Allway PL10 Instruction sheet

Open wireless earphone
PL10 Product Instructions
Please read this instructions carefully and keep them properly

①Packaging list：
1.PL10 x 1 2.Type-c Cable x 1 3.User manual x 1
②Configuration
Specifications are laboratory test data.
*Playback times are from laboratory tests using the SBC format at 60% volume level and are subject to
variation in equipment settings, environment, usage and many other factors
Product name：Open wireless earphone
Earphone Model：PL10
Product size：141.6*103.8*40.6mm
Distance: ＞10m
Bluetooth Version: BT5.3
Speaker Diameter: 16.2mm
Impedance: 16Ω
Frequency Response: 20HZ-20KHZ
Frequency Band: 2.402GHZ-2.480GHZ
Battery: 110mAH/3.7V
Charging time：1.5h
Usage time：8h
Standby time：30h
Input: 5V⎓0.5A
Type of charge: Type-C
Material：PC+ABC
Number of connections：2
Weight: 27g

③Operation instruction
Instructions for use
Power on
Hold down the function button for 2s
Power off
Automatic switch-off when charging。
Hold down the function button for 5s。
Enter pairing
When there is no pairing, the headphone automatically enters pairing after power on.
After pairing, the device is automatically connected.
Enters pairing when disconnected from the device.
When the connection fails and times out, the headphone will automatically enter pairing.
VOL-
VOL+
Function Button
Led

When switched off, press and press the multi-function button for 5 seconds to put the
headphone into forced pairing.
Reset operation
When the multi-function key and the volume - key are pressed simultaneously
for 5 seconds, the factory settings are restored and the Bluetooth pairing
record is cleared.
Multi-device connection
PL10 supports multi-device connection, if you need to connect two devices at
the same time, just search and add "PL10" to the Bluetooth list of the other
device.

④Bluetooth Pairing
Step1 - Turn on Bluetooth for your device
Step2 - Select "PL10" to connect
⑤Operation Instructions
Play/Pause
Short press on the multi-function key
Next song
Press the volume + key for 2s
Previous song
Press the volume - key for 2s
Answer
Click on the multi-function key
Hang up
Click the multi-function key
Refuse to answer
Press the multi-function key for 2s
Vol+
Press the vol- + key
Vol-
Press the vol- key
Outdoor mode/Indoor mode
Press the multi-function key for 2s
Voice Control
Press the multi-function key twice
Select "PL10"
Device Pairing
When the device is
connected to the earbuds,
the phone shows the earbuds
battery level.

⑥Light Description
Functions
Led status
Power on
Blue light flashes 3 times
Power off
Red light flashes 3 times and then goes out
Pairing status
Red and blue lights flash alternately
Power level
Red light flashes once every 3s
Charging in progress
Red light is always on
Fully charged
Red light off, blue light on for 30s and then off
Restore factory settings
Red and blue lights on and off at the same time for 3s

Safety Information
1. Never disassemble the headphones. There are no user-serviceable parts
inside,
2. Do not expose the headphones to temperatures below 32 F(0 ℃) or to
temperatures above 113°F(45°C).
3.Do not use the headphones in a thunderstorm storm. This could prevent the
headphones from working properly, and also increase your chance of being
electrically shocked.
4. Do not use oil or any volatile liquid to clean this product.
5.Do not listen at high volumes for extended periods of time.
6. Do not use the headphones in traffic.
7.Do not use the headphones any time it would be dangerous to be unaware of
noises around you.
Allway (1) Year Limited Warranty
Allway warrants to the original retail purchaser that this product is to be free
from defective materials and workmanship for a period of one year from the date
of purchase, if it is properly used and maintained. If this product proves defective
in either material or workmanship, Allway, at its option, will (a) repair the product,
or (b) replace the product, at no charge for parts or labor. If the product model is
no longer available and cannot be repaired effectively or replaced with an
identical model, Allway at its sole option may replace the unit with a current

model of equal or greater value. In some cases, modification to the mounting
surface may be required where a new model is substituted. Allway assumes no
responsibility or liability for such modification. To obtain a repair or replacement
under the terms of this warranty, please return to dealer first, if possible, and the
dealer will direct you accordingly for repairs or replacement. You will be required
to submit a copy of the original receipt.
Return shipping for exchanges/repairs is the sole responsibility of the original
retail purchaser,
Limitations:
This limited warranty does not cover failure of the product resulting from
improper installation, misuse, abuse, accident, neglect, mishandling, or wear
from ordinary use or environmental deterioration.
This limited warranty does not cover cosmetic damage, including paint damage,
or consequential damage to other components or premises which may result
for any reason from the failure of the product.
This limited warranty is null and void for products not used in accordance with
Allway's instructions.

FCC NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.

开放式无线耳机
PL10 产品手册
请仔细阅读本说明书并妥善保管

①包装清单：
1.PL10 x 1 2.Type-c 充电线 x 1 4.产品手册 x 1
②产品配置
产品名称：开放式无线耳机
型号: PL10
产品尺寸：141.6*103.8*40.6mm
连接距离: ＞10m
蓝牙版本: BT5.3
喇叭直径: 16.2mm
阻抗: 16Ω
频率响应: 20HZ-20KHZ
频段: 2.402GHZ-2.480GHZ
电池容量: 110mAH/3.7V
充电时间：1.5h
使用时间：8h
待机时间：30H
输入：5V⎓0.5A
充电方式：Type-C
材质 Material：PC+ABC
可连接数量：2
重量：27g
规格参数为实验室测试数据。
*播放时长为 SBC 格式、60%音量条件下的实验室测试数据，依设备设置、环境、使用情况及诸多因素可能有所差异

③操作说明
开机
长按多功能按键 2秒开机。
关机
当给耳机充电的时候，耳机自动关机。
长按多功能按键 5秒关机。
进入配对状态
当没有配对记录时，打开手机蓝牙功能，耳机开机后自动进入配对状态。
当有配对记录时，耳机开机后自动回连已配对设备。
当断开当前正在连接的设备时，耳机自动进入配对状态。
当耳机回连失败并超时，耳机会自动进入配对状态。
当耳机处于关机状态，长按多功能按键 5秒，耳机进入强制配对状态。
复位操作
音量-
音量+
功能键
指示灯

当同时长按多功能键键和音量-键5秒，耳机恢复出厂设置，清除蓝牙配
对记录。
多设备连接
PL10 支持多设备连接，如需要同时连接两台设备，只需在另外一台设备的
蓝牙列表中搜索并添加“PL10”即可。
④蓝牙配对
步骤 1 - 打开设备的蓝牙，取出耳机
步骤 2-选择“PL10”进行连接
⑤操作说明
选择 "PL10"
设备配对
当设备启动时与耳机相连，
手机会显示耳机电池的电量。

播放/暂停
短按多功能键
下一曲
长按 2秒音量+键
上一曲
长按 2秒音量-键
接听电话
单击多功能键
挂断电话
单击多功能键
拒接电话
长按 2秒多功能键
增加音量
单击音量+键
减少音量
单击音量-键
室外/室内模式切换（音效切换）
长按 2秒多功能键
语音助手
双击多功能键
⑥指示灯说明
功能
指示灯状态
开机
蓝灯快闪 3次
关机
红灯快闪 3次后熄灭
配对状态
红蓝灯交替快闪
电量＜20%
红灯每 3s 闪一次
充电中
红灯常亮
充满电
红灯熄灭，蓝灯亮 30s 后关机
恢复出厂设置
红蓝灯同时常亮 3s 熄灭

注意事项
1、请在常温环境下存放和使用本产品
2、请勿丢掷，避免跌落造成本产品损坏
3、请勿自行拆解、改造本产品
4、请勿置于高温、火中，以免引起危险
5、请勿雨淋或置于水中
三包细则
以下条款如果与国家政策不符或有遗漏之处，以国家政策为准。
由于产品本⾝出现性能故障，可以凭购机发票和有效三包凭证按照三包规定，享受下列三
包服务：
⾃售出之⽇起七⽇内，出现⾮⼈为产品性能故障，可选择免费退货、换货；
⾃售出之⽇起⼀个⽉内，出现产品本⾝原因造成的性能故障，消费者可选择换货或者修理；
⾃售出之⽇起⼀年内，出现产品本⾝原因造成的性能故障，消费者可享受保修服务。
在三包有效期内，⽤⼾必须出具购机发票和有效三包凭证才能享受包退、包换、保修的权
利。本公司对产品的其它配置（例如：包装盒等）不承担三包责任。
保修说明
保修服务仅限正常使⽤。⾮产品本⾝原因造成的损坏及属下列情况之⼀的，不实⾏三包。
①超过三包有效期的；

②⽆三包凭证及购机发票的，且⽆法证明该产品在三包有效期内的；
③三包凭证上的内容与产品实物标识不符或者涂改的；
④未按产品使⽤说明书要求使⽤、维护、保养⽽造成损坏的；
⑤浸泡、摔损等造成损坏的，或⾮官⽅客⼾服务中⼼拆修过的；
⑥因不可抗⼒造成损坏的；
⑦产品⾃然磨损；
所有被维修替换的零件、部件以及附件等归本公司所有。

有毒有害物质或元素声明
部件名
称
有害物质
铅PB
汞Hg
铬Cd
六价铬
Cr(VI)
多溴联
苯PBB
多溴二
苯醚
PBDE
邻苯二
甲酸二
异丁酯
DIBP
邻苯二
甲酸（2-
乙酯）
DEHP
邻苯二
甲酸二
丁酯
DBP
邻苯二
甲酸丁
苄酯 BBP
耳机主
体
×
○
○
○
○
○
○
○
○
○
电池
○
○
○
○
○
○
○
○
○
○
耳帽
○
○
○
○
○
○
○
○
○
○
配件
○
○
○
○
○
○
○
○
○
○
充电线
×
○
○
○
○
○
○
○
○
○
本表依据 SJ/T 11364 规则编制
O：表示该有害物质在部件所有均匀材质中的含量均在（EU）2015/863 规定的限量要求以下。
×：表示该有害物质至少在该部件的某一均匀材质中的含量超出（EU）2015/863 规定的限量要求，
但目前行业无成熟的替代方案，在豁免范围仍符合欧盟 ROHS 指令的环保要求。
使用年限
如手册所述，在正常使用条件下，本产品的环保使用期限为 10 年。在此期间，产品不会泄露任何有害物质，本产品可以回
收，必须按照当地法规处理。

Open wireless earphone
PL10取扱説明書
ご使用の前に必ずお読みになり、大切に保管してください。

①パッケージ内容：
1、本製品 PL10*1 2、Type-C ケーブル*1
3、取扱説明書*1 4、製品保証書*1
②製品仕様
※上記のパラメータは実験室よりの試験データです。
※再生時間は SBC 形式であり、60%の音量条件の実験室のテストデータは、デバイスの設定、環
境、使用状況および多くの要因によって異なる可能性があります。
商品名：Open wireless earphone
型番: PL10
サイズ：141.6*103.8*40.6mm
通信距離: ＞10m
Bluetooth Version: BT5.3
ドライバーユニット: Φ16.2mm
Impedance: 16Ω
周波数応答: 20HZ-20KHZ
周波数帯域: 2.402GHZ-2.480GHZ
バッテリー容量: 110mAH/3.7V
充電時間：1.5h
最大使用時間：約 8h
最大待機時間：30h
入力：5V⎓0.5A
端子: Type-C
材質：PC+ABC
接続数：2
重量: 27g

③操作説明
電源を入れる
多機能ボタンを 2秒間押し続けて、電源を入れます。
電源を切る
ヘッドセットを充電すると、ヘッドセットは自動的にオフになります。
多機能ボタンを 5秒間押し続けて、電源を切ります。
ペアリング状態
ペアリング記録がない場合は、スマホの Bluetooth 機能をオンにします。ヘッドセッ
トの電源を入れてから自動的にペアリング状態になります。
音量-
音量+
多機能ボタン
ライト
