AllTrade Trades Pro 830271 User manual

THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION,
MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY AND
UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE
TO DO SO COULD RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.
IF YOU SHOULD HAVEANY QUESTIONS OR EXPERIENCEA PROBLEMWITHYOURTRADES PRO
PRODUCT, DO NOT RETURN THIS PRODUCT TO THE STORE. PLEASE CALL OUR CUSTOMER
SERVICE DEPARTMENT AT 1-800-423-3598. BEFORE YOU CALL, HAVE THE FOLLOWING
INFORMATION AVAILABLE: MODEL No., DATE PURCHASED AND STORE LOCATION. AN
ALLTRADE REPRESENTATIVE CAN RESOLVE YOUR PROBLEM OVER THE PHONE.
ESTE MANUAL CONTIENE INFORMACIÓN IMPORTANTE SOBRE LA SEGURIDAD, OPERACIÓN,
MANTENIMIENTO Y ALMACENAMIENTO DE ESTE PRODUCTO. ANTES DE USARLO,
LEA CUIDADOSAMENTE Y COMPRENDA TODAS LAS PRECAUCIONES, ADVERTENCIAS,
INSTRUCCIONES Y ETIQUETAS DEL PRODUCTO. DE LO CONTRARIO PODRÍA SUFRIR
LESIONES GRAVES O CAUSAR DAÑOS MATERIALES.
SI TIENE DUDAS O SURGEN PROBLEMAS CON SU PRODUCTO TRADES PRO, NO LO
DEVUELVA A LA TIENDA LLAME A NUESTRO DEPARTAMENTO DE SERVICIO AL CLIENTE AL
1-800-423-3598. ANTES DE LLAMAR, TENGA A MANO LA SIGUIENTE INFORMACIÓN: NO.
DE MODELO, FECHA DE COMPRA Y DIRECCIÓN DE LA TIENDA. UN REPRESENTANTE DE
ALLTRADE PUEDE RESOLVER SU PROBLEMA POR TELÉFONO.
CE MANUEL CONTIENT DES RENSEIGNEMENTS IMPORTANTS CONCERNANT LA SÉCURITÉ,
LE FONCTIONNEMENT ET L’ENTREPOSAGE DE CE PRODUIT. LIRE ATTENTIVEMENT TOUS
LES AVERTISSEMENTS, PRÉCAUTIONS, INSTRUCTIONS ET ÉTIQUETTES DU PRODUIT AVANT
L’EMPLOI. LE NON RESPECT DE CETTE CONSIGNE PEUT ENTRAÎNER DES BLESSURES
CORPORELLES GRAVES ET/OU DES DOMMAGES MATÉRIELS.
POUR TOUTE QUESTION OU EN CAS DE PROBLÈME AVEC LE PRODUIT TRADES PRO, NE PAS
LE RETOURNER AU MAGASIN OÙ IL A ÉTÉ ACHETÉ. APPELEZ LE SERVICE À LA CLIENTÈLE
AU 1-800-423-3598 EN VEILLANT À VOUS MUNIR AU PRÉALABLE DES RENSEIGNEMENTS
SUIVANTS : N° DE MODÈLE, DATE D’ACHAT ET ADRESSE DU MAGASIN. VOTRE PROBLÈME
POURRA TRE RÉSOLU AU TÉLÉPHONE PAR UN AGENT D’ALLTRADE.
1800 PSI ELECTRIC PRESSURE
WASHER INSTRUCTION MANUAL
LAVEUSE À PRESSION ÉLECTRIQUE
1800 PSI (124 bars)
MANUEL DE L’UTILISATEUR
MANUAL DE INSTRUCCIONES PARA
LA LAVADORA ELÉCTRICA A
PRESIÓN DE 1800 LB/PULG2
Model #830271
Modèle nº 830271
Modelo No. 830271

TABLE OF CONTENTS
CONGRATULATIONS! ............................................................................................. 1
INTRODUCTION....................................................................................................... 2
GENERAL SAFETY............................................................................................... 2-4
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS............................. 2-3
IMPORTANT INFORMATION ABOUT THIS MANUAL................................... 3-4
UNPACKING & INSPECTION............................................................................... 4
SAFETY WARNINGS............................................................................................ 5-6
GENERAL SAFETY RULES ........................................................................... 5-6
SAFETY RULES FOR PRESSURE WASHERS....................................................... 6-9
GROUND FAULT CIRCUIT INTERRUPTER PROTECTION............................. 9
EXTENSION CORD USAGE .......................................................................... 9
FUNCTIONAL DESCRIPTION............................................................................... 10
PRESSURE WASHER TERMINOLOGY................................................................. 10
ASSEMBLY.......................................................................................................... 11-13
GUN HOLDER/ WASHER CONNECTION...................................................... 11
DETERGENT BOTTLE/WASHER CONNECTION............................................ 11
WAND/GUN CONNECTION.......................................................................... 11
PRESSURE HOSE/GUN CONNECTION ........................................................ 12
PRESSURE HOSE/WASHER CONNECTION ................................................. 12
GARDEN HOSE COUPLING/WASHER CONNECTION.................................. 12
GARDEN HOSE/WASHER CONNECTION..................................................... 12-13
POWER SUPPLY CONNECTION................................................................... 13
OPERATING THE PRESSURE WASHER ............................................................... 13-14
ADJUSTING THE NOZZLE................................................................................... 15
ADJUSTING FOR FLOW (FAN) PATTERN..................................................... 15
ADJUSTING FOR PRESSURE....................................................................... 15
USAGE OF CLEANING DETERGENTS.................................................................. 16-17
SHUTTING DOWN PRESSURE WASHER............................................................. 17
MAINTENANCE ................................................................................................... 18-20
TROUBLESHOOTING GUIDE ............................................................................... 20-25
SPECIFICATIONS ................................................................................................ 25
1 YEAR LIMITED WARRANTY ............................................................................. 26-28
CONGRATULATIONS!
Thank you for choosing this pressure washer. Our aim is to provide you with quality profes-
sional products, and we want you to be totally satisfied with your product and our Customer
Service. If any help or advice is needed, please contact us at 1-800-423-3598. When properly
cared for, this product will give you many years of satisfaction.

INTRODUCTION
This instruction manual is intended for your benefit. Please read and follow the safety, instal-
lation, maintenance and troubleshooting steps described within to ensure your safety and
satisfaction. The contents of this instruction manual are based upon the latest product infor-
mation available at the time of publication. The manufacturer reserves the right to make product
changes at any time without notice.
GENERAL SAFETY
READ AND FOLLOW ALL INSTRUCTIONS.
Failure to follow all instructions in this manual may result in severe
personal injury or death. Keep this manual and refer to it for Safety Instructions,
Operating Procedures, and Warranty.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS
The safety instructions provided in this manual are not intended to cover all possible con-
ditions and practices that may occur when operating, maintaining and cleaning power tools.
Always use common sense and pay particular attention to all the DANGER,
WARNING, CAUTION and NOTE statements in this manual.
DANGER
WARNING
CAUTION
NOTE
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety mes-
sages that follow this symbol to avoid possible injury or
death.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious
injury.
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
2

CAUTIONused without the safety alert symbol indicates
a potentially hazardous situation which, if not avoided,
may result in property damage.
NOTE provides additional information that is useful for
proper use and maintenance of this tool. If a NOTE is
indicated, make sure it is fully understood.
In addition to SAFETY ALERTS listed above, there could also be numerous symbols alerting
the operator that specific safety measures are required to safely operate this tool. Learn these
SAFETY SYMBOLS as well as the SAFETY ALERTS to prevent injury to the operator and
to bystanders.
READ OPERATING INSTRUCTIONS: Read and understand tool labels, safety
warnings and precautions in this manual before operating the tool. Failure to
follow WARNINGS could result in serious injury or even death to the operator or
bystanders.
ELECTRICAL SHOCK: This tool produces hazardous electrical voltage. Read
and become familiar with this manual’s WARNINGS and CAUTIONS so that it is
installed and used properly.
WEAR APPROVED EYE PROTECTION: Spray can splash back or propel
objects, including incorrectly attached accessories. Always wear approved eye
protection. Safety glasses must conform to the requirements of American National
Standards Institute (ANSI) Z87.1 and provide protection against flying particles
from both front and side.
INJECTION HAZARD: Pressure washers can produce fluid streams severe
enough to penetrate animal and human flesh.
SLIPPING and FALLING: Pressure washers produce puddles of slippery liquid
that can result in falls. Kickback from spray wand can result in falls when using
unstable platforms.
IMPORTANT INFORMATION ABOUT THIS MANUAL
Improper and unsafe use of this Pressure Washer can
result in death, fire and/or bodily injury. This instruction manual contains
important information about product safety. Keep the instruction manual
available for others to read before they use the Pressure Washer.
3

Improper maintenance and operation are responsible for the majority of accidents involving
electric Pressure Washers. The largest portion of these could be prevented by recognizing the
basic safety rules and precautions. Most accidents can be avoided if the operator recognizes
a potentially hazardous situation before it happens and by observing appropriate safety rules
and procedures as outlined in this manual.
Basic safety precautions are outlined in the SAFETY portion of this manual and throughout
the text in this manual where a potential hazard might occur.
Hazards that MUST be avoided to prevent serious injury follow headers marked DANGER or
WARNING. These same precautions are placed as labels on the tool itself.
NEVER use this Pressure Washer for applications that are NOT specified in this manual.
UNPACKING & INSPECTION
After opening the carton, unpack your new Pressure Washer and related parts
& accessories. Please inspect it carefully for any damage that may have occurred
during transit. If any parts are missing, please contact our Consumer Helpline:
Phone: [phone]
Do not operate this Pressure Washer if damaged during
shipment, handling or misuse. Damage may result in bursting, which
can cause serious injury or property damage. All damaged parts must be
repaired or replaced as needed prior to operating this Pressure Washer.
Check to see that all nuts, bolts and fittings are secure before putting this Pressure Washer
into service. If you have any questions, or require assistance with damaged or missing parts,
please contact our Consumer Helpline: Phone: [phone]
Please have the serial number, model number, date of purchase, and parts list (with missing
parts identified) available for reference when calling.
MODEL NUMBER:
SERIAL NUMBER:
DATE OF PURCHASE:
4

SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE
USING PRESSURE WASHER.
GENERAL SAFETY RULES
People with electronic devices, such as pacemakers, should consult their
physician(s) before using this product. Operation of electrical equipment in close
proximity to a heart pacemaker could cause interference or failure of the pacemaker.
WARNING: This product contains chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm.
Keep work area clean and well lit. Messy areas and cluttered workbenches invite
personal injury and/or property damage. Clear all work areas of unnecessary tools,
debris, furniture, etc.
Make sure the work area is well ventilated. Never operate in an enclosed area.
Do not place objects on top or against the tool.
Handle correctly. Always operate according to the instructions provided.
Never allow the tool to be operated by children, individuals unfamiliar with its operation
or unauthorized personnel.
Keep children and visitors away. All children should be kept away from the work
area. DO NOT let children handle the tool. Maintain a safe distance for any person near
the work area.
Childproof the workshop. The use of master switches and padlocks is highly recom-
mended. Remove starter keys where applicable.
Stay alert, watch what you are doing, and use common sense. Do not stand
on tool. Do not use tool while tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating the tool may result in serious
personal injury.
Operating any tools or equipment under the influence of drugs, alcohol, or
medication can cause personal injury to yourself and others.
Use the right tool. Use tools properly and for their intended task. Do not force
a small tool to do the job of a heavy-duty tool. Using the right tool to do the right job will
make doing the job safer.
5

Always make sure the tool is in the OFF position when making adjustments,
changing parts, or performing any maintenance.
Service must be performed only by qualified repair personnel. Service or
maintenance by unqualified personnel may result in a risk of injury.
Do not use the tool if the power switch does not turn it “ON” or “OFF”. A tool
that cannot be controlled with the switch is dangerous and must be repaired.
Store all maintenance tools away from the immediate area before turning
ON the tool.
Do not overreach. Proper footing and balance is a must at all times while using tools.
Unstable support may lead to personal injury. Do not stand on the tool. Serious injury
could result if the tool tips over or you accidentally contact tool.
When using accessories, consult the owner’s manual provided by the
manufacturer. The use of improper accessories may cause risk of injury to yourself and
others.
Keep protective guards in place and in proper working condition.
Maintain tools and equipment with care. They will function better and more safely
when kept clean and in good working condition. Keeping the tool clean, dry, and free of
grime will add to its life and performance.
Do not use the tool for applications other than specified.
SAFETY RULES FOR PRESSURE WASHERS
RISK OF INJURY
TO reduce the risk of injury, user must read and understand all
safety instructions and warnings at the beginning of this manual.
Pressure Washer produces fluid pressures and velocities high
enough to penetrate human and animal flesh which could result in
serious injury or amputation.
Ensure all connections are tightened securely. Inspect all hoses to ensure they
are not damaged or kinked. Loose connections or damaged hoses can result in injection
injuries.
Ensure all fittings are properly connected. Pull on connection to ensure fittings
are secure. Improperly connected fittings can unexpectedly separate resulting in injury.
6

NEVER place hands in front of nozzle.
NEVER attempt to attach or remove spray wand or hose fittings while Pressure Washer
system is pressurized.
DO NOT treat fluid injection injuries as a simple cut. Seek immediate med-
ical attention.
HIGH VELOCITY fluid spray can cause objects to break, propelling particles
at high speeds.
ALWAYS wear approved safety glasses when using or doing
maintenance on Pressure Washers.
ALWAYS wear protective clothing to prevent accidental spraying.
DO NOT permanently secure spray wand trigger in open position.
DO NOT use spray wand that does not have a trigger lock or trigger guard in place and
in proper working order.
DO NOT use acids, toxic or corrosive chemicals, poisons, insecticides, flammable sol-
vents or bleach with Pressure Washer. Use of these chemicals can result in damage to
equipment or serious injury or death.
RISK OF EXPLOSION - Do not spray flammable liquids.
RISK OF INJECTION OR INJURY to persons. Do not discharge stream at persons.
RISK OF INJECTION - Unit will start spraying when trigger is squeezed, if “ON/OFF”
switch is in “ON” position, point gun in safe direction.
GUN KICKS BACK - Firmly hold with both hands.
NEVER allow children to operate a Pressure Washer. Keep children at a safe
distance when an adult is using a Pressure Washer.
NEVER direct spray at Pressure Washer.
NEVER operate the Pressure Washer after it has tripped the GFCI or the main circuit
breaker unless the cause has been identified and resolved.
If an extension cord must be used, keep the power cord connection out of
any standing water, and use a heavy duty three-wire properly grounded type.
Keep the connection as far away as possible from the item being washed and any water
runoff.
7

NEVER cut or splice the power cord or extension cords.
DO NOT spray electrical apparatus and wiring.
WEAR rubber-soled tennis shoes or other footwear that provides some insulation
when operating the Pressure Washer.
COLD water use only.
FOR EITHER INDOOR OR OUTDOOR USE. Store indoors.
DO NOT direct spray toward electrical outlets, switches or products
connected to electrical service. Failure to observe this warning can result
in electrocution resulting in severe electrical shock or burns and possibly
resulting in death.
NEVER run the pressure pump without the water supply connected and
turned on. Non-repairable damage to the pump will occur.
RISK OF FALLING - Pressure washer can create puddles of slippery
solutions that can become hazardous.
ENSURE you stand on a stable surface while operating Pressure Washer. Initial kickback
from engaging spray wand can you to lose your balance and fall resulting in minor to
severe injuries.
USE EXTREME CAUTION if you must operate Pressure Washer from a ladder or
scaffolding. Kickback from spray wand can result to loss of balance and result in a fall
that could cause serious injuries.
WHEN cleaning Pressure Washer, ensure there are adequate slopes for drainage so
solutions don’t create puddles around unit that could result in slipping and falling.
RISK OF ELECTROCUTION:
Connect only to properly grounded outlet. Do not remove ground pin.
Inspect cord before using. DO NOT use if the cord is damaged.
Keep all connections dry and off the ground.
DO NOT touch plug with wet hands.
Connect to individual branch circuit only.
This product is provided with Ground Fault Circuit Interrupter built into the power cord
plug. If replacement of the plug or cord is needed, use only identical replacement parts.
8

GROUND FAULT CIRCUIT INTERRUPTER
This Pressure Washer is provided with a Ground-Fault Circuit-Interrupter
(GFCI) built into the plug of the power supply cord. This device provides
additional protection from the risk of electric shock. Should replacement of
the plug or cord become necessary, use only identical replacement parts
that include GFCI protection.
EXTENSION CORD USAGE
Extension cords are not recommended for use with this product. If used, extension cords must
be UL listed and use a minimum of 12 A.W.G. wiring. Extension cords should never exceed 25
feet in length. Extension cords, that are too long, cause a voltage drop over the extra distance
causing the motor to run slower with the possibility of causing damage to the motor. Using
extension cords with smaller than the recommended wire gauge run the risk of getting too hot,
melting, and/or causing fires.
9

FUNCTIONAL DESCRIPTION
PRESSURE WASHER FEATURES:
1. Gun
2. Adjustable Nozzle
3. Wand
4. Pressure Adjust Collar
5. Trigger
6. Trigger Safety Lock
7. Power Cord Hook
8. Handle
9. Pressure Washer
10. GFCI Power Cord
11. High Pressure Outlet
PRESSURE WASHER TERMINOLOGY
Following are common terms associated with the use of Pressure Washers:
PSI: Pounds per square inch – common unit measure used for water pressure, air pressure,
hydraulic pressure and pounds of force.
GPM: Gallons per minute (liters per minute [metric]) – common unit measure used for flow
rate of water. 10
12. Water Inlet
13. On/Off Switch
14. Nozzle Cleaning Needle
15. Pressure Hose
16. Gun/Wand Holder
17. Cooling Louvers
18. Wheel
19. Garden Hose Coupling
20. Detergent Bottle
21. Detergent Bottle Holder
22. Detergent Bottle Siphon Tube
2
4
15 14
1
6
5
3
9
12
13
21
FRONT VIEW BACK VIEW
17
22
19
18
10
16
20
7
8
11

ASSEMBLY
This Pressure Washer requires some assembly. If you have any problems with the
assembly of your Pressure Washer, please call the Pressure Washer helpline at
1-800-423-3598. If calling for assistance, please have the model, revision, and serial number
from the data tag available.
1. Using a box cutter, cut open the Pressure Washer carton on top.
2. Carefully remove all items from the box and inspect for completeness (see Functional
Description).
GUN HOLDER/WASHER CONNECTION
Attach and slide down holder to the side of the pressure washer as shown.
DETERGENT BOTTLE/WASHER CONNECTION
1. Attach and slide down detergent bottle holder to the side of the
pressure washer as shown.
2. Insert detergent bottle inside the holder.
3. Insert siphon tube inside the bottle and attach the bottle cap to
the bottle.
WAND/GUN CONNECTION
Attach the Wand to Gun by pressing the
Wand inside the Gun and then turning
clockwise until it locks inside the Gun. Tug
on the Wand to make sure it is secured.
11
WAND
GUN
GUN/WAND HOLDER

PRESSURE HOSE/GUN CONNECTION
1. Remove and discard the protective plastic
plug from the gun inlet.
2. Unpack the pressure hose and connect the
hose connector to the gun inlet. Ensure that
the threads are aligned properly. Securely
tighten the connector using a 17mm wrench
(not provided).
PRESSURE HOSE/WASHER CONNECTION
1. Remove and discard the protective
plastic plug from the high pressure outlet.
2. Connect the pressure hose
connector to the high pressure
outlet at the lower front of the unit. Ensure
that the threads are aligned properly.
Securely tighten the connector by hand.
GARDEN HOSE COUPLING/WASHER CONNECTION
If the coupling is not attached to the pressure washer, attach the
coupling (with screen filter side facing out) to the water inlet
connector in the lower back of the pressure washer. Securely
tighten the connector by hand.
GARDEN HOSE/WASHER CONNECTION
DO NOT run the pump without the water supply connected and
turned on. Damage to equipment resulting from failure to follow this instruction will void
warranty.
1. Before connecting the garden hose to the
Pressure Washer, connect the garden hose
to the water source and run water through
the hose to flush out any debris. Shut off
the water.
2. Attach garden hose to the pressure
washer water inlet in the lower back of the
unit. Ensure that the threads are aligned
properly. Securely tighten the nut by hand.
3. Turn on the water source. 12
WRENCH
HOSE
HOSE
12
GARDEN HOSE
WATER
SOURCE
COUPLING

For best result, use a short garden hose (30 ft. or less length),
cold water (less than 100 F) and adequate pressure (no less than 50 PSI).
POWER SUPPLY CONNECTION
KEEP all electrical connections dry and off the ground.
NEVER touch the plug with wet hands.
NEVER cut or remove grounding blade (round longer pin) on GFCI
attachment plug.
1. Connect the Pressure Washer GFCI power cord to a dedicated electrical outlet.
Outlet capacity must be 120V, 60HZ and minimum 15 AMP.
2.To ensure for GFCI proper operation:
a. Plug into receptacle: indicator should be “ON”
b. Press Test Button: Indicator should be “OFF”
c. Press Reset Button for use. Do not use if test fails
Do NOT use the pressure washer if RESET button does not pop out
when TEST button is pressed. Call Customer Service 1-800-423-3598.
OPERATING THE PRESSURE WASHER
ALWAYS wear approved safety glasses when operating Pressure
Washers. Spray can splash back or propel objects, including
incorrectly attached accessories.
The high pressure stream of water that this equipment
produces can cut through skin and its underlying tissues, leading to
possible amputation.
Spray gun traps high water pressure, even when the motor
is stopped and water is disconnected, which can cause injury.
Kickback from spray gun can cause you to fall.
13
TEST
RESET

1. For your protection, wear protective safety glasses (Not provided).
2. Place the Pressure Washer near the working surface.
Make sure that the water source is turned on and all connections to
the Pressure Washer and Spray Gun are secure and without any water leakage.
The Pressure Washer motor runs ONLY when the
trigger is engaged.
3. Hold the gun securely with both hands. Point the
gun in a safe direction. Make sure that the gun safety
is unlocked and squeeze the trigger to allow any air
that is trapped inside the unit and hoses to escape.
Continue to squeeze the trigger until a steady stream
of water comes from the nozzle.
Make sure wand is SECURELY tightened to Gun. If the wand
is not securely locked into place, it could be ejected under high pressure when
operating the gun, possibly causing injury or damage.
4. Turn on the ON/Off switch on the front of the Pressure Washer.
NOTE: Motor does not start until trigger is pulled.
5. Point the gun in a safe direction and squeeze the trigger to start
motor and water flow.
USAGE TIPS:
• To prevent damage to your surface and to select an
appropriate working pressure for your application,
always start with lowest pressure setting and
continue increasing the pressure until the best work
result is achieved.
• For most effective cleaning, keep spray nozzle from 8
to 24 inches away from cleaning surface.
• If you get spray nozzle too close, especially using
high pressure mode, you may damage surface being
cleaned.
• DO NOT get closer than 6 inches when cleaning tires.
14
UNLOCK
OFF
ON

ADJUSTING THE NOZZLE
Nozzle may not be easily adjusted during spraying. Release the
Gun Trigger to stop spraying before adjusting the Nozzle.
ADJUSTING FOR FLOW (FAN) PATTERN
The angle of spray coming out of the nozzle may be adjusted by rotating the front of the
nozzle (cone). This will vary the spray pattern from approximately a 0° narrow high impact
stream (by turning the nozzle fully to the left) to a 60° wide fan spray (by turning the nozzle
fully to the right).
A narrow stream has high impact force on the cleaning surface and results in maximum deep
cleaning in a concentrated area. However, this narrow high impact spray must be used cau-
tiously, as it may damage some surfaces.
A wide fan pattern will distribute the impact of the water over a larger area, result-
ing in excellent cleaning action with a reduced risk of surface damage. Large
surface areas can be cleaned more quickly using a wide fan pattern.
ADJUSTING FOR PRESSURE
The Adjustable Pressure Nozzle allows you to vary the pressure of your spray by turning the
end of the nozzle (collar). Turning the collar fully to the right will reduce the pressure to its
minimum. If the Pressure Washer has a detergent injection system you must use this minimum
pressure setting in order to suction detergent.
Turning the collar fully to the left will increase the pressure to its maximum for greatest cleaning
efficiency. Turning the collar changes the pressure but not the fan pattern.
Detergent will NOT flow until the Pressure Adjust Collar is set
(turned) to low pressure position.
LOW PRESSURE
HIGH PRESSURE
COLLAR
WIDE
STREAM CONE
15
HIGH
LOW
STREAM
WIDE

USAGE OF CLEANING DETERGENTS
TO APPLY DETERGENT:
1. Select a detergent/cleanser appropriate for the intended
application.
2. Prepare detergent solution as recommended by the
manufacturer.
3. Remove cap over the detergent bottle located on the side
of the Pressure Washer.
4. Fill bottle with prepared detergent solution. A small
funnel may help with this task. Replace the detergent
bottle cap.
5. Set (turn) the Pressure Adjust Collar to low pressure
position.
Detergent will NOT flow until the Pressure Adjust Collar is set
(turned) to low pressure position.
6. Pull spray gun trigger and apply detergent to a dry surface, starting at lower portion of
area to be washed and work upward, using long, even, overlapping strokes.
Wetting the surface first is not recommended, as it dilutes the
detergent and reduces its cleaning ability.
7. Allow detergent to “soak in” for 3-5 minutes before washing and rinsing. Reapply
as needed to prevent surface from drying. Do Not allow detergent to dry on surface
(prevents streaking).
TO RINSE:
1. Reset the Pressure Adjust Collar to high pressure, press the trigger and wait for the deter-
gent to clear.
2. Keep the spray gun a safe distance from the area you plan to spray.
3. Apply a high pressure spray to a small area, and then check the surface for damage. If no
damage is found, it is okay to continue cleaning.
4. Start at the top of the area to be rinsed, working down with same overlapping strokes as
you used for washing and applying detergent.
When you have completed use of the detergent injection system, continue to run in low pres-
sure mode and flush clean water through the detergent bottle until it is thoroughly cleaned.
Failure to clean properly will cause the injection system to become
clogged and inoperable.
16

CLEANING TIPS:
• Never leave the Pressure Washer unattended while it is plugged into an electrical outlet
and while water is supplied to the equipment.
• Never use the Pressure Washer water inlet to siphon detergent or wax.
• If you have the nozzle too far away from the surface being washed, the cleaning will not
be as effective.
IMPORTANT: DO NOT get closer than 6 inches when cleaning.
SHUTTING DOWN THE PRESSURE WASHER
To shut off the Pressure Washer:
1. Release spray gun trigger.
2. Move unit’s ON/OFF switch to OFF position.
IMPORTANT: Releasing the trigger will shut off the motor but does not shut off electrical
power to the unit.
3. Turn off water supply.
4. ALWAYS point spray gun in a safe direction and squeeze spray gun trigger to relieve built
up pressure in the unit.
Spray gun traps high water pressure, even when motor is stopped
and water is disconnected.
5. Engage trigger lock on spray gun when not in use.
6. Disconnect GFCI plug from outlet.
7. Loop the power cord and pressure hose and hang
on the hooks on the sides of the pressure washer.
8. Disconnect the wand from the gun and place both
in their holders on the side of the pressure washer.
9. Disconnect pressure washer from water supply and
store the unit (see MAINTENENCE section).
17

MAINTENANCE
Regular maintenance will improve performance and extend life of Pressure Washer.
Pressure Washer’s warranty does not cover items that have been subjected to operator abuse or
negligence. Only by maintaining Pressure Washer in accordance with instructions in this manual
will the full value of the warranty be honored.
Some adjustments will need to be made periodically to properly maintain the Pressure Washer.
All service and adjustments should be made at least one time each season. It is important that the
maintenance chart below be followed.
STORAGE
After each application or winter storage follow these instructions:
1. When finished using the Pressure Washer, you must first drain and rinse the detergent
bottle and siphoning tube.
2. Run the Pressure Washer in low pressure until all of the soap is drained from the detergent
bottle.
3. Pour clear water into the bottle and run it through on low pressure as though it were deter-
gent.
4. Turn the machine OFF and squeeze the trigger to release the trapped pressure inside of the
machine.
5. Remove both the garden hose and high pressure hose from the unit.
6. Turn ON the machine and allow it to run for 5 seconds. (This will clear out most of the
water trapped in the pump).
7. Unplug the machine and store in a dry, climate controlled environment.
NOTE: Do not store the machine or accessories in a place where the temperature could drop below
40°F.
AFTER EXTENDED STORAGE
Scale deposits may form in the pump when it is not used for some time. This causes the motor to
hesitate or not start up at all.
1. Do not plug the unit into electrical outlet or connect the pressure hose to the unit.
2. Connect garden hose to the unit and allow the water to exit from pressure outlet for a few
seconds to rinse the system.
3. Shut off the water.
4. Connect pressure hose to the gun and pressure washer.
18

CONNECTIONS
Connections (fittings) on Pressure Washer, pressure hose, gun and spray wand should be
cleaned regularly and lubricated with non-water soluble grease to prevent leakage and damage
to the o-rings.
NOZZLE
The nozzles should be lubricated with non-water soluble grease or light oil regularly. Clogging
of the nozzle causes the pump pressure to build up too high and cleaning is required.
1. Make sure Pressure Washer On/Off switch is set to
Off and spray gun trigger is locked.
2. Set the nozzle to high pressure setting to make the
nozzle hole accessible.
3. Clear blockage in nozzle by inserting the nozzle
cleaning needle (provided) through center hole.
4. After cleaning, remove the needle from nozzle and
store for future use.
WATER INLET FILTER
The Pressure Washer is equipped with a water inlet filter to protect the pump from foreign
debris.
1. Remove the garden hose coupling from pressure washer water inlet and then gently remove
the rubber gasket over the screen filter and remove the filter from inside the inlet.
2 . CAREFULLY clean the filter by using a nonabrasive and dull object (finger or soft brush).
Make sure screen is not torn or broken.
3. Reinstall the filter, rubber gasket and coupling. FIRMLY hand tighten the coupling to prevent
water leakage.
19
COUPLING
GASKET
FILTER
