Kärcher K 3 Full Control User manual

中文 .............. 5
English ....... 13
K 3 Full Control
59676360 (03/17)

2

3

4

中文 5
如有附件缺失或在运输过程中损坏，请联
系经销商。
图片参见第 4 页
1 高压接口
2 产品开关 “0/OFF” /“I/ON”
3 保存钩
4手柄
5 可拔下的运输手柄
6 喷头存储架
7 高压喷枪保存装置
8 洗衣粉吸软管 带有过滤器的盖和
9 洗涤剂储藏桶
10 带有水过滤器的供水连接装置
11 管接头
12 软管联轴器 ( 双重防漏保护阀 )
13 进水软管
14 软管联轴器
15 转接头
16 电源线
17 轮子
18 高压喷枪完全控制
19 压力显示
0 - MIX / 1 - SOFT / 2 - MEDIUM / 3
- HARD
20 高压喷枪锁定装置
21 高压喷枪与高压软管分离卡扣
22 高压软管
23 污垢清除器喷射管完全控制
针对顽固污垢
压力等级：较多
24 Vario Power 喷射管完全控制
适用于最通用的清洁任务
压力等级：较多 / 中档 / 较少 / 最少
25 洗涤刷
适于使用洗涤剂的清洗作业。
目录
设备说明 . . . . . . . . . . . . . 5
安全提示 . . . . . . . . . . . . . 6
合乎规定的使用 . . . . . . . . . . 8
环境保护 . . . . . . . . . . . . . 8
安装和调试 . . . . . . . . . . . . 8
设备运作 . . . . . . . . . . . . . 8
运输和存放 . . . . . . . . . . . . 9
维护和保养 . . . . . . . . . . . . 9
故障排除 . . . . . . . . . . . . . 10
附件和备件 . . . . . . . . . . . . 10
产品规格 / 参数 . . . . . . . . . . 10
质量保证 . . . . . . . . . . . . . 11
设备说明

6 中文
在您初次使用本产品前，请仔细
阅读本说明书，并请妥善保存以
便日后查阅。
除了操作说明书里的提示外，还要遵守立
法的一般安全和事故防范规定。
设备上相应的警告、指示标志为无风险的
运行提供重要提示。

危险
提示会导致人员重伤或死亡的直接威胁性
危险。
몇 警告
提示可能导致人员重伤或死亡的危险状况。
몇 小心
提示可能导致轻度伤害的危险状况。
注意
提示可能产生财产损失的危险状况。
 危险
电击危险。
 决不能用湿手触及电源插头或者插座。
 每次运行前都要测试一下带插头的电源
连接导线是否有损坏。损坏的电源连接
导线应立即让已授权的客户服务处 / 电
气专业人员进行更换。不得使用带受损
电源连接导线的设备。
 所有工作领域内的电气部件都必须防
水。
 电源插头和延长线缆的连接器必须确保
防水且不可置于水中。此外不能将连接
器置于地面。建议使用确保插座离地面
至少 60 毫米的电缆轴。
 注意电源接线或延长线缆不要受到碾
压、挤压、硬拉或类似行为而遭损伤或
损坏。防止电源线缆受热、油和尖锐棱
角的损坏。
 在进行所有维护和保养工作前关闭吸尘
器并拔下电源线。
 只允许接受过授权的客户服务人员进行
维修工作和在电气零部件上进行工作。
몇 警告
 本设备只能根据 IEC 60364 由电工连接
到电气接口。
 设备只能连接到交流电上。电压必须跟
设备型号标牌上给出的电压一致。
 出于安全原因，原则上我们建议您通过
故障电流保护开关 ( 最大 30 mA) 运行
设备。
 加长电线如不合适，将带来危险。在室
外请只使用经过许可并相应进行了标识
且具有足够横截面积的加长电线：
1
-
10 m: 1.5 mm
2
；
10
-
30 m: 2.5 mm
2
 延长线缆总是从电缆轴上完全展开。
 危险
 用户必须按规定使用该设备。同时要重
视地方现行的规定并在设备工作时照看
好场所内的人员。
 每次使用前检查重要部件，如高压软
管、手持喷枪和安全装置是否是否有
损。立即更换受损部件。不得使用带受
损部件的设备。
 高压喷枪使用不当，会带来危险。不能
对准人、动物、电器设备或者设备自身
喷射。
 高压水柱不可对准自己或他人喷射以清
洗衣服或鞋袜。
 汽车轮胎 / 轮胎阀门可能被高压水柱冲
坏并爆裂。对此损坏的首要征兆就是轮
胎变色。受损的汽车轮胎 / 轮胎阀门可
能带来生命危险。清洗时至少与水柱保
持 30 cm 距离！
몇 警告
 如射程范围内有其他人，除非他们穿上
防护服，否则不得使用本设备。
 儿童或未经指导的人员都不准操作本设
备。
 本设备不得让那些身体能力有限、感官
能力弱或理解能力差或者缺乏经验和 /
或缺乏知识的人员使用，除非他们有专
人监督或接受专人指导如何操作设备并
了解其可能产生的危险。
 儿童不得玩耍本设备。
 照看好儿童，以确保他们不用设备玩
耍。
安全提示
危险程度
电气部件
安全处理

中文 7
몇
小心
 用设备或在设备上进行任何作业前要先
确保设备的稳定性，以避免因设备翻倒
而导致的事故或故障发生。
 通过高压喷嘴上喷出的水束而对手持式
喷枪产生反冲力。注意保持安全可靠的
狀态，紧握高压喷枪和喷射管。
 设备运行期间不可无人看管。
注意
 若工休时间比较长，关闭设备开关。
 温度低于 0 °C 时无法运行机器。
 危险
 禁止在有爆炸危险的区域内运行本设
备。
 不要喷射含危害健康物质 （如石棉）的
物品。
 不得喷射可燃液体。
 决不使用设备抽吸具有溶媒性质的液体
或未经稀释的酸和溶剂！此外还有汽
油、颜料稀释剂或燃油等。极度易燃、
易爆且有毒的喷雾。不使用丙酮、未经
稀释的酸和溶剂，因为它们会侵蚀设备
上使用的材料。
 让儿童远离包装薄膜，否则会有窒息危
险！
몇 警告
 根据有效的使用说明规定，该设备在没
有系统分离器的情况下不能在饮用水网
上使用。请确保您的家庭供水系统上运
行高压清洁器的接口根据 EN 12729 的
规定配备了合适的 BA 型系统分离器。
 流经系統分离器的水不再视为饮用水。
 高压软管、水龙头和连接器对机器安全
十分重要。只能使用生产商推荐的高压
软管、水龙头和连接器。
 分离进水管或高压软管时，在此操作后
热水可能从接口中流出。
몇 小心
 为了避免事故和伤害，选择存放地点和
运输时要考虑到设备的重量 （参见技术
参数）。
몇 警告
 本设备只能使用制造商提供或推荐的洗
涤剂。使用其他的洗涤剂或化学试剂会
影响设备的安全性。
 错误使用洗涤剂可能会导致重伤或中
毒。
 洗涤剂应远离孩童妥善保管。
몇 小心
 请穿戴合适的防护服和防护镜，以防止
使用时从被清洁物体表面溅出的水渍或
污渍。
 使用高压清洁器期间可能产生气溶胶。
吸入气溶胶可能导致损害健康的后果。
– 根据应用情况，可以使用完全封闭的吸
嘴 （例如表面洗涤器）用于高压清洁，
将明显减少含水气溶胶的产生。
– 这种屏蔽并非适用于所有应用情况。
– 当无法使用完全封闭的吸嘴时，根据待
清洁的环境，应使用等级 FFP 2 或类似
的口罩。
몇 小心
安全装置用于保护使用者，不得更改或不
让其发挥功能。
设备开关是为了防止设备误启动。
水枪枪柄上的安全制动装置可防止设备被
误启动。
溢流阀阻碍压力超过允许的工作压力。
当松开手持喷枪的控制杆，压力开关关闭
泵，高压喷射停止。拉上该杆，泵又被开
启。
其他危险
使用清洁剂的清洗作业
个人防护装备
设备上的符号
高压喷头不得指向人、动物、带
电电气设备或设备本身。
设备防寒保护。
本设备不允许直接连接到公共饮
用水网。
安全装置
设备开关
安全制动装置
带压力开关的溢流阀

8 中文
本高压清洁器只限私人居家日用。
–使用高压喷水清洁机器、汽车、建筑
物、工具、墙面、露台、园林工具等
（需要时加清洁剂）。
–使用经 KÄRCHER 许可的附件、备件以及
洗涤剂。注意清洁剂随附的提示。
插图参见图片页
图
使用设备前，请按图示将部件组装好。
将设备置放在平坦地面上。
图
插入喷枪软管直至发出声音时。
拉高压软管以检查是否安全连接。
图
注意
水中的污物可能损坏高压泵和附件。为此
建议使用 KÄRCHER 水过滤器 （特殊附件，
订货号 4.730-059）进行保护。
몇 小心
干运转 （不加润滑油）2 分钟以上会导致
高压泵损坏。设备 2 分钟内没有压力形成，
关闭设备并按照 “ 故障帮助 ” 一章内的
提示进行操作。
몇 小心
洗涂漆表面时至少与水柱保持 30 厘米距
离，以避免损坏。
注意
不使用污垢清除器清洁轮胎、油漆或敏感
表面如木材，存在损坏的危险。
图
通过完全控制喷射管，高压喷枪的压力显
示灯显示当前设定的压力等级。
提示： 带有 T-Racer 和其他附件运行时，
压力显示灯无效。
注意
材料的灵敏性可能根据使用时间和状态有
较大偏差。上述建议并非强制性。
合乎规定的使用
环境保护
包装材料可以回收利用。请按照环保要
求处理包装。
旧的设备中含有宝贵的可再利用的材
料，应加以利用。请按照环保要求清理
旧设备。
电气和电子设备通常包含使用不当或错
误处理时可能对人身健康和环境带来潜
在危险的组成部分。然而这些组成部分
是设备正常运行所必需的。使用该符号
标记的设备不得与生活垃圾一起处理。
产生含油废水的清洗工作，如清洗发动
机和地坑，只允许在配有油分离器的清
洗场所对其进行清洗。
只允许在与排污系统相连的不渗透的工
作台上 , 使用洗涤剂执行作业。不要将
洗涤剂排放到河道或土壤中。
安装和调试
设备运作
高压运作
系统完全控制
压力等级 建议，例如
HARD 地砖或水洗混凝土石制露
台、沥青、金属表面、园艺
用具 （手推车、铁铲等）
MEDIUM 轿车 / 摩托车、砖面、灰泥
墙面、塑料家具
SOFT 木质表面、自行车、砂质表
面、藤制家具
MIX 使用洗涤剂的运行

中文 9
提示： 清洁剂只能在低压下混合。
图
在干燥的表面上少量喷射清洁剂，让清
洁剂在表面发生反应，但不要使之变
干。
利用高压喷射方式刷洗被溶解的杂质。
用洗涤剂作业后：设备开动约 1 分钟直
至冲洗干净。
注意
损坏漆的危险
在使用清洗刷工作时必须沒有脏的小颗粒
或其它小颗粒。
提示：需要时也可以将清洗刷和洗涤剂一
起使用。
图
松开并锁定高压喷枪的控制杆。
如，长时间 （5 分钟以上）运作中断
时，将设备开关设定为 “0/OFF”。
몇
小心
只有当系统中无压力时，才能把高压软管
从高压喷枪或设备上拆下来。
松开高压喷枪的控制杆。
将设备设定为关闭 “0/OFF”。
电源插头从插座上拔出。
关闭水龙头。
按下高压喷枪控制杆，以除去系统中残
留的压力。
锁定高压喷枪的控制杆。
自供水处分离设备。
몇
小心
受伤和损坏危险！
运输和存放时要注意设备的重量。
握住手柄拉高并提起设备。
拉出运输把手，可以听到卡進去的声
音。
握住运输手柄拖动设备。
确保设备不会滑倒和倾覆。
设备置放在平坦地面上。
将附件按照装置分类堆放在设备上。
长期存放之前，如在冬季特别要注意维护
一章的提示。
注意
霜冻会损坏未完全清空的清洁器和附件。
完全清空设备和附件，防止霜冻损害。
避免损害：
完全排空设备内的水：打开不带高压软
管和供水连接装置的设备 （最多 1 分
钟），等待直至无水从高压连接部位出
来时。关闭设备。
机器及所有附件应在防霜的室内保管。
该设备免维护。

危险
电击危险。
 在对机器进行任何操作之前，请务必先
关闭设备并将插头从电源上拔下。
定期清洗水接口的滤网。
注意
不允许损坏滤网。
从水接口上拆下联轴器。
图
取出滤网 （例如用平嘴钳），在流水下
清洗，然后再重新装入。
使用洗涤剂的运行
推荐的清洗方法
使用洗涤剂运行后
用清洗刷进行工作
中断设备操作
结束设备操作
运输和存放
手动搬运
车辆运输
设备储存
防霜冻
维护和保养
保养
清洗水接口的滤网

10 中文

危险
电击危险。
 在对机器进行任何操作之前，请务必先
关闭设备并将插头从电源上拔下。
当按下高压喷枪的控制杆，设备接通。
检查电源电压必须跟型号标识上给出的
电压一致。
检查电源线是否损伤。
检查喷头的设定状态。
完全打开水龙头。
运行前对设备进行通风。
不连接喷射管，接通并运行设备 （最多
两分钟），直至喷枪上没有水泡出现。
关闭设备，接上喷射管。
用尖嘴钳取下水接头中的滤网并用流动
的自来水清洗。
高压清洗：用针除去喷头孔处的杂物，
再用水清洗。
检查供水连接系统。
在技术方面可能存在高压泵少许漏水的
情况。漏水量较大时请联系本公司认可
的客户服务中心。
使用 Vario Power 喷射管。
将旋转喷头设定为 “Mix”。
取下清洁剂抽吸软管中的滤网并用流动
的自来水清洗。
检查清洁剂抽吸软管是否扭结。
只使用原厂配件和备件，它们能保证设备
的安全和无故障运行。
有关配件和备件的信息请登录
www.kaercher.com。
故障排除
设备不运作
设备压力不足
巨大的压力变化
设备漏水
无法吸取清洁剂
附件和备件
产品规格 / 参数
电气连接
电压 220-240
1~50-60
V
Hz
消耗电流 6 A
保护程度 IP X5
保护等级 II
保险丝 （慢断型） 10 A
水接口
供水 （最大） 1,2 MPa
进水温度 （最高） 40 °C
流量 （最小） 8 l/min
功率参数
工作压力 8 MPa
最大允许压力 12 MPa
水流消耗 5,5 l/min
最大流速 6,3 l/min
清洁剂剂消耗 0,3 升 / 分
后挫力 12 N
尺寸和重量
长度 307 mm
宽度 272 mm
高度 600 mm
重量，包括附件 5,5 kg
技术参数可能会有变化。

中文 11
质量保证

12 中文

English 13
In the event of missing accessories or any
transport damage, please contact your dealer.
Illustrations on Page 4
1 High pressure connection
2 Appliance switch „0/OFF“ / „I/ON“
3 Storage hook
4 Carrying handle
5 Transport handle, detachable
6 Storage for spray lance
7 Storage for trigger gun
8 Detergent suction hose with detergent
filter and lid
9 Detergent Tank
10 Water connection with integrated sieve
11 Coupling element for water connection
12 Hose coupling (Aquastop)
13 Water supply hose
14 Hose coupling
15 Adapter
16 Mains cable with mains plug
17 Bearing wheel
18 Full Control trigger gun
19 Pressure display
0 - MIX / 1 - SOFT / 2 - MEDIUM / 3 -
HARD
20 Lock trigger gun
21 Button for detaching the high-pressure
hose from the trigger gun
22 High pressure hose
23 Full Control spray lance Dirtblaster
For strong contaminations
Pressure level: HARD
24 Full Control spray lance Vario Power
Carrying out the most common cleaning
tasks
Pressure levels: HARD / MEDIUM /
SOFT / MIX
25 Washing brush
Suitable for use with detergents.
Please read and comply with
these original instructions prior
to the initial operation of your appliance and
store them for later use or subsequent own-
ers.
Apart from the notes contained herein the
general safety provisions and rules for the
prevention of accidents of the legislator
must be observed.
Warnings and notes that are attached on
the appliance provide important notes for
the safe operation.
DANGER
Pointer to immediate danger, which leads
to severe injuries or death.
몇WARNING
Pointer to a possibly dangerous situation,
which can lead to severe injuries or death.
몇CAUTION
Pointer to a possibly dangerous situation,
which can lead to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation,
which can lead to property damage.
DANGER
Risk of electric shock.
Never touch the mains plug and the
socket with wet hands.
Check the power cord with mains plug
for damage prior to every use. Immedi-
ately have damaged power cord re-
placed by an authorised customer ser-
vice / electrician. Do not operate an ap-
pliance if the power cord is damaged.
Contents
Description of the Appliance. . . . . . . . . 13
Safety instructions . . . . . . . . . . . . . . . . 13
Proper use . . . . . . . . . . . . . . . . . . . . . . 16
Environmental protection . . . . . . . . . . . 16
Installation and Startup. . . . . . . . . . . . . 17
Operation . . . . . . . . . . . . . . . . . . . . . . . 17
Transport and storage . . . . . . . . . . . . . 18
Maintenance and care . . . . . . . . . . . . . 19
Troubleshooting . . . . . . . . . . . . . . . . . . 19
Accessories and Spare Parts . . . . . . . . 19
Technical specifications . . . . . . . . . . . . 20
Warranty . . . . . . . . . . . . . . . . . . . . . . . . 20
Description of the Appliance
Safety instructions
Hazard levels
Electric components

14 English
All current-conducting parts in the work-
ing area must be protected against jet
water.
The mains plug and the coupling of an
extension cable must be watertight and
must never lie in water. Moreover, the
coupling may never lie on the ground.
The use of cable reels that ensure that
the sockets are at least 60 mm above
the ground is recommended.
Make sure that the power cord or exten-
sion cable is not damaged by running
over, pinching, dragging or the like. Pro-
tect the power cords from heat, oil, and
sharp edges.
Turn off the appliance and remove the
mains plug prior to any care and main-
tenance works.
Repair work and work on the electrical
components may only be performed by
an authorised customer service.
몇WARNING
The appliance may only be connected
to an electric supply that has been in-
stalled by an electrician in accordance
with IEC 60364.
The appliance may only be connected
to alternating current. The voltage must
correspond with the type plate of the
appliance.
For safety reasons, we recommend that
you operate the appliance only via a re-
sidual current device (max. 30 mA).
An unsuitable electrical extension cable
can be hazardous. Only use an electri-
cal extension cable which has been ap-
proved and labelled for this purpose
and has an adequate cable cross-sec-
tion outdoors: 1 - 10 m: 1.5 mm2;
10 - 30 m: 2.5 mm2
Always fully unreel the extension cable
from the cable drum.
DANGER
The user must use the appliance as in-
tended. The person must consider the
local conditions and must pay attention
to other persons in the vicinity when
working with the appliance.
Check important components, such as
high-pressure hose, hand spray gun
and safety installations, for damage pri-
or to every operation. Immediately re-
place damaged components. Do not
operate appliance with damaged com-
ponents.
High-pressure jets can be dangerous if
improperly used. The jet may not be di-
rected at persons, animals, live electri-
cal equipment or at the appliance itself.
The high-pressure jet must not be di-
rected at other persons or the user him-
/herself to clean clothing or footwear.
Vehicle tyres/tyre valves are suscepti-
ble to damage from the high-pressure
jet and may burst. The first indication for
this is a discolouration of the tyre. Dam-
aged vehicle tyres/tyre valves are peril-
ous. Keep a minimum jet distance of
30 cm during cleaning!
몇WARNING
Do not use the appliance when there
are other persons around unless they
are also wearing protective clothing.
The appliance must not be operated by
children or persons who have not been
instructed accordingly.
This appliance is not intended for use
by persons with limited physical, senso-
ry or mental capacities or lacking expe-
rience and/or skills, unless such per-
sons are accompanied and supervised
by a person in charge of their safety or
they have received precise instructions
on the use of this appliance and have
understood the resulting risks.
Children must not play with this appli-
ance.
Supervise children to prevent them
from playing with the appliance.
Safe handling

English 15
몇CAUTION
Create stability for the appliance prior to
any work on or with the appliance to
prevent accidents or damage.
The water jet that is emitted from the
high-pressure nozzle results in a repul-
sion power acting on the hand spray
gun. Make sure that you have a firm
footing and are also holding the hand
spray gun and spray lance firmly.
Never leave the appliance unattended
as long as it is in operation.
ATTENTION
In case of extended breaks, switch off
the appliance at the appliance switch.
Do not operate the appliance at temper-
atures below 0 °C.
DANGER
The appliance may not be operated in
explosive atmospheres.
Never use the appliance to clean ob-
jects containing hazardous substances
(e.g. asbestos).
Do not spray flammable liquids.
Never draw in fluids containing solvents
or undiluted acids and solvents! This in-
cludes petrol, paint thinner and heating
oil. The spray mist is highly inflamma-
ble, explosive and poisonous. Do not
use acetone, undiluted acids and sol-
vents, as they corrode the materials
used on the appliance.
Keep packaging films away from chil-
dren, there is a risk of suffocation!
몇WARNING
According to applicable regulations, the
appliance must never be used on the
drinking water net without a system
separator. Ensure that the connection
of your building water installation on
which the high-pressure cleaner is op-
erated is equipped with a system sepa-
rator pursuant to EN 12729 Type BA.
Water that has flown through a system
separator is no longer classified as
drinking water.
High-pressure hoses, fixtures and cou-
plings are important for the safety of the
appliance. Only use high-pressure hos-
es, fixtures and couplings recommend-
ed by the manufacturer.
When disconnecting the supply or high
pressure hose, hot water may leak from
the connections after operation.
몇CAUTION
Mind the weight of the appliance when
selecting the storage location and dur-
ing transport (see technical data) to pre-
vent accidents or injuries.
몇WARNING
This appliance was designed to be
used with detergents which are sup-
plied or recommended by the manufac-
turer. The use of other detergents or
chemicals may compromise the safety
of the appliance.
The improper use of detergents can
cause severe injuries or toxication.
Store detergents away from the reach
of children.
몇CAUTION
Wear protective clothing and safety
goggles to protect against splash back
containing water or dirt.
During the use of high-pressure clean-
ers aerosols can develop. Inhaling aer-
osols can cause health damage.
–Depending on the application, com-
pletely shielded nozzles (e.g. surface
cleaner) that significantly reduce the
emission of aqueous aerosols can be
used for high-pressure cleaning.
–The use of such shielding is not possi-
ble with all applications.
–If the use of a completely shielded noz-
zle is not possible, a respirator of the
category FFP 2 or the like should be
used, depending on the environment to
be cleaned.
Other risks
Working with detergent
Personal protective equipment

16 English
몇CAUTION
Safety installations serve the protection of
the user and may not be modified or by-
passed.
The appliance switch prevents unintention-
al operation of the appliance.
This lock locks the lever of the trigger gun
and prevents the inadvertent start of the ap-
pliance.
The overflow valve prevents the permissi-
ble working pressure from being exceeded.
If the lever on the trigger gun is released
the pressure switch turns off the pump, the
high pressure jet is stopped. If the lever is
pulled the pump is turned on again.
This high pressure cleaner is designed for
domestic use only.
– for cleaning machines, vehicles, build-
ings, tools, facades, terraces, garden-
ing tools, etc. by means of a high-pres-
sure water jet (if necessary, with addi-
tional cleaning agents).
– with accessories, replacement parts
and cleaning agents approved by
KÄRCHER. Please observe the infor-
mation accompanying the cleaning
agents.
Symbols on the machine
The high pressure jet must not be
directed at persons, animals, live
electrical equipment or at the ap-
pliance itself.
Protect the appliance against
frost.
The appliance must not be direct-
ly connected to the public drink-
ing water network.
Safety Devices
Appliance switch
Lock trigger gun
Overflow valve with pressure switch
Proper use
Environmental protection
The packaging material can be recy-
cled. Please arrange for the environ-
mentally appropriate disposal of the
packaging.
Old appliances contain valuable recy-
clable materials that should be recy-
cled properly. Please arrange for the
environmentally appropriate disposal
of the old devices.
Electrical and electronic devices often
contain components which could po-
tentially pose a danger to human
health and the environment if handled
or disposed of incorrectly. However,
these components are necessary for
the proper operation of the device. De-
vices marked with this symbol must not
be disposed of with regular household
rubbish.
Cleaning operations which produce
oily waste water, e.g. engine washes,
underbody washes, may only be car-
ried out using washing stations
equipped with an oil separator.
Work with detergents must only be per-
formed on liquid-tight work surfaces
with a connection to the sewer system.
Do not let release detergent into wa-
ters or earth.

English 17
Illustrations on the picture pages
Illustration
Mount loose parts delivered with appli-
ance prior to start-up.
Park the appliance on an even surface.
Illustration
Push the high pressure hose into the
trigger gun until it locks audibly.
Check the secure connection by pulling
on the high pressure hose.
Illustration
ATTENTION
Impurities in the water can damage the
high-pressure pump and the accessories.
For protection, the use of the KÄRCHER
water filter (optional accessory, order no.
4.730-059) is recommended.
몇CAUTION
Dry running of more than 2 minutes leads to
damage of the high-pressure pump. If the
appliance does not build up pressure within
2 minutes, switch the appliance off and pro-
ceed in accordance with the instructions in
Chapter "Troubleshooting".
몇CAUTION
Keep a distance of at least 30 cm when us-
ing the jet for cleaning painted surfaces to
avoid damage.
ATTENTION
Car tyres, paint or sensitive surfaces such
as wood should not be cleaned with the dirt
blaster, as there is a risk of damage.
Illustration
The pressure indicator on the trigger gun
shows the currently set pressure level dur-
ing operation with a Full Control spray
lance.
Note: The pressure indicator is not signifi-
cant during operation with the T-Racer and
other accessories.
ATTENTION
The sensitivity of the materials can strongly
differ depending on the age and the condi-
tion. The so-called recommendations are
non-binding.
Note: Detergent can only be added when
the device is operated in low pressure
mode.
Illustration
Spray the detergent sparingly on the
dry surface and allow it to react, but not
to dry.
Spray off loosened dirt with the high
pressure jet.
After operation with detergent: Run the
machine for approximately 1 minute for
a clear rinse.
Installation and Startup
Operation
High pressure operation
Full Control System
Pressure
level
For example,
recommended for
HARD Stone terraces made of
paving stones or exposed
aggregate concrete, as-
phalt, metal surfaces, gar-
den utensils (wheelbarrow,
spade, etc.)
MEDIUM Motorcar / motorcycle, brick
surfaces, plastered walls,
plastic furniture
SOFT Wooden surfaces, bicycles,
sand stone surfaces, rattan
furniture
MIX Operation with detergent
Operation with detergent
Recommended cleaning method
After operation with detergent

18 English
ATTENTION
Risk of damage to the paintwork
When working with the washing brush, it
must be free of dirt or other particles.
Note: If required, the washing brushes can
be used to work with detergent.
Illustration
Release the lever of the trigger gun and
lock it.
During longer breaks (more than 5 min-
utes), also turn the appliance off using
the "0/OFF" switch.
몇CAUTION
Only separate the high-pressure hose from
the trigger gun or the device when there is
no pressure in the system.
Release the lever of the trigger gun.
Turn off the appliance "0/OFF".
Disconnect the mains plug from the
socket.
Turn off tap.
Press the lever on the trigger gun to
release any remaining pressure in
the system.
Lock the lever of the trigger gun.
Detach the appliance from the water
supply.
몇CAUTION
Risk of personal injury or damage!
Mind the weight and storage of the appli-
ance during transport.
Lift appliance by the carrying handle
and carry it.
Pull out the transport handle until it au-
dibly snaps into place.
Pull the appliance by its transport han-
dle.
Secure the appliance against shifting
and tipping over.
Park the machine on an even surface.
Stow away the accessories on the ap-
pliance according to the device.
Prior to extended storage periods, as dur-
ing the winter, also observe the instructions
in the Care section.
ATTENTION
Appliances and accessories that are not
completely drained can be destroyed by
frost. Completely drain appliance and ac-
cessories and protect them against frost.
To avoid damage:
Completely drain all water from the ap-
pliance: Switch the appliance on with
detached high pressure hose and de-
tached water supply (max. 1 minute)
and wait, until no more water exits at the
high pressure connection. Turn off the
appliance.
Store the appliance and the entire ac-
cessories in a frost free room.
Operation with washing brush
Interrupting operation
Finish operation
Transport and storage
When transporting by hand
When transporting in vehicles
Storing the Appliance
Frost protection

English 19
The appliance is maintenance free.
DANGER
Risk of electric shock.
Prior to all work on the appliance,
switch off the appliance and pull the
power plug.
Clean the sieve in the water connection
regularly.
ATTENTION
The sieve must not be damaged.
Remove coupling from the water con-
nection.
Illustration
Pull the sieve out (e.g. using flat pliers),
clean under running water and then re-
insert it.
DANGER
Risk of electric shock.
Prior to all work on the appliance,
switch off the appliance and pull the
power plug.
Push the lever of the trigger gun, the de-
vice will switch on.
Check whether the voltage indicated on
the type plate corresponds to the volt-
age of the mains supply.
Check the mains connection cable for
damages.
Check setting at the spray lance.
Completely open the water tap.
Remove air from appliance before oper-
ation.
Switch on the appliance without con-
nection the HP hose (max. 2 minutes)
and run it until the water discharging
from the HP outlet is free of bubbles.
Switch off appliance and reconnect HP
hose.
Pull out the sieve in the water connec-
tion using flat-nose pliers and clean un-
der running water.
Clean high-pressure nozzle: Remove
dirt and debris from the nozzle bore, us-
ing a needle and rinse through with wa-
ter from the front.
Check water flow quantity.
Slight leakage from the appliance pump
is normal. If the leakage increases con-
tact the authorized customer service.
Use Vario Power spray lance.
Turn the spray lance to "Mix" position.
Remove filter from suction hose for de-
tergent and clean under running water.
Check the detergent suction hose for
kinks.
Only use original accessories and spare
parts, they ensure the safe and trouble-free
operation of the device.
For information about accessories and
spare parts, please visit www.kaerch-
er.com.
Maintenance and care
Care
Clean the sieve in the water connection
Troubleshooting
Appliance is not running
Pressure does not build up in the
appliance
Strong pressure fluctuations
Appliance is leaking
No detergent infeed
Accessories and Spare Parts

20 English
The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within the warranty period
free of charge, provided that such failure is
caused by faulty material or defects in man-
ufacturing. In the event of a warranty claim
please contact your dealer or the nearest
authorized Customer Service centre.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
Technical specifications
Electrical connection
Voltage 220-240
1~50-60
V
Hz
Power consumption 6 A
Protection class IP X5
Protective class II
Mains fuse (slow-blow) 10 A
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 8 l/min
Performance data
Working pressure 8 MPa
Max. permissible pressure 12 MPa
Water flow rate 5,5 l/min
Max. flow rate 6,3 l/min
Detergent flow rate 0,3 I/min
Recoil force of trigger gun 12 N
Dimensions and weights
Length 307 mm
Width 272 mm
Height 600 mm
Weight, ready to operate
with accessories
5,5 kg
Subject to technical changes.
Warranty
