Alotcer AR7088 User manual

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 1 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
AR7088 Router User Manual
Applicable Models：
Product Type
Model
Product Name
AR7088-W
WCDMA WIFI ROUTER
AR7088-E
EVDO WIFI ROUTER
AR7088-F
FDD-LTE WIFI ROUTER
AR7088-T
TDD-LTE WIFI ROUTER
Enhanced
AR7088-D
TDD/FDD-LTE WIFI ROUTER
AR7088-WSTD
WCDMA Router
AR7088-ESTD
EVDO Router
AR7088-FSTD
FDD-LTE Router
AR7088-TSTD
TDD-LTE Router
Standard
AR7088-DSTD
TDD/FDD-LTE Router

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 2 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Xiamen Alotcer Communication Technology Co., Ltd.
Tel:[phone]
Fax:[phone]
Web:en.alotcer.com
E-mail:[email protected]
Add:NO.146-148, 2nd XingBei Road, JiMei District,
XiaMen,China.

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 3 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 4 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 5 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Contents
Contents .............................................................................................................................3
Chapter 1 Brief Introduction................................................................................................5
1.1 General..................................................................................................................5
1.2 Product Feature.....................................................................................................6
1.3 Block Diagram .......................................................................................................7
1.4 Product SPEC .......................................................................................................7
1.5 Ordering Information..............................................................................................9
Chapter 2 Installation Introduction ......................................................................................9
.....................................................................................................................................9
2.1 General..................................................................................................................9
2.2 Encasement List ..................................................................................................10
2.3 Installation and Cable Connection.......................................................................10
2.4 Power ..................................................................................................................13
2.5 Indicator Lights Introduction ................................................................................13
2.6 Reset Button Introduction ....................................................................................14
Chapter 3 Configuration and Management.......................................................................14
...................................................................................................................................14
3.1 Configuration Connection ....................................................................................14

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 6 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
3.2 Access the Configuration Web Page...................................................................15
3.2.1 IP Address Setting.....................................................................................15
3.2.2 Access the Configuration Web Page.........................................................16
3.3 Basic....................................................................................................................18
3.3.1 WAN ..........................................................................................................18
3.3.2 WAN Status...............................................................................................21
3.3.3 LAN ...........................................................................................................21
3.3.4 LAN Status ................................................................................................23
3.4 Advanced.............................................................................................................24
3.4.1 Statically Assigned ....................................................................................24
3.4.2 Advanced Router.......................................................................................24
3.4.3 MAC Address Clone..................................................................................25
3.4.4 SDNS ........................................................................................................25
3.5 Wireless...............................................................................................................26
3.5.1 Basic Settings............................................................................................26
3.5.2 Wireless Security.......................................................................................27
3.5.3 Wireless Status .........................................................................................28
3.6 VPN .....................................................................................................................29
3.6.1 PPTP .........................................................................................................29
3.6.2 L2TP..........................................................................................................30
3.6.3 IPSEC........................................................................................................30

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 7 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
3.6.4 GRE...........................................................................................................31
3.7 Security................................................................................................................32
3.7.1 Firewall ......................................................................................................32
3.7.2 Access Restriction.....................................................................................33
3.7.3 MAC Filter .................................................................................................36
3.7.4 Packet Filter ..............................................................................................36
3.8 Forwarding...........................................................................................................37
3.8.1 Port Forwarding.........................................................................................37
3.8.2 Port Range ................................................................................................37
3.8.3 Port Triggering...........................................................................................38
3.8.4 DMZ...........................................................................................................38
3.9 QoS Setting .........................................................................................................39
3.9.1 Traffic monitoring.......................................................................................39
3.10 M2M...................................................................................................................39
3.10.1 Serial .......................................................................................................39
3.11 Administration....................................................................................................41
3.11.1 Language and Reboot.............................................................................41
3.11.2 Password.................................................................................................41
3.11.3 Management ...........................................................................................41
3.11.4 System Time ...........................................................................................43
3.11.5 Configure.................................................................................................43

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 8 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
3.11.6 Upgrade...................................................................................................44
3.11.7 DDNS ......................................................................................................45
3.11.8 Syslog......................................................................................................45

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 9 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Chapter 1 Brief Introduction
1.1 General
AR7088 ROUTER is a kind of terminal device that developed based on 2G/3G/4G, WIFI,
VPN technology. It adopts high-powered industrial 32-bits CPU and embedded real time
operating system. It supports RS232 (or RS485), Ethernet and WIFI port that can
conveniently and transparently connect one device to a cellular network, allowing to
connect to existing serial, Ethernet and WIFI devices with only basic configuration.
It has been widely used on M2M fields, such as intelligent transportation, smart grid,
postal services, industrial automation, telemetry, finance, POS, water supply,
environment protection, post, weather, and so on.

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 10 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Router Application Topology
1.2 Product Feature
Items
Contents
High-powered industrial cellular module
High-powered industrial 32bits CPU
Industrial
Design
Housing: iron, providing IP30 protection.

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 11 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Power range: DC 5~35V
Support hardware and software WDT
Support auto recovery mechanism to make router always online
Ethernet port: 1.5KV magnetic isolation protection
RS232/RS485 port: 15KV ESD protection
SIM/UIM port: 15KV ESD protection
Power port: reverse-voltage and over voltage protection
High
Reliability
Antenna port: lightning protection(optional)
Support standard RS232(or RS485), Ethernet and WIFI port that
can connect to serial, Ethernet and WIFI devices directly
Support standard WAN port and PPPOE protocol that can connect
to ADSL directly
Support intellectual mode, enter into communication state
automatically when powered
Support several work modes
Standard and
Convenience
Convenient configuration and maintenance interface（WEB or
CLI）
Support multiple WAN access methods, including static IP, DHCP,
PPPOE, 2.5G/3G/4G.
Support double link backup between 2.5G/3G/4G and WAN
(optional).
High-
performance
and Security
Support VPN client(PPTP, L2TP, IPSEC and GRE)(only for VPN

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 12 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
version).
Support remote management, SYSLOG, SNMP, TELNET, SSH,
HTTPS, etc.
Support local and remote firmware upgrade,import and export
configure file.
Support NTP, RTC embedded.
Support multiple DDNS provider service.
Support MAC address cloning.
WIFI support 802.11b/g/n. support AP, client.
WIFI support WEP,WPA,WPA2 encryption.
Support multiple online trigger ways, including SMS, ring and data.
Support link disconnection when timeout.
Support APN/VPDN.
Support multiple DHCP server and DHCP client, DHCP binding
MAC address, DDNS, Firewall, NAT, DMZ host, QoS, traffic
statistics, real-time display data transfer rate etc.
Support TCP/IP, UDP, FTP(optional), HTTP, etc.
Supports SPI firewall, VPN pass-through, access control, URL
filtering,etc.
Support local log storage.

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 13 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
1.3 Block Diagram
1.4 Product SPEC
Items
Contents
CPU
Industrial 32bits CPU
FLASH
16MB (Extendable to 64MB)
Hardware
System
SDRAM
128MB
WAN
1 10/100Mbps WAN port(RJ45), auto MDI/MDIX,
1.5KV magnetic isolation protection
Interface
LAN
1 10/100Mbps Ethernet ports(RJ45), auto

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 14 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
MDI/MDIX, 1.5KV magnetic isolation protection
Serial
1 RS232(or RS485/RS422) port, 15KV ESD
protection
Data bits: 5, 6 ,7, 8
Stop bits: 1, 1.5(optional), 2
Parity: none, even, odd, space(optional),
mark(optional)
Baud rate: 2400~115200 bps
Antenna
Cellular: Standard SMA female interface, 50 ohm
WIFI: Standard SMA male interface, 50 ohm
SIM/UIM
Standard 3V/1.8V user card interface, 15KV ESD
protection
Power
Standard 3-PIN power jack, reverse-voltage and
over voltage protection
Reset
Press this key for 8 seconds to restore the router to
its original factory default settings
Indicator
"Signal
strength"、"PWR"、"RUN"、"SIM"、"Online"、"LAN
"、”WAN"
Network
Wireless
Network
GSM/GPRS/EDGE: 850/900/1800/1900MHz
CDMA: 800/1900MHz
WCDMA/HSUPA/HSPA+: 850/900/1900/2100MHz

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 15 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
CDMA2000 1x/ EVDO Rev. A: 800/1900MHz
TD-SCDMA: 1880-1920/2010-2025MHz(A/F)
TDD-LTE: Band 38/39/40/41& Band 61/62 (Private
Network)
FDD-LTE: Band 1/2/3/4/5/7/8/13/17/20/25
WAN
Support PPP/PPPOE
LAN
Support APR
Network
Authentication
Support CHAP/PAP Authentication
Network
Access
Support APN/VPDN
IP Applications
Support Ping,Trace, DHCPServer, DHCP Relay,
DHCP Client, DNS relay, DDNS, Telnet
IP Routing
Support static routing
Standard
IEEE802.11b/g/n
Bandwidth
IEEE802.11b/g: 54Mbps (max)
IEEE802.11n: 150Mbps (max)
WIFI
Security
WEP, WPA, WPA2, etc. WPS (optional)
Standard
Power
DC 12V/1.5A
Power
supply
Power range
DC 5~35V

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 16 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Consumption
<410mA (@12VDC)
Dimensions
136x99x28mm
Physical
Weight
395g
Operating
Temperature
-35~+75ºC (-31~+167℉)
Storage
Temperature
-40~+85ºC (-40~+185℉)
Environm
ental
Limits
Operating
Humidity
95% ( unfreezing)
1.5 Ordering Information
Model
Network Abbreviation
AR7088
-W: WCDMA WIFI
-E: EVDO WIFI
-D: TDD/FDD-LTE WIFI
-T: TDD-LTE WIFI
-F: FDD-LTE WIFI
-WSTD: WCDMA Standard
-ESTD: EVDO Standard
-DSTD: TDD/FDD-LTE Standard

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 17 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
-TSTD: TDD-LTE Standard
-FSTD: FDD-LTE Standard
Example
AR7088-F: AR7088 router that support FDD-LTE &WIFI
Chapter 2 Installation Introduction
General
The router must be installed correctly to make it work properly.
Warning: Forbid to install the router when powered!
2.2 Encasement List
Name
Quantity
Remark
Router host
1
Cellular antenna (Male SMA)
1
WIFI antenna (Female SMA)
1
Network cable
1
Power adapter
1
Manual CD
1
Certification card
1

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 18 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Maintenance card
1
RS232 Console cable
1
Optional
RS485 Console cable
1
Optional
2.3 Installation and Cable Connection
Dimension(The fixing piece is detachable): (Unit: mm)
Installation of antenna:
Cellular antenna (Standard) WIFI antenna (Standard)

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 19 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Screw the SMA male pin of the cellular antenna to the female SMA interface of the router
with sign “ANT”(some models are two antennas, namely "ANT1", "ANT2").
Screw the SMA female pin of the WIFI antenna to the male SMA interface of the router
with sign “WIFI”.
Warning: The cellular antenna and the WIFI antenna can not be connected wrongly. And
the antennas must be screwed tightly, or the signal quality of antenna will be influenced!
Installation of SIM/UIM card:
SIM/UIM Card Installation
Firstly power off the router, and press the out button of the SIM/UIM card outlet with a
needle object. Then the SIM/UIM card sheath will flick out at once. Put SIM/UIM card into
the card sheath (Pay attention to put the side which has metal point outside), and insert
card sheath back to the SIM/UIM card outlet.
Warning: Forbid to install SIM/UIM card when powered!
Installation of cable:

AR7088 Router User Manual
Tel:[phone] Fax:[phone] E-mail:[email protected] Page 20 of 71
Web:en.alotcer.com Add: NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Network cable (Standard) Console cable (Standard)
Insert one end of the network cable into the switch interface with sign “Local Network”,
and insert the other end into the Ethernet interface of user’s device. The signal
connection of network direct cable is as follows:
RJ45-1
RJ45-2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
Insert the RJ45 end of the console cable into the RJ45 outlet with sign “console”, and
insert the DB9F end of the console cable into the RS232 serial interface of user’s device.
The signal connection of the console cable is as follows:
