel-
lectual rights associated with this Device belong to Allterco
Robotics EOOD.
